Trane 4TXK6512G1000AA User manual

CONTENTS
1 . Specification....................................................................................................................................................................1
2 . Dimension .......................................................................................................................................................................7
3 . Piping diagram ..............................................................................................................................................................29
4 . Wiring diagram..............................................................................................................................................................31
5 . Performance cure..........................................................................................................................................................42
6 . Capacity compensation rate for pipe length and height difference ...............................................................................54
7 . Installation ....................................................................................................................................................................60
8 . Indoor ....................................................................................................................................................................................118
9 . Outdoor...................................................................................................................................................................................128
10 . Failure code...............................................................................................................................................................141
11 . Sensor code and B&R value .....................................................................................................................................152

1 . Specification
18K 24K
TRANE Model IDU 4MXC6518G1000AA 4MXC6524G1000AA
Panel 4MXL2318BF0W0AA 4MXL2324BF0W0AA
Power supply
V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max)
Btu/h 6,500 ~ 17,700 ~ 19,200 9,800 ~ 24,000 ~ 28,400
Capacity (min ~ nor ~ max) W 1,900 ~ 5,190 ~ 5,625 2,870 ~ 7,030 ~ 8,320
Input
W 1,587 2,150
EER
W/W 3.27 3.27
Heating
Capacity (min ~ nor ~ max) Btu/h 10,000 ~ 18,300 ~ 20,000 10,200 ~ 24,500 ~ 27,400
Capacity (min ~ nor ~ max)
W 2,930 ~ 5,362 ~ 5,860 2,990 ~ 7,175 ~ 8,028
Input
W 1,675 2,242
COP W/W 3.20 3.20
Indoor fan
motor
Model
ZW465C03 ZWK465B500011
Qty
1 1
Input w 33 72
Capacitor
uF / /
Speed(hi/mi/lo)
r/min 850/700/600 500/430/360
Indoor coil
a.Number of rows 2 2
b.Tube pitch(a)x row pitch(b)
mm 21x13.3 21x13.3
c.Fin spacing
mm 1.25 1.4
d.Fin type (code)
Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and type
mm φ7 / Inner grooved φ7 / Inner grooved
f.Coil length x height x width
mm 1330×210×26.6 2242×168×26.6
g.Number of circuits
10 8
Indoor air flow (Hi/Med/Lo)
m 700/620/500 1260/1070/820
Sound level (sound pressure) dB(A) 44/39/37 36/33/29
Throttle type In ODU In ODU
1

18K 24K
TRANE Model IDU 4MXC6518G1000AA 4MXC6524G1000AA
Panel 4MXL2318BF0W0AA 4MXL2324BF0W0AA
Indoor unit
Dimension (W x Dx H)(body)
mm 570×570×260 840×840×246
Packing (W x Dx H)(body) mm 718×680×380 990×990×340
Dimension (W x Dx H)(panel)
mm 620×620×60 950×950×50
Packing (W x Dx H)(panel) mm 660×660×115 1000×1000×110
Net/Gross weight(body) kg 19/22 31/36
Net/Gross weight(panel)
kg 2.8/4.8 6.5/9
Design pressure
MPa 4.15/1.5 4.15/1.5
Drainage water pipe dia. mm 32 32
Refrigerant
piping Liquid side/ Gas side mm 6.35/12.7 9.52/15.88
Controller
Remote control Remote control
Operation temperature
16~30 16~30
Room
temperature
Cooling
18"32 18"32
Heating 15"27 15"27
Qty’per 20’ /40’ /40'HQ 118/240/284 55/125/144
2

