Transition Networks SGFEB10 Series User manual

33601 Rev. D www.transition.com Page 1 of 25
SGFEB10xx-xxx
10/100/1000 Bridging Media Converter
User Guide
•Auto Negotiation / AutoCross / Link Pass Through / Port Isolation
•Provides rate conversion while also increasing transmission distances
•Supports multimode or single mode fiber
Table of Contents
Introduction....................................................................................................................................................2
Package Contents.........................................................................................................................................2
Model Numbers.............................................................................................................................................2
Optional Accessories (sold separately).........................................................................................................3
Distances.......................................................................................................................................................3
Applications...................................................................................................................................................4
Installation.....................................................................................................................................................5
Configuration.............................................................................................................................................5
One DIP Switch Layouts ......................................................................................................................6
Two DIP Switch Layouts ......................................................................................................................7
Power Connection ....................................................................................................................................8
Port Locations and Layouts ......................................................................................................................9
Installing the RJ-45 Copper Cable..........................................................................................................10
Installing the Fiber Cable........................................................................................................................10
Operation.....................................................................................................................................................11
Status LEDs............................................................................................................................................11
Product Features ....................................................................................................................................12
Auto-Negotiation.................................................................................................................................12
Link Pass-Through (LPT) ...................................................................................................................12
Full-Duplex Network...........................................................................................................................12
Half-Duplex Network (512-Bit Rule)...................................................................................................12
AutoCross™.......................................................................................................................................13
Automatic Link Restoration ................................................................................................................13
Far End Fault (FEF)............................................................................................................................13
Remote Fault Detect (RFD)................................................................................................................13
Fiber Redundancy (Revertive / Non-revertive)...................................................................................13
New Features .....................................................................................................................................13
Port Isolation.......................................................................................................................................14
Energy Efficient Ethernet (EEE).........................................................................................................16
Cable Specifications....................................................................................................................................17
Copper Cable Specs...............................................................................................................................17
TP Port Specs.........................................................................................................................................17
Fiber Cable Specs ..................................................................................................................................18
Technical Specifications .........................................................................................................................19
Warnings.................................................................................................................................................20
Model Number Cross Reference ................................................................................................................21
Troubleshooting ..........................................................................................................................................22
Contact Us...................................................................................................................................................23
Compliance Information..............................................................................................................................24
Record of Revisions....................................................................................................................................25

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 2 of 25
Introduction
Transition Networks’ SGFEB 10/100/1000 Bridging Media Converters connect 10Base-T, 100Base-TX, or
1000Base-T twisted-pair copper cable to 1000Base-SX or 1000Base-LX fiber devices.
Package Contents
Before you start installing the SGFEB, verify that the package contains the following items:
•One SGFEB Media Converter
•One Documentation Postcard
•One 12VDC, 1.5A, 100VAC-240VAC Power Supply (25119) with Changeable AC Plugs (22280
or 22296)
•Four rubber feet
Please notify your sales representative immediately if any of the above items are missing or damaged.
Model Numbers
Model #
Description
SGFEB1040-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 100/1000Base-X SFP Slot (empty)
SGFEB1013-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-SX 850nm MM (SC) [62.5/125 um:
220 m/722 ft.] [50/125 um: 550 m/1804 ft.] Link Budget 7.5dB
SGFEB1039-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-SX 850nm MM (LC) [62.5/125 um:
220 m/722 ft.] [50/125 um: 550 m/1804 ft.] Link Budget 8.0dB
SGFEB1024-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-SX 1300nm Extended MM
(62.5/125um fiber only) (SC) [up to 2km] Link Budget: 7.0db
SGFEB1014-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-LX 1310nm SM (SC) [10 km/6.2
mi.] Link Budget 12.0dB
SGFEB1019-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-LX 1310nm SM (LC) [10 km/6.2
mi.] Link Budget 10.5dB
SGFEB1029-130
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-LX 1310nm TX/1550nm RX SM
(SC) [20 km/12.4 mi.] Link Budget 13.0dB
SGFEB1029-131
10/100/1000Base-T (RJ-45) [100 m/328 ft.] to 1000Base-LX 1550nm TX/1310nm RX SM
(SC) [20 km/12.4 mi.] Link Budget 13.0dB
SGFEB1040-230
(1) Port 10/100/1000Base-T (RJ-45) [100 m/328 ft.] to (2) Ports 100/1000Base-X SFP Slot
(empty)
SGFEB1040-330
(2) Port 10/100/1000Base-T (RJ-45) [100 m/328 ft.] to (2) Ports 100/1000Base-X SFP Slot
(empty)

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 3 of 25
Optional Accessories (sold separately)
Part #
Description
SPS-2460-PS
Wide Input (24 – 60VDC) Power Supply
SPS-2460-SA
Wide Input (24 – 60VDC) Power Supply
25025
[email protected], 100-240VAC (~1.0A) Power Supply (requires a country-specific power
cord; contact TN for power cord options)
WMBD
DIN Rail Mount Bracket 5.0 inches (127 mm)
WMBL
Wall Mount Bracket 4.0 inches (102 mm)
E-MCR-05
12-Slot Media Converter Rack
RMS19-SA4-01
4-Slot Media Converter Shelf
SFP Modules
See the TN Small Form factor Pluggables webpage
Distances
The distances listed below are typical maximum cable distances. Actual distance depends on the physical
characteristics of the network installation.
