TRENDnet 15-AH28B User manual

15-AH28B
Outdoor Internet Camera Server Housing
with Fan & Heater
Max Size Camera
Weight
Clear Window Area
Finish
Heater
Fan
Glass
Proposal
• L mm: 195 • W mm: 70 • H mm: 70
• 3mm
• Outdoor
• 2kg (4.55lb)
• Ø78
• Light Gray Powder – coating Body, Black End Caps
• Turn on at 5?±2?, Turn off at 10?±2?
• Turn on When Power in
• 90 ~ 230V AC
Housing Size
SPECIFICATIONS
Power Supply
Items
• L mm: 440 • W mm: 139 • H mm: 110
Housing Material • Aluminum
• Cable for camera can be run through centre of bracket for anti tamper protection
• Max Load: 10 kg.
• Construction: Steel
• Height: 230 mm
• Fixing: 4 screws
• Swivel Angle: 90ﾟ
• Tilt Angle: 120ﾟ
• Weight:4.7kg (10.5lb)
• Dimension:6.7 x3x48 cm (2.6 x1.2 x19 inches)
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
Heavy Duty Bracket
FEATURES
• Aluminum construction
• Additional heat insulation
• External use
• Require additional equipments for cable installation
Supported Models
• TV-IP201 / TV-IP201W
• TV-IP100 / TV-IP100W
• TV-IP301 / TV-IP301W
Ps. Cameras need to use the Camera’s own power adapter
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
• Flip open top
• 2 Year Warranty
