TRENDnet TV-IP344PI User manual

  

TRENDnetUser’sGuideCoverPage
































































  

©Copyright2017TRENDnet.AllRightsReserved. 


TRENDnetUser’sGuideTableofContents
i
Contents

ProductOverview....................................................................................1 
PackageContents.............................................................................................................1 
Features............................................................................................................................1 
ProductHardwareFeatures.............................................................................................2 
Installation..............................................................................................3 
HardwareInstallation.......................................................................................................3 
CameraInstallation..........................................................................................................4 
Configuration..........................................................................................7 
ViewingCameraBasicFunction.......................................................................................7 
ConfiguringtheCameraSetting.......................................................................................9 
SYSTEM.............................................................................................................................9 
NETWORK.......................................................................................................................12 
AUDIO/VIDEOSETTING..................................................................................................23 
EVENTCONFIGURATION................................................................................................27 
LOGOUT..........................................................................................................................33 
AccessingthecamerawithChrome.......................................................34 
Troubleshooting....................................................................................35 













  

©Copyright2017TRENDnet.AllRightsReserved. 
1

TRENDnetUser’sGuideLimitedWarranty
ProductOverview

TV‐IP344PI


PackageContents
 TV‐IP344PI
 QuickInstallationGuide
 CD‐ROM(Utility,Software&User'sguide)
 Networkcable(1.5M/5ft.)
 RJ‐45coupler
 CameraMountinghardware



Features
TRENDnet’sIndoor/Outdoor4MPVarifocalPoEIRNetworkCamera,modelTV‐IP344PI,
providespowerful4MPHDnightvisionat30fpsin completedarknessforupto30m
(100ft.). This IP66 weather rated camera features auto‐focus / optical zoom which
providesinstallationflexibilityandtimesavings.Usetheincludedpro‐gradesoftwareto
manageupto32TRENDnetcamerasordownloadthefreeiOS®orAndroid™mobileapp.
4Megapixel
Record2688x1520pixelresolutionata30fpsinthespacesavingH.264compression
format

Auto‐Focus/OpticalZoom
Auto‐focussavesinstallationandtroubleshootingtimeandremoteopticalzoomallows
userstocapturetheprecisedesiredviewingfield

NightVision
Nightvisionupto30m(100ft.)incompletedarkness

PoE
SaveinstallationcostswithPoweroverEthernet(PoE)

OutdoorReady
OutdoorIP66weatherratedwithanoperatingtemperaturerangeof‐20to60°C(‐4to
140°F)

MountingHardware
Integratedadjustablemountingbrackettilts180degreesandrotates360degrees

GPIOPortsandAlerts
NetworkanalarmsystemtoInput/Outputports

  

©Copyright2017TRENDnet.AllRightsReserved. 
2

TRENDnetUser’sGuideLimitedWarranty
AudioSupport
Audioinandoutportsforthirdpartymicrophoneandspeaker(soldseparately)

PowerPort
SaveinstallationcostswithPoweroverEthernet(IEEE802.3af)

MicroSDCardSlot
Addupto64GBmemoryforon‐boardvideostorage

D‐WDR
DigitalWideDynamicRangeimprovesvideoqualityinhighcontrastlighting
environments

MotionDetection
Createmotiondetectionwindowswithseparatesensitivitysettingsandeventtriggers

IPv6/ONVIF
IPv6supportedandONVIFcompliant

Varifocal
Opticalzoombyafactorof4.2xwithauto‐focustoafinalfixedpositionforinstallation
flexibility

Multi‐LanguageInterface
SupportforEnglish,French,Spanish,German,andPortuguese

ComplimentaryApp
LivevideotoamobiledevicewithafreeiOS
®
andAndroid
TM
apps

ComplimentarySoftware
Complimentarypro‐gradesoftwaretomanageTRENDnetcameras
ProductHardwareFeatures

CameraOverview




 Shield:Itisusedtoprotectthecamerafortheinclementweather.
 IRLens:IRlensforthecamera.
 CameraStand:themountingstandtoholdthecamera.






Shield
IR Lens
Camera Stand

  

©Copyright2017TRENDnet.AllRightsReserved. 
3

TRENDnetUser’sGuideLimitedWarranty
CameraConnectors







 PowerConnector:Connectsthepoweradaptertosupplypowertothecamera
ifusingnon‐PoEconnection
 Microphone In: Connects an external microphone to receive the on‐the‐spot
soundwherethecameraisinstalled
.

 SpeakerOut:Connectsanexternalaudiodevice(suchastheactivespeaker)to
deliversoundviathecamera.
 Ethernet/PoE Port: Plugs the network cable to connect to your local area
network (LAN). If you are using the PoE, you must have the network cable
connecttoyourPoEswitchorPoEInjector.
 Grounding:Groundthedevicetopreventdamage.
 GPIOPort:Connectexternaldevice.PleaserefertoI/Osettingparagraph.

Installation
HardwareInstallation
ViewingAngle
Choosethelocationwherehasgoodangleto shoot the image you expect tosee.The
motiondetectionareashouldalsobeconsideredwheninstallingthecamera.

BracketInstallation
TurnandlockthebracketintothemountingholeofIPcamera.Use screws to fix the
brackettoceilingorwall,andturntheknobtightlytofixtheangleofcamera.


LEDIndicator
The green LED will be flash when power on the camera and if there is the data
transmission.

Power
Connector
Speaker
Out
Microphone
In
Grounding
Ethernet /PoE
Port
Power On
LED
GPIO
Port

  

©Copyright2017TRENDnet.AllRightsReserved. 
4

TRENDnetUser’sGuideLimitedWarranty
Waterproofing
Thecameraisdesignedfeaturingwaterproof.However,youneedtoprotectthecable
connectorsfromwatersoaking.Forexample,youcantapethejunctionpointsofthe
connectorswhileyouconnectthecablesorpurchaseaweatherproofcable/powercord
protector.

