Ariesys ARP893 Assembly instructions

ARP 893 User Reference Manual

２
Specifications
Model No ARP893 ARP893-1
Construction Rugged Aluminum Construction with shock absorbing rubber corners
Motherboard Support up to EATX M/B
Display 3x 21.5" LCD display, 1920x 1080
Slots Offer 7 full-length expansion slots
Drive bay 3x 5.25”, 6x 3.5” drive bays 4x 5.25” drive bays
VGA AD conversion board
3 DisplayPort output for 3 screens
KB/MS Industrial multi-language keyboard/ touchpad
Power Supply PS2, 750W, 100~240VAC, Auto switch
Speaker Built-in amplified 2x 3W speake
r
Dimension 597x 435x 302.5 mm (Wx Hx D)
Weight 25.5 kgs
Carrying Case Padded carrying case with wheels
Environmental Factors
Operating Non-Operating
Temperature 0°C~50°C -20°C~60°C
Relative Humidity 10%~90% 10%~95%
Approval CE, FCC, RoHS
ARP893: power supply is located at left side
ARP893-1: power supply is located at right side (provides more space to CPU cooler)

３
ARP 893 series
Model Accessory Kit SKD
Qty
ARP 893
1
ARP893/ ARP893-1 Portable Computer Chassis 1
2
Carrying Case with wheels 1
3
User’s Manual 1
4
Power Cord 1
5
Anti-Static Bag 1
6
Screw Pack (stabilizer) 1
7
Stabilizer Supports Pack 1
8
9
Standard Accessory Kits
Carrying Case with Wheels

４
ARP 893 features:
●Rugged Aluminum Construction with shock absorbing rubber corners
●Built-in 3x 23.8” LCD display support Full HD, 1920x 1080 resolution
●Support standard EATX Motherboard
●Offer 7-slot full-length expansion capability
●Creates a stretched desktop with a maximal resolution of 5760x 1080 (3x 1920x 1080)
●Open an application on each display or span one across 3-screens
●Experience surround gaming by expanding supported 3D games
●PS2 750W power supply, 100~240VAC
●Offer 3x 5.25”, 6x 3.5” drive bays or 4x 5.25” drive bays (ARP893-1 model)
●Carrying case to manage portable PC with ease
The ARP893 is a triple LCD screen rugged portable computer which can be folded into a
neatly package for transportation. The system has three 23.8" widescreen LED LCD, each
with 1920x1080 resolution panel are available for a total 5760x1080 resolution. The
ARP893 is a combination of triple display highly mobile multi-slot computing system with
rugged aluminum chassis construction and corner bumper protection. It offers 7-slot
expansion slots and designed for EATX motherboard. Everything is integrated and folded
into a light weight portable package with the latest brightness contrast LED backlit LCD,
processors and foldable keyboard w/ touchpad.
ARP893: power supply is located at left side
ARP893-1: power supply is located at right side (provides more space to CPU cooler)
1.0 Introduction

５
2.0 Getting Started
1. Lift the lever on the bottom right of the outer LCD to release lock and the open the first LCD
panel from the main unit by swinging the LCD fixture toward the left
2. Open the second LCD from the main unit by swinging the LCD fixture toward the right
3. Once both the left and right LCD are opened. You will be able to view 3 LCD in full view.
2.0 Operation
LCD 1 LCD 2 LCD 3

６
4. Connect the power cable outlet into the power supply unit in the main chassis
5. Turn on the power by pressing the power button located in the front of the main unit.
6. Front panel button control allows you to adjust the LCD via OSD. Each individual LCD has its
own set of OSD control. There have indicator LED lights for Power and HDD activity, 2x USB in
the front for USB KB/MS
Insert Power Cord
HDD POWER LED 2x USB Port
Press Once to Power On
LCD OSD MANUAL
Power on/off

７
7. Access the available expansion slots on the left side of the chassis.
8. ARP893 Supports 3x 5.25”, 1x slim, 6x 3.5” drive bays
ARP893-1 supports 4x 5.25”, 1x slim drive bays
Drive bays
7 expansion slots
Drive bays

８
Be sure power cable is not connected to the system before proceeding
1. Open Back Cover
2. Remove the Card stabilizer bar
3.0 Internal Hardware Access
UnscrewUnscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
UnscrewUnscrewUnscrewUnscrew
UnscrewUnscrew
UnscrewUnscrewUnscrewUnscrew

９
3. Install the proper stand-off matching the ATX Motherboard into the
chassis and correct I/O plate supplied by board manufacturer and
secure the motherboard onto chassis.
4. Install your graphic card and add-on card into the appropriate slot
A
dd-on card
Gra
p
hic card

１０
5. Connect the 3 LCD cables to graphic card
LCD 1 LCD 2 LCD 3
