Transition Networks M/E-TX-FX Series User manual

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 1 of 12
User Guide
M/E-TX-FX Series
Mini Fast Ethernet Media Converters
•100Base-TX RJ-45 to 100Base-FX
•Low cost 100M standalone media converter
•With Auto-Negotiation, Auto-cross, etc.
Contents
Introduction .................................................................................................................................................. 2
Ordering Information.................................................................................................................................... 2
Features ........................................................................................................................................................ 3
Technical Specifications ................................................................................................................................ 3
Package Contents.......................................................................................................................................... 4
Installation .................................................................................................................................................... 5
Observe ESD Precautions ......................................................................................................................... 5
Copper and Fiber Ports............................................................................................................................. 5
Connect the Fiber Cable ........................................................................................................................... 6
Connect the Twisted-pair Copper Cable................................................................................................... 6
Power Warnings ....................................................................................................................................... 7
Power Supply Included ............................................................................................................................. 7
Power up the Media Converter................................................................................................................ 7
Power Adapter.......................................................................................................................................... 7
AC Power .............................................................................................................................................. 7
DC Power.............................................................................................................................................. 7
Operation...................................................................................................................................................... 8
Status LEDs ............................................................................................................................................... 8
Features.................................................................................................................................................... 8
Auto-Negotiation.................................................................................................................................. 8
AutoCross ............................................................................................................................................. 8
Automatic Link Restoration.................................................................................................................. 8
Far-End Fault (Always ON) ................................................................................................................... 8
Cable Specifications.................................................................................................................................. 9
Fiber Optics .......................................................................................................................................... 9
Copper Cable ........................................................................................................................................ 9
Troubleshooting..........................................................................................................................................10
Compliance Information ............................................................................................................................. 11
Declaration of Conformity ...................................................................................................................... 11
CE Mark................................................................................................................................................... 11
FCC Regulations..................................................................................................................................11
Canadian Regulations.........................................................................................................................11
European Regulations ........................................................................................................................12
Record of Revisions..................................................................................................................................... 12

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 2 of 12
Introduction
Transition Networks’M/E-TX is a series of Fast Ethernet stand-alone Mini media converters that provide
cost effective media conversion between 100Base-TX ports and 100Base-FX ports. With its fixed
configuration, deployments are just plug-and-play, and its small size makes it ideal for locations where
space is limited. Operating at Layer 1, the physical layer, data is passed through the converter at line speed,
making it ideal for applications where low latency is essential.
Ordering Information
O#
Description
M/E-TX-FX-01
100Base-TX (RJ-45) [100m/328 ft.]* to 100Base-FX 1300nm multimode (ST)
[2km/1.2mi.]* Link Budget: 11.0db
M/E-TX-FX-01(SC)
100Base-TX (RJ-45) [100m/328 ft.]* to 100Base-FX 1300nm multimode (SC)
[2km/1.2mi.]* Link Budget: 11.0db
M/E-TX-FX-01(SM)
100Base-TX (RJ-45) [100m/328 ft.]* to 100Base-FX 1310nm single mode (SC)
[20km/12.4mi.]* Link Budget: 16.0db
M/E-TX-FX-01(SFP)
100Base-TX (RJ-45) [100m/328 ft.]* to 100Base-X SFP Slot (empty)
Optional Accessories (sold separately)
SFP Modules
See the Transition Networks SFP Products webpage
SPS-2460-SA
24VDC to 60VDC input Stand-alone Power Supply
WMBM
Wall Mount Bracket for Mini
M-MCR-01
18-Slot Powered Mini Chassis
DRBM
DIN Rail Mount Bracket for Mini
RMBM
Rack Mount Bracket for Mini; use with RMS19-SA4-02 and/or E-MCR-05
*Typical maximum cable distance; actual distance depends on the physical characteristics of the
network. Longer transmission distances, bi-directional transmissions, and CWDM technology are all
supported via specific SFP modules.
M/E-TX-FX-01
M/E-TX-FX-01-SC
M/E-TX-FX-01-SM
M/E-TX-FX-01

