Travis industries Dvs gsr insert User manual

DVS GSR Insert

Owner's Manual

Featuring the

Burner

Tested and Listed by

OMNI-Test Laboratories, Inc.

Portland, Oregon

Report # 028-F-73-5

ANSI Z21.88



Direct Vent Fireplace Insert



Masonry or Factory Built (Metal) Wood-

Burning Fireplace



Residential or Mobile Home

WARNING: If the information in these instructions is not followed exactly, a fire or

explosion may result causing property damage, personal injury or loss of life.

- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this

or any other appliance.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any phone in your building.

• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's

instructions.

• If you cannot reach your gas supplier, call the fire department.

- Installation and service must be performed by a qualified installer, service agency or the

gas supplier.

This appliance may be installed in an aftermarket, permanently

located, manufactured home (USA only) or mobile home, where

not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the

rating plate. This appliance is not convertible for use with other

gases, unless a certified kit is used.

Installer: After installation give this manual to the home-owner and

explain operation of this heater.

Travis Industries, Inc.

www.travisproducts.com

4800 Harbour Pointe Blvd. SW

Mukilteo, WA 98275

2Introduction

Introduction

We welcome you as a new owner of a DVS Insert. In purchasing this fireplace insert you have joined the

growing ranks of concerned individuals whose selection of an energy system reflects both a concern for

the environment and aesthetics. It is one of the finest home heaters the world over. This manual will

explain the installation, operation, and maintenance of this heater. Please familiarize yourself with the

Owner's Manual before operating your heater and save the manual for future reference. Included are

helpful hints and suggestions that will make the operation and maintenance of your new heater an easier

and more enjoyable experience. We offer our continual support and guidance to help you achieve the

maximum benefit and enjoyment from your heater.

Important Information

No other DVS Insert has the same serial number as

yours. The serial number is below and to the left of the

gas control valve.

This serial number will be needed in case you require

service of any type.

Model: DVS GSR Insert

Serial Number:

Purchase Date:

Purchased From:

Register your warranty online at:

traviswarranty.com

Or, mail your warranty card to:

Travis Industries House of Fire

4800 Harbour Pointe Blvd. SW

Mukilteo, WA 98275

Save Your Bill of Sale.

To receive full warranty coverage, you will

need to show evidence of the date you

purchased your heater. Do not mail your Bill

of Sale to us.

We suggest that you attach your Bill of Sale

to this page so that you will have all the

information you need in one place should the

need for service or information occur.

Listing Details

This appliance was listed by Intertek. The listing label is attached to the appliance near the gas control

valve. A copy is shown on page 43.

Massachusetts Approval

This manual has been submitted to the Massachusetts Board of State Examiners of Plumbers and Gas

