TRENDnet TI-PG1284i User manual

TRENDnet User’s Guide
Cover Page

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Table of Contents
i
Contents
Product Overview ...........................................................................1
Package Contents .......................................................................................................... 1
Features......................................................................................................................... 1
Product Hardware Features........................................................................................... 3
SFP Transceiver/Optical Cable Installation .................................................................... 5
Switch Installation ..........................................................................6
DIN-Rail Installation ....................................................................................................... 6
Install power supply connections .................................................................................. 7
Basic IP Configuration.................................................................................................... 7
Connect additional devices to your switch.................................................................... 9
Accessing switch management interfaces ......................................10
Access your switch command line interface................................................................ 10
CLI Command Modes......................................................................................... 11
Access your switch web management page................................................................ 12
System Information.......................................................................13
Basic Settings ................................................................................14
General Settings .......................................................................................................... 14
System ............................................................................................................... 14
Jumbo Frame ..................................................................................................... 17
SNTP................................................................................................................... 18
Management Host ............................................................................................. 21
MAC Management....................................................................................................... 22
Static MAC Settings............................................................................................ 22
MAC Table.......................................................................................................... 24
Age Time Settings .............................................................................................. 24
Refusal (Black-hole MAC)................................................................................... 24
Port Mirror................................................................................................................... 26
Port Settings ................................................................................................................ 28
General Settings ................................................................................................ 29
Information........................................................................................................ 31
Advanced Settings ........................................................................ 32
Bandwidth Control ...................................................................................................... 32
QoS .................................................................................................................... 32
Rate Limitation .................................................................................................. 38
IGMP Snooping ............................................................................................................ 41
IGMP Snooping .................................................................................................. 41
IGMP Filtering.................................................................................................... 46
Multicast Listener Discovery (MLD) Snooping................................................... 49
MVR ................................................................................................................... 52
Multicast Address .............................................................................................. 56
Explicit Host Tracking......................................................................................... 58
VLAN ............................................................................................................................ 59
Port Isolation ..................................................................................................... 59
802.1Q VLAN...................................................................................................... 60
GARP/GVRP ....................................................................................................... 65
MAC-based VLAN............................................................................................... 67
Protocol-based VLAN......................................................................................... 68
Q-in-Q VLAN (VLAN Stacking) ............................................................................ 69
DHCP Option 82........................................................................................................... 76
DHCP Relay .................................................................................................................. 79
Dual Homing ................................................................................................................ 81
ERPS............................................................................................................................. 83
Link Aggregation.......................................................................................................... 87
Link Layer Discovery Protocol (LLDP)........................................................................... 91
Loop Detection ............................................................................................................ 94
Modbus........................................................................................................................ 96
PoE (Power over Ethernet) ........................................................................................ 100
PTP (IEEE-1588 v2)..................................................................................................... 106

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Table of Contents
ii
Static Route ............................................................................................................... 115
STP ............................................................................................................................. 118
Xpress Ring ................................................................................................................ 132
Security.......................................................................................134
IP Source Guard ......................................................................................................... 134
DHCP Snooping ................................................................................................ 134
Binding Table ................................................................................................... 139
ARP Inspection................................................................................................. 140
Access Control List (ACL)............................................................................................ 144
802.1x ........................................................................................................................ 147
Port Security .............................................................................................................. 153
TACACS+ .................................................................................................................... 154
Monitor ......................................................................................158
Alarm ......................................................................................................................... 158
Hardware Information ............................................................................................... 158
Port Statistics............................................................................................................. 159
Port Utilization........................................................................................................... 160
RMON Statistics ......................................................................................................... 160
SFP Information ......................................................................................................... 161
Traffic Monitor........................................................................................................... 161
Management ..............................................................................163
SNMP ......................................................................................................................... 163
SNMP Trap ....................................................................................................... 166
SNMPv3 ........................................................................................................... 166
Auto Provision ........................................................................................................... 169
Mail Alarm ................................................................................................................. 170
Maintenance.............................................................................................................. 172
System Log................................................................................................................. 176
User Account ............................................................................................................. 177
Technical Specifications .............................................................. 179
Troubleshooting ......................................................................... 182
Appendix .................................................................................... 183