36K 48K
TRANE Model IDU 4MXC6536G1000AA 4MXC6548G1000AA
Panel 4MXL2324BF0W0AA 4MXL2324BF0W0AA
Power supply V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max)
Btu/h 14,000 ~ 34,000 ~ 35,000 19,200 ~ 46,200 ~ 50,200
Capacity (min ~ nor ~ max)
W 4,100 ~ 9,960 ~ 10,260 5,625 ~ 13,540 ~ 14,710
Input
W 3,018 4,140
EER
W/W 3.30 3.27
Heating
Capacity (min ~ nor ~ max)
Btu/h 14,500 ~ 36,500 ~ 42,300 19,000 ~ 48,500 ~ 50,300
Capacity (min ~ nor ~ max) W 4,248 ~ 10,695 ~ 12,395 5,567 ~ 14,210 ~ 14,738
Input
W 3,342 4,440
COP W/W 3.20 3.20
Indoor fan
motor
Model ZWK511B51008 ZWK511B51008
Qty
1 1
Input
w 90 90
Capacitor uF / /
Speed(hi/mi/lo)
r/min 650/550/450 850/750/650
Indoor coil
a.Number of rows
2 2
b.Tube pitch(a)x row pitch(b)
mm 21×13.3 21×13.3
c.Fin spacing
mm 1.4 1.3
d.Fin type (code)
Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and type
mm φ7 / Inner grooved φ7 / Inner grooved
f.Coil length x height x width
mm 2242×210×26.6 2127×252×26.6
g.Number of circuits
10 11
Indoor air flow (Hi/Med/Lo)
m 1600/1440/1260 1950/1600/1440
Sound level (sound pressure)
dB(A) 50/46/42 52/48/45
Throttle type In ODU In ODU
3

36K 48K
TRANE Model IDU 4MXC6536G1000AA 4MXC6548G1000AA
Panel 4MXL2324BF0W0AA 4MXL2324BF0W0AA
Indoor unit
Dimension (W x Dx H)(body)
mm 840×840×246 840×840×288
Packing
(W x Dx H)(body)
mm 990×990×340 990×990×380
Dimension (W x Dx H)(panel)
mm 950×950×50 950×950×50
Packing (W x Dx H)(panel) mm 1000×1000×110 1000×1000×110
Net/Gross weight(body) kg 31/36 40/45
Net/Gross weight(panel)
kg 6.5/9 6.5/9
Design pressure
MPa 4.15/1.5 4.15/1.5
Drainage water pipe dia. mm 32 37
Refrigerant
piping Liquid side/ Gas side mm 9.52/19.05 9.52/19.05
Controller
Remote control Remote control
Operation temperature
16~30 16~30
Room
temperature
Cooling
18"32 18"32
Heating
15"27 15"27
Qty’per 20’ /40’ /40'HQ
55/125/144 54/110/125
4

60K
TRANE Model IDU 4MXC6560G1000AA
Panel 4MXL2324BF0W0AA
Power supply V-ph-Hz 220-1-60
Cooling
Capacity (min ~ nor ~ max)
Btu/h 20,800 ~ 51,000 ~ 55,200
Capacity (min ~ nor ~ max)
W 6,090 ~ 14,940 ~ 16,170
Input
W 4,611
EER
W/W 3.24
Heating
Capacity (min ~ nor ~ max)
Btu/h 21,100 ~ 52,000 ~ 56,300
Capacity (min ~ nor ~ max) W 6,180 ~ 15,235 ~ 16,500
Input
W 4,789
COP W/W 3.20
Indoor fan
motor
Model ZWK511B51008
Qty
1
Input
w 90
Capacitor uF /
Speed(hi/mi/lo)
r/min 880/760/590
Indoor coil
a.Number of rows
2
b.Tube pitch(a)x row pitch(b)
mm 21×13.3
c.Fin spacing
mm 1.3
d.Fin type (code)
Hydrophilic aluminium
e.Tube outside dia.and type
mm φ7 / Inner grooved
f.Coil length x height x width
mm 2127×252×26.6
g.Number of circuits
11
Indoor air flow (Hi/Med/Lo)
m 1950/1600/1440
Sound level (sound pressure)
dB(A) 52/48/45
Throttle type In ODU
5

