Treasure Garden AG28RK Installation instructions

Assembly and Operation Guide
AG28 CANTILEVER
AG28RK 11’ octagon

Thank you for purchasing Treasure Garden’s AG28 Cantilever.
Please remove all contents from the package, inspect and review checklist.
Some parts may be included in the styrofoam packaging.
Do not discard any packaging or box until assembly is complete.
CHECKLIST
1
Base Shell Base Lid
A
D
B
J
F
H
G
K
S
Q
IN
L
O
M
P
E
C
R
T
(1) Collar
(1) Clamp
(1) Stem
(2) Bolts
(1) Hexagon
Wrench
(1) Steel Wrench
Spring Loaded
Rib End Cap (8)
REQUIRED FOR ASSEMBLY:
• 200 lbs. of all purpose sand (not included).
NOTE: Avoid allowing sand into center of base shell.
A - (1) Base Shell and Base Lid K - (1) Canopy
B - (1) Collar Base Stem Assembly L - (1) Removable Crank Handle
C - (1) Locking Rotation Knob M - (1) Socket A - To extend arm
D - (1) Main Frame N - (1) Socket B - To open canopy
E - (1) Housing O - (1) Crank Handle Storage
F - (1) Outer Frame Arm P - (1) Light Adapter (light sold separately)
G - (1) Arm Connector Q - (8) Spring Loaded Rib End Cap
H - (1) Inner Frame Arm R - (1) Valance (optional)
I - (1) Bottom Pole S - (1) Hardware Assembly
J - (1) Gemel Hinge T - (1) Protective Cover

2
STEP 1BASE ASSEMBLY
Select area to set base and place in desired location.
Remove base lid from base shell and set aside (Fig. 1). Insert the base stem into the base
shell (Fig. 2). Turn collar base stem in a clockwise motion to engage threading. Fill base
shell with all-purpose sand (not included) (Fig. 3). NOTE: Base weight holds up to 200 lbs.
of sand. Remove the base stem carefully and avoid allowing sand into the center of the
base shell (Fig. 4). IMPORTANT: Do not allow sand to spill into the center of the base
(Fig. 4) as it will interfere with collar base stem installation. Place base lid back onto base
shell.
CAUTION: Fully assembled, the AG28 umbrella weighs over 300 lbs. Moving the
umbrella fully assembled will increase the risk of damage to your umbrella and can
cause serious injury. We recommend a two-person team to assemble the umbrella.
(Fig. 1)
(Fig. 3)
Avoid allowing sand into
the center of the base
shell.
!
(Fig. 2)
(Fig. 4)
IMPORTANT:
Prior to assembly it is important to decide on the location of the umbrella.
· Allow ample height to avoid damage to your umbrella during assembly and usage.
· Choose a location that is level and sturdy.
· Avoid any sloping of soft ground.
· Consider a location that will maximize the umbrella’s 360° rotating function. Placing the
umbrella between two entertaining areas is idea.

3
STEP 2ASSEMBLE COLLAR BASE STEM
Re-insert the base stem into the base shell. Turn collar base stem in a clockwise
motion to engage threading (Fig. 5). Insert steel wrench provided into holes on top of stem
and tighten (Fig. 6). NOTE: To avoid damage to your base, do not over-tighten base stem.
Insert clamp into base stem (Fig. 7). Attach collar to top of the base stem by engaging
threading (Fig. 8). Do not completely tighten before inserting AG28 umbrella frame.
Stem Steel
Wrench
Clamp
Collar
(Fig. 7)
(Fig. 5) (Fig. 6)
(Fig. 8)
Socket BSocket B

4
(Fig. 10)(Fig. 9)
(Fig. 11)
(Fig. 12)
Socket A
Stopper
STEP 3ASSEMBLE FRAME
To prevent scratching frame during assembly, lay umbrella parts on soft surface.
Remove packaging from umbrella. NOTE: Keep canopy structure and frame arm strapped.
Attach the bottom pole into the housing, bottom pole only fits one way. Line up holes and
secure the two bolts with hexagon wrench (Fig. 9). Insert crank handle into socket A of
housing (Fig. 10). Crank inner frame arm counter-clockwise until arm stops. To prepare
base for umbrella, release collar base stem by turning the collar counter-clockwise
(Fig. 11). Lift and insert umbrella frame into collar base stem (Two Person Team
Required). Secure position by tightening the collar in a clockwise direction (Fig. 12).
NOTE: Cantilever will open counter-clockwise but not designed to be operated in that
matter.