Install SGFEB1029-130 and SGFEB1029-131 single-fiber optic in the same network where one is the
local converter and the other is the remote converter.
Part #
Copper Ports
10/100/1000-Base-T
Duplex Fiber-Optic Ports
SGFEB1013-130
One RJ-45
100 m (328 ft)
SC, 1000Base-SX, 850nm multimode
220m (OM1)/550m (OM2) (720/1,805 ft)
SGFEB1040-130
One RJ-45
100 m (328 ft)
One 100/1000 Base-X SFP slot (empty)
SGFEB1040-230
One RJ-45
100 m (328 ft)
Two 100/1000 Base-X SFP slots (empty)
SGFEB1040-330
Two RJ-45
100 m (328 ft)
Two 100/1000 Base-X SFP slots (empty)
SGFEB1039-130
One RJ-45
100 m (328 ft)
LC, 1000Base-SX, 850nm multimode
220m (OM1)/550m (OM2) 720/1805 ft.)
SGFEB1024-130
One RJ-45
100 m (328 ft)
SC, 1000Base-SX 1300nm Extended MM
(62.5/125um fiber only) (SC) [up to 2km]
SGFEB1014-130
One RJ-45
100 m (328 ft)
SC, 1000Base-LX, 1310nm single mode
10km / 6.2 miles
SGFEB1019-130
One RJ-45
100 m (328 ft)
LC, 1000Base-LX, 1310nm single mode
10km / 6.2 miles
SGFEB1029-130
One RJ-45
100 m (328 ft)
SC, 1000Base-LX, 1310nm TX / 1550nm RX
Single mode, 20 Km / 12.4 miles
SGFEB1029-131
One RJ-45
100 m (328 ft)
SC, 1000Base-LX, 1550nm TX / 1310nm RX
Single mode, 20 Km / 12.4 miles

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 4 of 25
Applications
•Integrate 1000Base-SX/LX Fiber into 10/100/1000 Copper environments
•Extend Network Distance
•Bridge legacy 10/100 devices to a Gigabit backbone
Generic Application
Transition Networks ION Application

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 5 of 25
Installation
Warning: Before installing the SGFEB, make sure that proper electrical grounding procedures have been
followed.
To install the SGFEB, perform the following steps:
1. Determine your Model number and related DIP Switch layout. See “Configuration” below.
2. Set the DIPs / Jumpers on the PCB. See either “Two DIP Switch Layouts” on page 7 or “One DIP
Switch Layouts” on page 6.
3. Make the Power Connection. See “Power Connection” on page 8below.
4. Determine your port connection types. See “Port Locations“ on page 9below.
5. Install and connect the copper cable as required. See “Installing the RJ-45 Copper Cable“ on page 10
below.
6. Install and connect the fiber cable as required. See “Installing the Fiber Cable“ on page 10.
7. Continue to the “Operation” section on page 11.
Configuration
SGFEB models include one of two DIP switch layouts; either a single DIP switch or two DIP switches
accessible through a cutout in the right side of the enclosure. Both DIP switch layouts are described in the
following sections.
