Transition Networks SBFTF1011-260 User manual

* Typical maximum cable distance.
Actual distance is dependent upon the
physical characteristics of the network
installation.
Installation . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . .4
Cable Specifications . . . . . . . . . . .7
Technical Specifications . . . . . . . .9
Troubleshooting . . . . . . . . . . . . .10
Contact Us . . . . . . . . . . . . . . . . .11
Compliance Information . . . . . . .12
SBFTF10xx-26x
Stand Alone Media Converter
User’s Guide
• 10/100 Bridging (4-Port)
• Copper to Fiber
• 10Base-T/100Base-TX to 100Base-FX
The SBFTF10xx-26x 4-port Ethernet/Fast Ethernet bridging media converter
connects 10Base-T Ethernet and/or 100Base-TX Fast Ethernet twisted-pair copper
network devices to network devices on a 100Base-FX Fast Ethernet fiber network.
Part Number Copper
10Base-T/100Base-TX
Duplex Fiber-Optic
100Base-FX
SBFTF1011-260 RJ-45 (4 ports)
100 m (328 ft)*
ST, 1300 nm multimode
2 km (1.2 miles)*
SBFTF1013-260 RJ-45 (4 ports)
100 m (328 ft)*
SC, 1300 nm multimode
2 km (1.2 miles)*
SBFTF1014-260 RJ-45 (4 ports)
100 m (328 ft)*
SC, 1310 nm single mode
20 km (12.4 miles)*
SBFTF1015-260
(long haul)
RJ-45 (4 ports)
100 m (328 ft)*
SC, 1310 nm single mode
40 km (24.8 miles)*
SBFTF1016-260
(extra long haul)
RJ-45 (4 ports)
100 m (328 ft)*
SC, 1310 nm single mode
60 km (37.2 miles)*
SBFTF1017-260
(long wavelength)
RJ-45 (4 ports)
100 m (328 ft)*
SC, 1550 nm single mode
80 km (49.7 miles)*

2
SBFTF10xx-26x
* Typical maximum cable distance. Actual distance is dependent upon the
physical characteristics of the network. (TX) = transmit (RX) = receive
** SBFTF1029-260 and -261 are intended to be installed in the same network
where one is the local converter and the other is the remote converter.
*** SBFTF1029-262 and -263 are intended to be installed in the same network
where one is the local converter and the other is the remote converter.
Part Number Copper Simplex Fiber-Optic
SBFTF1029-260 ** RJ-45 (4 ports)
100 m (328 ft)*
SC, 1310 nm (TX)/1550 nm (RX)
single mode, 20 km (12.4 miles)*
SBFTF1029-261 ** RJ-45 (4 ports)
100 m (328 ft)*
SC, 1550 nm (TX)/1310 nm (RX)
single mode, 20 km (12.4 miles)*
SBFTF1029-262 *** RJ-45 (4 ports)
100 m (328 ft)*
SC, 1310 nm (TX)/1550 nm (RX)
single mode, 40 km (24.8 miles)*
SBFTF1029-263 *** RJ-45 (4 ports)
100 m (328 ft)*
SC, 1550 nm (TX)/1310 nm (RX)
single mode, 40 km (24.8 miles)*
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Installation
Connect the Twisted-Pair Copper Cable
1. Locate or build IEEE 803.2™ compliant 10Base-T or 100Base-TX cables
with RJ-45 connectors installed at both ends.
2. Connect the RJ-45 connector at one end of the cable to the RJ-45 port on
the SBFTF10xx-26x media converter.
3. Connect the RJ-45 connector at the other end of the cable to the RJ-45
port on the other device (switch, workstation, etc.).
NOTE: The AutoCross feature allows either MDI (straight-through) or MDI-X
(crossover) cable connections to be configured automatically, according to the
network conditions.
RJ-45 port
on the other device
(switch, work station, etc.)
RJ-45 port
on the media
converter
3
[email protected] -- Click the “Transition Now” link for a live Web chat.
Installation - Continued
Connect the Fiber Cable
Set the FX DUPLEX switch
•Up (half-duplex) - The fiber cable distances are
constrained by the 512-Bit Rule (see page 8).
•Down (full-duplex) - The fiber cable distances are
constrained by the cable requirements (see pages
1 and 2).
Install the Fiber Cable
1. Locate or build IEEE 803.2™ compliant 100Base-FX fiber cable with
male, two-stranded TX to RX connectors installed at both ends.
2. Connect the fiber cables to the SBFTF10xx-26x as described:
• Connect the male TX cable connector to the female TX port.
• Connect the male RX cable connector to the female RX port.
3. Connect the fiber cables to the other device (another media converter,
hub, etc.) as described:
• Connect the male TX cable connector to the female RX port.
• Connect the male RX cable connector to the female TX port.
Power the Media Converter
NOTE: The external power supply provided with this product is UL listed by
the power supply’s manufacturer.
1. Connect the barrel connector on the power adapter to the media
converter’s power port (located on the back of the media converter).
2. Connect the power adapter plug to AC power.
3. Verify that the media converter is powered by observing the illuminated
LED power indicator light.
For DC power, consult the user’s guide for the Transition Networks SPS1872-
xx DC external power supply for powering the media converter.
Connect the fiber cable
to the media converter
as shown.
Connect the fiber cable
to the other device
(media converter,
hub, etc.) as shown
RX
TX
RX
TX
FX DUPLEX
Full
Half