12K 18K
TRANE Model 4MXD6512G1000AA 4MXD6518G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h 2,800 " 12,000 " 14,000 9,500 " 18,000 " 19,800
Capacity (min ~ nor ~ max) W 820 " 3,516 " 4,100 2,783 " 5,275 " 5800
Input W 1,160 1,761
EER W/W 3.03 3.03
Heating
Capacity (min ~ nor ~ max) Btu/h 3,000 " 13,000 " 15,000 10,000 " 18,300 " 20,000
Capacity (min ~ nor ~ max) W 880 " 3,810 " 4,395 2,930 " 5,362 " 5,860
Input W 1,270 1,787
COP W/W 3.00 3.00
Indoor fan motor
Model
ZWK511B50502 ZWK511B50703
Qty
1 1
Input W 28 55
Speed(Hi/Med/Lo) r/min 950/850/750 900/800/700
Indoor coil
Number of rows
2
2
Tube pitch(a)*row pitch(b) mm 21×13.3 21×13.3
Fin spacing mm 1.4 1.4
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm (1)7 / Inner grooved (1)7 / Inner grooved
Coil length * height * width mm 640×210×26.6 960×210×26.6
Number of circuits
10 10
Indoor air flow (Hi/Med/Lo) m 600/480/420 900/780/660
ESP Rated Pa 50 50
Range Pa 10-50 10-50
Indoor noise level (Hi/Med/Lo) dB(A) 37/34/31 36/34/32
Throttle type
In ODU In ODU
Indoor unit
Dimension (WxDxH) mm 850×420×185 1170×420×185
Packing(WxDxH) mm 1045×540×270 1365×540×270
Net/Gross weight kg 16/21 22/28
Design pressure MPa 4.15/1.5 4.15/1.5
Drainage water pipe diameter mm 27 27
Refrigerant piping Liquid side/ Gas side mm 6.35/9.52 6.35/12.7
Controller
Wired control Wired control
Operation temperature
16"30 16"30
Room temperature Cooling
18"32 18"32
Heating 15"27 15"27
Qty’per 20’ /40’ /40'HQ 176/352/272 128/264/264
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
6

24K 36K
TRANE Model 4MXD6524G1000AA 4MXD6536G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h 9,700 " 24,000 " 27,000 14,000 " 36,000 " 42,000
Capacity (min ~ nor ~ max) W 2,842 " 7,032 " 7,911 4,100 " 10,550 " 12,300
Input W 2,321 3,481
EER W/W 3.03 3.03
Heating
Capacity (min ~ nor ~ max) Btu/h 10,200 " 24,500 " 27,400 14,500 " 36,500 " 42,300
Capacity (min ~ nor ~ max) W 2,990 " 7,179 " 8,028 4,248 " 10,695 " 12,395
Input W 2,393 3,565
COP W/W 3.00 3.00
Indoor fan motor
Model
ZWK511B50703 ZWK702B000027
Qty
1 1
Input W 55 200
Speed(Hi/Med/Lo) r/min 1250/1100/1000 1194/1065/964
Indoor coil
Number of rows
3
4
Tube pitch(a)*row pitch(b) mm 21×13.3 21×13.3
Fin spacing mm 1.4 1.3
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm φ7 / Inner grooved Φ7,innergroove tube
Coil length * height * width mm 640×210×39.9 1001×294×39.9
Number of circuits
15 10
Indoor air flow (Hi/Med/Lo) m 1000/950/850 1630/1488/1421
ESP Rated Pa 50 50
Range Pa 10-50 10-50
Indoor noise level (Hi/Med/Lo) dB(A) 38/35/33 49/47/44
Throttle type
In ODU In ODU
Indoor unit
Dimension (WxDxH) mm 1170×420×185 1140×710×275
Packing(WxDxH) mm 1365×540×270 1342×841×358
Net/Gross weight kg 24/30 46/52
Design pressure MPa 4.15/1.5 4.15/1.5
Drainage water pipe diameter mm 27 38
Refrigerant piping Liquid side/ Gas side mm 9.52/15.88 9.52/19.05
Controller
Wired control Wired control
Operation temperature
16"30 16"30
Room temperature Cooling
18"32 18"32
Heating
15"27 15"27
Qty’per 20’ /40’ /40'HQ 128/264/264 66/132/154
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
7

