TRENDnet TE100-S24D User manual

TE100-S24D
rev: 22.06.2011
24-Port 10/100Mbps Switch
TE100-S24D(V1.0R)
The 24-Port 10/100Mbps Switch, model TE100-S24D, is a reliable Plug-
and-Play solution in a compact form factor. Boost network effi ciency
with a total switching capacity of 4.8 Gbps with Full-Duplex mode.
Diagnostic LEDs on the front of the switch help with network trouble-
shooting. IEEE 802.3x fl ow control and 8K MAC address entry support
provide uninterrupted connectivity. This switch is well suited for net-
working room, departmental group, and home offi ce applications.
FEATURES
• 24 x 10/100Mbps Auto-Negotiation, Auto-MDIX Ethernet ports
• Compliant with IEEE 802.3/IEEE 802.3u standards
• 4.8Gbps switching fabric
• Store-and-Forward switching architecture with non-blocking wire-speed performance
• IEEE 802.3x fl ow control support
• Provides 8k MAC address entries
• 1.75Mbits RAM data buffer
• Diagnostic LEDs
• Compact housing
• Plug & Play installation
• 3 years limited warranty

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
without notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
NETWORKING SOLUTIONS
24-Port 10/100Mbps Switch
TE100-S24D(V1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TE100-S24D
Multi-Language Quick Installation Guide
Power adapter (5V DC, 2A)
RELATED PRODUCTS
TE100-S24g 24-Port 10/100Mbps GREENnet Switch
TE100-S16D 16-Port 10/100Mbps Switch
TEG-S50g 5-Port Gigabit GREENnet Switch
SPECIFICATIONS
HARDWARE
Standards • IEEE 802.3 10Base-T
• IEEE 802.3u 100Base-TX
• IEEE 802.3x Flow Control
Network Media • Ethernet: UTP/STP Cat. 5 up to 100 m
• Fast Ethernet: UTP/STPCat. 5, 5e, 6, up to 100 m
Data Rate • Ethernet: 10Mbps/20Mbps (half/full-duplex)
• Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
Protocol / Topology • CSMA /CD, Star
Power Consumption • 4.65 Watts (max.)
Switch Fabric • 4.8Gbps forwarding capcity
Interface • 24 x 10/100Mbps Auto-MDIX RJ-45 ports
RAM Data Buffer • 1.75Mbits
Filtering Table • 8K entries
Diagnostic LED • Power, Link/ACT
Power • 5V DC, 2A external power adapter
Dimension • 265 x 122.7 x 41 mm (10.4 x 4.8 x 1.6 in.)
Weight • 460 g (1.2 lb)
Temperature • Operating: 0° ~ 40° C (32° ~ 104° F); Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity • Max. 90% (non-condensing
Certications • CE, FCC