4
SBFTF10xx-26x
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Operation
Status LEDs
Use the status LEDs to monitor the media converter and the network
connections.
P(ower) On = Connection to external AC or DC power.
L(i)NK On = Fiber link connection.
F(ull) D(uplex) On = Full-duplex connection on the fiber link.
Off = Half-duplex connection on the fiber link.
ACT(ivity) Flashing = Fiber network activity.
The Duplex/Link and Speed LEDs are integrated into each of the RJ-45 ports
and are used to monitor each of the twisted-pair copper network connections.
Duplex/Link LED
Amber = A link on the half-duplex twisted-pair copper link.
Flashing Amber = Activity on the half-duplex copper link.
Green = A link on the full-duplex twisted-pair copper link.
Flashing Green = Activity on the full-duplex copper link.
Speed LED
Amber = 10 Mb/s operation.
Green = 100 Mb/s operation.
100Base-FX
P LNK
FD ACT
FX DUPLEX
Full
Half
10/100Base-TX
1 2 3 4
Duplex/Link Speed
5
[email protected] -- Click the “Transition Now” link for a live Web chat.
Operation -- Continued
Product Features
Rate Conversion
The SBFTF10xx-26x media converter allows connection of 10Mb/s terminal
devices on a 10Base-T legacy Ethernet copper network to 100Mb/s terminal
devices on a 100Base-TX Fast Ethernet copper network and/or to 100Mb/s
terminal devices on a 100Base-FX Fast Ethernet fiber network.
Congestion Reduction
The SBFTF10xx-26x media converter does not forward collision signals or
error packets from one collision domain to another, improving baseline
network performance. In addition, the media converter filters packets
destined for local devices, also reducing network congestion.
Full-Duplex Network
In a full-duplex network, maximum cable lengths are determined by the type
of cables that are used. See pages 1 and 2 for the cable specifications for the
different SBFTF10xx-26x models.
The 512-Bit Rule does not apply in a full-duplex network.
Half-Duplex Network (512-Bit Rule)
In a half-duplex network, the maximum cable lengths are determined by the
round trip delay limitations of each Fast Ethernet collision domain. (A
collision domain is the longest path between any two terminal devices, e.g. a
terminal, switch, or router.)
The 512-Bit Rule determines the maximum length of cable permitted by
calculating the round-trip delay in bit-times (BT) of a particular collision
domain. If the result is less than or equal to 512 BT, the path is good.
For more information on the 512-Bit Rule, see the white paper titled
“Collision Domains” on the Transition Networks website at:
www.transition.com.

