Travis Industries Large Flush User manual

Large Flush Wood Insert
(Rectangular)
with Hybrid-Fyre™ Technology
Owner's Manual
•Masonry Fireplace Insert
•Zero-Clearance (Metal) Fireplace Insert
Save these instructions for future reference
SAFETY NOTICE:
If this appliance is not properly installed, a house fire may result.
For your safety, follow the installation directions. Contact local
building or fire officials about restrictions and installation
inspection requirements in your area.
Dragon Wholesaling Pty. Ltd.
Unit 2, 16 Lexington Drive
Bella Vista NSW
Australia 2153
©Copyright 2012, T.I.
$10.00 100-01291
4111118
Tested by:
HRL Technology
Tramway Road, Morwell 3840
Victoria
Tested to: AS/NZS 4012/4013: 1999
Report Number: HCMG/12/022

2 Introduction
© Travis Industries 100-01291 4060512
Introduction
We welcome you as a new owner of a Large Flush Wood Insert. In purchasing a Large Flush Wood Insert
you have joined the growing ranks of concerned individuals whose selection of an energy system reflects
both a concern for the environment and aesthetics. This insert is one of the finest appliances the world
over. This manual will explain the installation, operation, and maintenance of this appliance. Please
familiarize yourself with the Owner's Manual before operating your appliance and save the manual for future
reference. Included are helpful hints and suggestions which will make the installation and operation of your
new appliance an easier and more enjoyable experience. We offer our continual support and guidance to
help you achieve the maximum benefit and enjoyment from your appliance.
Important Information
No other Large Flush Wood Insert appliance has the
same serial number as yours. The serial number is
stamped onto the label on the back of the appliance.
This serial number will be needed in case you require
service of any type.
Model: Large Flush Wood Insert_
Serial Number:
Purchase Date:
Purchased From:

Table of Contents 3
© Travis Industries 100-01291 4060512
Introduction ......................................................2
Important Information......................................2
Installation Options..........................................6
Features ............................................................6
Heating Specifications.....................................6
Dimensions.......................................................6
Installation Warnings.......................................7
Planning the Installation..................................7
Preparation for Installation....................................7
Additional Accessories Needed for Installation.....7
Fireplace Requirements ..................................8
Fireplace Altered Tag.......................................8
Insert Placement Requirements .....................9
Mantel Requirements.....................................10
Masonry Fireplace Requirements ................10
Drafting Performance ....................................10
Insert Rollers ..................................................10
Leveling Bolt Installation...............................11
Fettle Installation............................................11
Flue Installation..............................................12
Sealing the Flue to the Insert..............................12
Surround Panel Installation ..........................13
Face Installation.............................................13
Re-Routing the Electrical Cord to the Left
Side..................................................................14
Safety Notice ..................................................15
Before Your First Fire....................................15
Verify the Installation...........................................15
Curing the Paint..................................................15
Over-Firing the Stove..........................................15
Opening the Door...........................................16
Opening the Door................................................16
Closing the Door.................................................16
Bypass Operation ..........................................17
Starting a Fire.................................................18
Adjusting the Burn Rate................................19
Approximate Air Control Settings:.......................19
Ash Removal..................................................19
Blower Operation...........................................20
Re-Loading the Stove....................................20
Overnight Burn...............................................20
Normal Operating Sounds ............................20
Hints for Burning ...........................................21
Selecting Wood..............................................21
Why Dry Wood is Key.........................................21
Wood Cutting and Storage..................................21
Troubleshooting.............................................22
Daily Maintenance (while stove is in use)...23
Remove Ash (if necessary).................................23
Clean the Glass (if necessary)............................23
Monthly Maintenance (while appliance is in
use)..................................................................24
Door and Glass Inspection..................................24
Door Latch Adjustment .......................................24
Creosote - Formation and Need for Removal .....24
Yearly Maintenance .......................................25
Touch-Up Paint...................................................25
Cleaning the Air Duct and Blower (if applicable).25
Firebrick and Baffle Inspection............................25
Cleaning the Catalytic Combustor.......................26
Door Parts.......................................................27
Replacing the Glass............................................27
Replacing the Door Gasket.................................27
Blower and Electrical Parts ..........................27
Firebox Parts..................................................28
Baffle Parts .........................................................28
Baffle Removal....................................................28
Combustor ..........................................................28
Air Tube Removal & Replacement...............29
Brick Removal & Replacement ...........................30
Catalytic Combustor Temperature Probe
Installation Instructions ................................31
GreenStartTM Igniter – Firebrick and Housing
Installation......................................................32
Listing Label........................................................36

