Trane SRV-SVN06C-EN User manual

Rental Services
Electric Heaters
Installation Manual
July 2020 SRV-SVN06C-EN
SAFETY WARNING
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.

©2020 Trane SRV-SVN06C-EN
Introduction
Warnings, Cautions, and Notices
Safety advisories appear throughout this manual as required. Your personal safety and the proper
operation of this machine depend upon the strict observance of these precautions.
The three types of advisories are defined as follows:
WARNING Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTIONsIndicates a potentially hazardous situation which, if not avoided, could result in
minor or moderate injury. It could also be used to alert against unsafe practices.
NOTICE Indicates a situation that could result in equipment or property-damage only
accidents.
Important Environmental Concerns
Scientific research has shown that certain man-made chemicals can affect the earth’s naturally
occurring stratospheric ozone layer when released to the atmosphere. In particular, several of the
identified chemicals that may affect the ozone layer are refrigerants that contain Chlorine, Fluorine
and Carbon (CFCs) and those containing Hydrogen, Chlorine, Fluorine and Carbon (HCFCs). Not all
refrigerants containing these compounds have the same potential impact to the environment.
Trane advocates the responsible handling of all refrigerants-including industry replacements for
CFCs and HCFCs such as saturated or unsaturated HFCs and HCFCs.
Important Responsible Refrigerant Practices
Trane believes that responsible refrigerant practices are important to the environment, our
customers, and the air conditioning industry. All technicians who handle refrigerants must be
certified according to local rules. For the USA, the Federal Clean Air Act (Section 608) sets forth the
requirements for handling, reclaiming, recovering and recycling of certain refrigerants and the
equipment that is used in these service procedures. In addition, some states or municipalities may
have additional requirements that must also be adhered to for responsible management of
refrigerants. Know the applicable laws and follow them.
WARNING
Proper Field Wiring and Grounding Required!
Failure to follow code could result in death or serious injury. All field wiring MUST be
performed by qualified personnel. Improperly installed and grounded field wiring poses FIRE
and ELECTROCUTION hazards. To avoid these hazards, you MUST follow requirements for field
wiring installation and grounding as described in NEC and your local/state electrical codes.
Failure to follow code could result in death or serious injury.

WARNING
Personal Protective Equipment (PPE) Required!
Failure to wear proper PPE for the job being undertaken could result in death or serious injury.
Technicians, in order to protect themselves from potential electrical, mechanical, and chemical
hazards, MUST follow precautions in this manual and on the tags, stickers, and labels, as well
as the instructions below:
• Before installing/servicing this unit, technicians MUST put on all PPE required for the work
being undertaken (Examples; cut resistant gloves/sleeves, butyl gloves, safety glasses, hard
hat/bump cap, fall protection, electrical PPE and arc flash clothing). ALWAYS refer to
appropriate Safety Data Sheets (SDS) and OSHA guidelines for proper PPE.
• When working with or around hazardous chemicals, ALWAYS refer to the appropriate SDS
and OSHA/GHS (Global Harmonized System of Classification and Labeling of Chemicals)
guidelines for information on allowable personal exposure levels, proper respiratory
protection and handling instructions.
• If there is a risk of energized electrical contact, arc, or flash, technicians MUST put on all PPE
in accordance with OSHA, NFPA 70E, or other country-specific requirements for arc flash
protection, PRIOR to servicing the unit. NEVER PERFORM ANY SWITCHING,
DISCONNECTING, OR VOLTAGE TESTING WITHOUT PROPER ELECTRICAL PPE AND ARC
FLASH CLOTHING. ENSURE ELECTRICAL METERS AND EQUIPMENT ARE PROPERLY RATED
FOR INTENDED VOLTAGE.
WARNING
Follow EHS Policies!
Failure to follow instructions below could result in death or serious injury.
• All Trane personnel must follow the company’s Environmental, Health and Safety (EHS)
policies when performing work such as hot work, electrical, fall protection, lockout/tagout,
refrigerant handling, etc. Where local regulations are more stringent than these policies,
those regulations supersede these policies.
• Non-Trane personnel should always follow local regulations.
Introduction
SRV-SVN06C-EN 3
Copyright
This document and the information in it are the property of Trane, and may not be used or
reproduced in whole or in part without written permission. Trane reserves the right to revise this
publication at any time, and to make changes to its content without obligation to notify any person
of such revision or change.
Trademarks
All trademarks referenced in this document are the trademarks of their respective owners.
Revision History
Updated for Trane Technologies.

