TrekStor SurfTab twin 10.1 User manual

EN
OPERATING INSTRUCTIONS
SurfTab®twin 10.1

EN 2
Content
1) About the SurfTab ……………………………………………………… 4
2) Safety information ……………………………………………………… 5
Operational safety ………………………………………………………… 5
Repair …………………………………………………………………… 6
Intended operating conditions …………………………………………… 7
Power supply……………………………………………………………… 7
Care and maintenance …………………………………………………… 7
Information on the memory capacities indicated ………………………… 7
3) Technical specications ………………………………………………… 8
4) Package contents ……………………………………………………… 8
5) Controls and ports ……………………………………………………… 11
6) Removing the tablet from the keyboard and replacing it …………… 12
Removing the tablet from the keyboard. ………………………………… 12
Reconnecting the tablet to the keyboard ………………………………… 13
7) Starting up the SurfTab for the rst time ……………………………… 14
Charging the SurfTab …………………………………………………… 14
Switching on the SurfTab ………………………………………………… 14
8) Info Center ……………………………………………………………… 15
Activating tha automatic roation function ……………………………… 15
9) Accessing and using the Start menu…………………………………… 16
Layout of the Start menu ………………………………………………… 16
Accessing the Start menu ………………………………………………… 17
Navigating / selecting an element in the Start menu …………………… 17
Adding, organising and removing apps ………………………………… 17
10) Accessing settings ……………………………………………………… 18
11) Connecting to the Internet via WiFi …………………………………… 19
12) Launching the Internet browser/entering a URL……………………… 19
13) Switching o the SurfTab ……………………………………………… 19

EN
3
14) Notes on copyright and trademarks …………………………………… 20
15) Notes on disposal ……………………………………………………… 20
Disposal…………………………………………………………………… 20
Recycling ………………………………………………………………… 21
16) Notes on liability and warranty ………………………………………… 21

EN 4
We hope you enjoy your TrekStor SurfTab twin 10.1.
Please read the following sections carefully to familiarise yourself with the
functions of this product and how to operate it.
IMPORTANT!
Always follow the safety information in Section 2.
IMPORTANT!
Please keep these instructions in a safe place, and pass them on to the new
owner if the device change hands.
Up-to-date product information can be found on the TrekStor website:
www.trekstor.de
For more products and accessories, visit: www.trekstor-onlineshop.de
1) About the SurfTab
The TrekStor SurfTab twin 10.1 is a two-in-one device incorporating the
Windows 10 operating system, which can be used for surfing the Internet,
running apps, and playing music, videos and games. It consists of a tablet PC
and a high-quality QUERTY keyboard with hard shell. A special hinge fitting
allows you to work at different display angles in notebook mode, or completely
remove the tablet from the fitting and work in tablet mode.
Only ever use the device for its intended purpose. The manufacturer is not liable
for damages resulting from improper use. Furthermore, the manufacturer shall
not be responsible for damages or loss of data and any subsequent damage
caused.

EN
5
2) Safety information
These instructions use the following warning symbols and key words:
aDANGER
Indicates possible danger to life and/or danger of severe, irreversible injuries.
rCAUTION
Follow instructions to avoid injuries and material damage.
rWARNING
Follow instructions to avoid material damage.
iNOTE
Further information about the use of the device.
Operational safety
rCAUTION Those who, as a result of their physical, sensory or mental capabilities,
or lack of experience or knowledge, are not in a position to use the product
safely must not be allowed in the vicinity of the product without supervision
or instruction by a person responsible for their safety. Supervise children
around the product.
aDANGER
Keep packaging materials out of reach of children (e.g., plastic sheets).
There is a danger of suffocation.
aDANGER
Some accessories can pose a choking hazard for babies and young children.
Keep these accessories out of reach of babies and young children.
aDANGER
Never open the casing of the device or the charger: This may cause an
electrical shock, short circuit or fire!
aDANGER
Do not insert any object into the ports or openings of the device or
charger: This may cause an electrical shock, short circuit or fire!