4 Safety Precautions
© Travis Industries 100-01291 4060512
The viewing door must be
closed and latched during
operation.
Smoke from this appliance may
active a smoke detector when
the door is open.
Never block free airflow through
the air vents on this appliance.
Gasoline or other flammable
liquids must never be used to
start the fire or "Freshen Up" the
fire. Do not store or use
gasoline or other flammable
liquids in the vicinity of this
appliance.
This appliance is designed and
approved for the burning of cord
wood only. Do not attempt to
burn any other type of fuel other
than cord wood in this
appliance, it will void all
warranties and safety listings.
Ashes must be disposed in a
metal container with a tight lid
and placed on a non-
combustible surface well away
from the home or structure.
Do not touch the appliance while
it is hot and educate all children
of the danger of a high-
temperature appliance. Young
children should be supervised
when they are in the same room
as the appliance.
Keep furniture, drapes, curtains,
wood, paper, and other
combustibles a minimum of 36"
away from the front of the
appliance.
This appliance must be properly
installed to prevent the
possibility of a house fire. The
instructions must be strictly
adhered to. Do not use
makeshift methods or
compromise in the installation.
Contact your local building
officials to obtain a permit and
information on any installation
restrictions or inspection
requirements in your area.
Notify your insurance company
of this appliance as well.
Inspect the chimney connector
and chimney at least twice
monthly and clean if necessary.
Creosote may build up and
cause a house fire.
Do not connect this appliance to
any chimney serving another
appliance.
This appliance must be
connected to a listed high
temperature (UL 103 HT)
residential type chimney or an
approved masonry chimney with
a standard clay tile, or stainless
steel liner.
Gas
ASHES
36"
Ok
Type
HT Clay
Liner

Safety Precautions 5
© Travis Industries 100-01291 4060512
Never try to repair or replace
any part of this appliance unless
instructions are given in this
manual. All other work must be
done by a trained technician.
Do not place clothing or other
flammable items on or near this
appliance.
Allow the appliance to cool
before carrying out any
maintenance or cleaning.
Do not make any changes or
modifications to an existing
masonry fireplace or chimney to
install this appliance.
Do not make any changes to the
appliance to increase
combustion air.
Maintain the door and glass seal
and keep them in good
condition.
Do not operate this heater with
broken or missing glass.
Avoid placing wood against the
glass when loading. Do not
slam the door or strike the glass.
Over-firing the appliance may
cause a house fire. If a unit or
chimney connector glows, you
are over-firing.
Do not throw this manual away.
This manual has important
operating and maintenance
instructions that you will need at
a later time. Always follow the
instructions in this manual.
Do not use a grate or other
device to elevate the fire off of
the firebox floor. Burn the fire
directly on the bricks.
Travis Industries, Inc. grants
no warranty, implied or
stated, for the installation or
maintenance of your
appliance,and assumes no
responsibility of any
consequential damage(s).



This
Manual

6 Stove Installation (for qualified installers only)
© Travis Industries 100-01291 4060512
Installation Options
•Masonry Fireplace Insert
•Zero-Clearance (Metal) Fireplace Insert
Features
•3 Cubic Foot Firebox Volume
•Single Air Control
•Accepts Logs Up to 610mm Long
•Steel Plate Construction (up to 8mm)
•Heavy Duty Refractory Firebrick
•Standard High-Tech Blower
Heating Specifications
Approximate Maximum Heating Capacity (in square meters)* 140 to 230
Maximum Burn Time Up to 12 Hours
* Heating capacity will vary depending on the home's floor plan, degree of insulation, and the outside
temperature. It is also affected by the quality and moisture level of the fuel.
Dimensions
Figure 1
(a) Measure clearances from base of insert (b) Fireplace Opening
6.25"
159 mm
530 Lbs. (236 Kg)
6" (153mm) Dia.
19"
483mm
23.5"
597mm
a
b
31" 788mm
22"
559mm
20.75"
528mm
9.75"
248mm