48K 60K
TRANE Model 4MXD6548G1000AA 4MXD6560G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h 19,000 " 48,000 " 50,000 20,000 " 50,500 " 54,000
Capacity (min ~ nor ~ max)
W 5,567 " 14,064 " 14,650 5,860 " 14,800 " 15,822
Input W 4,642 4,884
EER W/W 3.03 3.03
Heating
Capacity (min ~ nor ~ max) Btu/h 19,000 " 48,500 " 50,300 20,100 " 52,600 " 58,000
Capacity (min ~ nor ~ max)
W 5,567 " 14,210 " 14,738 5,890 " 15,412 " 17,000
Input W 4,737 5,138
COP W/W 3.00 3.00
Indoor fan motor
Model
Y7S423C21 ZWK702B500025
Qty
1 1
Input W 280 375
Speed(Hi/Med/Lo) r/min 1260/1145/1100 1400/1300/1200
Indoor coil
Number of rows
4
3
Tube pitch(a)*row pitch(b) mm 21×13.3 21×13.3
Fin spacing mm 1.3 1.8
Fin type
Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm c17 / Inner grooved c17 / Inner grooved
Coil length * height * width mm 1001×294×39.9 1062×425×39.9
Number of circuits
10 5
Indoor air flow (Hi/Med/Lo) m 2090/1097/1792 2600/2200/1950
ESP Rated Pa 100 100
Range Pa 10-100 10-100
Indoor noise level (Hi/Med/Lo) dB(A) 49/47/44 52/47/42
Throttle type
In ODU In ODU
Indoor unit Dimension (WxDxH) mm 1140×710×275 1197×650×360 Packing(WxDxH) mm 1342×841×358 1345×770×390
Net/Gross weight kg 46/52 56/59
Design pressure MPa 4.15/1.5 4.15/1.5
Drainage water pipe diameter mm 38 38
Refrigerant piping Liquid side/ Gas side mm 9.52/19.05 9.52/19.05
Controller
Wired control Wired control
Operation temperature
℃
16"30 16"30
Room temperature
Cooling
℃
18"32 18"32
Heating
℃
15"27 15"27
Qty’per 20’ /40’ /40'HQ 66/132/154 60/125/150
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
8

18K 24K
TRANE Model 4MXX6518G1000AA 4MXX6524G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h 6,500 ~ 18,000 ~ 19,300 9,800 ~ 24,000 ~ 28,500
Capacity (min ~ nor ~ max) W 1,900 ~ 5,270 ~ 5,655 2,870 ~ 7030 ~ 8,350
Input W 1,612 2,099
EER W/W 3.27 3.35
Heating
Capacity (min ~ nor ~ max) Btu/h 10,000 ~ 18,300 ~ 20,000 10,200 ~ 24,500 ~ 29,400
Capacity (min ~ nor ~ max) W 2,930 ~ 5,362 ~ 5,860 2,990 ~ 7,175 ~ 8,615
Input W 1,675 2,242
COP W/W 3.20 3.20
Indoor fan
motor
Model ZWK511A800053 ZWK511A800054
Qty 1 1
Input W 90 260
Capacitor uF / /
Speed(Hi/Med/Lo) r/min 850/800/750 850/750/650
Indoor coil
Number of rows 2 2
Tube pitch(a)x row pitch(b) mm 21×18.186 21×18.186
Fin spacing mm 1.3 1.3
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm φ7 / Inner grooved φ7 / Inner grooved
Coil length x height x width mm 679×294×36.37 1007×294×36.37
Number of circuits 14 14
Indoor air flow(Hi/Med/Lo) m3/h 880/750/650/500 1250/1128/930
Indoor noise level (sound pressure)(Hi/Med/Lo) dB(A) 46/40/36 46/44/42
Throttle type In ODU In ODU
Indoor unit Dimension (WxDxH) mm 1000×680×230 1325×680×230 Packing (WxDxH) mm 1100×779×305 1425×779×305
Net/Gross weight kg 26/32 33.5/41.9
Design pressure MPa 4.15/1.5 4.15/1.5
Drainage water pipe diameter mm 25 25
Refrigerant
piping Liquid side/Gas side mm(inch) 6.35/12.7 6.35/15.88
Controller Remote control Remote control
Operation temperature °C 16~30 16~30
Room
temperature Cooling °C 18~32 18~32
Heating °C 15~27 15~27
Qty’per 20’ /40’ /40'HQ (indoor unit) 112/224/256 84/168/192
1