6
SBFTF10xx-26x
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Operation -- Continued
Product Features -- Continued
Auto-Negotiation
The Auto-Negotiation feature allows the SBFTF10xx-26x media converter to
automatically configure itself to achieve the best possible mode of operation
over a link. The media converter broadcasts its speed (10 Mb/s, 100 Mb/s,
etc.) and duplex capabilities (full or half) to the other devices and negotiates
the best mode of operation. Auto-Negotiation allows quick and easy
installation because the optimal link is established automatically. No user
intervention is required to determine the best mode of operation.
AutoCross™
AutoCross feature allows either straight-through (MDI) or crossover (MDI-X)
copper cables to be used when connecting to 100Base-TX devices. AutoCross
determines the characteristics of the connection and automatically configures
the unit to link up, regardless if the copper cable is MDI or MDI-X
configuration.
Pause
The Pause feature is used to temporarily suspend data transmission in order to
relieve buffer congestion. If a media converter needs some time to clear
network congestion, it will send a pause signal to the media converter at the
other end, which will wait a predetermined amount of time before re-
transmitting the data. This feature reduces data bottlenecks, allows for a more
efficient use of the network devices, and prevents the loss of valuable data.
This feature reduces data bottlenecks, allows for a more efficient use of the
network devices, and prevents the loss of valuable data.
Far End Fault
When a fault occurs on an incoming fiber link (1), the media converter
transmits a Far-End Fault signal on the outgoing fiber link (2). In addition the
Far-End Fault signal also activates the Link Pass-Through, which, in turn,
disables the link on the copper portion of the network (3) and (4).
Far-End Fault
si
g
nal is sent
Media
Converter A
Media
Converter B
Near-End
Device
Far-End
Device
original fault
on the fiber link
media converter B
disables the co
pp
er lin
k
media converter A
disables the co
pp
er link
3
42
1
7
[email protected] -- Click the “Transition Now” link for a live Web chat.
Cable Specifications
The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate: <10-9
single mode fiber (recommended): 9 µm
Multimode fiber (recommended): 62.5/125 µm
Multimode fiber (optional): 100/140, 85/140, 50/125 µm
SBFTF1011-260 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
SBFTF1013-260 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
SBFTF1014-260 1310 nm single mode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm
Link Budget: 16.0 dB
SBFTF1015-260
(long haul) 1310 nm single mode
Fiber-optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 26.0 dB
SBFTF1016-260
(extra long haul) 1310 nm single mode
Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 29.0 dB
SBFTF1017-260
(long wave length) 1550 nm single mode
Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 29.0 dB
SBFTF1029-260 1310 nm (TX) / 1550 nm (RX) simplex
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
SBFTF1029-261 1550 nm (TX) / 1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
SBFTF1029-262 1310 nm (TX) / 1550 nm (RX) simplex
SBFTF1029-263 1550 nm (TX) / 1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 25.0 dB
The fiber optic transmitters on this device meets Class I Laser safety
requirements per IEC-825/CDRH standards and complies with 21
CFR1040.10 and 21CFR1040.11.

8
SBFTF10xx-26x
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Cable Specifications -- Continued
Copper Cable
Category 3: (Minimum requirement for 10 Mb/s operation)
Gauge 24 to 22 AWG
Attenuation 11.5 dB/100m @ 5-10 MHz
Maximum Cable Distance 100 meters
Category 5: (Minimum requirement for 100 Mb/s operation)
Gauge 24 to 22 AWG
Attenuation 22.0 dB /100m @ 100 MHz
Maximum Cable Distance 100 meters
• Both straight-through or crossover twisted-pair cable may be used.
• Shielded (STP) or unshielded (UTP) twisted-pair cable may be used.
• Pins 1&2 and 3&6 are the two active pairs in an Ethernet network .
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
Crossover Cable
1
2
3
6
Straight-Through Cable
Twisted Pair #1
Twisted Pair #1
Twisted Pair #2
Twisted Pair #2
1
2
3
6
1
2
3
6
1
2
3
6
9
[email protected] -- Click the “Transition Now” link for a live Web chat.
Technical Specifications
For use with Transition Networks Model SBFTF10xx-26x or equivalent.
Standards IEEE 802.3™ 2003
Data Rate 10 Mb/s, 100 Mb/s
Dimensions 7.29" x 4.34" x 1.2" (185 x 110 x 30 mm)
Weight 1.4 lbs. (0.6 kg) (approximate)
Power Consumption 4.95 watts
Power Supply 12 VDC, 1.25 Amp (minimum)
The external power supply provided with this product
is UL listed by the power supply’s manufacturer.
MTBF 48,000 hours (MIL217F2 V5.0) (MIL-HDBD-217F)
129,000 hours (Bellcore7 V5.0)
Packet Size: Memory: 128 Kbytes (1 Mbit)
Maximum packet size: 1536 bytes
Unicast MAC addresses: 2K
Environment Tmra*: 0 to 50°C (32 to 122°F )
Storage Temp: -20 to 85°C (-4 to 185°F)
Humidity: 5 to 95%, non condensing
Altitude: 0 to 10,000 feet
Warranty Lifetime
*Manufacturer’s rated ambient temperature.
The information in this user’s guide is subject to change. For the most up-to-date
information on the SBFTF10xx-26x media converter, view the user’s guide on-
line at: www.transition.com.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into
the beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other
than those specified herein may result in hazardous radiation exposure.