Table of Contents
4SRV-SVN06C-EN
Electric Heater Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Units Affected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Heating Capacity (Btu) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rigging Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unit Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
50 kW and 150 kW (F0) Electric Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
150 kW (F1) Electric Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Fan Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation/Start-up Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Start-up Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
50 kW and 150 kW (F0) Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
150 kW (F1) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Shut Down Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
50 kW and 150 kW (F0) Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
150 kW (F1) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

SRV-SVN06C-EN 5
Electric Heater Overview
Introduction
This installation manual covers the 50 kW and 150 kW electric heaters available to rent from Trane
Rental Services for temporary heating solutions. It includes heater technical information, start-up
information and unit maintenance. The information contained in this bulletin is provided to ensure
the safe installation and operation of the equipment and its surroundings.
The information provided in this Installation Manual is to be used as a reference for each heater,
to aid in determining unit size, power requirements or lifting requirements. If additional
information regarding a particular unit is required, please contact Trane Rental Services.
Also, contact Trane Rental Services Marketing for availability of equipment (including ancillary
items: electrical cable, flexible duct, etc.) prior to proceeding with securing the rental equipment.
Equipment is available on a first-come, first-serve basis, but can be reserved with a signed rental
agreement.
Call Rental Services 24/7 at 1-800-755-5115 for specific questions.
Units Affected
RSEH0050F0XX – 50 kW electric heater
RSEH0150F0XX – 150 kW electric heater
RSEH0150F1XX – 150 kW electric heater (narrow width)
Note: Where xx represents the unique inventory number.
WARNING
Live Electrical Components!
During installation, testing, servicing and troubleshooting of this product, it may be necessary
to work with live electrical components. Have a qualified licensed electrician or other
individual who has been properly trained in handling live electrical components perform these
tasks. Failure to follow all electrical safety precautions when exposed to live electrical
components could result in death or serious injury.
WARNING
Failure to follow state/local codes could result in death or serious
injuries!
All electric heating units should be installed per the National Electric Code (NEC) and/or
applicable state/local codes.
Note: All information contained in this document is for reference only.
General Information
The Trane Rental Services electric heaters provide clean electric heat that is free from the moisture
and fumes that are associated with other types of heating. The electric heaters can be used in free
blow or ducted applications. The hot air is discharged horizontally. When used in free blow
applications, the supply ducting on the front of the unit must be removed. Flexible duct is available
upon request.

6SRV-SVN06C-EN
Electric Heater Overview
Table 1.
Model 50 kW 150 kW (F0) 150 kW (F1)
Manufacturer United Cool Air United Cool Air OnSite
Manufacturing
Airflow Orientation Horizontal Horizontal Horizontal
Nominal Airflow 2300 cfm 9,000 cfm 5,000 cfm
Blower RPM 1,725 3,450 1770
Max Static 
Discharge Pressure 1.0 in. ESP 3.0 in. ESP 3.0 in. ESP
Supply Air Connection(s) Type Duct Duct Duct
Quantity 1 1 1
Size 19 in. 19 in. 19 in.
Return Air Connection(s) Type Duct Duct Duct
Quantity 1 1 1
Size 19 in. 19 in. 19 in.
Filter Type Permanent
Cleanable Permanent
Cleanable N/A
Quantity 1 4 N/A
Dimensions 19.4 in. x 21.4 in. 23.0 in. x 24.0 in. N/A
Insurance Value $10,000 $38,000 $38,000
Heating Capacity (Btu)
Table 2.
Model
Temperature Rise 
@ Max cfm (°F)
Maximum Leaving Air
Temperature (°F)
Number of 
Heat Stages Total Capacity (Btu)
50 kW 50 160 2170,600
150 kW (F0) 50 160 4512,000
150 kW (F1)* 50 300 2512,000
*The 150 kW (F1) heater has two stages of heat and can be used as a 75 kW heater. BTU capacity in this scenario is
296,000 Btu.
Note: Capacities are gross values and are not adjusted for motor heat.
Weights and Dimensions
Table 3.
Model Length Width Height Weight
50 kW 4 ft, 7 in 2 ft, 10 in 3 ft, 11 in 575 lb
150 kW (F0) 7 ft, 6 in 4 ft, 1 in 4 ft, 4 in 1,385 lb
150 kW (F1) 6 ft, 9 in 2 ft, 9 in 4 ft, 0 in 1,480 lb