36K 48K
TRANE Model 4MXX6536G1000AA 4MXX6548G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Cooling
Capacity (min ~ nor ~ max) Btu/h 14,000 ~ 36,000 ~ 37,000 19,200 ~ 47,000 ~ 50,500
Capacity (min ~ nor ~ max) W 4,100 ~ 10,550 ~ 10,840 5,625 ~ 13,770 ~ 14,800
Input W 3,149 4,211
EER W/W 3.35 3.27
Heating
Capacity (min ~ nor ~ max) Btu/h 14,500 ~ 36,500 ~ 42,300 19,500 ~ 48,500 ~ 51,300
Capacity (min ~ nor ~ max) W 4,248 ~ 10,695 ~ 12,395 5,710 ~ 14,210 ~ 15,030
Input W 3,342 4,440
COP W/W 3.20 3.20
Indoor fan motor
Model ZWK511A800054 ZWK511B500030
Qty 1 1
Input W 120 150
Capacitor uF / /
Speed(Hi/Med/Lo) r/min 1050/950/900 1030/950/870
Indoor coil
Number of rows 2 2
Tube pitch(a)x row pitch(b) mm 21×18.186 21×18.186
Fin spacing mm 1.3 1.3
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm φ7 / Inner grooved φ7 / Inner grooved
Coil length x height x width mm 1007×294×36.37 1333×294×36.37
Number of circuits 7 7
Indoor air flow(Hi/Med/Lo) m3/h 1820/1750/1600 2150/1980/1800
Indoor noise level (sound pressure)(Hi/Med/Lo) dB(A) 52/49/46 52/49/46
Throttle type In ODU In ODU
Indoor unit Dimension (WxDxH) mm 1325×680×230 1650×680×230 Packing (WxDxH) mm 1425×779×305 1750×779×305
Net/Gross weight kg 33.5/41.9 41.8/49.5
Design pressure MPa 4.15/1.5 4.15/1.5
Drainage water pipe diameter mm 25 25
Refrigerant piping Liquid side/Gas side mm(inch) 9.52/19.05 9.52/19.05
Controller Remote control Remote control
Operation temperature °C 16~30 16~30
Room temperature Cooling °C 18~32 18~32
Heating °C 15~27 15~27
Qty’per 20’ /40’ /40'HQ (indoor unit) 84/168/192 63/133/152
2

12K 18K
TRANE Model 4TXK6512G1000AA 4TXK6518G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Max. input consumption W 2000 2500
Max. input current A 10 12.5
Compressor
Model ASD102RKQA6JT6B C-6RZ146H1AH
Type ROTARY ROTARY
Brand HITACHI SANYO
Capacity Btu/h
1211
14873
Input W 789 1000
Rated current(RLA) A 2.72 6.85
Locked rotor Amp(LRA) A 21.84 21.84
Thermal protector position INTERNAL INTERNAL
Refrigerant oil ml 320±20 350
Outdoor fan motor
Model RD-310-50-8A RD-310-50-8A
Qty 1 1
Input W 40 40
Speed r/min 850 900
Outdoor coil
Number of rows 1 2
Tube pitch(a)* row
pitch(b)
mm 21x18.186 21x18.186
Fin spacing mm 1.35 1.37
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm φ7 / Inner grooved φ7 / Inner grooved
Coil length * height * width
mm 780×504×18.186 822×504×36.37
Number of circuits 3 5
Outdoor noise level (sound pressure) dB(A)
5
56
Throttle type EEV EEV
Outdoor unit Dimension(WxDxH) mm 780×260×545 860×345×550
Packing(WxDxH) mm 905×336×594 939×394×590
Net/Gross weight kg 31/33 31/35
Refrigerant type/
Quantity Type R410A R410A
Charged volume kg 0.95 1.4
Design pressure MPa 4.15/1.5 4.15/1.5
Refrigerant piping Liquid side/ Gas side mm(inch) 6.35/9.52 6.35/12.7
Max. pipe length m 30 30
Max. difference in level m 10 10
Ambient
temperature Cooling 18
-
43 18
-
43
Heating
-15
-
24 -15
-
24
Qty’per 20’ /40’ /40'HQ Outdoor unit 126/261/261 108/216/216
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
3