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 3 of 12
Features
•Fiber integration used in pairs or as a single unit, this mini media converter will ease the integration
of fiber optic cabling into copper-rich fast Ethernet environments
•Extend Network Distance as fiber supports the transmission of Fast Ethernet data over much longer
distances than possible twisted pair
•Low-Latency Layer 1 Design, this mini converter will retransmit Fast Ethernet signals without any
store-and–forward packet inspection delays found in other Layer 2 devices
•Small Size is ideal for conversion locations where available space is limited - 65% smaller than
standard media converters
•Unit and port LEDs allow for quick status information
•Auto-Negotiation and Auto-MDI/MDIX
Technical Specifications
Standards IEEE 802.3u, 100Base-TX, 100Base-FX
Status LEDs PWR (Power) below RJ-45: On = Power
FX-Link/Act (Fiber Link / Activity) Upper Left on RJ-45:
On = link, Flashing = Activity
TX-Link/Act (Copper Link / Activity) Upper Right on
RJ-45: On = link, Flashing = Activity
Dimensions Width: 1.8” [46 mm] x Depth: 3.3” [85 mm] x Height: 0.85 [22 mm]
Power Consumption 2.6 Watts
Power sources: Barrel connector –Wall Mount AC power adapter 12VDC 400mA (the external
power supply provided with this product is UL listed and C-UL listed Canada by
the manufacturer).
Power Supply External AC/DC required; +12VDC, 0.5A
Power Input 7.5VDC to 13.9VDC
Environment Operating: 0°C to 50°C
Storage: -15°C to 65°C
Humidity: 5% to 95% (non-condensing)
Altitude: 0 –10,000 ft.
Weight 2 lbs. [0.90 kg]
MTBF 41,680 hours (MIL-HDBK-217F)
114,580 hours (Bellcore7 V5.0)
Certifications Wall Mount Power Supply, UL Listed, cUL Listed (Canada)
Regulatory Compliance for Emission FCC Class A; EN55022 Class A
Regulatory Compliance for Immunity EN55024,
Safety Compliance Unit: CE Mark
Warranty Lifetime
WARNING: If the media converter is an IEEE802.3-2005 Powered Device (PD) capable of receiving power
via the Media Dependent Interface (MDI) leads, the power source, connector, and cable attached to the
barrel power connector must meet the isolation requirement specified in IEEE802.3-2005. Failure to
observe this warning could result in an electrical shock.

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 4 of 12
CAUTION: Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485, DS1,
DS3, Video Coax, etc., are intended to be connected to intrabuilding (inside plant) link segments that are
not subject to lightening transients or power faults. These Copper-based media ports are NOT to be
connected to interbuilding (outside plant) link segments that are subject to lightening transients or
power faults. Failure to observe this caution could result in damage to equipment.
WARNING: Visible and invisible laser radiation when open. Do not stare into the beam or view directly
with optical instruments. Failure to observe this warning could result in an eye injury or blindness.
WARNING: Use of controls, adjustments, or the performance of procedures other than those specified
herein could result in hazardous radiation exposure. The information in this user guide is subject to
change. For the most current information, view the online user guide at https://transition.com.
Package Contents
Make sure you have received the following items. Contact your sales representative if any item is
missing or damaged. Please save the packaging for possible future use.
•One M/GE-PSW-SFP-01 Media Converter
•One documentation postcard
•One country- specific power supply
M/E-TX-FX-01

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 5 of 12
Installation
10BObserve ESD Precautions
Always observe the following ESD (Electrostatic Discharge) precautions when installing or handing the
media converter:
•Do not remove the converter from its protective packaging until you are ready to install it.
•Wear an ESD wrist grounding strap before handling any module or component. If you do not have a
wrist strap, maintain grounded contact with the system unit throughout any procedure requiring
ESD protection.
11BCopper and Fiber Ports
The figure below shows the front panel of the M/E-TX-FX-01 media converters.