MicroSDSlot
AfterinstalledaMicroSDCard,pleaseensurethecoverwasscrewtightlytoprotect
watersoaking.












CameraInstallation

1. InserttheInstallationCD‐ROMintoyourcomputer’sCD‐ROMdrive toinitiate the
Auto‐Runprogram.ClicktheInstallCamera.


2. WritedowntheMACIDofthecamera


  

©Copyright2017TRENDnet.AllRightsReserved. 
5

TRENDnetUser’sGuideLimitedWarranty
3. Pluginandconnectthepoweradaptertothecamera.IfyouareusingthePoEto
supplypowertothecamera,pleaseskiptothenextstep.ClickNextwhenyouare
done.


4. Waitwhilecameraissearching.


5. The founded cameras will show on the screen. The camera already selected by
defaultifyouhaveonlyonecamerainstalled.Ifyouhavemorethanonecamerain
thesameNetwork,youwillneedtoidentifythecamerabytheMACID.ClickNext.


6. Select"DHCP"optiontoassignanIPbyDHCPserverorSelect"FixedIP"tosetIP
addressmanually.ClickNext.


  

©Copyright2017TRENDnet.AllRightsReserved. 
6

TRENDnetUser’sGuideLimitedWarranty
7. Ifyou select"FixedIP",fillouttheIPaddress,subnetmask,defaultgateway,DNS
server.PleaseensurethattheIPaddressofthecameraandthe computer must
withinthesamenetwork.ClickNext.

8. TypeinthePassword.Thedefaultpasswordis“admin”.Youmustchangethedefault
passwordofthecamera.Enterthedefaultpassword:adminandenter the new
password.Thepasswordmustbebetween8and32characters.(Alphanumeric:a‐z,
A‐Z,0‐9),andenteringthepasswordtwotoconfirmpassword.

9. Click the hyperlink heretoaccesstothecamera’swebpageorclickNext. It is
recommendedthatyouaccesstheIPcameranowifitwasusingaDHCPconnection.

10. Click FinishtoexittheprogramorclickHometoreturntothemainscreen.
ThisdevicealsosupportstheMobileApp.UsingyourmobiledevicetoscantheQR
codetoinstalltheApp.
   

  

©Copyright2017TRENDnet.AllRightsReserved. 
7

TRENDnetUser’sGuideLimitedWarranty
Configuration

ViewingCameraBasicFunction
OpentheWebbrowseronyourcomputer(exampleshowedinthisUser’sGuideisbased
ontheInternetExplorer).IntheAddressbar,typetheIPaddressyougotfrom"Camera
Installation"chapterorfoundbyIPInstaller,andthenpress[Enter].


Whentheloginwindowappears,entertheUsername(admin)andPasswordandpress
OKtoaccesstothemainscreenofthecamera’sWebConfiguration.








Afteryouloginintothelivescreenofthecamera,themainpagewillappearasbelow:
 

ThelivescreenoftheIPcameraconfigurationprovidesyouwithmanyusefulinformation
andfunctions,including:
SETUP:Clickthebuttontoconfigurethecamera.
LOGOUT:Clickthebuttontologoutofthecameraviewingandconfigurationpage.
DigitalZoom:Clickonthe+or–orthedigitalbuttontozoominandout,orrightclick
ontheliveviewandselectzoomtoconfigurefrom100%to400%zoomsize.
FOCUS:Clickon+or–buttonorAFbuttontoadjustthefocusofthecamera.
Homebutton:resumethecamerabacktodefaultviewingsettings.
Snapshotbutton:Clickonsnapshotbuttontosavethecurrentimagetoadestination
folder.
Recording button:Clickonrecordingbuttontosavethecurrentimagetoa
destinationfolder.


  

©Copyright2017TRENDnet.AllRightsReserved. 
8

TRENDnetUser’sGuideLimitedWarranty
Speaker/Microphone:Clickthe"Mic"tospeakoutthroughthecamera.Clickthe
“Speaker”toreceivetheon‐sidesoundandvoicefromthecamera.
OnlineVisitor:ItshowshowmanypeopleconnecttothisIPcamera.
RelayOn:ClicktheRelayout"ON"totriggertherelayoutputfortesting.click"Off"
tostoptriggering.Toswitchbetweenthesetwotypesofrelayout,pleasereferto
EventConfiguration>>GPIOSettingsessionfordetail.

Onetheliveviewvideo,rightclickthemousefortheadditionalmenuoptions.

 Snapshot:SaveaJPEGpicture
 RecordStart:RecordthevideointhelocalPC.Itwillaskyouwheretosavethevideo.
To stop recording, right‐click the mouse again. Select “Record Stop”.Thevideo
formatisAVI.UseMicrosoftMediaPlayertoplaytherecordedfile.
 Mute:Turnofftheaudio.Clickagaintoturnonit.
The"mute"buttondoesnotaffecttheplaybackrecordingvideo.Aslongasthe"2‐
WayAudio"optionintheaudiosettingisenabled,alltheaudiowillberecordedinto
theplaybackvideoevenyouclick"mute"inthelivepage.
 FullScreen:Full‐screenmode.
 Zoom:Enablezoom‐inandzoom‐outfunctions.Select“Enabledigitalzoom”option
firstwithinthepop‐updialogueboxandthendraganddropthebartoadjustthe
zoomfactors.



 FrameBuffermSec:Thisfunctionistobuildatemporarybuffertoaccumulate
severalvideoframes.Thisfunctioncanmakevideosmooth‐goingwhentheNetwork
speedisslowandlag.










