TEF 1531
SOCKET USER MANUAL
IMPORTANT
Read this instruction carefully before installing the
product
TUM 1058

TEF 1531 SOCKET USER MANUAL
INTRODUCTION
Thank you for purchasing this product!
For installation, maintenance and assurance of a long life
of this product, please follow this manual.
CONTENT IN BOX
The product is fully assembled, and ready for installation.
SAFETY PRECAUTIONS
Note that changes made to the product and/or installation of
components which do not conform to the approval, may be
a safety violation. The manufacturer will in no circumstance
be held responsible for such activity.
For your health and safety, always use safety gear suited
for the task. Be certain to follow codes, regulations and/or
specific procedures that are related to the installation.
TOOLS REQUIRED
Regular tools required for installation:
• 10 mm wrench –for assembling the socket
• 6,5mm flat screwdriver - for cover of junction box. Earth
screw and terminal box.
• 24 mm wrench –for tightening pressure nut.
MAINTENANCE INSTRUCTIONS
The socket should be inspected according to Company
routines. The manufacturer suggests regular check for
water intrusion/condensation which should be removed
immediately.
NOTE:
Replace the cap when not in use.
APPLICATIONS
Power outlet for marine use.
APPROVALS
NA

TEF 1531 SOCKET USER MANUAL
INSTALLATION INSTRUCTIONS
SPARE PART
Description Part No.
Blind cover with chain 1000 004
Insert socket 2p 10A DC / 16A AC 250V 5082 0002
Cup ring 40,5 x 34,5 x 0,5mm 5001 0011
Ring nut, for insert R1 3/8” 5082 0003
Rubber ring, conical 5082 0004
terminal block, 2p, 2,5 qmm, 25V
Cover for socket, 1531 1000 005
Gasket (o-ring) for cover 5087 0011
Max. cable diam.: 2 x 2,25mm²
Be sure to install the cable in a way wich prevents water to
penetrate into the enclosure through the cable

Tranberg AS | P.O. Box 8033 | N-4068 Stavanger | Norway | Tel.: [phone] | Fax.: [phone]
E-mail: [email protected] | www.tranberg.com
Tranberg Systems | Hjulmagervej 15C | 7100 Vejle | Denmark | Tel.: [phone]
E-mail: [email protected] | www.tranbergsystems.com
TEF 1531 SOCKET USER MANUAL
TECHNICAL DATA
Hight: 75mm
Width: 115mm
Length: 135mm
Weight: 1,05 kg.