SRV-SVN06C-EN 7
Rigging Guidelines
The 50kW and 150kW (F1) units conveniently fit through a standard doorway. The 50kW and 150kW
heaters include a rugged, weatherproof enclosure for reliable outdoor operations. The 50 kW
electric heaters are equipped with lockable caster wheels and handles on each end of the unit to
allow the unit to be maneuvered into position. The 150 kW (F1) electric heaters are equipped with
casters and fork pockets on one side. The 150 kW (F0) electric heater has forklift pockets on two
sides only and lifting rings at the top corners of the unit.
WARNING
Heavy Objects!
Use a forklift of suitable capacity to move the unit. Failure to properly lift unit could result in
death or serious injury or possible equipment or property only damage.
Figure 1. 50 kW Electric Heater
Figure 2. 150 kW (F0) Electric Heater

8SRV-SVN06C-EN
Figure 3. 150 kW (F1) Electric Heater

SRV-SVN06C-EN 9
Electrical Information
The 50 kW, 150 kW (F0) and 150 kW (F1) have color-coded cam-type electrical connections for
connecting our temporary electrical cable to the unit. The 50 kW electric heaters are equipped with
two sets of color coded cam-type electrical connections to allow you to connect multiple units in
series. Ensure that the electrical cable that is utilized is adequately sized to handle the additional
load for powering multiple units.
Table 4.
Model 50 kW 150 kW (F0) 150 kW (F1)*
VFD No Yes Yes
Fan Motor HP 215 3
Unit Power 460V, 3-phase 460V, 3-phase 460V, 3-phase
Unit MCA 74.4 248.3 235
Motor FLA 318 7.6
Unit FLA 56.6 187.5 190
MOP 75 250 250
* The 150 kW (F1) heater has two stages of heat and can be used as a 75 kW heater. In this scenario, the unit FLA is 92
amps and MOP is 150 amps.

10 SRV-SVN06C-EN
Unit Controls
50 kW and 150 kW (F0) Electric Heater
The 50 kW electric heater is a constant volume unit. The 150 kW (F0) electric heater contains a
variable frequency drive (VFD) to control the supply fan. The VFD on the 150 kW (F0) electric heater
is controlled using the potentiometer dial labeled “Fan Speed” located behind the metal door on
the side of the unit. The 50 kW and 150 kW (F0) units are also equipped with an emergency stop
button and a fan switch to provide on-off fan control.
The 50 kW and 150 kW (F0) units are manufactured with internal time delays to protect the system
from overloading the supply power with a large inrush at the same time. The 50 kW and 150 kW
(F0) heaters are supplied with discharge air thermostats. The discharge air thermostat is located
internal to the unit control box directly behind the unit's main thermostat and system ON/OFF
switch. This thermostat prevents the discharge air temperature from exceeding 160°F which
prevents internal damage to the unit. These units also have high limit switches that are designed
to shut the heaters down if the discharge air temperatures exceed 180°F.
Note: At least one section of duct must be connected to the supply or return of the 50 kW electric
heater to prevent the fan breaker from tripping due to excessive fan speed.
Figure 4. 50 kW Control Panel
Figure 5. 150 kW (F0) Control Panel

