Treasure Garden GLIDE TILT UM970 Installation instructions

Assembly and Operation Guide
www.treasuregarden.com
©2020 Treasure Garden, Inc. - All Rights Reserved.
v.02.28.20
UM970 9’ octagon
UM977 7.5’ octagon
GLIDE TILT

Thank you for purchasing Treasure Garden’s Glide Tilt Umbrella.
Please remove all contents from the package, inspect and review checklist.
STEP 1SET UP
CHECKLIST
A - (1) Finial
B - (1) Canopy/Mainframe
C - (1) Bottom Pole
A -
B -
C -
Carefully remove umbrella from box. Attach finial to top of canopy/mainframe. Insert bottom
pole into canopy/mainframe pole. Line up button with hole and snap into place.
STEP 2OPENING & TILTING UMBRELLA
Turn the umbrella upright and insert into
umbrella base. Crank handle clockwise to
open umbrella to its fully open position.
To tilt, simply press down on housing.
STEP 3CLOSING UMBRELLA
Simply pull up on housing to bring umbrella back to a
horizontal position. Turn crank handle in counter-clockwise
direction to close umbrella. Tie string around canopy and
cover umbrella with protective cover (sold separately).
WARRANTY:
Treasure Garden warrants this product (in
residential use) to be free from defects in
original materials and workmanship for a
period of 1 year from the date of purchase.
If a defect in the original material or
workmanship appears during the warranty
period; Treasure Garden will (at its option)
repair or replace the product without
charge.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can
be solved with a replacement part that
can be shipped directly to the dealer for
professional installation / repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges on warranted product for the first
year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped / billed
at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the aging
process of steel or iron based materials,
and is therefore NOT considered a defect.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect
of reasonable and necessary care are not
covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes, tornadoes,
and storms) are not covered by this
warranty.
SAFETY PRECAUTIONS
• Close and store the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy. If damage
occurs, this is not covered by the warranty.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE
• When not in use, close and cover umbrella with a protective cover (not included).
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
