TRENDnet's TEW-223PI 11Mbps Wireless LAN PCI Adapter
is a powerful 32-bit adapter that installs right into your
computer's PCI Bus Slot (PCI specification 2.2), providing
wire-free access to networked resources on your LAN and the
Internet. An optional high-gain antenna can be attached to
the adapter via a reverse SMA connector to improve signal
quality and extend the connection distance. It dynamically
shifts between 11, 5.5, 2, and 1 Mbps for maximum availability
and reliability. Complying with 2.4 GHz frequency band and
IEEE 802.11b standard, TRENDnet's TEW-223PI ensures
great security and performance for your wireless networking
environment.
TEW-223PI
11Mbps Wireless PCI Network Adapter
Low interference and high susceptibility guarantee
reliable performance
Wire-Free access to networked resources for desktop PC
Uses 2.4 GHz frequency band (DSSS), which complies
with world wide requirements
Dynamically shifts between 11, 5.5, 2, and 1 Mbps
network speed, based on signal strength, for maximum
availability and reliability of connection
Diagnostic LED indicators
Reverse SMA Antenna Connector
Supports Windows 98/2000/ME/XP
Ensures great security by providing the 64-bit and 128-bit
Wired Equivalent Privacy (WEP) defined in IEEE 802.11b
standard
3-Year Warranty
BENEFITSFEATURES
Integration Friendly:
Economical:
Flexible:
Cost Effective:
Performance:
Drivers support most popular Network
Operating Systems.
Save time, labor and material for
network cable installation.
Creates wireless peer-to-peer network
in Ad-Hoc mode or connects to
Ethernet LAN in Infrastructure mode
using wireless Access Point.
Supports IEEE 802.11b wireless
standard; users can connect to any
IEEE 802.11b wireless network.
Connects at a speed of up to 11Mbps,
wirelessly!
TEW-223PI (01-07-2003)
TRENDnet
TRENDware, USA
What's Next in Networking

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TEW-221PC: 11Mbps Wireless CardBus PCMCIA
Network Adapter
TEW-223PI: 11Mbps Wireless PCI Network Adapter
TEW-224UB: 11Mbps Wireless USB Network Adapter
TEW-303PI: 22/11Mbps Wireless PCI Network Adapter
TEW-310APB: 22/11Mbps Wireless Access Point + Bridge
TEW-311BRP: 22/11Mbps Wireless Broadband Router
+ Access Point
TEW-PS3: 3-port Wireless Ethernet Print Server
NETWORKING SOLUTIONS
SPECIFICATIONS
TEW-223PI
11Mbps Wireless PCI Network Adapter
TEW-223PI
11Mbps Wireless PCI Network Adapter
Interface Type:
PCI Bus Power Management
Specification 2.2
Standards:
IEEE 802.11b WLAN Standard
Antenna:
2dBi Dipole antenna with
reverse SMA connector
Data Rate:
11Mbps, 5.5Mbps, 2Mbps,
and 1Mbps
Media Access Protocol:
CSMA/CA with ACK
Module Technique:
Direct Sequence Spread
Spectrum (DSSS), CCK,
DQPSK, DBPSK
•
•
•
•
•
•
Frequency:
2.4 to 2.4835 GHz (Industrial
Scientific Medical Band)
LED Indicator:
Link/Act
Output Power:
15dBm (typical)
Receiving Sensitivity:
-82dBm @11Mbps with
10-5 Bit Error Rate
(BER) (typical)
Channels:
11 Channels (US & Canada)
Power Consumption:
3.3V, 350mA (Max.)
Dimensions:
127 x 47 x 14 mm
(5 x 1.85 x 0.55 inches)
(without the metal bracket)
•
•
•
•
•
•
•
Weight:
Appr. 42.5 grams (1.5 Oz.)
with antenna
Temperature:
Operating: 0°~65°C (32°~149°F)
Storage:-20°~75°C (-4°~167°F)
Humidity:
95% max. (Non-condensing)
Certification:
FCC Part 15 in US, EN300328
and EN300826 in Europe
•
•
•
•
•