24K
36K
TRANE Model 4TXK6524G1000AA 4TXK6536G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Max. input consumption W 3000 4500
Max. input current A 15 20.5
Compressor
Model SNB140FULMC SNB200FNMMC
Type ROTARY ROTARY
Brand MITSUBISHI ELECTRIC MITSUBISHI ELECTRIC
Capacity Btu/h 14880 21070
Input W 1310 1960
Rated current(RLA) A 4.4 6.7
Locked rotor Amp(LRA) A 18.4 /
Thermal protector position INTERNAL INTERNAL
Refrigerant oil ml 350 400
Outdoor fan motor
Model ZWK465B50503 EHDS82AAS
Qty
1 1
Input W 41 90
Speed r/min 900 700
Outdoor coil
Number of rows
2 2
Tube pitch(a)* row
pitch(b)
mm 21x18.186 21×18.186
Fin spacing mm 1.4 1.45
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm φ7 / Inner grooved φ7 / Inner grooved
Coil length * height * width
mm 795×566×36.37 940×714×36.37
Number of circuits
4 7
Outdoor noise level (sound pressure) dB(A) 59 58
Throttle type EEV EEV
Outdoor unit Dimension(WxDxH) mm 810×288×680 950×370×965
Packing(WxDxH) mm 1031×445×745 1050×450×1095
Net/Gross weight kg 42/47 83/89
Refrigerant type/
Quantity Type
R410A R410A
Charged volume kg 1.5 2.45
Design pressure MPa 4.15/1.5 4.15/1.5
Refrigerant piping Liquid side/ Gas side mm(inch) 9.52/15.88 9.52/19.05
Max. pipe length m 30 50
Max. difference in level m 10 20
Ambient
temperature Cooling
18~43 18~43
Heating
-15~24 -15~24
Qty’per 20’ /40’ /40'HQ Outdoor unit 78/145/145 52/106/106
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
4

48K
60K
TRANE Model 4TXK6548G1000AA 4TXK6560G1000AA
Power supply V-ph-Hz 220-1-60 220-1-60
Max. input consumption W 5500 6200
Max. input current A 25.5 28
Compressor
Model TNB306FWSMC MNB40F
Type ROTARY ROTARY
Brand MITSUBISHI ELECTRIC MITSUBISHI ELECTRIC
Capacity Btu/h 33800 44000
Input W 3065 4020
Rated current(RLA) A 9.48 15
Locked rotor Amp(LRA) A / /
Thermal protector position INTERNAL INTERNAL
Refrigerant oil ml 1070 1100
Outdoor fan motor
Model ZWK511B51006 "ZWK511B50004
SIC-71FW-F190-4"
Qty
2 2
Input W 100×2 140×2
Speed r/min 850 750
Outdoor coil
Number of rows
2 3
Tube pitch(a)* row
pitch(b)
mm 21×18.186 21×18.186
Fin spacing mm 1.4 1.45
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type
mm φ7 / Inner grooved φ7 / Inner grooved
Coil length * height * width
mm 970×1197×36.37 1005×1302×39.9
Number of circuits
12 12
Outdoor noise level (sound pressure) dB(A) 58 61
Throttle type EEV EEV
Outdoor unit Dimension(WxDxH) mm 948×340×1250 960×370×1350
Packing(WxDxH) mm 1095×410×1400 1090×480×1500
Net/Gross weight kg 104/112 106/120
Refrigerant type/
Quantity Type
R410A R410A
Charged volume kg 3.0 4.2
Design pressure MPa 4.15/1.5 4.15/1.5
Refrigerant piping Liquid side/ Gas side mm(inch) 9.52/19.05 9.52/19.05
Max. pipe length m 50 50
Max. difference in level m 20 20
Ambient
temperature Cooling °C 18~43 18~43
Heating °C -15~24 -15~24
Qty’per 20’ /40’ /40'HQ Outdoor unit 27/55/55 24/48/48
Remarks:1.The above design and specifications are subject to change without prior notice for product improvement.
5

60K
TRANE Model 4MXX6560G1000AA
Power supply V-ph-Hz 220-1-60
Cooling
Capacity (min
-
nor
-
max) Btu/h 21,000
-
54,000
-
58,000
Capacity (min
-
nor
-
max) W 6,150
-
15,820
-
17,000
Input W 4,883
EER W/W 3.24
Heating
Capacity (min
-
nor
-
max) Btu/h 21,100
-
55,000
-
58,300
Capacity (min
-
nor
-
max) W 6,180
-
16,115
-
17,080
Input W 5,036
COP W/W 3.20
Indoor fan motor
Model ZWK511B500030
Qty 1
Input W 150
Capacitor uF /
Speed(Hi/Med/Lo) r/min 1250/1020/870
Indoor coil
Number of rows 3
Tube pitch(a)x row pitch(b) mm 21×13.3
Fin spacing mm 1.3
Fin type Hydrophilic aluminium
Tube outside dia.and type mm φ7 / Inner grooved
Coil length x height x width mm 1333×294×39.9
Number of circuits 10
Indoor air flow(Hi/Med/Lo) m3/h 2350/1980/1800
Indoor noise level (sound pressure)(Hi/Med/Lo) dB(A) 52/49/46
Throttle type In ODU
Indoor unit Dimension (WxDxH) mm 1650×680×230 Packing (WxDxH) mm 1750×779×305
Net/Gross weight kg 46.8/54.5
Design pressure MPa 4.15/1.5
Drainage water pipe diameter mm 25
Refrigerant piping Liquid side/Gas side mm(inch) 9.52/19.05
Controller Remote control
Operation temperature °C 16
-
30
Room temperature Cooling °C 18
-
32
Heating °C 15
-
27
Qty’per 20’ /40’ /40'HQ (indoor unit) 63/133/152
6