EN 6
aDANGER
Do not cover the device or charger during operation or while charging.
This may cause the device/charger to overheat and potentially catch fire!
uCAUTION
This device can generate high sound volumes. Never listen at high volumes
for long periods. Doing so can result in immediate or gradual hearing
damage. Remember: Permanent hearing damage may only emerge
later in life. You may become used to listening to high volumes over time,
making them appear normal to you. However, your hearing may have
already been damaged. The higher you set the volume, the more quickly
your hearing can be damaged.
aDANGER
Your safety is very important to us! Safety always has first priority
in road transport. Protect yourself and other road users by operating
the device only if the traffic situation allows it and you do not endanger
or hinder anyone. Adjust the volume of the device for your safety so that
you can continue to react to all the sounds around you. Local legislation
in force applies.
rWARNING
Do not exert excessive pressure on the display, as it may break.
oAvoid using USB cables over 3 m in length.
Exposing the device to electrostatic discharge can interrupt the data
ptransfer between the device and the computer or impair the functions
of the device. Should this happen, disconnect the device from the USB
port and reconnect it or rebuild the WiFi connection from scratch.
Repair
rWARNING
No parts inside the device require maintenance or cleaning.
rWARNING Should the device become wet, turn it off immediately. Ensure the device
is checked for operational safety before using it again.

EN
7
Intended operating conditions
jProtect the device from extremely high or low temperatures and fluctuations in temperature. Use it at an ambient temperature
between 10º C and 40º C.
mDo not place the device near a heat source and protect it from direct sunlight.
eNever expose the device to humidity, condensation or moisture.
hEnsure you use and store the device in a dust-free environment.
Power supply
rCAUTION Only ever use the original charger or a charger with the correct
voltage and amperage to prevent damage to the device. If you have
to resort to a universal charger, pay attention to the polarity
of the charging device as well as the voltage and amperage. Your
device may suffer irreparable damage if these specifications are not
properly adhered to.
rCAUTION
Do not use or charge the device if the battery is damaged or leaks.
Care and maintenance
gNever clean the surface of the device with solvents, paint thinners, cleaning agents or other chemical products. Use a soft, dry cloth
or a soft paintbrush.
Information on the memory capacities indicated
qThe storage capacity indicated on the packaging and in the technical
specifications refers to the total storage capacity of your device.
The storage capacity of the device indicated by your operating system
may differ from the stated storage capacity, as a portion of the total
storage is also used by the operating system and system applications.

EN 8
3) Technical specifications
Processor (CPU): Intel® Atom™ Z3735F processor
(up to 1.83 GHz, 2 MB Intel® Smart
Cache)
RAM: 2 GB (DDR3)
Storage capacity: 32 GB
Graphics processing unit (GPU): Intel® HD Graphics
Display type: 10-point capacitive multi-touch
HD-IPS display
Display size: 10.1" (25.7 cm)
Aspect ratio: 16 : 10
Screen resolution: 1280 x 800
Camera: 2 MP (auto focus) / 2 MP webcam
Interfaces: Micro-USB 2.0 (with host function),
2 x USB 2.0, audio out/mic in,
microphone, camera, Mini-HDMI®,
memory card reader, WiFi,
Bluetooth®, Miracast™,
keyboard dock
Supported memory cards: microSD, microSDHC, microSDXC
(max. 128 GB)
Dimensions (W x H x D): 260 x 175 x 10,8 mm (tablet)
Weight: 599 g (tablet) / 540 g (keyboard)
Battery: Lithium polymer
Housing material: Plastic
Operating system: Windows® 10
4) Package contents
• SurfTab twin 10.1
• Power adapter (100 V – 240 V)
• USB cable (Micro-USB / USB-A)
• Protective display film
• Quick guide
• Product safety and legal information

EN
9
A
C
N
O
M
P
B
E F G H KJI LD

EN 10
Strg Alt Alt Gr
Pos1 Ende Druck
Esc Einfg EntfBild Bild
´
&
Ü
ÄÖ
Q
R

EN
11
5) Controls and ports
A) Front camera
B) Windows button
C) Status LED
D) Microphone
E) Audio jack
F) Micro-USB socket (charging socket)
G) Mini-HDMI socket
H) USB A socket
I) Reset
J) Memory card slot
K) Protective cover
L) Speaker
M) On/off switch
N) Volume control
O) Rear camera
P) Keyboard dock
Q) Tablet dock
R) USB A socket

