TransCore 1422E User manual

1422E Reader
User Guide
Trusted Transportation Solutions
16-0058-001 Rev A5 9/16
The AI1422E Reader User Guide provides information necessary for
interfacing the AI1422E Reader System to a host computer system.
Purpose of This Guide
This user guide provides information for interfacing the AI1422E Reader System
with a host computer system. This guide provides on-site test procedures useful in
troubleshooting any problems encountered after installation. Command codes, which
allow the user to configure the reader system for communicating with the host computer,
are discussed as is ASCII character conversion to TransCore 6-bit character codes.
Intended Audience
The intended audience for the AI1422E Reader User Guide are skilled personnel
(including trainedengineers and technicians). These people are involved in the design,
specification, and installation of AI1422E Reader Systems.

User Guide
TransCore Proprietary
ii
Information in this document is subject to change and does not represent a commitment on the part of
TransCore, LP.
© 2016 TransCore, LP. All rights reserved. TRANSCORE, AMTECH, EGO, and ENCOMPASS are registered
trademarks and are used under license. All other trademarks are the property of their respective owners.
Contents are subject to change. Printed in the U.S.A.
For further information, contact:
TransCore
8600 Jeerson StreetNE
Albuquerque, New Mexico 87113 USA
TransCore Technical Support
Web: www.transcore.com/rfidsupport
Phone: [phone]
Lantronix ® Technical Support (Ethernet Support)
Web: www.lantronix.com/support/
Phone: [phone]

AI1422E Reader
TransCore Proprietary iii
WARNING TO USERS IN THE UNITED STATES
FEDERAL COMMUNICATIONS COMMISSION FCC
LOCATION AND MONITORING SERVICE STATEMENT
47 CFR §90.351
NOTE: The user is required to obtain a Part 90 site license from the Federal Communications
Commission (FCC) to operate this radio frequency identification (RFID) device in the United States.
The FCC ID number is FIHAI1422E. Access the FCC website at www.fcc.gov to obtain additional
information concerning licensing requirements.
NOTE: Users in all countries should check with the appropriate local authorities for licensing
requirements.
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
47 CFR §15.105A
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate RF energy and may cause harmful
interference to radio communications if not installed and used in accordance with the instruction
manual. Operating this equipment in a residential area is likely to cause harmful interference, in
which case, depending on the laws in eect, the user may be required to correct the interference
at their own expense.
NO UNAUTHORIZED MODIFICATIONS
47 CFR §15.21
CAUTION: This equipment may not be modified, altered, or changed in any way without
permission. Unauthorized modification may void the equipment authorization from the FCC and will
void the warranty.
USE OF SHIELDED CABLES AND GROUNDING
47 CFR §15.27A
NOTE: Shielded cables and earth grounding the unit is recommended for this equipment to comply
with FCC regulations.
TRANSCORE, LP
USA

User Guide
TransCore Proprietary
iv
AVERTISSEMENT À L’ATTENTION DES
UTILISATEURS AUX ÉTATSUNIS
DÉCLARATION 47 CFR §90.351 CODE DES
RÈGLEMENTS FÉDÉRAUX DE LA FEDERAL
COMMUNICATIONS COMMISSION FCC SUR LES
SERVICES DE LOCALISATION ET DE CONTRÔLE
REMARQUE : L’utilisateur est tenu d’obtenir une licence d’utilisation sur site Partie 90 auprès de
la Federal Communications Commission (FCC) afin de pouvoir utiliser ce dispositif RFID (radio-
identification) aux États-Unis ou au Canada. Le numéro d’identification de la FCC est FIHAI1422E.
Pour obtenir de plus amples informations concernant les exigences relatives aux licences, prière
de consulter le site web de la FCC à www.fcc.gov.
REMARQUE : Il est recommandé à tous les utilisateurs, quel que soit leur pays, de consulter les
autorités locales compétentes sur les exigences de licence.
DÉCLARATION 47 CFR §15.105A DE LA FCC SUR
LES INTERFÉRENCES DES FRÉQUENCES RADIO
REMARQUE : Cet appareil a été testé et déclaré conforme à la catégorie d’un appareil numérique
de classe A en accord avec la partie 15 des directives de la FCC. Ces normes visent à assurer
une protection raisonnable contre les interférences nuisibles lorsque l’appareil est utilisé dans
un environnement commercial. Cet appareil génère, utilise et peut émettre de l’énergie RF et
peut être à l’origine d’interférences nuisibles aux communications radio s’il n’est pas installé et
utilisé en suivant les directives du manuel d’instructions. Si cet appareil est utilisé dans une zone
résidentielle, il est probable qu’il cause des interférences nuisibles. Dans ce cas, l’utilisateur
pourrait être amené à remédier aux interférences à ses propres frais, selon les lois du pays en
vigueur.
AUCUNE MODIFICATION NON AUTORISÉE
47 CFR §15.21
MISE EN GARDE : Il est interdit de modifier, d’altérer ou d’apporter des changements à cet appareil
de quelque manière que ce soit sans autorisation. Toute modification non autorisée peut annuler
l’autorisation d’utilisation accordée par la FCC et annulera la garantie.
UTILISATION DE CÂBLES BLINDÉS ET MISE À LA TERRE
47 CFR §15.27A
REMARQUE : Il est recommandé d’utiliser des câbles blindés et une mise à la terre avec cet
appareil afin de répondre aux réglementations de la FCC
TRANSCORE, LP
ÉTATSUNIS