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
1
Product Overview
TI-PG1284i
Package Contents
In addition to your switch, the package includes:
Quick Installation Guide
CD-ROM (User’s Guide)
RJ-45 to RS-232 console cable (1.8 m / 6 ft.)
If any package contents are missing or damaged, please contact the retail store, online
retailer, or reseller/distributor from which the product was purchased.
Please note power supply is sold separately (model: TI-24048).
Features
TRENDnet’s 12-Port Hardened Industrial Gigabit PoE+ Layer 2+ Managed DIN-Rail
Switch, model TI-PG1284i, has eight Gigabit PoE+ ports, four Gigabit SFP slots, and a
240W PoE budget. The switch is equipped with an IP30 rated metal enclosure and
designed to withstand a high degree of vibration, shock, protection against
ESD/EMI/surge, and operate within a wide temperature range (- 40 –75 °C (- 40 -
167°F)) for harsh environments. L2+ management include features such as PoE port
control, 802.1Q/Q-in-Q VLAN, multicast, spanning tree, link aggregation, QoS, IPv4/IPv6
static routing, ACLs, and 802.1X which allow for network integration flexibility.
Industrial Hardened Design
Equipped with a rugged IP30 rated enclosure and designed to withstand a high degree
of vibration, shock, protection against ESD/EMI/surge, and operate with a wide
temperature range (- 40 –75 °C (- 40 - 167 °F)) for harsh environments.
Integration Flexibility
Managed features include PoE control, IP static routing, access control lists, VLAN, IGMP
snooping, QoS, RMON, SNMP trap, and syslog for monitoring and flexible network
integration.
Fault Tolerance
Features dual redundant power inputs (Primary and RPS) from external power sources
and an output alarm relay to indicate the event of input power failure

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
2
Full PoE+ Power Budget
Supplies up to 30 Watts of PoE/PoE+ power per port with a 240 Watt PoE power budget
Network Ports and Capacity
8 x Gigabit PoE+ ports and 4 x Gigabit SFP slots allow for a 24Gbps switching capacity
and 1 x console (RJ-45 to RS-232) for out-of-band management
Integrated DIN-Rail Mount
IP30 rated metal enclosure with integrated DIN-Rail mounting hardware
Full PoE Control Per Port
PoE control features include enabling/disabling PoE and class, power priority, PD alive
check, scheduling, and power delay per port using CLI or web management.
Traffic Management
Managed features include 802.1Q/Q-in-Q/GVRP/MAC & Protocol-Based VLAN, IGMP
v1/2/3, IGMP Snooping, MLD, MVR, per port bandwidth control/802.1p/DSCP/Queue
Scheduling (SPQ/WRR), STP/RSTP/MSTP spanning tree, static and dynamic link
aggregation, and Xpress Ring + ERPS protection for flexible network integration.
Layer 2+ Management
Offers IPv4/IPv6 static or DHCPv4/v6 assignment, IPv4/IPv6 static routing and proxy
ARP, DHCP server/relay/option 82, and DHCP server snooping/screening to filter out
unauthorized DHCP servers
Access Controls
Management via HTTPS and SSH protocols and features such as trusted host, ACLs, IP-
MAC-Port binding, ARP inspection, 802.1X RADIUS, MAC address learning, IP Source
Guard provide layered network access controls.
System Monitoring
Monitoring features include SNMP v1/v2c/3, MIB support, SNMP trap, RMON Groups (1,
2, 3, 9), SMTP alert, syslog, port mirroring, SFP DDMI, and ModBus/TCP.
Redundant Power
Dual redundant power inputs (primary and RPS) with overload current protection
Alarm Output
Alarm relay output triggered by power failure of primary and/or redundant power and
failure per port (DIP switch)
Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 10K)
Wide Temperature
Hardened switch is rated for an operating temperature range of - 40 to 75 °C (-40 to 167
°F)
Electro Magnetic Compliance
Complies with IEC61000-6-2 EMC generic standard immunity for industrial
environments
Shock and Vibration Resistant
Rated for shock (IEC 60068-2-27), freefall (IEC 60068-2-32), and vibration (IEC 60068-2-
6)
LED Indicators
LED indicators convey power, redundant power, alarm, SFP, PoE, and network port
status
Grounding Point
Grounding point protects equipment from external electrical surges