EN 12
6) Removing the tablet from the keyboard and replacing it
The tablet is delivered connected with its associated keyboard.
iImportant: In delivery state, automatic screen rotation is deactivated.
Please read in Section 7 how to activate it.
Removing the tablet from the keyboard.
To remove the SurfTab from the keyboard, please proceed as follows:
a) Fold the tablet upwards until it is standing at a 90° angle to the keyboard.
b) Holding the keyboard down with one hand, pull the tablet up and away
from the keyboard. While doing this, try as far as possible not to press on the
keys, but rather on one of the free areas at the keyboard edges.
rWARNING
To avoid permanent damage to the display, try as far as possible not to
press on it when removing the tablet. Grip the tablet by the edge instead.
iIt is easier to remove the tablet if you pull it up at a slight left or right angle, rather
than vertically.

EN
13
Reconnecting the tablet to the keyboard
To reconnect the tablet to the keyboard, please proceed as follows:
a) Align the hinge fitting on the keyboard so that the tablet dock is pointing
vertically upwards.
b) Next, lower the tablet vertically, with its tablet dock resting on the keyboard
tablet dock, and press carefully until it locks.
iThe tablet is locked if it cannot be removed vertically upwards from the keyboard
without the use of significant force.

EN 14
7) Starting up the SurfTab for the first time
Charging the SurfTab
Our SurfTab tablets are generally delivered with the battery 70% charged.
Nonetheless, you should connect the SurfTab to a power socket before
starting it up for the first time.
To charge the SurfTab, connect the USB cable to the power adapter,
and use this to connect the SurfTab to a power socket.
iThe maximum battery life is reached after approximately ten charging cycles.
Switching on the SurfTab
Press the on/off switch for approximately 2-3 seconds to switch on the SurfTab.
A configuration assistant will appear. Follow the configuration assistant
instructions to set up your SurfTab.
iDuring the setup process, the configuration assistant will prompt you to sign in
with your Microsoft account. If you do not yet have a Microsoft account, please
set one up at this point.
As soon as the device has been set up (and every time it is subsequently
switched on and booted up), the lock screen appears. Drag the lock screen
upwards with your fingertip to unlock the screen.
iIf your SurfTab is password protected, you must then enter the password.

EN
15
8) Info Center
The Info Center is a bar with quick links to some important SurfTab functions,
which you can either display or hide. To access the Info Center, swipe your finger
from the right edge of the screen towards the centre, or click/tap on the memo
symbol in the bottom right hand corner.
iAmong other things, the Info Center includes a quick link to what is known as
the
"TableT mode"
. If you tap on this function, the Start menu is enlarged within
the display, making fingertip operation considerably easier.
Activating tha automatic roation function
In delivery state, automatic screen rotation is deactivated.
To activate it, proceed as follows:
a) Open the Info Center by swiping your finger from the right edge of the
screen towards the centre of the screen.
b) Tipe on "
Rotation lock
" in the lower left part of the Info Center to activate
automatic screen rotation.

EN 16
9) Accessing and using the Start menu
You’re already familiar with the Start menu from your desktop PC at home.
It acts as the starting point for all the important contents of your SurfTab twin.
Below you can read some useful information about the Start menu’s basic functions.
Layout of the Start menu
In addition to the straightforward navigation bar (A) found in the "classic" Start
menu of older Windows versions, the Start menu of the SurfTab twin 10.1 has
a useful App field (B) to the right of the navigation bar. Here you can "add" and
organise apps and favourites in the form of live tiles. This gives you quick and
uncomplicated access to your most frequently used apps and contents.
i"Underneath" the navigation bar (A) there’s an alphabetically ordered list of all
the apps installed. To access this, "drag" the navigation bar upwards or tap on
"
all apps"
in the bottom left of the navigation bar.