AI1422E Reader
TransCore Proprietary v
WARNING TO USERS IN CANADA
INDUSTRY CANADA IC INDUSTRY CANADA’S RADIO STANDARD SPECIFICATIONS RSS137 LOCATION
AND MONITORING SERVICE IN THE BAND 902928 MHZ SECTION 2.1
NOTE: The user is required to obtain a license from Industry Canada (IC), to operate this radio
frequency identification (RFID) device in Canada. The IC ID number is 1584A-AI1422E, access the
IC website at www.ic.gc.ca to obtain additional information concerning licensing requirements.
Industry Canada (IC) Industry Canada’s Radio Standard Specifications General Requirements
(RSS-GEN) for Compliance of Radio Apparatus Statement Section 8.4
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
1 ) This device may not cause interference; and
2 ) This device must accept any interference, including interference that may cause
undesired operation of the device.
AVERTISSEMENT AUX UTILISATEURS AU CANADA
INDUSTRIE CANADA IC INDUSTRIE CANADA RADIO STANDARD SPECIFICATIONS CNR137
EMPLACEMENT ET SERVICE DE SURVEILLANCE DANS LA BANDE 902928 MHZ, SECTION 2.1
Remarque : L’utilisateur est tenu d’obtenir une licence d’Industrie Canada (IC), afin d’exploiter
ce dispositif d’identification par radiofréquence au Canada. Le numéro d’identification d’IC est
1584A-AI1422E. Pour obtenir de plus amples informations concernant les exigences relatives aux
licences, prière de consulter le site web de d’IC à www.ic.gc.ca .
Radio Standard Spécifications exigences générales Industrie Canada (IC) Industrie Canada
(CNR-GEN) pour s’acquitter du Radio appareil déclaration article 8.4
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
1 ) l'appareil ne doit pas produire de brouillage, et
2 ) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.

User Guide
TransCore Proprietary
vi
RADIO FREQUENCY HEALTH LIMITS FOR AI1422 READER
USING AN EXTERNAL ANTENNA IN FREQUENCY BAND
OF 902.25 TO 903.75 AND 910.00 TO 921.50 MHZ
Several agencies (OSHA, FCC, IC) have environmental guidelines regulating maximum permissible
exposure (MPE) or “safe” exposure levels that this product falls under. To ensure that proper safety
guideline for the end users of this product, i.e. Occupational (Controlled) and General Population/
Public (Uncontrolled), the recommended levels for each of the agencies are presented in the next
sections with TransCore’s recommendations for safety in the last section.
OSHA (Occupational Safety and Health Administration)
OSHA (an agency of The United States of America) legislates in the Code of Federal Regulations
(CFR) Title 29 Part 1910 Subpart G 1910.97 titled “Nonionizing radiation”, a maximum safe exposure
limit of 10 milliwatts per square centimeter (mW/cm2) during any 0.1-hour period (i.e. 6 minutes).
Using the frequency (in the middle of the band of operation of this equipment) of 915 MHz and the
highest antenna gain that this equipment is certified for use in a final installation, the minimum safe
distance was calculated to be 8in (20cm).
FCC (Federal Communication Commission)
FCC (an agency of The United States of America) legislates in the Code of Federal Regulations
(CFR) Title 47 Chapter I Subchapter A Part 1 Subpart I Section 1.1310 titled “Radiofrequency radiation
exposure limits” that the maximum permissible exposure (MPE) is the following:
Occupational/Controlled Exposure
Power density = frequency(in MHz)/300 mW/cm2with an Averaging time of 6 Min
General Population/Uncontrolled Exposure
Power density = frequency(in MHz)/1500 mW/cm2 with an Averaging time of 30 Min
Using the frequency (in the middle of the band of operation of this equipment) of 915MHz and the
highest antenna gain that this equipment is certified for use in a final installation, the minimum
safe distance was calculated. The MPE minimum distances are 14in (36cm) for the Occupational/
Controlled environment, and 31.5in (80.5cm) for the General Population/Uncontrolled environment.
Industry Canada (Innovation, Science and Economic Development Canada)
Industry Canada (a Department of the Government of Canada) sets out the requirements in Radio
Standards Specification RSS-102, Issue 5 guidelines, recommending a maximum safe

