Travis Industries Cypress GS2 User manual

GS2 Basic Wall Mount Remote Installation
SKU# 99300695
Page 1 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Compatibility
 Radiant Large GSB2 & MV
 Radiant Medium GSB2 & MV
 Radiant Small GSB2 & MV
 42 PB Linear GSB2 & MV
 54 PB Linear GSB2 & MV
 72 PB Linear GSB2 & MV
 Northfield MV
 Berkshire MV
 Greenfield MV
 36 PB CF GSB2 & MV
 42 PB CF GSB2 & MV
Packing List
 (1) Remote Transmitter
 (1) Remote Receiver w/ Attached Wire Harness
 (1) Switch Blank
 (4) AA Batteries
 (3) AAA Batteries
Warnings
The transmitter and receiver are radio frequency devices. Placing the transmitter in or near metal may
severely reduce the signal range.
Turn off power to the heater during installation or maintenance (unplug or turn off at the breaker).
Turn off the main gas supply to the appliance during appliance installation or maintenance.
REMOTE CONTROL / PILOT WARNING: Installing batteries in the battery holder or connecting the
appliance to power may automatically initiate the CPI pilot mode, resulting in a lit pilot flame. Do not
place combustibles inside the firebox.
If Using the Optional Blower, Install it First
The optional blower should be installed before installing the remote.
Table of Contents
MV Fireplace and Insert Installation ....................................................................... 2
MV Stove Installation .............................................................................................. 3
GSB2 Installation .................................................................................................... 4
Wiring Diagram MV ................................................................................................ 5
Wiring Diagram GSB2 ............................................................................................ 6
Operating Instructions ............................................................................................ 7
Direct Fireplace Operation ...................................................................................... 8
Remote Operation .................................................................................................. 9
Low Battery Indicator ............................................................................................ 11
Display Fahrenheit or Celsius ............................................................................... 11
Power Outages ..................................................................................................... 12
Child-Proof Feature .............................................................................................. 12
How to Turn the Thermostat Feature On and Off................................................. 12
Disabling Modes From the Remote ...................................................................... 13

GS2 Basic Wall Mount Remote Installation
SKU# 99300695
Page 2 of 13 17601967 - 2/12/19 Travis Industries, Inc.
MV Fireplace and Insert Installation
This set of installation instructions shows a summary of the remote installation.
For detailed instructions on placement of the receiver and other details, refer to the
installation manual included with your appliance.
1. Remove the Brown and Red wires from the back of the on/off switch.
2. Place the remote receiver in the appliance (see appliance manual for placement details). Connect the
Brown and Red wires to the Green and White wires from the receiver (polarity does not matter in this
application).
NOTE: The Molex connector with the Red and White wires remains empty in this application.
3. Remove the on/off switch from its mounting location. Place the switch blank into this location.
4. Verify the wiring does not contact any hot or moving components. Restore the appliance to the correct
configuration. Install the batteries in the remote and receiver. Synchronize the remote to the receiver
(page 8).
Squeeze tabs in to remove switch

GS2 Basic Wall Mount Remote Installation
SKU# 99300695
Page 3 of 13 17601967 - 2/12/19 Travis Industries, Inc.
MV Stove Installation
This set of installation instructions shows a summary of the remote installation.
For detailed instructions on placement of the receiver and other details, refer to the
installation manual included with your appliance.
1 Locate the Green and White wires labeled “REMOTE” near the gas control valve. Connect the Green and
White wires from the back of the remote to the “REMOTE” wires found in step 1.
2 Remove clear plastic film from the Velcro strips on the bottom of the heatshield for the receiver. Turn the
assembly over so the strips are facing downward. Gently push the wires back into the appliance as you move
the receiver assembly into place. Adhere the assembly to the floor of the controls area of the stove. Make
sure the placement does not obstruct the movement of the door.
3 Verify the wiring does not contact any hot or moving components. Restore the appliance to the correct
configuration. Install the batteries in the remote and receiver. Synchronize the remote to the receiver (page
9).