Fireplace Insert Installation (for qualified installers only) 7
© Travis Industries 100-01291 4060512
SAFETYNOTICE:
Please read this entire manual before you install and use your new room heater. Failure to
follow instructions may result in property damage, bodily injury, or even death. Contact
local building or fire officials about restrictions and installation inspection requirements in
your area.
Installation Warnings
•Failure to follow all of the requirements may result in property damage, bodily
injury, or even death.
•This heater must be installed by an authorised installer who has gone through
a training program for the installation of direct vent gas appliances.
•This appliance must be installed in accordance with the manufacturer's
installation instructions, local gas fitting regulations, municipal building
codes, water supply regulations, electrical wiring regulations, AS 5601 / AG
601—2000, Gas installations and any other relevant statutory regulations.
•This heater is either approved for natural gas (NG) or for propane (LP).
Burning the incorrect fuel will void the warranty and safety listing and may
cause a house fire. Direct questions about the type of fuel used to your
dealer. To determine which fuel your heater is using, check for a label on the
flame adjust knob on the gas control valve (this is the best place to check).
You may also check for a label on the gas control valve body.
•All exhaust gases must be vented outside the structure of the living-area.
Combustion air is drawn from outside the living-area structure.
•Notify your insurance company before hooking up this heater.
•The requirements listed below are divided into sections. All requirements must
be met simultaneously. The order of installation is not rigid – the authorised
installer should follow the procedure best suited for the installation.
Planning the Installation
We suggest that you have an authorized Travis Industries dealer install your fireplace insert. If you
install the fireplace insert yourself, your authorized dealer should review your installation plans.
Check with local building officials for any permits required for installation of this fireplace insert and
notify your insurance company before proceeding with installation.
Preparation for Installation
•Check for damage to the exterior of the fireplace insert (dents should be reported, scratches can be
fixed by applying touch-up paint).
•Check the interior of the firebox (replace cracked firebrick and make sure baffle is in place).
The fireplace insert can be lightened by removing the firebricks and baffle (pg. 30) - replace before
operation.
Additional Accessories Needed for Installation
•Face
•Surround Panels (see page13)

8 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01291 4060512
Fireplace Requirements
Figure 2 shows the minimum size requirements for the type of fireplace used.
Minimum Fireplace Size
a Height (front) 23.5" 597mm
b Height (rear) 22" 559mm
c Width (front) 33”* 839mm*
d Width (rear) 20.75” 528mm
e Depth 19” 483mm
f Hearth Depth
NOTE: Base of insert must be a
minimum 1” above combustible floor
surfaces (carpet, wood, etc.). See
“Hearth Requirements” for further
details.
See “Hearth
Requirements”
g Hearth Width See “Hearth
Requirements”
h Facing Width 41.25” 1045mm
i Facing Height Above Base of Insert 47.75” 1210mm
j Mantel Height Above Base of Insert 51.25” 1300mm
Figure 2 * Includes 2” (51mm) for power cord installation.
Fireplace Altered Tag
Attach the "This fireplace has been altered..." plate to the fireplace (use two screws or other suitable
method). You may wish to place it in a location where it will be covered by the surround panels.
a
ce
f
b
d
h
i
j
g
Non-Combustible Hearth
Combustible Mantel
Non-Combustible Facing

Fireplace Insert Installation (for qualified installers only) 9
© Travis Industries 100-01291 4060512
Insert Placement Requirements
•The insert must be placed so that no combustibles are within, or can swing within (e.g. drapes,
doors), 36" (915mm) of the front of the insert ( Figure 3 “q”).
•Insert and hearth must be installed on a level, secure floor
•The minimum clearances, facing, and hearth requirements in Figure 3 must be met.
Minimum Clearances
k Sidewall 10.5” 267mm
l Side Facing (non-combustible) 5.125” 131mm
m Top Facing (non-combustible) 47.75” 1210mm
n Mantel (combustible) 51.25” 1300mm
o Front Hearth
NOTE: Base of insert must be a minimum 1” above
combustible floor surfaces (carpet, wood, etc.). See
“Hearth Requirements” for further details.
See “Hearth Requirements”
p Side Hearth See “Hearth Requirements”
q Front of Insert 36” 915mm
r Mantel Breastplate (max. 1-1/8” 30mm thick) 47.75” 1210mm
s Mantel Column (max. 3.375” 80mm deep) 5.875” 150mm
x Extension Onto Hearth (from front edge of insert) 0” 00mm
Figure 3
Combustible Top Facing


























