TradeQuip 1026 User manual

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
OWNER’S MANUAL
PRODUCT CODE: 1026
WALL MOUNT FAN
Blade
Diameter
Motor
Input Output
Max. Air
Delivery
Oscillating
Range
No of
Speeds
Fan Head
Tilt
750mm
240V 50Hz 280W
Up to 300m³/min
0º to 90º
3
15°

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before
using or operating this equipment. Do not allow anyone to use or operate this equipment until
they have read this manual and have developed a thorough understanding of how this
equipment works. Failure to observe any of the instructions contained in the manual could
result in severe personal injury to the user or bystanders, or cause damage to the equipment
and property. Keep this manual in a convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual,
the TQB Brands Pty Ltd policy of continuous improvement determines the right to make
modifications without prior warning.
CONTENT
WARNING .............................................................................................................................. 2
CONTENT ............................................................................................................................... 2
SAFETY INSTRUCTIONS ........................................................................................................... 3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE .......................................................... 4
PARTS LIST WALL FAN............................................................................................................. 7
WARRANTY ............................................................................................................................ 8

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 3
Visit us at www.tqbbrands.com.au
SAFETY INSTRUCTIONS
SAFETY OPERATING INSTRUCTIONS
- When servicing, use only TradeQuip identical replacement parts. Use of any other
parts will void the warranty.
- Ensure the Wall Mount Fan is disconnected from power before servicing.
- Use the right product for the job. There are certain applications for which the Wall
Mount Fan was designed.
- Do not modify the Wall Mount Fan and do not use the Wall Mount Fan for a
purpose for which it was not intended.
CAUTION WITH WALL FITMENT INSTRUCTIONS
Installation of the wall bracket support arm:
The bent support arm can be installed upward or downward. In both cases, the longest
locking bolt must penetrate the small hole at the end of the bent part in order to avoid
falling off the wall.
Assembly and installation:
For convenient transportation, the supporting arm of the wall mount fan is disassembled
in packing. Please ensure you assemble and install the fan according to the drawings of
this manual.
WALL MOUNT INSTRUCTIONS

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
This TradeQuip "Made for the Trade" Oscillating Wall Mount Fan is powered by a vented,
steel-cased 3-speed 240V 280W motor that delivers 300m³ per minute. High-temperature
resettable thermal auto reset and durable bearings allow operation in high temperatures.
Non-corroding aerodynamically balanced cast aluminium blades allow quiet operation.
Adjust the 15° fan head tilt adjustment and double-locking guard to direct the airflow
wherever necessary.
The "TradeQuip "Made for the Trade" Workshop Fans are commercial quality, industrial
duty fans ideal for cooling large open workshop areas in the hottest Australian climates.
Conforms to Australian Standards requirements.
2. BEFORE USE
Prior to each use conduct a visual inspection by checking for abnormal conditions, such as
cracked joins and damaged, loose, or missing parts.
Ensure that the fan is switched off from the supply mains before removing the guards.
If the supply cord is damaged, it must be replaced by the manufacturer, service agent or
similarly qualified persons in order to avoid a hazard.
3. ASSEMBLY
Assemble the Wall Plate (17) to the Support Arm (18):
a) Secure the Support Arm [18) to the Wall Plate [17) using the bolts (19,20,21,22)
and firmly tighten.
Attach the Fan Motor to the Support Arm
a) Locate the fixing hole on the motor locating tube & align the hole with the hole
in the Support Arm [18) & push in place.
b) To secure the fan motor to the wall bracket Support Arm, use the long bolt and
washer and push through the lower hole & tighten, using the short bolt push
through the upper hole and tighten.
Attach the rear Safety Grill to the Fan Motor
a) Align the rear safety grill (8) to the fan motor housing so that the fan grill
securing hole is at the bottom of the fan and align the four screw holes.
b) Firmly tighten all the four screws.
c) Ensure the cable clip (14) is secured so that the cable does not become trapped
during oscillation