•Some SFP versions (SGFEB1040-230 and SGFEB1040-330) have two DIP switches.
•Other SFP versions and the Fixed optic version (models SGFEB1040-130, SGFEB1013-130,
SGFEB1014-130, SGFEB1019-130, SGFEB1029-130, SGFEB1029-131, and SGFEB1039-130.)
have one DIP switch.
The DIP Switch settings for both layouts are described and illustrated in the following sections.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 6 of 25
One DIP Switch Layouts
This layout has one six-position DIP Switch. The DIP switch is located on the right side of the SGFEB.
Use a small, flat-blade screwdriver (or a similar device) to set the DIP switches according to your site
requirements.
A. 6-Position DIP switch:
1- Twisted Pair Port (Port 2) Autonegotiation: Up = Enabled, Down = Disabled.
2- Twisted Pair Port (Port 2) Speed: Up = 100Mbps, Down = 10Mbps (only for Autoneg disabled).
3- Twisted Pair Port (Port 2) Duplex: Up = Full, Down = Half (only for Autoneg disabled).
4- Link Pass Through (LPT) Up = Disabled, Down = Enabled) (TX to FX and FX to TX).
5, 6SFP Port control: these DIP switch settings have no affect on fixed optics models.
5
6
Status
Up
Up
1000Base-X
Up
Down
SGMII Mode
Down
Up
100 Full Duplex
Down
Down
100 Half Duplex

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 7 of 25
Two DIP Switch Layouts
This layout has one six-position DIP Switch and one four-position DIP Switch. The DIP switches are
located on the right side of the SGFEB (SGFEB1040-230 or SGFEB1040-330).Use a small, flat-blade
screwdriver (or a similar device) to set the DIP switches according to your site requirements.
The SGFEB version with two SFP ports supports two modes, controlled via DIP switches (Multi-port
switch mode and Redundant fiber path mode).
A. 6-Position DIP switch:
1- Twisted Pair Port 2 Autonegotiation: Up = Enabled, Down = Disabled.
2- Twisted Pair Port 2 Speed: Up = 100Mbps, Down = 10Mbps (only for Autoneg disabled).
3- Twisted Pair Port 2 Duplex: Up = Full, Down = Half (only for Autoneg disabled).
4- No affect; Link Pass Through does not apply to 3-port and 4-port models.
5, 6(Port control): Port 1 (SFP)
5
6
Status
Up
Up
1000Base-X
Up
Down
SGMII Mode
Down
Up
100 Full Duplex
Down
Down
100 Half Duplex
Note: For multi-port switch mode and two twisted-pair port models, connecting two ports to a non-
spanning tree enabled switch is not recommended.
Note: Port 4, if present, is permanently set for Auto-negotiate mode.
4-Position DIP Switch (on SFP versions, Port 3 populated) (default = all Up):
Switches 1 and 2(Fiber port 3):
1
2
Status
Up
Up
1000Base-X
Up
Down
SGMII mode (Autoneg)
Down
Up
100BaseFX Full Duplex
Down
Down
100BaseFX Half Duplex
Switches 3 and 4:
3
4
Status
Up
Up
Multi-port switch mode
Up
Down
Fiber Redundacy Mode: Revertive
Down
Up
Fiber Redundancy Mode: Non-revertive
Down
Down
Port Isolation enable

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 8 of 25
Power Connection
Use the supplied AC power adapter to power the SGFEB standalone converter. To connect power to the
SGFEB, do the following:
1. Connect the barrel connector on the power adapter cord to the power connector on the media
converter shown below.
2. Plug the power adapter plug into AC power.
3. Verify that the media converter has powered UP—the power LED on the front panel is lit.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 9 of 25
Port Locations and Layouts
Port layouts and locations also vary by model number and PCB assembly as shown below.
SGFEB1013/14-130
SGFEB1040-130
SGFEB1040-230
SGFEB1040-330
SGFEB1019-130 / 1039-130
SGFEB1029-130 / 131
Note: Port 1 and Port 2 always refer to Fiber port 1 and Copper port 1. Port 3 refers to a second Fiber
port, and Port 4 refers to a second RJ45 (copper) port.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 10 of 25
Installing the RJ-45 Copper Cable
10/100/1000Base-T Copper Port:
1. Locate a 10/100/1000Base-TX compliant copper cable with male RJ-45 connectors installed at both
ends.