Fitters

National Fireplace Institute

Table of Contents 3

Introduction and Important Information

Introduction................................................................ 2

Safety Precautions

Safety Precautions..................................................... 4

Features & Specifications

Features..................................................................... 6

Installation Options .................................................... 6

Heating Specifications................................................ 6

Dimensions................................................................ 6

Installation

Installation Warnings.................................................. 7

Packing List................................................................ 7

Additional Items Required.......................................... 7

Items Packed with the Face....................................... 7

Order of Installation.................................................... 7

Top Convection Deflector........................................... 8

Fireplace Requirements............................................. 8

Factory-Built (Metal) Wood-Burning Fireplace

Requirements....................................................... 9

Clearances................................................................. 10

Mantel Clearances ............................................... 10

Gas Line Requirements ............................................. 13

Gas Line Location ................................................ 13

Gas Inlet Pressure................................................ 13

Vent Requirements .................................................... 14

Altitude Considerations ........................................ 14

Vent Restrictor ..................................................... 15

Vent Installation.................................................... 15

Vent Location ....................................................... 16

Vent Configurations.............................................. 16

Vent Connector Removal and Installation ............ 17

Surround Panel Installation........................................ 19

Finalizing the Installation

Glass Frame Removal and Installation ...................... 20

Log Set Installation .................................................... 22

Steps for Finalizing the Installation............................. 26

Air Shutter Adjustment............................................... 27

Operation

Before You Begin....................................................... 28

Starting the Heater for the First Time......................... 29

Location of Controls................................................... 29

Normal Operating Sounds.......................................... 37

Normal Operating Odors............................................ 37

Maintenance

Maintaining Your Heater's Appearance...................... 38

Troubleshooting Table ............................................... 40

Wiring Diagram .......................................................... 41

Replacement Parts List.............................................. 42

Safety Label

Safety Label............................................................... 43

Warranty

Warranty ................................................................... 44

Optional Equipment

LP Conversion Instructions........................................ 45

Firebacks ................................................................... 48

Index

Index.......................................................................... 50

4Safety Precautions

IF YOU SMELL GAS:

* Do not light any appliance

* Extinguish any open flame

* Do not touch any electrical switch or plug or unplug anything

* Open windows and vacate building

* Call gas supplier from neighbor's house, if not reached, call fire department

This unit must be installed by a qualified installer to prevent the possibility of an explosion.

Your dealer will know the requirements in your area and can inform you of those people

considered qualified. The room heater should be inspected and cleaned before use and

at least annually by a qualified service person. More frequent cleaning may be required

due to excessive lint from carpeting, bedding material, etc.

The instructions in this manual must be strictly adhered to. Do not use makeshift methods

or compromise in the installation. Improper installation will void the warranty and safety

listing.

This heater is either approved for natural gas (NG) or for propane (LP). Burning

the incorrect fuel will void the warranty and safety listing and may cause an

extreme safety hazard. Direct questions about the type of fuel used to your dealer.

Check for a label on the flame adjust knob on the gas control valve (this is the best

place to check). You may also check for a label on the gas control valve body.

Ok

Contact your local building

officials to obtain a permit and

information on any installation

restrictions or inspection

requirements in your area.

Notify your insurance company

of this heater as well.

If the flame becomes sooty, dark

orange in color, or extremely tall,

do not operate the heater. Call

your dealer and arrange for

proper servicing.

It is imperative that control

compartments, screens, or

circulating air passageways of

the heater be kept clean and

free of obstructions. These

areas provide the air necessary

for safe operation. ?Do not operate the heater if it is

not operating properly in any

fashion or if you are uncertain.

Call your dealer for a full

explanation of your heater and

what to expect.

Gas

Do not store or use gasoline or

other flammable liquids in the

vicinity of this heater.





Do not operate if any portion of

the heater was submerged in

water or if any corrosion occurs.

Immediately call a qualified

service technician to inspect the

appliance and to replace any part

of the control system that has

been under water.

Safety Precautions 5

• Do not place clothing or

other flammable items on or

near the heater. Because

this heater can be controlled

by a thermostat there is a

possibility of the heater

turning on and igniting any

items placed on or near it.





• Light the heater using the

built-in igniter. Do not use

matches or any other

external device to light your

heater.

• Allow the heater to cool

before carrying out any

maintenance or cleaning.

• The viewing glass should be

opened only for lighting the

pilot or conducting service.

• Any safety screen or guard

removed for servicing must

be replaced prior to

operating the heater.

• Do not operate with the

glass removed or damaged.

• Never remove, replace,

modify or substitute any part

of the heater unless

instructions are given in this

manual. All other work must

be done by a trained

technician. Don't modify or

replace orifices.

• Operate the heater

according to the instructions

included in this manual.

• If the main burners do not

start correctly turn the gas

off at the gas control valve

and call your dealer for

service.

• Instruct everyone in the

house how to shut gas off to

the appliance and at the gas

main shutoff valve. The gas

main shutoff valve is usually

next to the gas meter or

propane tank and requires a

wrench to shut off.



• This unit is not for use with

solid fuel

• Do not place anything inside

the firebox (except the

included fiber logs).

• If the fiber logs become

damaged, replace with

Travis Industries log set.

This

Manual

• Do not throw this manual

away. This manual has

important operating and

maintenance instructions

that you will need at a later

time. Always follow the

instructions in this manual.