5
(Fig. 13) (Fig. 14)
(Fig. 15)
Socket A
Socket A
Socket BSocket B
Socket B
Socket A
Socket A
STEP 5TILTING UMBRELLA
IMPORTANT: PRIOR TO USING TILT FEATURE.
To avoid personal injury or damage to the umbrella, make sure the area behind you is clear
and free from any furniture or structure.
Insert crank handle into socket A (Fig. 15) and slowly crank counter-clockwise to desired
degree of vertical shade.
STEP 4OPENING UMBRELLA
To Open and Extend Arm:
Insert crank handle fully into socket A (Fig. 13), crank handle will snap into place, then
slowly crank the handle clockwise until crank handle stops and arm is fully extended
outward. CAUTION: Arm must be fully extended before retracting. Do not over crank, as it
will damage your umbrella.
To Open Canopy:
Insert crank handle fully into socket B (Fig. 14), crank handle will snap into place, then
slowly crank the handle clockwise until canopy is completely open and hub is inserted
under center pole and crank handle stops.

STEP 6ROTATING UMBRELLA
Pull out the locking rotation knob to disengage lock (Fig. 16) and place second hand on
Socket B crank system simultaneously to rotate in either direction (Fig. 17). After desired
location is reached, release rotation knob to lock into one of the 12 preset locking positions.
6
Socket A Socket BSocket B
(Fig. 16)
(Fig. 17)

7
(Fig. 18) (Fig. 19)
(Fig. 20) (Fig. 21)
STEP 7LIGHT ADAPTER FEATURE
To ATTACH Umbrella Light: (sold separately)
Loosen the light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 18). After loosening, pull down light adapter post (Fig. 19) to attach the umbrella light
(sold separately).
To OPEN and ATTACH Light:
Open the umbrella light by holding firmly with one hand and then depress the clamp release
button with the other hand to release the clamp lock. Open up the light and clasp around
the light adapter post (Fig. 20). Snap to close (Fig. 21).
To REMOVE Light and CLOSE adapter:
Hold the umbrella light, depress the clamp release button to release the clamp lock.
Remove umbrella light and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 18). NOTE: It is not necessary to remove light to close
umbrella.

8
STEP 8CLOSING UMBRELLA
NOTE: Prior to closing ensure that the canopy is in a level (non-vertical tilt) position.
Insert crank handle fully into socket B (Fig. 22), crank handle will snap into place, then
slowly crank the handle counter-clockwise until canopy is completely closed.
Insert crank handle fully into socket A (Fig. 23), crank handle will snap into place, then
slowly crank the handle counter-clockwise until crank handle stops and arm has fully
retracted to a closed position.
Properly store umbrella when not in use. Close umbrella, tie string around canopy and
cover umbrella with provided protective cover.
CARE AND MAINTENANCE
TO PROPERLY FOLD CANOPY:
The canopy will last longer if you fold it as it was packed and shipped. This technique is
similar to the way a parachute is folded and is especially important when folding the canopy
for seasonal storage or when left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the life of the canopy.
• When the umbrella has been fully closed, stand in front of the canopy
structure and begin the folding process by pulling out two panels
opposite the main frame. Pull the two panels together and roll tight into
the canopy.
• Once rolled tight, pull adjacent panels out one at a time and fold to the
center, alternating sides until all the panels have been pulled out from
the arms and folded into the center.
• Tie string around canopy and cover umbrella with provided protective
cover.
(Fig. 23)(Fig. 22)
Socket BSocket B
Socket B Socket A

9
SAFETY PRECAUTIONS
• To reduce risk of personal injury in which a person is injured or harmed, and/or damage
to personal property, read and follow the Assembly Guide prior to assembling and
operating umbrella and base.
• Close and store the umbrella in windy conditions or when a storm approaches. Never
allow the umbrella to flap in the wind; this could cause personal injury, damage to
personal property, damage to umbrella and/or umbrella canopy. Do not use tilting
function during windy conditions.
• Keep umbrella secured to umbrella base at all times.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s), item(s) or personal property
are close to the umbrella. This is important to prevent injury or material damage.
• Do not allow children to play on or with umbrella or umbrella base.
• When adjusting or assembling the umbrella or umbrella base, make sure fingers, toes
or any other parts of the body are clear from moving parts. Failing to do so many result
in serious injury.
CARE AND MAINTENANCE
• When not in use, close and cover umbrella with provided protective cover.
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.

10
WARRANTY:
Treasure Garden warrants this product
(for residential use ONLY) to be free
from defects in original materials and
workmanship for a period of 1 year from
the date of purchase. If a defect in the
original material or workmanship appears
during the warranty period; Treasure
Garden will (at its discretion) repair or
replace the product without charge.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can
be solved with a replacement part that
can be shipped directly to the dealer for
professional installation / repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the first
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped / billed
at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the aging
process of steel or iron based materials,
and is therefore NOT considered a defect.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect
of reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes, tornadoes,
and storms) are not covered by this
warranty.

www.treasuregarden.com
©2021 Treasure Garden, Inc. - All Rights Reserved.
v.05.19.21