2. Connect the RJ-45 connector at one end of the cable to the SGFEB’s 10/100/1000Base-RJ-45 port.
3. Connect the RJ-45 connector at the other end of the cable to the 10/100/1000Base-RJ-45 port on the
other device (switch, workstation, etc.).
Note: The AutoCross feature allows the use of either straight-through or crossover configuration cables.
Installing the Fiber Cable
1000Base-X Fiber Port:
1. Locate a 1000Base-X compliant fiber cable with male, two-stranded TX to RX connectors installed at
both ends.
2. Connect the fiber cables to the media converter’s 1000Base-X fiber port as described below:
• Connect the male TX cable connector to the female TX connector.
• Connect the male RX cable connector to the female RX connector.
3. Connect the fiber cables to the 1000Base-X fiber port on the other device (another media converter,
hub, etc.) as described below:
• Connect the male TX cable connector to the female RX connector.
• Connect the male RX cable connector to the female TX connector.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 11 of 25
Operation
Status LEDs
Use the status LEDs to monitor SGFEB operations.
PWR (Power): On = Power is provided to the SGFEB.
Fiber Status LEDs
The status LEDs for the 1000Base-SX/LX fiber connection (labeled LACT and DUP) are located under
the fiber port (Port 1 and Port 3).
LACT: On (contiuously lit) means a link has been established for the fiber connection.
Flashing means that the fiber connection is tranmistting or receiving data.
DUP: On (contiuously lit) means Full Duplex (FDX); Off means Half duplex (HDX). Note: Half duplex is
only an option in SFP versions of this converter. If Half duplex on the fiber port is desired, it is configured
by DIP switches #5and #6 on the 6-position DIP switch.
Copper Status LEDs
The status LEDs for the copper connection (port 2 and Port 4) are integrated into the RJ-45 port.
These LEDs are not labeled.
TP Link / Activity / Duplex LED (upper left)
Amber: A link in half-duplex mode has been established for the copper connection.
Flashing Amber: The copper connection is transmitting or receiving data in half-duplex mode.
Green: A link in full-duplex mode has been established for the copper connection.
Flashing Green: The copper connection is transmitting or receiving data in full-duplex mode.
Speed LED (upper right)
Off: 10 Mbps operation.
Amber: 100 Mbps operation.
Green: 1000 Mbps operation.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 12 of 25
Product Features
Auto-Negotiation
The Auto-Negotiation feature allows the SGFEB10xx to automatically configure itself to achieve the best
possible mode of operation over a link. The media converter broadcasts its speed (10 Mb/s, 100 Mb/s, or
1000 Mb/s) and duplex capabilities (full or half) to the other devices and negotiates the best mode of
operation. Auto-Negotiation allows quick and easy installation because the optimal link is established
automatically. No user intervention is required to determine the best mode of operation.
A scenario where the media converter is linked to a non-negotiating device is a case where the user may
want to disable Auto-Negotiation. In this instance, the mode of operation will drop to the least common
denominator between the two devices (e.g. 100 Mb/s, half-duplex). Disabling this feature gives the user
the ability to force the connection to the best mode of operation.
Note: The SGFEB10xx-13x supports 1000 Mbps fiber Auto-Negotiation.
Link Pass-Through (LPT)
The Link Pass-Through feature allows the media converter to monitor both the fiber and copper RX
(receive) ports for loss of signal. In the event of a loss of an RX signal (1), the media converter will
automatically disable the TX (transmit) signal (2), thus, “passing through” the link loss (3). The far-end
device is automatically notified of the link loss (4), which prevents the loss of valuable data unknowingly
being transmitted over an invalid link. Note that LPT is an option on 2 port versions.
The LPT firmware algorithm will detect both fiber and Cu RX link loss; the link transmitter is disabled to
propagate loss indication. Link Pass Through is a troubleshooting feature that allows the media converter
to monitor both the fiber and copper RX ports for loss of signal. In the event of a loss of RX signal on one
media port, the converter will automatically disable the TX signal of the other media port, thus "passing
through" the link loss.
Full-Duplex Network
In a full-duplex network, maximum cable lengths are determined by the type of cables that are used.