AI1422E Reader
TransCore Proprietary vii
Occupational/Controlled Environment
Agency Power Density (mW/cm2) MPE minimum distance Time (min)
in cm
OSHA 10 8 20 6
FCC 3.05 14 36 6
IC 1.95 18 45 6
General Population/Public/Uncontrolled Environment
Agency Power Density (mW/cm2) MPE minimum distance Time (min)
In cm
OSHA 10 8 20 6
FCC 0.61 31.5 80 30
IC 0.28 47 120 6
power density in W/m2. Thus, the maximum permissible exposure for general population/
uncontrolled exposure at 915MHz is 2.77 W/m2. The average time is 6 minutes. The maximum
permissible exposure (MPE) is the following:
Controlled Environment
Power density = 0.6455*frequency(in MHz)0.5 W/m2with a Reference Period time of 6 Min
General Public/Uncontrolled Environment
Power density = 0.02619*frequency(in MHz)0.6834 W/m2with a Reference Period time of 6 Min
Using the frequency (in the middle of the band of operation of this equipment) of 915MHz and the
highest antenna gain that this equipment is certified for use in a final installation, the minimum
safe distance was calculated. The MPE minimum distances are 18in (45cm) for the Controlled
environment and 47in (120cm) for the General Public/Uncontrolled environment.
TransCore Recommendation on MPE (Maximum Permissible Exposure)
The calculated power densities and MPE distance for each of the agencies respective to the
environment is shown below.

User Guide
TransCore Proprietary
viii
With the equipment installed and running at the maximum transmit power of 2.0W (33dBm), 0
dB transmit attenuation, using the highest gain antenna that the equipment is certified for, the
recommendation for each of the operation environments is as follows:
1 ) The antenna should be installed at least 47in (120cm) from the General Population/
Public i.e. Uncontrolled Environment.
2 ) Maintenance personnel (i.e. Occupational/Controlled Environment) must remain at least
18in (45cm) from the antenna and limit their time in the environment to 6 minutes when
the system is operating.