• Children and adults should

be alerted to the hazards of

high surface temperature

and should stay away to

avoid burns or clothing

ignition. Young children

should be supervised when

they are in the same room

as the heater.

• Plug the heater into a 120V

grounded electrical outlet.

Do not remove the

grounding plug.

• Don’t route the electrical

cord in front of, over, or

under the heater

• Travis Industries, Inc.

grants no warranty,

implied or stated, for the

installation or

maintenance of your

heater, and assumes no

responsibility of any

consequential damage(s).

6Features and Specifications

Features

- Ember Fyre™ Burner for "Wood Fire" Look

- Works During Power Outages (battery backup system)

- Blower and Remote Control Included

- Standing or Intermittent (GreenSmart) Pilot

- Convenient Operating Controls

- Variable-Rate Heat Output

- Accent Light

Installation Options

Residential or Mobile Home

Fireplace Insert

Masonry or Factory Built (Metal) Wood-

Burning Fireplace

Heating Specifications

Natural Gas Propane

Approximate Heating Capacity (in square feet)* 500 to 1,500 500 to 1,500

Maximum BTU Input Per Hour 31,000 31,000

* Heating capacity will vary with floor plan, insulation, and outside temperature.

Dimensions

18"

See the section "Vent Requirements"

for vent location.

1-1/4"*

19-1/2"

26-1/2"

15-1/8"

37-1/8"* 4x6 Panels

40-3/8"* 8x10 Panels

44-3/8"* 10x13 Panels

25"*

4x6 Panels

28-7/8"*

8x10 Panels

31-7/8"*

10x13 Panels

Weight:

115 Lbs.

* Includes trim

NOTE: on older style panels the 3/8" standoffs

are no longer required and may be bent back.

Electrical Specifications

Electrical Rating.............................................................115 Volts, 1.5 Amps, 60 Hz (180 watt)

Fuel:

This heater is shipped in natural gas (NG) configuration but may be converted to propane (LP) using

a conversion kit. The sticker on top of the gas control valve will verify the correct fuel.

Installation (for qualified installers only) 7

Installation Warnings

Failure to follow all of the requirements may result in property damage, bodily

injury, or even death.

This heater must be installed by a qualified installer who has gone through a

training program for the installation of direct vent gas appliances.

This appliance must be installed in accordance with all local codes, if any; if

not, follow ANSI Z223.1 and NFPA 54(88).

In Manufactured or Mobile Homes must conform with Manufactured Home

Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a

standard is not applicable, the Standard for Manufactured Home Installations,

ANSI/NCSBCS A225.1. This appliance may be installed in Manufactured

Housing only after the home is site located.

The heater is designed to operate on natural gas, or propane (LP).

All exhaust gases must be vented outside the structure of the living-area.

Combustion air is drawn from outside the living-area structure.

Notify your insurance company before hooking up this heater.

The requirements listed below are divided into sections. All requirements

must be met simultaneously. The order of installation is not rigid – the

qualified installer should follow the procedure best suited for the installation.

Packing List

LP Orifices and Orifice Gaskets

Log Set

Cove Covers

Panel Trim Rectangular & Button Plug (see page 19)

"Fireplace Altered" tag (attach to the fireplace)

Remote Control

Cover Plate for Receiver (with screws)

Additional Items Required

If using lp (propane) a conversion kit is required (sku 94400999 – GSR Stepper Motor Kit)

Faceplate

Simpson Duravent 6-5/8" to 3" & 3" Co-Linear Adapter with flashing

3" Diameter Gas Liner (2)

Direct Vent Cap (Use Simpson Duravent High Wind Cap)

Gas Line Equipment (shutoff valve, pipe, etc.)

Items Packed with the Face

Face with attachment hardware (Note: use the cove covers included with the heater)

Face Installation Instructions

Order of Installation

1 If the heater is to use LP (propane), convert the appliance (see page 45).

2Install gas line into the fireplace (do not connect to unit).

3Position the heater.

4Connect the gas line and gas vent to the appliance.

5Install the optional surround panels and trim. Attach the on/off switch.

6Follow the instructions under "Finalizing the Installation" on page 26.