10
SBFTF10xx-26x
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Troubleshooting
If the media converter fails, isolate and correct the failure by determining the
answers to the following questions and then taking the indicated action:
1. Is the “P” (power) LED illuminated?
NO
• Is the power cord properly installed in the media converter and at the
external power source?
• Does the external power source provide power?
• Contact Technical Support: US/Canada: 1-800-260-1312,
International: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the “FD” (fiber duplex) LED illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables are connected to the RX and TX
ports, respectively, on the remote 100Base-FX device.
• The media converter is set for half-duplex mode. If the mode is not
correct, set the “FX DUPLEX” switch to the down (full-duplex)
setting. Next, disconnect and reconnect the fiber cable to restart the
initialization process.
YES
• The media converter is set for full-duplex mode. If the mode is not
correct, set the “FX DUPLEX” switch to the up (half-duplex) setting.
Next, disconnect and reconnect the fiber cable to restart the
initialization process.
• Proceed to step 3.
3. Is the “LNK” (link) LED illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables are connected to the RX and TX
ports, respectively, on the remote 100Base-FX device.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 4.
11
[email protected] -- Click the “Transition Now” link for a live Web chat.
Troubleshooting -- Continued
4. Is the “Duplex/Link” LED illuminated on a twisted-pair copper
port?
NO
• Check the copper cables of that port for proper connection.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Amber = The media converter has selected half-duplex mode.
• Green = The media converter has selected full-duplex mode.
• If the mode is not correct, disconnect and reconnect the twisted pair
cable to restart the initialization process.
• Proceed to step 5.
5. Is the “Speed” LED illuminated on a twisted-pair copper port?
NO
• Check the copper cables of that port for proper connection.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Amber = The media converter has selected 10Mb/s operation.
• Green = The media converter has selected 100Mb/s operation.
• If the speed is not correct, disconnect and reconnect the twisted pair
cable to restart the initialization process.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
Contact Us
Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
Ask a question anytime by sending an e-mail to our technical support staff.
[email protected]
Transition Networks; 6475 City West Parkway; Minneapolis, MN 55344; USA
telephone: [phone]
toll free: 800-526-9267
fax: [phone]

Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 2003-2005 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any
means - graphic, electronic, or mechanical - without written permission from Transition
Networks.
Printed in the U.S.A. 33259.C
Compliance Information
CISPR22/EN55022 Class A & B + EN55024; CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a Class A & B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the
interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A&B limits for radio noise for digital
apparatus set out on the radio interference regulations of the Canadian Department of
Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la Class A&B prescrites dans le Règlement sur le
brouillage radioélectrique édicté par le ministère des Communications du Canada.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-
Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.
Declaration of Conformity
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
Model: SBFTF10xx-26x Series Media Converters
Part Number(s): SBFTF1011-260, SBFTF1013-260, SBFTF1014-260, SBFTF1015-260,
SBFTF1016-260, SBFTF1017-260, SBFTF1029-260, SBFTF1029-261,
SBFTF1029-262, SBFTF1029-263
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the
SBFTF10xx-26x to which this declaration refers is in
conformity with the following standards.
CISPR 22: 1993; EN 55022:1998 Class A & B; EN 55024:1998; FCC Part 15 subpart B;
CFR 21 subpart J
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
_February 17, 2003_____
Stephen Anderson, Vice-President of Engineering Date
