TRENDnet TEW-658BRM User manual

TEW-658BRM
1.01
Quick Installation Guide

Table of Contents
Version 02.14.2011
English 1
1. Before You Start
2. Hardware Installation 7
3. Configure the Modem 8
1
Troubleshooting 13
Wireless Tips 16

1. Before You Start
Ÿ
ŸA computer with a wired or wireless network adapter properly installed.
ŸWeb Browser such as Internet Explorer 6.0 and above, Firefox 2.0 and above or
Chrome
A working ADSL Internet Connection
Package Contents
Ÿ
ŸCD-ROM (User's Guide)
ŸMulti-Language Quick Installation Guide
ŸNetwork Cable (1.5m/4.9ft)
ŸRJ-11 Telephone Cable (1m/3ft)
ŸPower Adapter (12V DC, 1A)
TEW-658BRM
System Requirements
1

2
Please verify your DSL Internet broadband connection type with your ISP and ensure
you have all the information for one of the following connection types:
1. PPPoE (RFC-2516 PPP over Ethernet)
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____ (0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____ (0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)
ŸState of Connection (Enable/Disable)
ŸIPMode of Connection (Dynamic/Static)
ŸIP Address: _____. _____._____._____ (Static IPMode only)
ŸSubnet Mask: _____. _____._____._____ (Static IPMode only)
ŸName: ________________
ŸNAT (Enable/Disable)
ŸUser Name: ___________________________
ŸUser Password: ________________
ŸConfirm Password: ________________
ŸMax MRU: _____ (576~1492)
ŸDNS Enabled (Enable/Disable)
ŸDNS Override Allowed (Enable/Disable)
ŸDNS Server 1: _____. _____._____._____ (optional)
ŸDNS Server 2: _____. _____._____._____ (optional)
ŸPPPoE Service Name: ________________ (optional)
ŸMac Address: ________________
ŸPPPoE AC Name:________________ (optional)
ŸConnection Trigger (OnDemand/ AlwayOn/ Manual)
ŸIdle Disconnect Time (30~3600 seconds)
ŸAs system default route (Current setting : pppoe ) (Setup " Internet Setup)
ŸICMP Reply Enable (Setup " Internet Setup)
ŸLCP Interval (0~86400 seconds)
ŸProxy ARP Enable
Collect Internet Service Provider (ISP) Information

3
2. PPPoA (RFC-2364 PPP over ATM)
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____ (0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____ (0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)
ŸState of Connection (Enable/Disable)
ŸIPMode of Connection (Dynamic/Static)
ŸIP Address: _____. _____._____._____
ŸSubnet Mask: _____. _____._____._____
ŸName: ________________
ŸNAT (Enable/Disable)
ŸUser Name:________________
ŸUser Password: ________________
ŸConfirm Password: ________________
ŸMax MRU: _____ (576~1492)
ŸDNS Enabled (Enable/Disable)
ŸDNS Override Allowed (Enable/Disable)
ŸDNS Server 1: _____. _____._____._____ (optional)
ŸDNS Server 2: _____. _____._____._____ (optional)
ŸConnection Trigger (OnDemand/ AlwayOn/ Manual)
ŸIdle Disconnect Time (30~3600 seconds)
ŸLCP Interval: _____ (0~86400 seconds)
ŸAs system default route (Current setting : pppoe ) (Setup " Interent Setup)
ŸICMP Reply Enable (Setup " Interent Setup)
ŸProxy ARP Enable
3. IPoA (RFC-1483 Routed)
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____ (0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____ (0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)

