Travis Industries B29 User manual

Retrofit, Burner - B29 Instructions
For the DVS Insert, DVS Fireplace, Allegiance, and Spirit -- SKU 93007337
Page 1 of 2 2/10/05 © Travis Industries, Inc.
Compatibility
DVS Insert - SN 3401-98953 to 3401-119111
DVS ZC Fireplace - SN 3402-108668 to 3402-115149
Allegiance - SN 3102-175000 to 3102-176977
Spirit - SN 3104-57975 to 3104-58797
When to Use This Kit
This kit modifies the above model(s) to accept the newer "cast iron" burner.
Important Warnings
Turn off gas to the appliance and make sure it has fully cooled prior to conducting service.
Packing List
Allegiance DVS Insert, Fireplace, and Sprit
Pilot
Bracket
Pilot
Bracket
B29 Burner
(2) #8 x 3/8" Screws (2) #8 x 3/8" Type B Screws
DVS Insert, DVS Fireplace, and Spirit Installation
1. Remove the logs, em ers, and urner following the instructions included with the heater.
2. The new cast urner requires a slightly different pilot racket (it is a different height). Remove
the existing pilot racket and replace it with the pilot racket included with this kit (make sure to
select the correct racket).
AAA
AAA
AAA
AA
AA
AAA
AAA
AAA
AAA
AA
AA
AA
A
A
Remove the four screws holding the pilot
assembly to the pilot bracket and the pilot
bracket to the floor of the firebox.
Install the new pilot bracket and attach
the pilot connections. Attach the pilot
assembly and bracket using the
screws removed in step “a”.
Disconnect the pilot assem ly connections
and discard the old pilot racket.
b
a
NOTE: Re-seal this joint with
high-temperature silicone
after installation.
c
3. Install the urner following the directions included with the heater (the new urner installs in the
same fashion as the old urner).

Retrofit, Burner - B29 Instructions
For the DVS Insert, DVS Fireplace, Allegiance, and Spirit -- SKU 93007337
Page 2 of 2 2/10/05 © Travis Industries, Inc.
Allegiance Installation
1. Remove the logs, em ers, and urner following the instructions included with the
heater.
2. The new cast urner requires a slightly different pilot racket (it is a different height).
Remove the existing pilot racket and replace it with the
new racket included with this kit (make sure to select the correct
components - see page 1).
AA
AA
A
A
AA
AA
AA
Remove the four screws holding the pilot
assembly to the pilot bracket and the pilot
bracket to the back wall of the firebox.
Discard the old pilot bracket. Install
the new pilot bracket and attach the
pilot assembly using the screws
removed in step “a”.
Pilot Bracket
Disconnect the thermopile and slide the
pilot assem ly through the hole in the pilot
racket (this eliminates the need to
disconnect the other pilot assem ly
connections).
b
NOTE: if the pilot assembly connections do not have
enough slack to reach the new pilot position, you may need
to remove this plate and pull the connections through
(remember to re-seal the joint with silicone).
a
c
BURNER INSTALLATION NOTE
Make sure the burner supports and locator tab are
not bent. The burner, when being installed, fits very
tight within the burner area, and is somewhat difficult
to locate correctly. Pay close attention to the hole
on the bottom of the burner and locator pin to insure
correct installation. Test burn the heater after
installation to verify.
3. Install the urner following the directions included with the heater (the new urner
installs in the same fashion as the old urner).