SRV-SVN06C-EN 11
150 kW (F1) Electric Heater
The 150kW (F1) electric heaters contain a 3 hp blower with variable speed drive allows for precise
air flow control. The NEMA 4 control panel includes main disconnect, high limit controller and an
industrial three-pole shutdown contactor for each heating circuit. The unit includes an emergency
shutdown button and indicator lamps for Power On, Heat On, Low Air Flow and Over Temperature.
Also included is a process controller with remote setpoint capacity, digital communications and 4-
20 mA analog output.
The 150 kW (F1) heater is a portable assembly capable of operating at either a 75 kW or 150 kW
heating capacity. The fan speed is controlled with a variable frequency drive to change air flow
volume and is adjusted by the “Variable Speed Control” dial. The output temperature is controlled
with Chromalox®Temperature Controller with a thermocouple mounted in the output air stream.
The heater has two modes of operation – LOCAL and REMOTE.
Local operation relies on the thermocouple located in the heater outlet air flow only and connected
to the Chromalox®Temperature Controller. The default temperature setting is 300°F. The
controller will maintain this output air flow temperature. The controller temperature level can be
adjusted to a lower temperature based on the ambient conditions and operator discretion. The
temperature cannot be adjusted higher than 300°F.
Remote operation relies on the thermostat locatedin the remote controller panel, as well as the
thermocouple located on the heater outlet. The heater will produce 300°F outlet temperature. Once
the remote thermostat is satisfied, the heater will cycle to maintain the remote thermostat setting.
The operator can vary both the output temperature setting and fan speed to achieve desired results.
There are two ON/OFF switches on the control panel. The large rotary switch on the left of the
control panel energizes control power. The smaller ON/OFF selector switch starts the heater. There
are three main fault indicators on the front panel. Any of these faults will shut down the heater.
• High Limit Fault – indicates heater element temperature has exceeded 1000°F. Probes are
located in each of the 75 kW heater element assemblies.
• Air Limit Fault – indicates insufficient air flow over the heater elements. Check for obstructions
to inlet air and fouling of the draft tube.
• VFD Fault – indicates internal problem on VFD. Refer to manufacture’s manual for
troubleshooting procedures. (NOTE: Pushing the Emergency Stop Button will shut down the
VFD and indicate VFD FAULT. 480V power must be removed to reset this fault.)

12 SRV-SVN06C-EN
Fan Curves
Figure 6. 50 kW Fan Curve

SRV-SVN06C-EN 13
Fan Curves
Figure 7. 150 kW (F0) Fan Curve

14 SRV-SVN06C-EN
Figure 8. 150 kW (F1) Fan Curve

SRV-SVN06C-EN 15
Installation/Start-up Guidelines
Installation
• Confirm unit is properly leveled.
• Verify air inlet and heater outlet are clear of any debris or obstructions.
• Connect power cable from unit to the power source and confirm that the wires are properly
phased, connected and locked securely to panel.
• For ducted applications:
•Install the supply and return air ducts on the duct adapters on the front of the unit. Ensure
as straight a run of duct as possible. Excessive bends or kinks may cause the heaters to short
cycle.
• For free blow applications:
•No duct installation required.
• For 150 kW (F0) only:
•Turn the Fan Speed potentiometer to its minimum setting – full counterclockwise position
(See Figure 3 for reference).
• For 150 kW (F1) only:
•Verify air flow draft (Pitot) tube is clear and clean. Draft tube is located behind outlet grill.
•Verify heater temperature probe is clear and clean. Probe is located behind outlet grill, next
to draft tube.
•If using Remote Control Panel, verify cable remote thermostat is properly seated and locked
into control panel. (If used – otherwise place switch in Local mode).
•Adjust variable speed dial to full clockwise position.
Start-up Guidelines
50 kW and 150 kW (F0) Units
WARNING
Hazardous Voltage!
Disconnect all electric power, including remote disconnects before servicing. Follow proper
lockout/tagout procedures to ensure the power cannot be inadvertently energized. Failure to
disconnect power before servicing could result in death or serious injury.
• Verify that the unit disconnect (toggle switch) is in the “OFF” position on the unit.
• Energize the source power to the electric heater.
•Switch the unit disconnect (toggle switch) to the “ON” position to supply power to the unit.
Note: If the Power LED is illuminated, the unit is ready for operation. If not, check the unit supply
voltage at the main power source. Disconnect (turn off) the unit’s circuit breaker and the
main power at the power source when checking voltage.