Side
Wall
Non-Combustible
Hearth
Facing
q
l
p
o
m
Combustible Mantel
n
Max. 1"
26mm
r
k
s
x

10 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01291 4060512
Mantel Requirements
•See Installation Clearances Addendum.
Masonry Fireplace Requirements
•Must utilize a positive connection (full reline)
•Entire fireplace, including chimney, must be clean and undamaged. Any damage must be repaired
prior to installation of the insert.
•Chimney height: 15' (4.5M) minimum; 33' (10M) maximum (measured from base of insert).
•Entire fireplace, including chimney, must meet local building requirements.
Hearth Requirements
•Non-combustible hearth must extend 12" (300mm) in front of the insert and 4.625" (118mm) from
both sides of the insert
•When installed over a timber floor:
Hearth must be a minimum of 75mm of non-
combustible masonry with 16mm of FC sheet
along with offcuts to provide air flow (see
illustration to the right).
NOTE: if using the “Lopi Flush Wood Zero
Clearance Box” (www.lopi.com.au) see the
instructions included with the zero clearance
box for hearth requirements.
•When installed over a cement floor:
Hearth must be non-combustible.
Drafting Performance
This appliance relies upon natural draft to operate. External forces, such as wind, barometric pressure,
topography, or factors of the home (negative pressure from exhaust fans, chimneys, air infiltration, etc.),
may adversely affect draft. Travis Industries cannot be responsible for external forces leading to less
than optimal performance.
Insert Rollers
Two rollers are built into the back edge of the insert. This
allows the insert to be rolled into position by lifting the front
of the insert and pushing it into position (see Figure 4).
Figure 4

Fireplace Insert Installation (for qualified installers only) 11
© Travis Industries 100-01291 4060512
Leveling Bolt Installation
MASONRY NOTE: Place a metal plate below the
bolts on masonry fireplaces to prevent damage to the
floor brick.
Two leveling bolts are pre-installed on the insert to
allow for proper leveling within the fireplace. To
access the bolts, remove the back corner firebricks
and cover plates “a” and “b”). The bolts are pre-
threaded to a weld-nut on the base of the insert. Use
a 3/4” (19mm) socket wrench to screw the bolts down
(clockwise) until the insert is level (see “c”).
SEALING THE COVER PLATE: We recommend
sealing the cover plate with furnace cement (place on
underside of cover plate).
BOLT LENGTH: The included bolts allow
approximately 26mm of rise. If additional rise is
required, use a longer 1/2-13 thread bolt. Make sure
the additional bolt length does not interfere with the
cover plate.
Figure 5
Fettle Installation
The fettle is designed to prevent ash from spilling out of the firebox opening. It is held in place with two tabs
and slots at the front of the firebox (see pictures below). The fettle is optional and may be removed if desired.
a
b
c

12 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01291 4060512
Flue Installation
RLH Chim-Flex Starter Sections
RLH manufactures starter
sections in straight or
angled configurations to
suit your application.
They are secured from
inside the firebox, making
installation much easier.
Contact RLH for additional
details:
www.chim-flex.com
Sealing the Flue to the Insert
This insert utilizes a catalytic combustor to increase efficiency and decrease emissions. This increases
the air resistance inside the firebox, making the flue connection especially important. To insure proper
draft, and to prevent smoke spillage during re-loading, it is crucial for the flue to be sealed with
fireplace cement. If an adapter is used, both joints to the liner and to the insert must be sealed. Use a
generous amount of fireplace cement at every connection (where the flue connects to the insert and at
every joint).
In addition, we recommend using non-combustible fiberglass insulation to seal the fireplace enclosure.
By sealing the top and bottom of the chimney, and the surround panels, you will be ensuring outside air is
not pulled into the chimney.
Included in the owner’s pack are
three “flue brackets” and six self-
drilling screws. Use these
components to secure the flue to the
fireplace insert.
Flue Opening
Flue (flexible or rigid)
Flue Bracket
Self-Drilling Screws


The liner must be stainless
steel connector or flexible vent.
Follow the liner manufacturer's
insturctions for installation and
support.
















Remove damper or wire it open
Airtight Insulated
Clean-Out
Combustible Mantle
Flue Liner
See the section "Insert
Placement Requirements" for
minimum clearances and
hearth required.