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 5
Visit us at www.tqbbrands.com.au
Attach the Fan Blade to the Fan Motor
a) Rotate the fan motor shaft until the rebated flat area on the shaft is in the 12
o'clock position.
b) Locate the lock screw in the fan blade coupling; whilst aligning the screw and
motor shaft rebated flat area push the Fan Blade (3) all the way onto the shaft
and firmly tighten the grub screw by rotating in a clockwise direction.
Attach the front Safety Grill to the Fan Motor
a) Align the top locking clip on the Front Grill (2) to the top centre of the Rear Grill
(8) that has already been secured to the fan motor.
Lock the side and bottom clips in place.
b) Secure the front & rear safety grills together using the fan grill securing hole in
the bottom of the fan grill by inserting the fixing screw and nut provided.
c) Push the centre plate onto the front of the Grill with the TQ logo level or
horizontal.
d)
4. OPERATION
Oscillating Control:
The oscillation pattern can be adjusted from 0-90 degrees. When the adjusting screw is
moved towards the rotating axle, the fan will oscillate less of an angle. The longer-the
distance from adjusting screw, the larger the oscillating angle will be. Before you change
the oscillating angle, disconnect the 240V power supply, then loosen the adjusting screw
and adjust to obtain a satisfactory angle.
Change of the wind direction:
If you want to change the direction of the air circulation, disconnect the power supply and
loosen the direction adjustment bolt to adjust the direction of the fan head to required
position and re-tighten the bolt. It is not necessary to move the base of the fan.
Head angle adjustment:
Disconnect the power, hold the head of fan, loosen the adjustment bolt and stopping
bolt, adjust the fan to satisfactory position and tighten up the two bolts. When adjusting
the angle of the fan, ensure to keep it within the groove of the lower connection. If you
do not follow these instructions, the oscillating function may wear and stop working.
Adjustment of air volume
Turn the switch on the back of the fan head to control the operation of the fan to adjust
air volume, “1-3” speeds indicate different air volume.

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 6
Visit us at www.tqbbrands.com.au
5. STORAGE
This TradeQuip Industrial Wall Fan should always be stored in a dry location on a level
surface.
When you stop using the fan, you should clean the fan, pack it and put it in dry places, be
careful not to damage the fan.
6. MAINTENANCE
Disconnect power prior to any maintenance
Inspect the general condition of the TradeQuip Industrial Wall Fan checking:
- for loose hardware
- cracked, bent, or broken parts, and
- any other condition that may affect the TradeQuip Industrial Wall Fans safe
operation
Grease Change:
After the fan is operated over 2000 hours (or at least once a year), the grease in the gear
box and bearing should be changed.
7. SERVICE & REPAIR
Any TradeQuip Industrial Wall Fan found damaged in any way, or found to be worn or
operates abnormally should be removed from service until repaired by an authorised
service agent. Owners and / or operators should be aware that repair of this product may
require specialised equipment and knowledge. Only authorised parts, labels and decals
shall be used on this equipment. Annual inspection of the Pedestal & Wall Fan is
recommended and can be made by an authorised repair facility to ensure that your
equipment is in optimum condition and that the equipment has the correct decals and
safety labels specified by the manufacturer.

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 7
Visit us at www.tqbbrands.com.au
PARTS LIST WALL FAN
Part #
Description
QTY
Part #
Description
QTY
1
Centre Plate
1
12
Washer
1
2
Front Grill
1
13
Lower Connection
1
3
Fan Blade
1
14
Wiring Clip
1
4
Screw
1
15
Bolt
1
5
Bolt
4
16
Screw
1
6
Spring Washer
4
17
Support Arm
1
7
Washer
4
18
Wall Plate
1
8
Rear Grill
1
19
Bolt
1
9
Motor
1
20
Bolt
1
10
Nut
1
21
Nut
1
11
Spring Washer
1
22
Bolt
1

Oct-18 Product Code: 1026
Made in China to TQB Brands Pty Ltd specifications Page 8
Visit us at www.tqbbrands.com.au
WARRANTY
TradeQuip products have been carefully tested and inspected before shipment and are
guaranteed to be free from defective materials and workmanship for a period of 12 months
from the date of purchase except where tools are hired out when the guarantee period is
ninety days from the date of purchase.
Should this piece of equipment develop any fault, please return the complete tool to your
nearest authorised warranty repair agent or contact TQB Brands Pty Ltd Warranty team –
[email protected].
If upon inspection it is found that the fault occurring is due to defective materials or
workmanship, repairs will be carried out free of charge. This guarantee does not apply to
normal wear and tear, nor does it cover any damage caused by misuse, careless or unsafe
handling, alterations, accident, or repairs attempted or made by any personnel other than the
authorised TQB Brands Pty Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its
terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a
dated receipt or invoice to verify your proof of purchase within the 12month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a
major failure.