AI1422E Reader
TransCore Proprietary ix
LIMITES D’EXPOSITION AUX RADIOFRÉQUENCES POUR LE LECTEUR AI1422
UTILISANT UNE ANTENNE EXTERNE SUR LA BANDE
DE FRÉQUENCES DE 902.25 À 903.75 ET DE 910.00 À 921.50 MHZ
Plusieurs organismes (OSHA, FCC, IC) publient des directives environnementales qui
recommandent des limites d’exposition maximale autorisée (normes MPE) ou des niveaux
d’exposition «sûrs» auxquels cet appareil se conforme. Pour faire en sorte que chaque utilisateur
final ait connaissance des directives de sécurité qui le concerne, que ce soit dans son travail
(accès contrôlé) ou pour la population générale/le grand public (accès non contrôlé), TransCore
présente les niveaux recommandés par chaque organisme dans ses recommandations sécuritaires
détaillées dans la dernière section.
OSHA (Occupational Safety and Health Administration)
Dans le Code des réglementations fédérales (CFR), Titre 29, Partie 1910, Sous-partie G 1910.97,
intitulée «Nonionizing radiation» (Rayonnements non ionisants), l’OSHA (organisme américain)
recommande un plafond d’exposition maximale de 10 milliwatts par centimètre carré (mW/cm2)
pendant une période de 0,1 heure (soit 6 minutes). En utilisant la fréquence de 915 MHz (milieu de
la bande de fréquences de cet appareil) et le gain d’antenne maximal pour lequel cet appareil a
reçu une certification d’utilisation dans une installation finale, la distance minimale sécuritaire est
de 20 cm (8 po).
FCC (Federal Communication Commission)
Dans le Code des réglementations fédérales (CFR), Titre 47, Chapitre I, Sous-chapitre A, Partie
1, Sous-partie I, Section 1.1310 intitulée «Radiofrequency radiation exposure limits» (Limites
d’exposition aux rayonnements de radiofréquence), la FCC (organisme américain) établit les limites
d’exposition maximale autorisée (normes MPE) comme suit :
Exposition professionnelle/contrôlée
Densité de puissance = fréquence (en MHz)/300 mW/cm2avec une durée moyenne de 6 min.
Exposition de la population générale/non contrôlée
Densité de puissance = fréquence (en MHz)/1500 mW/cm2avec une durée moyenne de 30 min.
En utilisant la fréquence de 915 MHz (milieu de la bande de fréquences de cet appareil) et le
gain d’antenne maximal pour lequel cet appareil a reçu une certification d’utilisation dans une
installation finale, la distance minimale sécuritaire est la suivante : les distances MPE minimales
sont de 36 cm (14 po) pour l’environnement professionnel/contrôlé et de 80,5 cm (31,5 po) pour la
population générale/environnement non contrôlé.

User Guide
TransCore Proprietary
x
Industrie Canada (Innovation, Sciences et Développement économique Canada)
Le Cahier des charges sur les normes radioélectriques 102, 5eédition, d’Industrie Canada (un
ministère du Gouvernement du Canada) établit des recommandations pour une densité de
puissance maximale sécuritaire en W/m2. Ainsi, l’exposition maximale admissible pour la population
générale/non contrôlée à 915 MHz est calculée à 2,77 W/m2. La durée moyenne est de 6 minutes.
Les limites d’exposition maximale autorisée (normes MPE) sont les suivantes :
Environnement contrôlé
Densité de puissance = 0,6455*fréquence (en MHz)0,5 W/m2avec une durée de référence de 6 min.
Grand public/environnement non contrôlé
Densité de puissance = 0,02619*fréquence (en MHz)0,6834 W/m2avec une durée de référence de 6 min.
En utilisant la fréquence de 915 MHz (milieu de la bande de fréquences de cet appareil) et le
gain d’antenne maximal pour lequel cet appareil a reçu une certification d’utilisation dans une
installation finale, la distance minimale sécuritaire est la suivante : les distances MPE minimales
sont de 45 cm (18 po) pour l’environnement professionnel/contrôlé et de 120 cm (47 po) pour le
grand public/environnement non contrôlé.
Recommandations de TransCore sur les limites d’exposition maximale autorisée (normes MPE)
Les densités de puissance et la distance MPE calculées par chaque organisme pour un envi-
ronnement donné sont présentées ci-dessous.
Exposition professionnelle/environnement contrôlé
Organisme Densité de puissance (mW/
cm2)
Distance MPE minimale Durée (en
min.)
po cm
OSHA 10 8 20 6
FCC 3,05 14 36 6
IC 1,95 18 45 6
Population générale/environnement non contrôlé
Organisme Densité de puissance (mW/
cm2)
Distance MPE minimale Durée (en
min.)
po cm
OSHA 10 8 20 6
FCC 0,61 31,5 80 30
IC 0,28 47 120 6

AI1422E Reader
TransCore Proprietary xi
Avec l’appareil installé et fonctionnant à la puissance de transmission maximale de 2,0 W (33 dBm),
0 dB d’atténuation de transmission, et en utilisant le gain d’antenne maximal pour lequel l’appareil
a reçu une certification, les recommandations pour chaque environnement d’exploitation sont les
suivantes :
1 ) L’antenne devrait être installée à au moins 120 cm (47 po) de la population générale/du
grand public, c’est-à-dire d’un environnement non contrôlé.
2 ) Le personnel d’entretien (c’est-à-dire dans un environnement professionnel/contrôlé)
doit rester à au moins 45 cm (18 po) de l’antenne et limiter son temps d’exposition à 6
minutes lorsque l’appareil est en fonctionnement.