16 SRV-SVN06C-EN
Installation/Start-up Guidelines
Figure 9. 50 kW and 150 kW (F0) Main Unit Disconnect
• Verify proper sequencing of the input power by looking at the phase indicating light. If the light
is lit, change any two of the conductors (excluding the ground wire) at the power source. Do
not change wiring internal to the unit!
• For 50 kW:
•Turn Selector Switch to “Heat”
For 150 kW (F0):
•Turn the system switch to the “ON” position and adjust the air flow using a flat head
screwdriver on the “Fan Speed” dial.
•Turn the "Fan Speed"dial counter-clockwise to decrease the blower motor speed. Turn the
"Fan Speed" dial clockwise to increase the blower motor speed. Set the blower speed as
appropriate.
Note: When the speed of the motor decreases below a preset frequency of 45 Hz three stages of
heating will automatically shut down to prevent the heaters from overheating.
• Use the thermostat dial to adjust discharge temperature.
150 kW (F1) Unit
WARNING
Hazardous Voltage!
Disconnect all electric power, including remote disconnects before servicing. Follow proper
lockout/tagout procedures to ensure the power cannot be inadvertently energized. Failure to
disconnect power before servicing could result in death or serious injury.
• Verify E-Stop is not engaged (Pull button out).
• Rotate disconnect to the “ON” Position. (Note: This energizes control power and allows the user
to adjust the Chromalox®temperature controller, but will not start the heater.)
• Set the outlet temperature on the Chromalox®using the “Up” and “Down” arrows.
• If you are using the remote thermostat, you will place the LOCAL/REMOTE button to REMOTE.
• Set key switch position to available feeder circuit breaker.
•75 kW operation (key switch position #1) – 150 amp feeder circuit breaker required
•150 kW operation (key switch position #2) – 250 amp feeder circuit breaker required
• Rotate “ON/OFF” switch to “ON” position to commence heater operation. Heater will start, and
the operator can observe the output temperature increase to programmed set point.
Note: Hi limit fault and air limit fault lights will operate until the air flow is sufficient to remove the
faults – these faults will turn off within 2-3 seconds after fan operates!
• Push each fault light button to verify all fault lights function correctly.

SRV-SVN06C-EN 17
Installation/Start-up Guidelines
• Adjust outlet temperature and fan speed to obtain desired heating performance (Do not attempt
to set outlet temperature above 300°F).
• Close all covers (local and remote panels) and secure.

18 SRV-SVN06C-EN
Installation/Start-up Guidelines
Shut Down Guidelines
50 kW and 150 kW (F0) Units
• To Power off the unit:
•For 50 kW: Turn Selector Switch to the "OFF" position
•For 150 kW (F0): Turn the system switch to the "OFF" position
• Switch the unit disconnect (toggle switch) to the "OFF" position to remove power from the unit.
• De-energize the source power to the electric heater.
150 kW (F1) Unit
• Turn ON/OFF selector switch on control panel to “OFF” position. Heater will then commence
an automatic 3 minute cool down cycle, then automatically shut down.
CAUTION
The heater cool down cycle is needed to safely shut down the system. Do not disconnect or
shut power off to the unit until the cool down cycle is complete!
• Rotate disconnect to the "OFF" position
• Close all covers (local and remote panels) and secure.
Maintenance Guidelines
The motor and blower bearings are permanently lubricated and require no maintenance. The unit
fan is belt driven. The drive belts should be examined periodically for wear and correct tension.
Each unit is provided with cleanable filters that are installed in the evaporator return air section.
The return air grill must be removed to gain access to the filters. Check filters periodically to verify
that they are clean. The filters can be cleaned by rinsing them with water.

©2020 Trane
Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without
notice. We are committed to using environmentally conscious print practices.
Trane - by Trane Technologies (NYSE: TT), a global climate innovator - creates comfortable, energy
efficient indoor environments for commercial and residential applications. For more information,
please visit trane.com or tranetechnologies.com.
SRV-SVN06C-EN 17 Jul 2020
Supersedes SRV-SVN06B-EN (Nov 2011)