GS2 Basic Wall Mount Remote Installation
SKU# 99300695
Page 4 of 13 17601967 - 2/12/19 Travis Industries, Inc.
GSB2 Installation
This set of installation instructions shows a summary of the remote installation.
For detailed instructions on placement of the receiver and other details, refer to the
installation manual included with your appliance.
1 Remove the Green and White wires from the back of the on/off switch..
2 Connect the Green and White wires to the Green and White wires on the remote receiver (Green must attach
to Green and White to White).
3 Disconnect the Molex connector that attaches to the battery holder (discard the battery holder)
4 Connect the Molex connector to the connector from the remote receiver.
5. Verify the wiring does not contact any hot or moving components. Restore the appliance to the correct
configuration. Install the batteries in the remote and receiver. Synchronize the remote to the receiver (page 8).
Stock Configuration
Green to Green
White to White
Discard

GS2 Basic Wall Mount Remote Installation
SKU# 99300695
Page 5 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Wiring Diagram MV
Orange
White
Piezo Igniter
Thermopile
Red


Thermocouple
Copper Co-Axial
Wire
Red*
Spark Electrode
Pilot Hood
Brown*
Receiver (Manual
On/Off)
TOP
(4) AA Batteries
White
Green
* Some units use green & white wires with
additional on/off circuit.

GS2 Basic Wall Mount Remote Installation
SKU# 99300695
Page 6 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Wiring Diagram GSB2
Pilot Sensor
Appliance
Ground
Green
Orange
Yellow / Green
White
Blue
IPI/CPI
Switch
120 VAC
Power In
Black
Red
Yellow
Black
White
Green
Base
Integrated
Fireplace
Control
(IFC)
3.15A
FUSE
Optional
Blower(s)
ThermodiskRheostat
Spark
Rod
Appliance
Ground
Flame
Detect
Receiver (Manual
On/Off)
TOP
(4) AA Batteries

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 7 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Operating Instructions
Transmitter Battery Installation
Install the three included AAA batteries into the remote (see illustration below).
Receiver Battery Installation
Install four AA batteries into the receiver (see illustration below). You can use the batteries from the battery
backup tray on the appliance. See the installation instructions for details. These batteries power the receiver.
The batteries also act as a power-backup in case the household (AC) current goes out (GSB2 units only).

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 8 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Synchronize the Transmitter to the Remote
The transmitter will need to be synchronized to the receiver before the remote will work correctly. Synchronizing
is done in the following two steps below (see illustration below):
a) Press the PRG (Program) button on the receiver (receiver will beep 3 times).
b) Press the “ON” button on the transmitter (receiver will beep 4 times).
NOTE: If power is cut off to the receiver for an extended period of time, you may need to re-synchronize the
remote.
Direct Fireplace Operation
The fireplace may be directly operated from the receiver. The three positions are below (see Figure 4):
ON – Fireplace burner turns on (regardless of transmitter settings).
OFF – Fireplace burner turns off (regardless of transmitter settings).
REMOTE – Fireplace is controlled by the transmitter.
Figure 4
NOTE: When the receiver switch is turned to ON or OFF, the thermostat and burner on/off operating functions will
not work on the transmitter.
°F
"Beep"
"Beep"
"Beep"
"Beep"
"Beep"
"Beep"
ON REMOTE OFF
“Bee
p
”

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 9 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Remote Operation
When the switch on the receiver is set to “REMOTE” the transmitter operates the fireplace. Once you understand
how the transmitter works, you will be able to operate your fireplace quickly and easily.
Display Overview
The transmitter display has three main sections (see below).
Listen for the “Beep”
Each time you press a button on the transmitter that controls the fireplace, a “beep” will come from the IFC. When
you change thermostat target settings the IFC will not beep.
NOTE: When the batteries start to get low, the IFC will beep intermittently. When the batteries are nearly
depleted, the IFC will no longer beep. See “Receiver Batteries” on page 11).
ON
F
Thermostat Display
Room Temperature Display
Read-Out (Thermostat Setting, Function, etc.)
Mode Display (Flame, Blower, Light, Comfort Control)