AI1422E Reader
TransCore Proprietary i
Table of Contents
Purpose of This Guide ............................................. i
Intended Audience ..................................................i
Before You Begin
Before You Begin ............................................ 1-2
Licensing Requirements.......................................... 1-4
System Overview
System Overview .............................................2-2
Transponder Interrogator.........................................2-3
Interface Connections
Description of AI1422E Reader System .............................3-2
Antenna Interface ...............................................3-2
Interface Selection Switch ........................................3-2
Main RS–232 Interface...........................................3-2
Aux RS–232 Interface ...........................................3-3
RS–422 Interface ...............................................3-3
Ethernet (M12) Interface..........................................3-3
Customer I/O Interface...........................................3-4
Installation Instructions
General ........................................................4-2
Mechanical ....................................................4-2
Electrical .......................................................4-2
Power .........................................................4-2
Assembling the Power Connector .................................4-2
Installing Wires into Connector....................................4-5
System Test Procedures
System Test Procedures..........................................5-2
Required Tools and Equipment ....................................5-2
Testing Basic Operation ..........................................5-2
Reading the Tag.................................................5-3
Communications Protocols

User Guide
TransCore Proprietary
ii
Communications Protocols .......................................6-2
Basic Protocol ..................................................6-2
Error Correcting Protocol.........................................6-3
Data Inquiry Protocol ............................................6-3
Command Codes
Command Codes................................................7-2
Operating Modes ...............................................7-2
Command List ..................................................7-3
Reader Mode Control — Command Group 0 ........................7-4
Communications Port Control — Command Group 1..................7-4
Command Group 2 ..............................................7-6
Append Information — Command Group 3..........................7-7
ID Filtering — Command Group 4..................................7-9
Reader Status — Command Group 5 .............................. 7-15
Reader Control Functions — Command Group 6....................7-25
Auxiliary Reader Control — Command Group 8 .....................7-36
Troubleshooting and Maintenance
Required Tools and Equipment ....................................8-2
Troubleshooting ................................................8-2
Error Messages .................................................8-4
AI1422E Reader Repair...........................................8-5
Technical Support ...............................................8-5
Character Conversion
Appendix A.....................................................A-2
Technical Specifications
Appendix B.....................................................B-2
Lantronix® Ethernet Module Configuration
Appendix C.....................................................C-1

AI1422E Reader
TransCore Proprietary iii
List of Figures
Figure 2 – 1 Typical Reader System Configuration. . . . . . . . . 2-2
Figure 2 – 2 Antenna-to-Tag Centerline Tolerance . . . . . . . . 2-5
Figure 3 – 1 Sample Front Panel of an AI1422E Reader . . . . . . 3-2
Figure 3 – 2 RS-232, DE09 Inerface Connector Pin-outs . . . . . 3-3
Figure 3 – 3 Customer I/O Interface Pin-outs . . . . . . . . . . . 3-4
Figure 5 – 1 Power Source Connections . . . . . . . . . . . . . . 5-2
Figure B – 1 AI1422E Reader System Specifications . . . . . . . . B-2
Figure B – 1 AI1422E Reader Mechanical Dimensions. . . . . . . B-3

User Guide
TransCore Proprietary
iv
List of Tables
Table 1 – 1 Overview of Contents ................................................................................................1-2
Table 1 – 2 Conventions used in this manual...........................................................................1-3
Table 7 – 1 Select Baud Rate Commands................................................................................. 7-5
Table 7 – 2 Select Stop Bits Commands .................................................................................. 7-5
Table 7 – 3 Select Parity Commands......................................................................................... 7-6
Table 7 – 4 Append Time and Date Commands.................................................................... 7-8
Table 7 – 5 Append Auxiliary Information Commands........................................................ 7-8
Table 7 – 6 Unique ID Code Criteria......................................................................................... 7-10
Table 7 – 7 Select Valid Code Commands and Frames .......................................................7-11
Table 7 – 8 Open/Closed Conditions for Output Status...................................................... 7-19
Table 7 – 9 Open/Closed Conditions for Output Status (IAG Applications)................... 7-19
Table 7 – 10 Open/Closed Conditions for Input Status........................................................ 7-19
Table 7 – 11 Output Control Commands ..................................................................................7-27
Table 7 – 12 RF Control Commands ........................................................................................7-28
Table 7 – 13 RF Attenuation Command Variables.................................................................7-28
Table 7 – 14 Select RF Operating Frequency Commands ..................................................7-30
Table 7 – 15 Output Pulse Duration Commands ..................................................................7-32
Table 7 – 16 Presence Without Tag Report Commands..................................................... 7-33
Table 7 – 17 RF Control Algorithm Commands ..................................................................... 7-33
Table 7 – 18 Timeout Period Values.......................................................................................... 7-34
Table 7 – 19 Input Inversion Options ........................................................................................7-35
Table 7 – 20 Input Status Change Report Options.............................................................. 7-37
Table 8 – 21 Error Messages........................................................................................................ 8-4
Table A – 22 TransCore 6-Bit-Per-Character Conversion....................................................A-2