Cap (prevents water from
entering)
Install a non-combustible
cover plate to prevent water
from entering the chimney
Seal the flue connection to the insert








We recommend using non-combustible
fiberglass insulation to seal the fireplace
enclosure (chimney top and bottom, and
surround panels)
Furnace
Cement









Fireplace Insert Installation (for qualified installers only) 13
© Travis Industries 100-01291 4060512
Surround Panel Installation
Width Height Part#
Standard Size 1067 mm 826 mm 96100392
1. Before installing, the insert should be in place with the flue attached. Attach the brackets as
shown below, using the screws included in the hardware pack with the insert. Make sure the
brackets are flush with the front of the convection chamber.

2. Attachthesurroundpanelasshownbelow.
HINT: When installing the panel, route the wires through the notch on the bottom of
the panel (either side).
Face Installation
There are several face options available for this fireplace insert. Refer to the instructions included with
your face.

14 Fireplace Insert Installation (for qualified installers only)
© Travis Industries 100-01291 4060512
Re-Routing the Electrical Cord to the Left Side
The power cord is connected to the right side of the insert when it leaves the factory. It may be re-routed
to the left side following the directions below. Do this procedure before installing the surround panels.
•Disconnect the Molex connector and remove the power cord following the directions below.
•Connect the power cord to the left side following the directions below.
NOTE: An additional knockout is
provided if using the insert wiring kit.
Route the power through one hole,
the rheostat through the other.
Power
Cord
Rheostat Wires
Disconnect the molex connector
leading from the power cord.
Use pliers to compress the strain relief
from the top and bottom while pulling it
out of the hole in the side of the insert.
Remove the power cord.
Leave the rheostat
wires in place.
Make sure the power cord is
disconnected prior to
conducting these steps.
Remove the button plug from the left side.
Re-attach the strain relief to the left side (use
pliers to compress the strain relief from the top
and bottom while pushing it into the hole).
Power
Cord
Attach the molex connector on the
power cord to the molex connector
on the left side of the insert.

Operating Your Appliance 15
© Travis Industries 100-01291 4060512
Safety Notice
If this appliance is not properly installed, a house fire may result. For your safety, follow the installation
directions. Contact local building or fire officials about restrictions and installation inspection
requirements in your area.
Read and follow all of the warnings on pages 4 and 5 of this manual.
Before Your First Fire
Verify the Installation
Before starting the stove, verify that the stove is properly installed and all of the requirements in this
manual have been followed.
Keep all flammable materials 36" away from the front of the stove (drapes, furniture, clothing, etc.).
Curing the Paint
This heater uses a heat-activated paint that will emit some fumes while
starting the first fire. Open doors and windows to the room to vent these
fumes. This typically lasts two to four hours. You may also notice oil burning
off of the interior of the heater. This rust-stopping agent will soon dissipate.
Door Gasket - The door gasket might adhere to the paint on the front of the
heater. Leave the door slightly ajar for the first fire and be careful when
opening the door after the first fire.
Over-Firing the Stove
This stove was designed to operate at a high temperature. But due to differences in vent configuration,
fuel, and draft, this appliance can be operated at an excessive temperature. If the stove top or other area
starts to glow red, you are over-firing the stove. Shut the air control down to low and allow the stove to
cool before proceeding.
Over-firing may lead to damage of plated surfaces. If any portion of the heater glows red, it is
considered over-firing and will void the warranty.








2 to 4 hours

16 Operating Your Appliance
© Travis Industries 100-01291 4060512
Opening the Door
The door becomes hot during use. Use a glove to open the door if the handle is hot.
To prevent smoke from entering the room, open the bypass before opening the door (see following page
for directions). You can also open the door a small amount and let air enter the firebox.
Opening the Door
Closing the Door

Operating Your Appliance 17
© Travis Industries 100-01291 4060512
Bypass Operation
The bypass controls the flow of smoke inside the heater. When pulled out, smoke goes directly up the
flue, creating more draft. When pushed in, the smoke goes around the baffle, utilizing the secondary
combustion and making the heater more efficient.
•When starting or re-loading, pull the bypass out, if necessary.
•During normal operation, push the bypass in.
Bypass Pushed In
Used for normal operation
Bypass Pulled Out
Used for starting and re-loading
Use the included pull tool
to operate the bypass rod


