8Installation (for qualified installers only)

Top Convection Deflector

Install the top convection deflector as

shown to the right.

The deflector is shipped on top of the

insert. The screws are shipped inside

the owner's pack.

Fireplace Requirements

Insert must be placed within a code-conforming masonry fireplace or tested and listed factory-built

(metal) wood-burning fireplace. Repair any fireplace damage prior to installation.

Because the insert uses a circulation blower, clean the fireplace, smoke shelf, and chimney prior to

installation.

This heater may be placed in a bedroom. Please be aware of the large amount of heat this appliance

produces when determining a location.

The DVS inserts 15-1/8" into the

fireplace.

Min. 26-1/2" - additional space may be required for gas line installation.

For tight fits (under 24") see the section "Removing the

Vent Connector"

See "Leveling Bolts" for details

on leveling the heater.

Min. 19-1/2"

The gas line and shutoff

valve should be installed

prior to insert placement.

Attach the "This fireplace has been altered..." plate

to the fireplace (use two screws or other suitable

method). You may wish to place it in a location

where it will be covered by the surround panels.

Installation (for qualified installers only) 9

Factory-Built (Metal) Wood-Burning Fireplace Requirements

NOTE: Any parts that are removed must be removed in a way that would allow them to be re-installed if

the insert is ever removed (removal of rivets or screws is acceptable).

The damper ("A") and grate (with log set) ("B") must be removed (see the illustration below)

The smoke shelf ("C"), internal baffles ("D"), screen ("E"), masonry lining or refractory ("G" & "I"), and

metal or glass doors ("F") may be removed (if applicable)

The fireplace must be permanently marked to

indicate that it has been altered and is no longer

suitable for burning solid fuel (wood), unless the

removed parts are re-installed. Cutting of any

sheet metal parts is prohibited, except the metal

floor (“J”) as noted below.

The insulation ("H"), and any structured rigid frame

members must not be removed or altered (side and

top of door frame, side and top of the face of the

fireplace, metal sides, etc.).

The metal floor ("J") may be removed to allow

additional room for installation of the insert. If the

floor is removed the insert must be placed directly

on the metal base of the metal fireplace.



C

B

F

I

D

E

A











G





H



J

Hearth Requirements

The heater and face must not contact combustible surfaces. A non-combustible hearth extension is not

required. However, if the heater is installed next to the floor, we recommend a hearth to protect the

flooring surface from discoloration or other negative impact from the heater.

Leveling Bolts

This heater includes

front and rear leveling

bolts to accommodate

fireplaces with a step-

down firebox.

NOTE: To access the

rear leveling bolts,

remove the burner (see

page 48).

Use a 1/2” socket wrench

(with extension) to adjust

the leveling bolts.

To access the rear leveling bolts remove these

access plates (replace access plate and

gasket after adjustment).

Front Leveling Bolts

Rear Leveling Bolt





10 Installation (for qualified installers only)

Clearances

Due to the high temperature of the heater, it should be located out of traffic and away from furniture and

draperies.





Side

Wall

Combustible or Non-Combustible Mantel

Combustible Top Facing



Non-Combustible

Facing

Minimum Clearances

k

l

m

n

x

Sidewall to Insert

Side Facing

Top Facing

Mantel

Extension onto Hearth

4-1/2"

35" *

1-1/4"

l

k

x

n

m* Measured from the base of the insert.

Mantel Clearances

The maximum mantel depth is 12”.

NOTE: The combustible area above the facing must not protrude more than 3/4" from the facing. If it

does, it is considered a mantel and must meet the mantel requirements listed in this manual.

Installation (for qualified installers only) 11

Modifying the Face Connector for Discovery, Rosario, and Artisan Faces

The Discovery, Rosario, and Artisan face require re-positioning of the face connector. See the directions

below for details.

Face Connector

Bracket

Remove the face connector bracket

from the heater (on both sides). Re-attach the face connector to the

heater using the forward mounting holes.

12 Installation (for qualified installers only)

Face Mounting Brackets -- Arched, Metropolitan, Artisan Vict. Lace Faces

Some Arched, Artisan, Metropolitan, and Victorian Lace Faces include old brackets that will not mount to

the heater (see illustration below). For these faces, make sure to use the new mounting brackets (either

included with the heater or available through your dealer - SKU 250-00519).