See pages 3 and 4 for the cable specifications for the different SGFEB models. The 512-Bit Rule does
not apply in a full-duplex network.
Half-Duplex Network (512-Bit Rule)
In a half-duplex network, the maximum cable lengths are determined by the round trip delay limitations of
each Fast Ethernet collision domain. (A collision domain is the longest path between any two terminal
devices, e.g. a terminal, switch, or router.) The 512-Bit Rule determines the maximum length of cable
permitted by calculating the round-trip delay in bit-times (BT) of a particular collision domain. If the result
is less than or equal to 512 BT, the path is good. For more information on the 512-Bit Rule, see the white
paper titled “Collision Domains” on the Transition Networks website at: www.transition.com.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 13 of 25
AutoCross™
The AutoCross feature allows either straight-through (MDI) or crossover (MDI-X) cables to be used when
connecting to devices such as hubs, transceivers, or network interface cards (NICs). AutoCross
determines the characteristics of the cable connection and automatically configures the unit to link up,
regardless of the cable configuration.
Automatic Link Restoration
The SGFEB will automatically restore the link between networked devices after a fault condition has been
corrected. In contrast, products from competitors generally require the user to power down, then power
up the converters after a fault condition has been corrected.
Far End Fault (FEF)
The FEF feature applies to IEEE 802.3u 100Mbit Cu/Fiber rate only. The MAC may use FEF when Auto
negotiation is disabled. When the MAC detects a PHY fault/TX loss link, a FEFI idle pattern is sent to the
link partner TX (100BASE-FX only).
Remote Fault Detect (RFD)
The RFD feature applies to 1000Mbps operation only. Remote Fault Detect (RFD) is a troubleshooting
feature found on GigEthernet copper-to-fiber media converters. By enabling RFD on the remotely located
media converter, the status of the fiber link will be monitored and any link failures will be reported back to
the local converter. Should the remote converter lose its fiber RX signal, RFD will force the converter to
shut down its fiber TX port. If Link Pass Though is enabled on both ends, then the copper ports will also
be shut down to notify both end devices of the link failure.
Fiber Redundancy (Revertive / Non-revertive)
Multiport versions provide 3 or 4 port switch functionality or provide redundant fiber links, with a
switchover (failover) time of less than 1 second. In Revertive mode, after the failed link is recovered, it
becomes the active link again (reverts to the failed link). In Non-revertive mode, after the failed link is
recovered, the failed link does not become active again. The 4 port version does not support Fiber
Redundancy mode but does support port isolation.
New Features
1. Jumbo 10K frame support
2. 8k MAC addresses (vs 1k)
3. EEE 802.3az
4. Multi-port mode default for multiple SFP assemblies.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 14 of 25
Port Isolation
The SGFEB -230 and -330 support Port Isolation. This function uses Port Isolation (Port Based VLAN) to
disable the data paths between ports. This allows two customer-facing fiber ports and prevents each
customer from seeing the other’s traffic.
The Port Isolation (Port Based VLAN) feature creates a PVLAN (Private Virtual Local Area Network), but
it does not use 802.1Q tags. The current Port Based VLAN implementation only forwards traffic to ports in
a specific port’s VLAN Table. Tagged and untagged traffic will move through the SGFEB unmodified.
Port isolation setup varies between models as shown and described below.
Port Isolation on 3-Port Models
Port Isolation on 3-port devices sets up a port-based VLAN between the TP port and each Fiber port as
shown below.
Port Ports Traffic Forwarded To (VLAN Table)
1 (Fiber) 3
2 (Fiber) 3
3 (TP) 1,2

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 15 of 25
Port Isolation on 4-Port Models
Port Isolation on 4 port devices sets up a private VLAN between ports 1 and 2, and a second Port Based
VLAN between ports 3 and 4 (like having two independent converters).
Port Ports Traffic Forwarded To (VLAN Table)
1 (Fiber) 2
2 (Fiber) 1
3 (TP) 4
4 (TP) 3

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 16 of 25
Energy Efficient Ethernet (EEE)
Energy efficient Ethernet can significantly reduce the power consumption of the device over a period of
time especially when there is a large amount of idle signals on the copper port. IEEE standard 802.3az
which implements a Low Power Idle mode on copper interfaces with internal PHYs. SGFEB TP Ports
have the EEE Low Power Idle mode enabled. Note that the Link LED remains lit when in low power
mode. You can disable the 802.3az EEE function with a 2-pin header and a jumper (J13) on the board.