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 10 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Manual On-Off / Standard Thermostat
Use the thermostat button to cycle through the two thermostat settings (see below).
 MANUAL ON/OFF – The burner will turn on and off using the remote (see below). Press the On/Off
button to control the burner. When off, the display will only show the current temperature.
 THERMOSTAT - While in standard thermostat setting, the transmitter will turn the burner on and off to
achieve the target temperature (see below). To adjust the target temperature, press the up and down
buttons until a suitable temperature is achieved.
NOTE: If the transmitter batteries go dead while in thermostat setting, the appliance will shut off after
approximately 24 hours.
ON
F
OFF
ON SMART
Look here for the
thermostat setting.
Press the thermostat button to cycle
through the thermostat settings.
F
OFF
When in manual setting, the
word "OFF" will appear here.
F
ON
When in standard thermostat
setting, the word "ON" will
appear here.
This is the target
temperature on the
read-out. Use the up or
down buttons to adjust
the target temperature.

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 11 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Low Battery Indicator
Transmitter Batteries
The transmitter has a battery-level indicator. When it indicates low battery voltage (see Figure 1 below), install
four new AAA alkaline batteries into the transmitter (see “Transmitter Battery Installation” on page 7).
Figure 1
Receiver Batteries
The receiver will “beep” periodically when the receiver batteries go low. Install four new AA alkaline batteries into
the receiver when this occurs (see “Receiver Battery Installation” on page 7). In applications where the appliance
is required to provide heat, we recommend replacing the batteries before each heating season.
Display Fahrenheit or Celsius
 With the system in the “OFF” position, press both the MODE and THERMOSTAT buttons simultaneously
to toggle between Fahrenheit (F) and Celsius (C).
ON
F
AUX
Low Battery Indicator
MAX
F
C
F

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 12 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Power Outages
On MV versions of the appliance, the receiver is powered by batteries only so power outages will not change the
function operation of the remote but the optional fan, if installed, will not operate.
On the GS units, the remote will work if household current (AC power) is disconnected. The batteries inside the
battery box will continue to power the appliance but the blower will not operate.
Child-Proof Feature
The child proof feature disables the control buttons, preventing un-wanted use of the remote.
 Press both the MODE and UP buttons simultaneously to turn this feature on and off (see below).
HINT: This feature is especially useful while using the thermostat setting.
How to Turn the Thermostat Feature On and Off
NOTE: The remote is shipped from the factory with the thermostat enabled.
1 Remove one battery from the remote.
2 Press down on the thermostat button while replacing the battery. This will toggle the
thermostat function. Repeat this process to toggle the thermostat function to the desired
setting.
MAX
F
OFF
Child Proof Indicator
°F
AAA Battery
When "CLR" appears,
the thermostat function
is disabled.
When "SET" appears,
the thermostat function
is enabled.

GS2 Basic Wall Mount Remote Operation
SKU# 99300695
Page 13 of 13 17601967 - 2/12/19 Travis Industries, Inc.
Disabling Modes From the Remote
NOTE: The remote is shipped with the modes disabled. These instructions are for reference purposes only.
1 Remove one battery from the remote.
2 Press down on the on/off button and mode button while replacing the battery.
Make sure to keep the on/off button depressed during the following steps.
HINT: The easiest way to do this step is to place the top
battery in the holder, slightly ajar. Then hold the the
buttons down as you press the battery into place.
3 While keeping the on/off button depressed, press and release the mode button until the mode that needs to
be changed is illuminated.
4 With the desired mode illuminated (the illustration below shows the AUX mode illuminated), press the “up” or
“down” button to activate or clear the mode being addressed. Make sure to keep the on/off button depressed
during this process.
5 Release the on/off button to complete programming.
°F
AAA Battery
Flame
Height
Optional
Blower
Comfort
Control
Accent
Light
AUX
Standing
Pilot
Press the "up" button to activate
("SET") the mode selected.
Press the "down" button to clear
("CLR") the mode selected.