2 . Dimension
2.1 Dimension -4MXC6518G1000AA
7

2.2 Dimension
-
4MXC6524G1000AA
181
Code Name
1
Gas pipe
2
Liquid pipe
3
Observe plate
4
Drain pipe
5
Air return grille
6
Air outlet
7
Drain soft pipe
(accessory)
8
Power supply inlet
9PQ line inlet
10
Fresh air inlet
11
Move eye( optional)
68
V
iew
A
840
10
9
Suspend
ing
bolt
4
-
M10
Ceiling hole 890mm
Gap between suspending rod 765mm
Lessthan100
Hoisting heightlessthan
600mm
©
600
Adjustable(0
-
360)
©
Ceiling hole 890mm
Gap between suspending rod 765mm
Decoration board 950mm
Drain pipe
connection
©
④
A
©
270
330
470
© ©
126
130
170
8
Decoration board 950mm
11
A
Model
A (mm)
4MXC6524G1000AA 246
8

181
Code
Name
1
Gas pipe
2
Liquid pipe
3
Observe plate
4
Drain pipe
5
Air return grille
6
Air outlet
7
Drain soft pipe
(accessory)
8
Power supply inlet
9
PQ line inlet
10
Fresh air inlet
11
Move eye( optional)
68
V
iew
A
840
10
9
Suspend
ing
bolt 4-M10
Ceiling hole 890mm
Gap between suspending rod 765mm
Lessthan100
Hoisting heightlessthan
600mm
©
600
Adjustable(0
-
360)
©
Ceiling hole 890mm
Gap between suspending rod 765mm
Decoration board 950mm
Drain pipe
connection
©
④
A
©
270
330
470
© ©
126
130
170
8
Decoration board 950mm
11
A
2.3 Dimension -4MXC6536G1000AA
Model
A (mm)
4MXC6536G1000AA 246
9

181
Code Name
1
Gas pipe
2
Liquid pipe
3
Observe plate
4
Drain pipe
5
Air return grille
6
Air outlet
7
Drain soft pipe
(accessory)
8
Power supply inlet
9PQ line inlet
10
Fresh air inlet
11 Move eye( optional)
68
V
iew
A
840
10
9
Suspend
ing
bolt
4
-
M10
Ceiling hole 890mm
Gap between suspending rod 765mm
Lessthan100
Hoisting heightlessthan
600mm
©
600
Adjustable(0
-
360)
©
Ceiling hole 890mm
Gap between suspending rod 765mm
Decoration board 950mm
Drain pipe
connection
©
④
A
©
270
330
470
© ©
126
130
170
8
Decoration board 950mm
11
A
2.4 Dimension -4MXC6548G1000AA
Model A (mm)
4MXC6548G1000AA 288
10

181
Code Name
1
Gas pipe
2
Liquid pipe
3
Observe plate
4
Drain pipe
5
Air return grille
6
Air outlet
7
Drain soft pipe
(accessory)
8
Power supply inlet
9
PQ line inlet
10
Fresh air inlet
11
Move eye( optional)
68
V
iew
A
840
10
9
Suspend
ing
bolt 4-M10
Ceiling hole 890mm
Gap between suspending rod 765mm
Lessthan100
Hoisting heightlessthan
600mm
©
600
Adjustable(0
-
360)
©
Ceiling hole 890mm
Gap between suspending rod 765mm
Decoration board 950mm
Drain pipe
connection
©
④
A
©
270
330
470
© ©
126
130
170
8
Decoration board 950mm
11
A
2.5 Dimension -4MXC6560G1000AA
Model A (mm)
4MXC6560G1000AA 288
11