The SGFEB ships with EEE enabled; Jumper J13 has the jumper (shorting plug) uninstalled. Contact TN
Tech Support to obtain the two-position jumper TN6907 if you want to disable EEE.
The amount of delay experienced while waiting for the copper interfaces to wake up and come out of low
power idle mode is determined by the speed of the port:
Delay = ASSERT TIME + WAKE TIME
For 1000 Base, delay = 0 + 17us = 17us. For 100 Base, delay = 0 + 30us = 30us.
EEE Low Power Idle mode requires the copper port to advertise via the auto negotiation registers the
ability to support EEE for both 1000Base-T and 100Base-T. Both local and remote ports must indicate
they can support low power idle mode before the port can initiate a low power idle state.
During Auto –Negotiation the Port EEE capabilities are exchanged using the next page process to
establish the speed and duplex information. Timer information with regards to tx_idle, assert and wake
cycles are set in SGFEB registers by the CPU. When a port egress queue remains empty for a specific
period of time set by the EEE TX_IDLE Timer register, then a low power state can be entered. The
default setting for the TX_IDLE is 2 milliseconds.
After the TX_IDLE time the PHY will start the assert timer. The Assert timer will require the SGFEB to wait
until the assert timer is zero before a wake up request can be processed. Currently the default Assert
timer is set to 0, giving the PHY the ability to immediately start processing a request to leave the low
power idle state. The PHY then enters low power idle mode. This mode is defined by a 22.35mili-seconds
quiet period followed by a 210us refresh pulse. Then once a port sends a packet and the egress queue is
no longer empty a wake up period is needed for the PHY to return to full operation. The default wake
times are set to 17 micro-seconds for 1000Base and 30 micro-seconds for 100Base. During this wakeup
time the packet will continue to buffer in the egress queue until the wake up timer has completed at this
point port traffic will begin to flow as normal.
The SGFEB can also support a reduced power mode for 10Base-T in which it modifies the copper media
transmit waveform to achieve power consumption savings.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 17 of 25
Cable Specifications
The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Copper Cable Specs
Category 5 (minimum requirement) STP or UTP
Gauge: 24 to 22 AWG
Attenuation: 22.0 dB /100 m @ 100 MHz
Maximum Cable Distance: 100 meters (328 ft)
• Straight-through OR crossover twisted-pair cable may be used.
• Shielded (STP) OR unshielded twisted-pair (UTP) cable may be used.
• All pin pairs (1&2, 3&6, 4&5, 7&8) are active pins in a Gigabit Ethernet network.
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
TP Port Specs
1000BaseT Twisted Pair Ports:
•Connector: RJ45
•MDI/MDI-X selection: Automatic

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 18 of 25
Fiber Cable Specs
The fiber optic transmitters on these devices meet Class I Laser safety requirements per IEC-825/CDRH standards
and comply with 21 CFR1040.10 and 21CFR1040.11.
Bit Error Rate: <10-9
Single mode fiber: 9 μm
Multimode fiber: 62.5/125 μm
Multimode fiber: 50/125 μm
SGFEB1013-130 850nm multimode
Fiber Optic Transmitter Power: min: -9.5 dBm max: -4.0 dBm
Fiber Optic Receiver Sensitivity: min: -17.0 dBm max: 0.0 dBm
Link Budget: 7.5 dB
SGFEB1029-130 1310nm TX/1550nm RX single mode
SGFEB1029-131 1550nm TX/1310nm RX single mode
Fiber Optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber Optic Receiver Sensitivity: min: -21.0 dBm max: -3.0 dBm
Link Budget: 13.0 dB
SGFEB1039-130 850nm multimode (LC)
Fiber Optic Transmitter Power: min: -9.0 dBm max: -4.0 dBm
Fiber Optic Receiver Sensitivity: min: -17.0 dBm max: -3.0 dBm
LInk Budget: 8.0 dB
SGFEB1024-130 1300nm Extended MM (SC)
Fiber Optic Transmitter Power: min: -10.0 dBm max: -3.0 dBm
Fiber Optic Receiver Sensitivity: min: -17.0 dBm max: -3.0 dBm
Link Budget: 7.0db
SGFEB1014-130 1310nm SM (SC)
Fiber Optic Transmitter Power: min: -9.0 dBm max: -3.0 dBm
Fiber Optic Receiver Sensitivity: min: dBm -21.0 dBm max: -3.0 dBm
LInk Budget: 12.0 dB
SGFEB1019-130 1310nm SM (LC)
Fiber Optic Transmitter Power: min: -9.5 dBm max: -3.0 dBm
Fiber Optic Receiver Sensitivity: min: -20.0 dBm max: -3.0 dBm
LInk Budget: 10.5 dB

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 19 of 25
Technical Specifications
The SGFEB was designed to meet these specifications.
