1080 CF – Accessing the Firebox
Page 1 of 2 10/10/07 © Travis Industries, Inc.
The logs, battery box, door latch tool, and other necessary components are packed inside the firebox. To access
these items, follow the directions below.
The glass frame is held in
place with four latches.
Use a pair of needle-nose pliers to pull the
latch forward and away from the glass frame.
These tabs insert over posts
on the fireplace and help
guide the glass into place.
REPLACING THE GLASS
Slide the glass into place and secure the four latches.
Lift and remove the glass frame
cover. Four hooks on the sides of
the coverhold it in place.
Dust Cover
(slides into place)
NOTE: Replace the glass, glass frame cover and dust cover after accessing the firebox to prevent dust from
entering the firebox.
IMPORTANT NOTE ON REMOVING THE FIREPLACE FROM THE PALLET
The fireplace is secured to the pallet with screws (the screws go through brackets at each corner). After removing
the screws, lift the fireplace off the pallet. TAKE CARE TO PREVENT DAMAGE TO THE STANDOFFS
ATTACHED BELOW THE BASE OF THE FIREPLACE.

1080 CF –New Features
Page 2 of 2 10/10/07 © Travis Industries, Inc.
Non-Combustible Fiber Board (Facing) Now Included
Non-Combustible Fiber Board is now included. These
four pieces of fiber board are directly attached to the
fireplace and framing, eliminating the need to purchase
cement board or other non-combustible backing board.
The fiber board is shrink-wrapped to the back of the
fireplace.
AAAAA
AAAAA
AAAAA
AAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAA
AAAA
AAAA
AAAA
AAAA
AAAA
Shutoff Valve –Turn “ON”After Installing Gas Line
A shutoff valve is built into the fireplace. It is located on
the left side of the fireplace and acts as the gas inlet
connection. After installing the gas line (and testing),
remove the cover plate shown to the right and turn the
gas shutoff valve to “ON”.
Shutoff Valve
Gas Inlet
LEFT SIDE OF
FIREPLACE
Cement Board is Not Required Under the 1080 CF Fireplace
The 1080 CF has specially-designed standoffs below the baseplate, eliminating the need for cement board.
Improved Top Stand-Off Design
The metal stand-offs above the fireplace are included to ease installation. A center standoff is provided to allow the
two included pieces of fiber board to be supported in the middle. Furthermore, the cross-beam on the upper stand-
off has been placed so that the drywall edge is supported. Use drywall screws to secure the facing, and drywall,
directly to the fireplace standoffs and framing. See the installation manual for details.
Lifting Handle-Compatible
Four sheet-metal tabs are attached to the base of the fireplace. By attaching the optional lifting handles (sku
98500711), you can easily lift the fireplace into position.
AC Powered (with battery backup)
The 1080 CF has a built-in AC adapter along with a battery backup. This extends battery life and allows the
homeowner to run the fireplace in cases where the batteries have drained (flame height will no longer be controlled
in this case). See installation manual for complete details on hooking up the AC power.