WARNING: When attaching the Victorian Lace Face, do not over-tighten the screws. Over-tightening

the screws may damage the face – simply tighten the screws until they contact the face.

Old Arched,

Metropolitan, or

Artisan Bracket

New

Bracket

Old Victorian

Lace

Bracket

Install the face mounting brackets to

the heater with the included nuts.

NOTE: The brackets

install with this pair of

closely spaced

flanges at the top.

NOTE: The face attaches to the brackets with the screws included with the face – see the instructions

included with the face.

Mounting the Bedford Face

Some Bedford Faces include old brackets that will

not mount to the heater. For these faces, make

sure to use the new DVS Insert EF II Face

Upgrade Kit (either included with the face or

available through your dealer - SKU 250-00029).

The kit lowers the face and surround panels 1-1/4”.

This means you must install this with a raised

fireplace or raise the insert 1-1/4” above the hearth.

To do this you may extend the leveling bolts or

place bricks or other non-combustible under the

insert.

1-1/4”

Installation (for qualified installers only) 13

Gas Line Requirements

MASSACHUSETTS INSTALLATIONS - WARNING:

THIS PRODUCT MUST BE INSTALLED BY A LICENSED PLUMBER OR GAS FITTER WHEN INSTALLED WITHIN THE

COMMONWEALTH OF MASSACHUSETTS.

OTHER MASSACHUSETTS CODE REQUIREMENTS:

Flexible connector must not be longer than 36 inches.

Shutoff valve must be a “T” handle gas cock.

Only direct vent sealed combustion products are approved for bedrooms or bathrooms.

Fireplace dampers must be removed or welded in the open position prior to the installation of a fireplace insert or gas log.

A carbon monoxide (CO) detector is required in the same room as the appliance.

The gas line must be installed in accordance with all local codes, if any; if not, follow ANSI 223.1 and

the requirements listed below.

A manual shutoff valve is required within 3’ of the heater. It should be placed upstream of the flex

line (if used) and may be installed behind the access door inside the heater. ).

The heater and gas control valve must be disconnected from the gas supply piping during any

pressure testing of that system at test pressures in excess of 1/2 psig. For pressures under 1/2 psig,

isolate the gas supply piping by closing the manual shutoff valve.

Leak test all gas line joints and the gas control valve prior to and after starting the heater.

This heater is designed either for natural gas or for propane (but not for both). Check the sticker on

the top of the gas control valve to make sure the correct fuel is used (see illustration on page 4).

Installation must be performed by a qualified installer, service agency or the gas supplier (In

Massachusetts a licensed plumber/gasfitter).

Gas Line Location

The gas inlet

accepts a 1/2" MPT.

2-3/4"

Shutoff Valve (secured to

the fireplace insert)

Fireplace Opening

Gas Inlet Pressure Standard Input Pressure

Natural Gas 7" W.C. (1.74 kPA)

Propane 13" W.C. (2.73 kPA)

If the pressure is not sufficient, make sure the piping used is large enough, the supply regulator is

adequately adjusted, and the total gas load for the residence does not exceed the amount supplied.

The supply regulator (the regulator that attaches directly to the residence inlet or to the propane tank)

should supply gas at the suggested input pressure listed above. Contact the local gas supplier if the

regulator is at an improper pressure.

Electrical Connection

Route the power cord out of the access hole on the right side of the appliance.

Plug the power cord into a grounded 120 Volt outlet (do not remove the grounding pin).

The electrical connection may also be made using the optional Wiring Kit (SKU 97200315).

14 Installation (for qualified installers only)

Vent Requirements

The gas appliance and vent system must be vented directly to the outside of the building, and never

be attached to a chimney serving a separate solid fuel or gas-burning appliance. Each direct vent

gas appliance must use it's own separate vent system.

Make sure the exhaust pipe on the heater connects to the exhaust portion of the cap. The

illustrations below show how the flex liners should be attached.

