Transmitter Solutions TRAKEYFREE2-W User manual

Carrier frequency..............................433,92 MHz
Modulation........................................AM/ASK
N° channels ......................................1
E.r.p. .................................................300 uW
Battery type ......................................ER14505 Lithium
Operating voltage .............................3,6 Vdc
Current consumption ........................2 µA : stand-by
..........................................................60 mA : transmission
Battery life:........................................ 2 years
Security protocol...............................KeeLoq® Hopping code
Code combinations...........................2exp64
Range in open space........................200/300 m
Operating temperature .....................-20°/+80°C
Enclosure IP grade ...........................IP55
Dimensions (mm) .............................105 x 70 x 23,5
Weight ( gr. ).....................................100
The Touch transmitter TRAKEYFREE2 transmitter is a special radio transmitter oper-
ating at 433,92 MHz in AM/ASK modulation.
It’s mainly composed by a capacitive touch sensitive circuit and by a radio transmitter.
It can be used to operate gates, doors or garage doors or any device with the corre-
sponding compatible 433 MHz receiver.
The security protocol is a KeeLoq® Hopping code .
A special sensor lights the led frame when the hand approaches the device at about 10
cm and triggers the radio transmission when it touches the front surface.
The enclosure allows outdoor installations ( IP55).
Each product is already factory programmed with a different security code.
The transmitter is battery supplied with a ER14505 lithium battery for 2 year life.
1CH TOUCH TRANSMITTER TRAKEYFREE2
2Technical Specications
1Introduction
Fig. 2
105
70 23,5
Fig.1
3Mounting 4Battery replacement
+
_
ER14505
3,6 V
NOTE: Please dispose of the baeries correctly, they are
hazardous waste.
Replace the baery with another idencal or equivalent
respecng the polarity as indicated above
!
Color P/N
White TRAKEYFREE2-W
Black TRAKEYFREE2-B
Fig. 3
Fig. 4

The warranty period for this product is 24 months, beginning from the manufacturer date. During this period, if the product does not work
correctly, due to a defective component, the product will be repaired or substituted at our discretion. The guarantee does not cover the
plastic container integrity. After-sale service is supplied at the factory.
5Use
7Memorization
6Battery Low
10 Guarantee
Beep
BLUE
GREEN
Beep
BLUE
RED
The light of the touch transmitter becomes BLUE when the hand approaches at about 10 cm and becomes GREEN when the hand
touches the surface.
The RF transmission starts at the “Beep” of the buzzer.
In case of battery low the GREEN color becomes RED.
For the memorization of the transmitter onto the corresponding receiver, follow the procedure described on the receiver manual.
The touch transmitter is read by any Erone receiver as the button “A”
Any changes or modications on equipment not expressly approved by the Transmitter Solutions could void the user’s authority to
operate with the equipment.
Transmitter Solutions
2505 Chandler Avenue, Suite, 1
Las Vegas, NV 89120 -
[phone] - [phone] Fax
[email protected]
9Notice
IS-TTHTSEN rev.0 on 16/10/2017
is device complies with Part 15 of the FCC Rules provided it is assembled in exact accordance with the instructions provided
with this kit. Operation is subject to the following conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received including interference that may cause undesired operation.
FCC ID = PWJTTH
8FCC