EN
17
Accessing the Start menu
To display the start menu, tap the Windows icon in the bottom left of the display,
or press the Windows button on the keyboard. Tapping/pressing a second time
hides the Start menu.
iIf you’ve activated tablet mode (see note in Section 8), all the attached elements
from the App field of the Start menu are magnified and distributed across the
entire screen. To access the Start menu navigation bar, tap the menu icon in the
top left of the screen (three horizontal lines).
Navigating / selecting an element in the Start menu
To select an element (app or favourite) from the Start menu or the associated
App field, tap the element you want with your finger – or use the keyboard
arrow keys to navigate to it – and then press the Enter key on the keyboard.
Adding, organising and removing apps
You have the option of ordering the elements contained in the App field in the
form of live tiles (apps and favourites) according to your own preferences, as well
as adding new elements or removing those you don’t use.
Adding apps
a) Call up the Start menu as described above.
b) Tap on "
all apps"
in the bottom left of the Start menu.
c) Scroll to the app you want by swiping the Start menu navigation bar with
your finger from top to bottom (or vice versa).
iAlternatively, you can use the keyboard arrow keys.
d) Keep your finger on the app you want, and drag it to the desired position in
the Start menu App field.

EN 18
Organising and removing apps
To access edit mode for a particular live tile, place your finger on the live tile
you want and keep it there until it highlights (the background becomes darker,
the live tile stands out visually).
Two edit symbols now appear at the corners of the tile.
To remove the live tile from the Start menu App field, tap the pin symbol in the
top right corner of the highlighted tile.
To access further editing options, tap the symbol containing three dots in the
bottom left corner of the tile.
10) Accessing settings
The button for accessing settings (a cogwheel symbol) can be found in the
bottom left corner of the Start menu.
Alternatively, you can access settings by opening up the Info Center and tapping
on
"all settings"
.

EN
19
11) Connecting to the Internet via WiFi
a) Call up settings (see Section 10).
b) In the settings menu, tap on "
netwoRk & inteRnet"
.
c) In the next screen, tap on
"wo-Fi"
to the left.
d) Drag the WiFi slider from
"oFF"
to
"on"
. SurfTab searches for all available
wireless networks in the area and then displays them as a list.
e) Tap the network that you wish to connect to.
iIf you do not want the SurfTab to connect to the selected network automatically
(if available), remove the tick next to
"ConneCT auTomaTiCally"
.
f) Tap next on
"connect"
. The SurfTab now connects to the network selected.
You can now surf the Internet as usual using the Internet browser.
12) Launching the Internet browser/entering a URL
The button for launching the Internet browser can be found on the start bar at
the bottom of the display. Tap/click on the little blue "e" to launch the browser.
iThe "e" stands for
"edge"
, the default Internet browser installed in Windows 10.
To enter an Internet address (URL), tip/click on the search bar displayed centrally
at the top of the window.
13) Switching off the SurfTab
a) To switch off the SurfTab, press the on/off switch for about 5 seconds.
The lock screen appears in the top half of the screen.
b) Drag the lock screen downwards with your finger to shut down and switch
off the SurfTab.

EN 20
14) Notes on copyright and trademarks
Copyright law prohibits the copying of the content of these operating
instructions (illustrations, reference documents etc.), in whole or in part,
without the permission of the copyright holder.
The Bluetooth word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such marks by TrekStor GmbH is under license.
Other trademarks and trade names are those of their respective owners.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC.
Intel, Intel Atom and the Intel Inside logo are trademarks of Intel Corporation in
the U.S. and/or other countries.
Microsoft, Windows and Windows Store are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
TrekStor and SurfTab are registered trademarks of TrekStor Ltd. in the European
Community and other countries.
Copyright © 2015 TrekStor GmbH. All rights reserved. Some product or company
names mentioned elsewhere may be brand names or trade names of the
respective proprietor.
15) Notes on disposal
Disposal
vThis symbol indicates that this product and/or the battery used contain
components that are harmful to the environment and/or human health
if not disposed of correctly. As the owner of a used electrical or electronic
device, you may not dispose of this device together with unsorted
domestic waste.
aRemove the battery from the device before disposing of your old device.
Contact your city or municipal authority for information on how to
correctly dispose of the device and its battery.