Before You Begin
1

User Guide
TransCore Proprietary
1-2
Before You Begin
Guide Topics
This chapter presents an overview of the AI1422 Reader User Guide. Table 1 – 1
describes the contents of each chapter.
Table 1 – 1 Overview of Contents
Chapter 1 – Before You Begin
Describes the purpose, intended audience,
guide topics, related documentation, document
conventions, and licensing requirements
Chapter 2 – System Overview
Provides an overview of the AI1422E Reader
System’s features, options, supported tag
descriptions and tag mounting primer, and
accessories
Chapter 3 – Interface Connections Describes the AI1422E Reader System interface
connectors and identifies their primary functions
Chapter 4 – Installation
Instructions
Describes installation of the AI1422E Reader
System
Chapter 5 – System Test
Procedures
Provides testing procedures that the user can
use to fine-tune the AI1422E Reader System
Chapter 6 – Communications
Protocols
Describes the communications protocols for the
AI1422E Reader
Chapter 7 – Command Codes
Discusses the host-transmitted commands
that are used to control the AI1422E Reader
configuration and operation
Chapter 8 – Troubleshooting and
Maintenance
Provides troubleshooting indications and
maintenance procedures that are used to keep
the AI1422E Reader System operating
Appendix A – Character
Conversion
Provides TransCore 6-bit-per-character
conversions from the standard ASCII character
set
Appendix B – Technical
Specifications
Provides the product specifications
Appendix C – Lantronix® Tech
Support
Provides information on the Lantronix Ethernet
Module Configuration.

AI1422E Reader
TransCore Proprietary 1-3
Typographical Conventions
Table 1 – 2 lists the conventions used in thismanual.
Table 1 – 2 Conventions used in this manual
Convention Indication
This procedure might cause harm to the equipment
and/or the user.
Concerns about a procedure
Code
Code, including keywords and variables within text and
as separate paragraphs, and user-defined program
elements within text appear in courier typeface.
Dialog Box Title Title of a dialog box as it appears on screen
Function
Start with the characters, G4, and are in mixed case
with no underscores, and include parentheses after the
name, as in G4FunctionName().
Menu Item Appears on a menu. Capitalization follows the interface.
Note
Auxiliary information that further clarifies the current
discussion. These important points require the user’s
attention. The paragraph is in italics and the word Note
is boldface.
NUL Zero-value ASCII character or a zero-value byte
NULL
Zero-value pointers. Null-terminated string refers to
strings of printable ASCII characters with a zero-value
byte placed in memory directly after the last printable
character of the string.

User Guide
TransCore Proprietary
1-4
Licensing Requirements
To operate a radio frequency (RF) system in a given country, the user must first obtain
permission from the regulatory agency that controls radio operations in that country. Most
countries require type and safety approval, as well as licensing for RF transmitters. Users in
all countries should check with the appropriate local authorities for licensing requirements.
U.S. Licensing
This AI1422E Reader System requires an FCC Part 90 license to operate in the U.S. The
authorized frequency bands in the U.S. are 902 to 904 MHz and 909.75 to 921.75 MHz.
The user is responsible for filing the FCC license according to FCC regulations. Access
the FCC Web site at www.fcc.gov/Forms/Form601/601.html or at wireless.fcc.gov/index.
htm?job=online_filing to obtain additional information concerning licensing requirements.
An FCC license provides the user with the legal authorization to operate the RFID
systems on the licensed frequencies at the site specified in the license. Only an
authorized installer or service technician can set the frequency for the AI1422E Reader
System to that specified in the FCC site license.
The FCC license also provides the user with protection and authorization to maintain
the system should any other RFID be used in the licensed area after the AI1422E Reader
System is installed.

AI1422E Reader
TransCore Proprietary 1-5