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
3
Product Hardware Features
LED Indicators
Ports 1-8 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in both
half-duplex and full-duplex transfer modes. Supports Auto MDI-X and capable
of delivering up to 30W (802.3at PoE+) per port.
SFP Slots 9-12 –Designed to operate at Gigabit speeds.
Reboot Button –Push the button and release to reboot the switch.
Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
Note: For any unused ports or SFP slots, it is recommended to leave the rubber plugs
installed during operation.
LED
State
Status
PWR
(Green)
ON
When the PWR LED is on, the device is using the primary
power input source.
OFF
Primary power input source is off, disconnected, or has
failed.
RPS
(Green)
ON
When the RPS LED lights on, the device is using the
redundant power input source.
OFF
Redundant power input source is off, disconnected or has
failed.
ALM
(Red)
ON
Indicates alarm has been triggered on DIP switch settings and
signal sent out through ALM terminals on terminal block to
third party alarm device.
OFF
No alarm triggered.
POST
(Green)
ON
Device is ready and completed boot process.
OFF
Device is not ready.
SFP Slots 9-12
(Green)
ON
SFP link is connected.
BLINKING
Data is transmitting/receiving.
OFF
SFP link is disconnected.
PoE Ports 1-8
(Green)
ON
PoE supplied to Ethernet port.
OFF
No PoE supplied to Ethernet port.
Ports 1-8
1000M
(Green)
10/100M
(Orange)
ON
Ethernet port is connected.
BLINKING
Data is transmitting/receiving.
OFF
Ethernet port is not connected.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
4
6-pin Removable Terminal Block
Note: Turn off the power before connecting modules or wires.
Calculate the maximum possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for each wire size. If current
go above the maximum ratings, the wiring could overheat, causing serious damage to
your equipment.
ALM DIP Switches
Input/Ouput
Function
PWR Input
(+) & (-)
Connects primary power source (ex. external power supply) to power the
device. Device will obtain power from this input first priority if available.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to loosen (counter-clockwise) or tighten
(clockwise) the wiring from the external power supply.
Please ensure that the external power supply is supplying within the
range of 48VDC ~ 57VDC @ 240W or above. 260W for max. PoE+ power.
Please note power supply is sold separately (model: TI-24048)
Device supports overload current protection and reverse polarity
protection.
RPS Input
(+) & (-)
Connects redundant power source (ex. external power supply) to power
the device. Device will obtain power from this input secondary priority if
primary power input is not available or has failed.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to loosen (counter-clockwise) or tighten
(clockwise) the wiring from the external power supply.
Please ensure that the external power supply is supplying within the
range of 48VDC ~ 57VDC @ 240W or above. 260W for max. PoE+ power.
Please note power supply is sold separately (model: TI-24048)
Device supports overload current protection and reverse polarity
protection.
ALM Output
Connects external alarm and sends output signal if fault is detected
based on DIP switch settings.
Supports an output with current carrying capacity of 1A @ 24V DC.
DIP No
Name
State
Status
1
PWR
ON
Primary power input source alarm trigger enabled.
OFF
Primary power input source alarm trigger disabled.
2
RPS
ON
Redundant power input source alarm trigger enabled.
OFF
Redundant power input source alarm trigger disabled.
3
P1
ON
Ethernet port 1 link alarm trigger enabled.
OFF
Ethernet port 1 link alarm trigger disabled.
4
P2
ON
Ethernet port 2 link alarm trigger enabled.
OFF
Ethernet port 2 link alarm trigger disabled.
5
P3
ON
Ethernet port 3 link alarm trigger enabled.
OFF
Ethernet port 3 link alarm trigger disabled.
6
P4
ON
Ethernet port 4 link alarm trigger enabled.
OFF
Ethernet port 4 link alarm trigger disabled.
7
P5
ON
Ethernet port 5 link alarm trigger enabled.
OFF
Ethernet port 5 link alarm trigger disabled.
8
P6
ON
Ethernet port 6 link alarm trigger enabled.
OFF
Ethernet port 6 link alarm trigger disabled.
9
P7
ON
Ethernet port 7 link alarm trigger enabled.
OFF
Ethernet port 7 link alarm trigger disabled.
10
P8
ON
Ethernet port 8 link alarm trigger enabled.
OFF
Ethernet port 8 link alarm trigger disabled.
11
P9
ON
SFP slot 9 link alarm trigger enabled.
OFF
SFP slot 9 link alarm trigger disabled.
12
P10
ON
SFP slot 10 link alarm trigger enabled.
OFF
SFP slot 10 link alarm trigger disabled.
13
P11
ON
SFP slot 11 link alarm trigger enabled.
OFF
SFP slot 11 link alarm trigger disabled.
14
P12
ON
SFP slot 12 link alarm trigger enabled.
OFF
SFP slot 12 link alarm trigger disabled.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
5
SFP Transceiver/Optical Cable Installation
1. Remove the rubber plug from the SFP slot.
Note: For any unused ports or SFP slots, it is recommended to leave the
rubber plugs installed during operation.
2. Slide the selected SFP module into the selected SFP slot (Make sure the SFP
module is aligned correctly with the inside of the slot)
3. Insert and slide the module into the SFP slot until it clicks into place.
4. Remove any rubber plugs that may be present in the SFP module’s slot.
5. Align the fiber cable’s connector with the SFP module’s mouth and insert the
connector
6. Slide the connector in until a click is heard
7. If you want to pull the connector out, first push down the release clip on top
of the connector to release the connector from the SFP module
To properly connect fiber cabling:Check that the fiber terminators are clean. You can
clean the cable plugs by wiping them gently with a clean tissue or cotton ball moistened
with a little ethanol. Dirty fiber terminators on fiber optic cables will impair the quality of
the light transmitted through the cable and lead to degraded performance on the port.
Note: When inserting the cable, be sure the tab on the plug clicks into position to
ensure that it is properly seated.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
6
Switch Installation
DIN-Rail Installation
The site where the switch will be installed may greatly affect its performance. When
installing, consider the following pointers:
Note: The switch model may be different than the one shown in the example
illustrations.
Install the switch in the appropriate location. Please refer to the technical
specifications at the end of this manual for the acceptable operating temperature
and humidity ranges.
Install the Switch in a site free from strong electromagnetic field generators (such
as motors), vibration, dust, and direct exposure to sunlight.
Install the switch in a location that is not affected by strong electromagnetic field
generators (such as motors), vibration, dust, and direct sunlight.
Leave at least 10cm of space at the front and rear of the switch for ventilation.
Fasten the DIN-Rail bracket to the rear of the switch using the included
fasteners/screws.
Note: The DIN-Rail bracket may already be installed to your switch when received.
The movable clip at the top of the DIN-Rail bracket should be on top.
The switch can be installed to a 35mm (W) DIN-Rail located in cabinet, rack, or
enclosure.
To mount the switch to a DIN-Rail using the attached DIN-Rail bracket, position the
switch in front of the DIN-Rail and hook the bracket over the top of the rail.
Then rotate the switch downward towards the rail until your hear a click indicating the
bracket is secure and locked into place.
To unmount the switch from the DIN-Rail, slightly pull the switch downwards to clear
the bottom of the DIN-Rail and rotate away from DIN-Rail to unmount.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
7
Install power supply connections
Connect the power supply (sold separate, e.g. TRENDnet TI-S24048) to the switch
terminal block as shown below.
Note: Polarities V+ and V- should match between power supply and connections to
switch terminal block.
Optional: The switch chassis can also be connected to a known ground point for
additional safety and protection (grounding wire not included).
Basic IP Configuration
2. Assign a static IP address to your computer’s network adapter in the subnet of
192.168.10.x (e.g. 192.168.10.25) and a subnet mask of 255.255.255.0.
4. Open your web browser, and type the IP address of the switch in the address bar, and
then press Enter. The default IP address is 192.168.10.200.
5. Enter the User Name and Password, and then click Login. By default:
User Name: admin
Password: admin
Note: User name and password are case sensitive.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
8
6. Click Basic Settings and then click General Settings.
7. Configure the switch IP address settings to be within your network subnet, then click
Apply.Note: You may need to modify the static IP address settings of your computer’s
network adapter to IP address settings within your subnet in order to regain access to
the switch.
8. Click Save at the top right.
9. When confirmation message appears click OK.
Note: Once the settings are saved, you can connect the switch to your network.