18 Operating Your Appliance
© Travis Industries 100-01291 4060512
Starting a Fire
Since the dawn of time man has debated the best way to start a fire. Some use the boy-scout "tee-pee";
some prefer the "tic-tac-toe" stack. Either way, review the hints and warnings below to ensure proper fire
starting.
•Make sure the air control is pushed in and the by-pass pulled out. If additional air is needed, open
the doors 7mm during the first five minutes of start-up.
Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start
or "freshen up" a fire in this stove. Keep all such liquids well away from the stove while it is in use.
DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. DO NOT BURN GARBAGE OR
FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. Do not place such fuel
within space heater installation clearances or within the space required for charging and ash removal.
If using a fire-starter, use only products specifically designed for stoves - follow the manufacturer's
instructions carefully.
HOT WHILE IN OPERATION. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT
MAY CAUSE SKIN BURNS.
If the smoke does not pass up the chimney, ball up one sheet of newspaper, place it in the center of the
firebox and light it. This should start the chimney drafting (this eliminates "cold air blockage").
Use plenty of kindling to ensure the stove reaches a proper temperature. Once the kindling is burning
rapidly, place a few larger pieces of wood onto the fire.
Starting a “Top-Down Fire”
One particularly successful method for starting a fire is to
stack several large pieces of wood in the center of the stove
(see the illustration to the right). Then place a several wads
of newspaper in the center with kindling on top. When you
light the newspaper this “top-down” fire will burn its way to
the center, igniting the larger pieces. With some practice,
this method should work for you.

Operating Your Appliance 19
© Travis Industries 100-01291 4060512
Adjusting the Burn Rate
Use the air control slider to control the burn rate of the stove. See the illustration below for details.
Approximate Air Control Settings:
Overnight Burn Pulled fully out
Medium Burn Pulled fully out to 1.5mm In
Medium High Burn 1.5mm to 1.3mm In
High Burn 1.3mm to Pushed All the Way In
The air control becomes hot during operation - use gloves or a tool to prevent burns.
The air control may take several minutes to influence the burn rate. When making adjustments, you
may wish to let the stove burn for 10 minutes to gauge performance.
Ash Removal
Ashes should be placed in a metal container with a tight-fitting lid. The closed container of ashes
should be placed on a noncombustible floor or on the ground, away from all combustible materials,
pending final disposal. If the ashes are disposed of by burial in soil or otherwise locally dispersed,
they should be retained in the closed container until all cinders have thoroughly cooled.
Low Burn
(air control closed)
High Burn
(air control open)









Use the air control to
change the burn rate.
ASHES

20 Operating Your Appliance
© Travis Industries 100-01291 4060512
Blower Operation
The blower will turn on once the stove is up to temperature. This is typically 15 to 30 minutes after
starting the fire. Follow the directions below to alter the blower speed.
The blower rheostat dial may look different. It does operate in the same fashion.
The blower may be used to affect heat output (i.e.: to reduce heat output, turn the blower down).
Route the power cord in a location where it will not come in contact with the appliance or become hot.
Re-Loading the Stove
Follow the directions below to minimize smoke spillage while re-loading the stove.
1 Open the air control all the way (push it in). Open the bypass; pull it out if necessary.
2 Open the door slightly. Let airflow inside the firebox stabilize before opening the doors fully.
3 Load wood onto the fire.
Overnight Burn
Follow the steps below to achieve an overnight burn.
1 Move the air control to high burn and let the stove become hot (burn for approximately 15 minutes).
2 Load as much wood as possible. Use large pieces if possible.
3 Let the stove burn on high for 15 minutes to keep the stove hot, and then turn the air control to
low.
4 In the morning the stove should still be hot, with embers in the coal bed. Stir the coals and load
small pieces of wood to re-ignite the fire, if desired.
Differences in chimney height and draft may lower overall burn times.
Normal Operating Sounds
OFF
Turn the dial all the
way counter-clockwise
until it clicks off.
HIGH
The high position is all the
way counter-clockwise,
without clicking off.
LOW
Turn the dial all
the way
clockwise.
Creaks and Clicks:
The steel may creak or click when the stove heats up
and cools down - this is normal.
Blower Sounds:
The blower will make a slight "humm" as it
pushes air through the stove.