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 6 of 12
Connect the Fiber Cable
Full duplex (always ON) is on the fiber side only; therefore, the 512-Bit Rule does not apply. The cable
lengths are constrained by the cable requirement.
1. Locate or build IEEE 803.2 compliant 100 Base-X fiber cable with male, two-stranded TX to RX
connectors installed at both ends.
2. Connect the fiber cable to the M/E-TX-FX-01 media converters as follows:
•Connect the male TX cable connector to the female TX port.
•Connect the male RX cable connector to the female RX port.
3. Connect the fiber cable to the other device (another media converter, hub, etc.) as follows:
•Connect the male TX cable connector to the female RX port.
•Connect the male RX cable connector to the female TX port.
13BConnect the Twisted-pair Copper Cable
The AutoCross feature allows either MDI (straight-through) or MDI-X (crossover) cable connections to be
configured automatically, according to network conditions.
•If full-duplex mode is used, the 512-Bit Rule does not apply. The cable lengths are constrained by the
cable requirements.
Perform these steps:
1. Locate or build IEEE 803.2™compliant 100Base-TX cable, with RJ-45 connectors installed at both
ends.
2. Connect the RJ-45 connector at one end of the cable to the RJ-45 port on the M/E-TX-FX-01 media
converter.
3. Connect the RJ-45 connector at the other end of the cable to the RJ-45 port on the other device
(switch, workstation, etc.).

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 7 of 12
14BPower Warnings
WARNING: If the media converter is an IEEE802.3-2005 Powered Device (PD) capable of receiving power
via the Media Dependent Interface (MDI) leads, the power source, connector, and cables attached to
the barrel power connector must meet the isolation requirement specified in IEEE 802.3-2005.
Power Supply Included
To order the corresponding country- specific power supply, add the extension from the list below to
the end of the SKU. For example: M/E-TX-FX01-NA = North America, -LA = Latin America, -EU = Europe,
-UK = United Kingdom, -SA = South Africa, -JP = Japan, -OZ = Australia, and -BR = Brazil.
15BPower up the Media Converter
The figure below shows the power connector.
M/E-TX-FX-01 and M/E-TX-FX-01(SFP) Back Panel Power
16BPower Adapter
22BAC Power
1. Connect the barrel connector of the power adapter to the media converter’s power port (located on
the back panel of the media converter).
2. Connect the power adapter plug to AC power.
3. Verify that the media converter is powered up by observing the lit power indicator LED on the front
panel.
23BDC Power
See the Transition Networks SPS-1872-SA DC external power supply user guide for powering the media
converter.

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 8 of 12
Operation
17BStatus LEDs
Use the LEDs to monitor the status of the media converter.
FX-Link/Act LED
Green ON = Link ( fiber )
Flashing = Activity
TX-Link/Act LED
Green ON = Link
Flashing = Activity
Power LED ON = Connected to power
18BFeatures
24BAuto-Negotiation
The Auto-Negotiation feature is ON permanently for the M/E-TX-FX-01 media converters. Auto-
Negotiation allows the media converter to configure itself automatically to achieve the best possible
mode of operation over a link. It broadcasts speed (100 Mbps) and duplex capabilities (full) to the other
device and negotiates the best mode of operation. Auto-Negotiation allows quick and easy installation
because the optimal link is established automatically.
In a scenario where an auto-negotiation device is linked to a non-negotiating device, the negotiating
device via parallel detection recognizes the speed of the second device then establishes the best
operating speed (100 Mbps).
25BAutoCross
The AutoCross feature allows using either straight-through (MDI) or crossover (MDI-X) copper cables
when connecting to 100Base-TX devices. AutoCross determines the characteristics of the connection
and automatically configures the device to link up, regardless of the copper cable configuration (MDI or
MDI-X).
26BAutomatic Link Restoration
The media converter will automatically re-establish the link when connected to a switch if the link is lost,
even with Auto-Negotiation enabled.
27BFar-End Fault (Always ON)
When a fault occurs on an incoming fiber link (1), the media converter transmits a Far-End Fault signal
on the outgoing fiber link (2).