4
ŸState of Connection (Enable/Disable)
ŸName: ________________
ŸNAT (Enable/Disable)
ŸAddress Type (DHCP/Static)
ŸExternal IP Address: _____. _____._____._____
ŸSubnet Mask: _____. _____._____._____
ŸDefault Gateway:_____. _____._____._____
ŸDNS Enabled (Enable/Disable)
ŸDNS Override Allowed (Enable/Disable)
ŸDNS Server 1: _____. _____._____._____ (optional)
ŸDNS Server 2: _____. _____._____._____ (optional)
ŸAs system default route (Current setting : pppoe ) (Setup " Interent Setup)
ŸICMP Reply Enable (Setup -> Interent Setup)
ŸProxy ARP Enable
4. Dynamic IP Address (IPoEoA/MER (MAC Encapsulated Routed) with DHCP)
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation: _____ (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____ (0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____ (0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)
ŸState of Connection (Enable/Disable)
ŸName: ________________
ŸNAT (Enable/Disable)
ŸAddress Type (DHCP/Static)
ŸDNS Enabled (Enable/Disable)
ŸDNS Override Allowed (Enable/Disable)
ŸDNS Server 1: _____. _____._____._____ (optional)
ŸDNS Server 2: _____. _____._____._____ (optional)
ŸMac Address: ________________
ŸOption 125 (Enable/Disable)
ŸOption 60 Vendor ID: _____ (optional)
ŸOption 61 IAID: _____ (optional)
ŸOption 61 DUID : _____ (optional)
ŸAs system default route (Current setting : pppoe ) (Setup " Interent Setup)
ŸICMP Reply Enable (Setup -> Interent Setup)
ŸProxy ARP Enable

5
5. Static IP Address
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____ (0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____ (0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)
ŸState of Connection (Enable/Disable)
ŸName: ________________
ŸNAT (Enable/Disable)
ŸAddress Type (DHCP/Static)
ŸExternal IP Address: _____. _____._____._____
ŸSubnet Mask: _____. _____._____._____
ŸDefault Gateway:_____. _____._____._____
ŸDNS Enabled (Enable/Disable)
ŸDNS Override Allowed (Enable/Disable)
ŸDNS Server 1: _____. _____._____._____ (optional)
ŸDNS Server 2: _____. _____._____._____ (optional)
ŸMac Address: ________________
ŸAs system default route (Current setting : pppoe ) (Setup " Interent Setup)
ŸICMP Reply Enable (Setup -> Interent Setup)
ŸProxy ARP Enable
6. Bridge Mode (RFC-1483 Bridged)
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____ (0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____ (0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)
ŸState of Connection (Enable/Disable)
ŸName: ________________

6
7. CIP (RFC-1577 Classic IP/ARP over ATM)
ŸVPI: _____ (0~255)
ŸVCI: _____ (32~65535)
ŸEncapsulation (LLC or VCMUX)
ŸATMQoS (UBR, CBR, VBR-nrt, VBR-rt)
ŸPeak Cell Rate: _____ (0~6000 cells/s)
ŸMaximum Burst Size: _____
(0-65535 Cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸSustainable Cell Rate: _____
(0~65535 cells)(VBR-nrt/VBR-rt ATMQoS only)
ŸEnable Default VLAN (Enable/Disable)
ŸPPPoE PassThrough (Enable/Disable)
ŸState of Connection (Enable/Disable)
ŸName: ________________
ŸNAT (Enable/Disable)
ŸAddress Type (DHCP/Static)
ŸExternal IP Address: _____. _____._____._____
ŸSubnet Mask: _____. _____._____._____
ŸDefault Gateway:_____. _____._____._____
ŸDNS Enabled (Enable/Disable)
ŸDNS Override Allowed (Enable/Disable)
ŸDNS Server 1: _____. _____._____._____ (optional)
ŸDNS Server 2: _____. _____._____._____ (optional)
Ÿ As system default route (Current setting : pppoe )
(Setup " Interent Setup)
ŸICMP Reply Enable (Setup -> Interent Setup)
ŸProxy ARP Enable

7
2. Hardware Installation
1. Connect one end of the Network cable to one of
the TEW-658BRM's LAN ports. Connect the
other end of cable to the computer's Ethernet
port.
2. Connect one end of the RJ-11 telephone cable
to the TEW-658BRM's ADSL port. Connect the
other end of the cable to the phone jack.
3. Connect the Power Adapter to the
TEW-658BRM and then to a power outlet. Push
the power button to the “On” position. Wait for
about 20 seconds.
4. Verify that the following panel lights are on:
Power (Green), LAN 1~4 (Green) (port your
computer is connected to), Wireless (Green)
and DSL (Green). Please see trouble shooting
section for additional information on LED
behaviors.

8
3. Configure the Modem
Note: It is recommended that you configure the Modem from a wired computer.
1. Open your web browser, type
http://192.168.10.1 in the Address bar, and then
press Enter.
2. Enter the User Name and password and then
click OK. By default:
User name: admin
Password: admin
Note: User name and Password are case
sensitive.
3. The Setup wizard will automatically appear.
Click Setup Wizard if the Setup Wizard does
not automatically appear.
4. Select PVCO and click Next.