Standards IEEE 802.3, IEEE 802.3ab,IEEE 802.3u, IEEE 802.3z (EEE)
Regulatory Compliance - Emission EN55022 Class A, CE, FCC Part15 Class. A
Regulatory Compliance - Immunity EN55024
Safety Compliance Wall Mount Power Supply: UL Listed, UL60950 and CSA Certified
Power Consumption 2.2 Watts (not including AC/DC power adapter)
Power Source 7.5 to 24 VDC - Wall Mount AC Adapter
Dimensions 3.25 x 1 x 4.8 in (82 x 122 x 25 mm)
Weight SGFEB: 0.55 lbs (0.25 kg)
Power Supply: 0.85 lbs (0.38 kg)
Operating Temperature 0 to 50 degree C
Storage Temperature -15 to 65 degree C
Altitude 0-10,000 feet
Operating Humidity 5% to 95% (non-condensing)
MTBF
Greater than 250,000 MIL-HDBK-217F Hours.
Greater than 687,500 Bellcore Hours
When bundled with a typical 50,000 hour power supply:
Greater than 41,660 MIL-HDBK-217F Hours
Greater than 114,580 Bellcore Hours
Data Rate (copper) 10/100/1000 Mbps
Data Rate (fiber) 1000 Mbps (operates in full-duplex only)
Filtering Addresses 8K MAC addresses
Maximum Frame Size 10260 bytes Jumbo Frame
Environment: Tmra* 0°C to 50°C (32°F to 122°F)
Warranty Lifetime
For current information on the SGFEB, view the product page at www.transition.com.

Transition Networks SGFEB 10/100/1000 Bridging Media Converter User Guide
33601 Rev. D www.transition.com Page 20 of 25
Warnings
WARNING: Visible and invisible laser radiation when open. Do not stare into the beam or view the beam
directly with optical instruments. Failure to observe this warning could result in an eye injury or blindness.
WARNING: Use of controls, adjustments or the performance of procedures other than those specified
herein may result in hazardous radiation exposure.
Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485, DS1, DS3,
Video Coax, etc., are intended to be connected to intra-building (inside plant) link segments that are not
subject to lightening transients or power faults.
Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232, RS422, RS485, DS1, DS3,
Video Coax, etc., are NOT to be connected to inter-building (outside plant) link segments that are subject
to lightening transients or power faults.
Warning Class 1 laser product.
Warning Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into
beams or view directly with optical instruments.
Warning Use of controls, adjustments, or performing procedures other than those specified may result in
hazardous radiation exposure.
Laser safety standards:
• Class 1 LASER PRODUCT (IEC 60825-1 2001-01)
• Class I LASER PRODUCT (complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser
Notice 50, dated July 26, 2001)
All fiber-optic ports have been tested and comply with the Class 1 limits of IEC 60825-1 and Class I limits of 21 CFR
1040.10.
Waarschuwing Klasse-1 laser produkt.
Varoitus Luokan 1 lasertuote.
Attention Produit laser de classe 1.
Warnung Laserprodukt der Klasse 1.
Avvertenza Prodotto laser di Classe 1.
Advarsel Laserprodukt av klasse 1.
Aviso Produto laser de classe 1.
¡Advertencia! Producto láser Clase I.
Varning! Laserprodukt av klass 1.
Aviso Produto a laser de classe 1.
Advarsel Klasse 1 laserprodukt.