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 9 of 12
19BCable Specifications
Cable physical characteristics must meet or exceed IEEE 802.3™specifications.
28BFiber Optics
Bit Error Rate: <10-9
Single mode fiber (recommended): 9 μm
Multimode fiber (recommended): 62.5/125 μm
Multimode fiber (optional): 100/140, 85/140, 50/125 μm
M/E-TX-FX-01
M/E-TX-FX-01 (SC) 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
M/E-TX-FX-01 (SM) 1310 nm single mode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm
Link Budget: 16.0 dB
The fiber optic transmitters on this device meet Class I Laser safety requirements per
IEC825/CDRH standards and comply with 21 CFR1040.10 and 21CFR1040.11.
Copper Cable
Category 5: (Minimum requirement for 100 Mb/s operation)
Gauge 24 to 22 AWG
Attenuation 22.0 dB /100m @ 100 MHz
Maximum Cable Distance 100 meters
•Straight-through or crossover twisted-pair cable may be used.
•Shielded (STP) or unshielded (UTP) twisted-pair cable may be used.
•Pins 1&2 and 3&6 are the two active pairs in an Ethernet network.
•Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
•Do not use flat or silver satin wire.

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 10 of 12
6BTroubleshooting
If the media converter fails, isolate and correct the failure by determining the answers to the following
questions, and then taking the indicated action:
1. Is the power LED lit and did the TX and FX LEDs turn ON and then turn OFF?
NO
•Is the device powered by an adapter?
•Is the power adapter the proper type of voltage and cycle frequency for the AC outlet?
•Is the power adapter properly installed in the media converter and in the AC outlet?
•Contact Technical Support: See Contact Us below.
YES
Proceed to step 2.
Note: the M/E-TX-FX-01 (no link pass-through option), the TX LED will turn ON when the twisted pair
copper cable is installed; the FX LED will turn ON when the fiber cable is installed.
2. Are the TX and FX-Link/ACT LEDs lit on the RJ-45 port?
NO
Check the copper cables for proper connection.
Check the fiber cables for proper connection.
Contact Technical Support: See Contact Us below.
YES
Contact Technical Support: See Contact Us below.
Contact Us
Technical Support: Technical support is available 24-hours a day
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Main Office
tel: [phone] | toll free: 1.800.526.9267 | fax: [phone]
[email protected]om | [e-mail] | [e-mail]
Address
Transition Networks
10900 Red Circle Drive
Minnetonka, MN 55343, U.S.A.
Web: https://www.transition.com

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 11 of 12
8Compliance Information
20BDeclaration of Conformity
21BCE Mark
30BFCC Regulations
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at the user's own expense.
31BCanadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on
the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la Class A prescrites dans le Règlement sur le brouillage radioélectrique
édicté par le ministère des Communications du Canada.

Transition Networks, Inc. M/E-TX-FX-01 User Guide
33517 Rev. B https://www.transition.com/ Page 12 of 12
European Regulations
Warning : This is a Class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.
Achtung ! : Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb
dieses Gerätes Rundfunkstörungen auftreten. In diesem Fäll is der Benutzer für Gegenmaßnahmen
verantwortlich.
Attention ! : Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de
créer des interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures
spécifiques appropriées.
In accordance with European Union Directive 2002/96/EC of the European Parliament and of
the Council of 27 January 2003, Transition Networks will accept post usage returns of this
product for proper disposal. The contact information for this activity can be found in the
'Contact Us' portion of this document.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE PUBLIC TELEPHONE
NETWORK. Failure to observe this caution could result in damage to the public telephone
network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den
EGMitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie
91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer Konformität.
9B
Record of Revisions
Rev
Date
Notes
A
04/11/13
Initial release.
B
6/7/21
Add PEM and update specs and certifications.
Trademark Notice : All trademarks and registered trademarks are the property of their respective
owners.
Copyright restrictions : © 2012-2021 Transition Networks, Inc. All rights reserved. No part of this work
may be reproduced or used in any form or by any means - graphic, electronic or mechanical - without
written permission from Transition Networks.