The exhaust vent must reline the entire length of the chimney and terminate above the chimney top

Be careful not to crimp or rupture the liner when bending it into chimney offsets

When installed, the vent must meet all of the vent manufacturer's requirements

Make sure to use the following:

3” UL 441 or 1777 Gas Liner for Exhaust and Air Inlet

Simpson Duravent 6-5/8” to 3” & 3” Co-Linear Adapter and Flashing

Simpson Duravent High-Wind Vertical Termination Cap



Max. Ht. 40'

Min. Ht. 8'

Inlet

(3" dia.)

Exhaust

(3" dia.)

Max. 2'

offset

Altitude Considerations

This heater has been tested at altitudes ranging from sea level to 8,000 feet (2,400 M). In this testing

we have found that the heater, with its standard orifice, burns correctly with just an air shutter

adjustment.

Failure to adjust the air shutter properly may lead to improper combustion which can create a safety

hazard. Consult your dealer or installer if you suspect an improperly adjusted air shutter.

Installation (for qualified installers only) 15

Vent Restrictor

WARNING: Restrictor adjustment should only be done by a qualified installer.

Only those installations determined to be over-drafting require this adjustment. The best indication of

over-drafting is a hyper-active flame pattern (flames that move too quickly). If the air shutter is

constricted, the flames become short and yellow, yet still very active. Over-drafting may affect the pilot,

but this is not the best way to determine over-drafting. Over-drafting is most likely in tall venting

configurations (especially if using an “Exhaust Only Re-Line”). Do not over-restrict the vent (this leads to

ghosting or lifting flames - reduce restrictor setting).

Remove the face.

To Adjust the Restrictor:

To Access the Restrictor:

This restrictor is in position 1

(factory setting). This restrictor is in

position 2.

Adjustment

Bracket

To adjust, lift up on the

adjustment plate and push it back

(use pliers if necessary).

WARNING: Use a glove to protect

your hand from burns.

Adjustment

Plate

#2#3

1

2

Determine a restrictor position. Start low (move

the restrictor a maximum two positions at a time)

and thoroughly test the heater before adjusting further.

Lift up the adjustment plate and move it so the correct notch falls

into the slot on the adjustment bracket.

#4 #5 #6

#1

Vent Installation

Inlet (3")

Exhaust (3")

Inlet

Exhaust

High Wind

Termination Cap

Simpson Duravent

6-5/8" to 3" & 3"

Co-Linear Adapter

3" dia. Gas Liner







Use hose-clamps

to secure the vent.

Alternative Method: use high-temperature

silicone and secure with screws.











Use hose-clamps to

secure the vent.

Alternative Method: use

high-temperature

silicone and secure with

screws.

16 Installation (for qualified installers only)

Vent Location

A vent restrictor is built into the appliance to adjust the flow rate of exhaust gases. This ensures

proper combustion for all vent configurations. Depending upon the vent configuration, you may be

required to adjust the restrictor position.

1-1/4”

Center Line Inlet (3” Dia.)

Exhaust (3” Dia.)

Fireplace

Opening

1-1/4”

2-5/8”

15-1/8”

6-1/8”

NOTE: Vent location changes based

upon restrictor position. Position # 1 is

shown to the right. Each restrictor

position moves the vent location forward

(toward the fireplace opening)

approximately 1/4”.

Vent Configurations





Factory Built (Metal) Wood-

Burning Fireplace

Inlet & Exhaust Re-Line































Exhaust Only Re-Line

Direct Vent Cap

Recommended Block-Off

Plate (non-combustible

metal and/or insulation).

Prevents odors from

chimney entering room.

6-5/8" to 3" & 3" Colinear

Adapter & Flashing



A block-off plate must

seal the intake to the

chimney space. This

way air is drawn down

the chimney for

combustion air.

Block-Off Plate

(non-combustible

materials)

NOTE: You may use either re-line configuration with a masonry or zero-clearance fireplace.

Inlet

Masonry Fireplace

Any cracks or

damage inside the

chimney must be

repaired.

Exhaust

3" dia.

