Tranberg TEF 2440 User manual

R. Stahl Tranberg AS
E[email protected] | stahl-tranberg.com
Main office: Strandsvingen 6 | N-4032 Stavanger | Norway | T+47 51 57 89 00 | F+47 51 57 89 50
Office Oslo: Luhrtoppen 2 | N-1470 Lørenskog |Norway | T+47 24 08 44 10
IMPORTANT
Read this instruction carefully before installing the
product
Subject to change without prior notice TUM1004 REV. C 20.09.2019
LIGHTING
TEF 2440 LUMINAIRE
ZONE 2 & SAFE AREA
USER MANUAL

TEF 2440 LUMINAIRE USER MANUAL
INTRODUCTION
Thank you for purchasing this product!
For installation, maintenance and assurance of a long life
of this product, please follow this manual.
CONTENT IN BOX
The product is fully assembled, and ready for installation.
SAFETY PRECAUTIONS
Note that changes made to the product and/or installation
of components which do not conform to the approval, may
be a safety violation. The manufacturer will in no
circumstance be held responsible for such activity.
For your health and safety, always use safety gear suited
for the task. Be certain to follow codes, regulations and/or
specific procedures that are related to the installation.
TOOLS REQUIRED
Regular tools required for installation.
• 10mm wrench whien installing the luminaire.
• 32mm wrench whien installing the cable gland.
• 30mm wrench when installing the lock nut.
• 25mm wrench when tightening the pressure nut.
• PZ 2 screwdriver for assemble/dissemble the globe.
• 3 mm straight screwdriver for terminal to connect the
lighting.
• 5 mm straight screwdriver for earth screw.
Do not use powertools when fastening globe!
MAINTENANCE INSTRUCTIONS
The luminaire should be inspected according to Company
routines. The manufacturer suggests regular check for
water intrusion/condensation which should be removed
immediately. Check the drain plug / drain hole function.
When cleaning, use only mild detergents. Alcohol or
petroleum based products may damage lens, paint or
plastic components.
RUBBER SEAL
Cable diameter Size Part No.
8,5 - 13,5mm Ø23/13x8mm 5002 0124
13 - 17mm Ø23/16x8mm 5002 0125
Be sure to install cable in a way wich prevents water to penetrate into the enclosure through the cable gland,
also make sure to use the correct rubber seal when you install the luminaire.
APPLICATIONS
• Deck lighting
• Signal lighting
• Obstacle marking
• Perimeter light for helideck landing areas
APPROVALS
NEMKO Certificate No.: 03ATEX3336

TEF 2440 LUMINAIRE USER MANUAL
COMPLETE THE INSTALLATION
Before replacing the globe assembly, please review the
following:
• Verify that the grommet kit used match the cable diameter.
• Cables should have a bend before entering the cable
gland, which will avoid water intrusion into the luminaire.
• An unused cable gland should be replaced with a blind
plug.
Ensure the globe gasket is clean and properly aligned
around the bottom of the globe. Then carefully position
the globe over the PL-C light source and into the circular
opening in the luminaire base. Slightly tighten two opposite
screws, then repeat with the other two opposite screws.
This ensures that the globe is positioned evenly and the
pressure on the globe gasket is distributed evenly. Tighten
all four screws until the globe is firmly positioned. Power
tools should under no circumstances be used!
ELECTRICAL INSTALLATION
The luminaire is factory configured with grommet kit 3C, suitable for cable diameters ranging from 8.5 mm to 13.5 mm. For
cable diameters ranging from 13.0 mm to 17.0 mm, please ensure to replace the installed grommet kit with kit 3D. Cable
entries should be tightened properly. Do not use execessive force, as this may disalign the grommet components and lead
to water intrusion.
Make sure electrical connections are safe and reliable.

R. Stahl Tranberg AS
E[email protected] | stahl-tranberg.com
Main office: Strandsvingen 6 | N-4032 Stavanger | Norway | T+47 51 57 89 00 | F+47 51 57 89 50
Office Oslo: Luhrtoppen 2 | N-1470 Lørenskog |Norway | T+47 24 08 44 10
TEF 2440 LUMINAIRES USER MANUAL
TECHNICAL DATA
Material: Acid proof stainless steel, coated with three separated layers of paint.
RAL 9002
Globe : Polycarbonate lexan
Input voltage: 230 VAC 50/60Hz / 120 VAC 60Hz
Light output: >10 candela red
>80 candela yellow
>90 candela white
Power comsumption: 18 Watt
IP-rating: IP66/67
Standard cable entries: 1 x M25 stopping plug / 1 x M25 cable gland
Weight: 1,9 kg.
Ex-marking: ExnA II T3/T4 II 3 G
For use in zone: Zone 2 and safe area
SPARE PARTS
Description Part No.
Globe clear, without gasket, spare part kit 230V 2548
Globe green, without gasket, spare part kit 230V 2592
Globe red, without gasket, spare part kit 230V 2553
Globe yellow amber, without gasket, spare part kit 230V 2604
Globe blue, without gasket, spare part kit 230V 2593
Globe amber, without gasket, spare part kit 230V 2557
Globe clear, without gasket, spare part kit 120V 2448
Globe blue, without gasket, spare part kit 120V 3000
Globe red, without gasket, spare part kit 120V 2847
Globe yellow amber, without gasket, spare part kit 120V 2810
Globe gasket, silicone 5001 0021
Globe retainer ring 2547
Fluorescent tube PL-C 13W/84 230VAC 9400 060
Fluorescent tube PL-C 10W/84 230VAC 9400 062
Fluorescent tube PL-C 13W/USA/35 120VAC 9400 064
Cable gland E704/CD/M25 9147 200
Stopping plug M25, EExe, L-9 7947 304
Ballast and lamp holder, spare part kit 230VAC 2510
Ballast and lamp holder, spare part kit 120VAC 2805
