TRAXION 3-100 User manual
engineered products
Foldable Topside Creeper
Please read and understand all safety advisories and
operating instruction in this manual to ensure safe and
productive operation of your new Topside Creeper.
Safety First
WARNING: Failure to follow these safety requirements could result in personal injury.
This product is a tool to reach what are normally hard to reach places, such as the topside of an
engine compartment for mechanics.
Always inspect the product for damage before each use. Do not use if damage is detected. Make
sure all nuts and bolts are secure before each use.
Always engage the caster locks before using the Topside Creeper.
Always make sure the angle adjustment bar is secure in one of the three position slots before using.
Always face the Topside Creeper when climbing up or down. Use both hands and keep your body
centered between the rails.
DO NOT USE THE PRODUCT if you tire easily or are subject to fainting spells or disorientation.
DO NOT USE THE PRODUCT if you are taking medication that could impair judgement.
DO NOT USE THE PRODUCT if you are under the influence of drugs or alcohol.
DO NOT USE THE PRODUCT if you are physically challenged.
DO NOT sit or stand on the chest pad.
DO NOT overload the product. The maximum capacity is 400 lbs (180 kg) which includes body
weight, tools and torque applied to tools.
DO NOT use the Topside Creeper over a running engine.
12mm wrench
8mm socket
6mm wrench
philips screwdriver
Tools Needed
Assemble legs (M1 and M2)
to Base (N) using bolts (F),
Nuts (C) and Pins (I) as
shown. Do not overtighten.
The two legs must be
angled outward with
angle adjustment
notches on the inside.
NOTE
With angle adjustment notches
upward, secure two Locking
Casters (A2) to closed end of
the base (N) using Flange Nut
(B). Secure two non-locking
casters (A1) to the outward
protruding legs using Flange
Nuts (B) as shown.
Position step section (O) as shown.
Secure step section to base using two
Bolts (F) and two Locknuts (C).
Inside step section must be secured
before proceeding. Insert both spring
loaded pins into corresponding hole in
outside rail of Climbing Section (M).
Slide inside step section frame until
both spring loaded adjustment pins
fully engaged through oblong adjust-
ment holes of inside rails.
Place angle adjustment bar into one of the
three adjustment slots located on the base.
Secure Angle Adjustment Keepers (N) to base
using Bolts (G3) and Lock Nuts (E).
Using two Bolts (G1), two Nuts
(D) and Washers (Q), attach
Square Tube Cross Bar Sup-
port (J) to base as shown.
Using Bolts (G2) and Nuts (D) secure
chest frame to climbing section as
shown.
Insert Philips Head Screws (H)
through Bracket (S), Pouch (R)
and Padded Deck Frame as
shown. Secure to frame using
Lock Nuts (E).
Using two Philips Head Screws (H)
secure the padded deck to the
frame. Insert screws through holes
in the bottom of the frame and into
the threaded inserts in the bottom
of the pad.
Slide the three Bumper Pads (U)
onto the angle support bars and the
crossbar with the spring-loaded pins.
Operating Instructions
Using the adjustable angle lean-in feature
There are three different lean-in angles that allow the user to adjust positioning. This helps the user to
maximize safety and productivity. To adjust angle lean-in:
1. Lock casters (A2) by pressing the lock tab with your foot on each of the locking casters. 2. Push back
on the climbing section (O).
3. Move angle adjustment to one of the three notches located on the base.
Changing Working Height
The working height of the Topsdie Creeper can be adjusted to fit the needs of each individual task from
44” (110cm) to 68” (172cm) in height. To change the working height:
1. Lock casters (A2) by pressing the lock tab with your foot on each of the locking casters.
2. Grasp a step within the sliding section with one hand while using the other hand to pull one of the
spring loaded locking pins outward. Rotate the pin so it does not slide back into the locking slot.
3. Repeat step 2 on the other side of the sliding section to remove the second spring loaded locking pin.
IMPORTANT: one hand MUST have a firm hold of a step within the sliding section when the second
spring loaded locking pin is removed from the locked position. This prevents the sliding section from free
falling which could cause serious personal injury.
4. Slide the inside step section up or down to desired height while maintaining a firm grip.
5. While holding a step within the sliding section with one hand guide one of the spring loaded locking
pins into its corresponding hole in the outside rail.
Done. Now use your
Topside Creeper safely
for maximum productivity.
Lock Casters by pressing
downward on the locking tab
with your foot.
Remove two locking pins from
the assembled base section.
Push the Angle Adjustment Bar
forward to the first setting of the
notched Angle Adjustment Keeper.
Grasp each of the two legs
(M1 and M2) and raise to the
climbing section.
Replace pins back into their
holes for safekeeping.