Gas Liner

Inlet

3" dia. Gas Liner

Exhaust

3" dia. Gas Liner

Installation (for qualified installers only) 17

Vent Connector Removal and Installation

The vent connector is shipped attached to the insert, but may be removed to facilitate tight

installations. See the directions below for installation.

1. Route the flex vent through the chimney from above (leave an extra 3' at the top). Make sure the flex

is thoroughly stretched.

2. Remove the vent connector and attach it to the flex vent (see the instructions on the following page).

NOTE: be careful of the anti-seize on the connector – it will stain clothing, etc.

3. Pull on the flex vent until the vent connector is at the same height as the insert. Temporarily attach

the flex vent to the top of the chimney (leave extra slack).

4. Slide the insert into place, guiding the vent connector into the guides on top of the insert.

5. Attach the vent connector to the appliance (see the following page for details).

6. Remove any excess slack in the flex line and attach the vent termination.

4



















3

































2

1



5

























6







2

18 Installation (for qualified installers only)

Vent Connector Removal and Installation (continued)

Vent Connector Removal

Slide the

connector to the

rear. It will

"snap" out.

Pull the vent connector

rod forward.

Vent Connector Installation

Attach the flex vent to

the vent connector.

Slide the insert

into place, lining

up these guides

with the edges of

the vent

connector.

Push the vent

connector rod in, lift

slightly, and line it up

so the tabs on the end

of the rod engage the

hooks on the vent

connector

Pull on the vent connector rod until the

vent connector snaps into place. Slide

the vent connector rod in to conceal it.



























WARNING: The anti-seize on

the vent connector can stain

clothing, carpets, or other

items.

Installation (for qualified installers only) 19

Surround Panel Installation

PANEL SIZE WIDTH HEIGHT PART #

8" x 10" Rectangular 40-3/8" 28-7/8" 96100301

Arched (8” x 10”) 40-3/8" 28-7/8" 98500605

10” x 13” Rectangular 44-3/8" 31-7/8" 96100302

4” x 6” Rectangular 37-1/8” 25” 96100300

NOTE: The insert may be installed

without surround panels.

1 Follow the directions to the

right to install the side panels.

2 Follow the directions below to

install the top panel.

Line up each side surround

panel and insert two screws from

the inside to secure in place.

5/16" Nutdriver

Pre-thread the holes on the surround

panels with the screws included in the

surround panel kit.

b

a

Run the power cord to

the right of the insert.

Top

Panel

Top Trim

"L" Bracket

Right Side Trim

"L" Bracket

Right Side

Trim

Top Trim

Trim Installation:

Insert one leg of each "L" bracket into the top

and side trim piece. Align the trim to form a

precise corner, then tighten the two set

screws with a small standard screwdriver.

Slide the trim over the panels. Place the

spring clips behind the panels at the locations

shown. This keeps the trim tight against the

panel.

Micro (1/16”)

Standard

Screwdriver



Spring

Clips

Optional Knock-Out

An optional knock-out is provided if the power cord is

routed behind the surround panel.

Install the top panel so

the tabs insert into the

joggle clips on the top

panel







b

a

3 Install the rectangular plug and button plug

into the surround panel trim to conceal the

two holes on the surround panel trim.

20 Finalizing the Installation

Glass Frame Removal and Installation

Warning: The appliance must be completely cool before removing the glass.

Warning: Do not strike or slam the glass.

Open the four latches holding the glass

frame in place (start with the two below

the glass) - follow the directions shown

to the right.

a

Glass Frame

Lift the glass frame up

and pull it forward to

remove. NOTE:

You may need to lift the

glass frame while re-

attaching.

b

Re-Attaching the Glass Frame:

a) Hang the glass frame on the firebox.

b) While holding in place, attach the upper latches

(follow the instructions to the right in reverse).

c) Lift the glass frame slightly and attach the lower latches.

NOTE:

Replace the cove

covers for those faces

using them.

Twist 1/4 turn.

The latch will then

disengage from the

latch bracket.

Push in on

the latch.

Top of

Firebox

Glass

Latch

Travis Industries DVS GSR Insert User manual

Popular Burner manuals by other brands