© Copyright 2016 TRENDnet. All Rights Reserved.
9
TRENDnet User’s Guide
TI-PG1284i
Connect additional devices to your switch
You can connect additional computers or other network devices to your switch using Ethernet cables to connect them to one of the available Gigabit PoE+ Ports (1-8). Check the status of
the LED indicators on the front panel of your switch to ensure the physical cable connection from your computer or device.
Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network
settings (also called TCP/IP settings) are configured properly within the network subnet your switch is connected.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
10
Accessing switch management interfaces
Access your switch command line interface
Note: The system may be managed out-of-band through the console port. The console
port is a female RJ-45 port and the included RJ-45 male to RS-232 serial DB-9 female
console cable. Throughout this user’s guide, the term “CLI Configuration” will be used
reference access through the command line interface.
1. Using the included RJ-45 to RS-232 serial DB-9 cable, connect the RJ-45 end to the
switch console port and connect the RS-232 end to your computer RS-232 DB-9 male
port.
2. On your computer, run the terminal emulation program (ex. HyperTerminal,
TeraTerm, Putty, etc.).
3. Select the appropriate COM port used for connecting to the switch console.
4. Use the following settings for the connection.
Setting
Default Value
Terminal Emulation
VT100
Baud Rate
38400
Parity
None
Number of Data Bits
8
Number of Stop Bits
1
Flow Control
None
5. After you have setup all of the parameters appropriately, the terminal emulation
window should display a prompt for user name and password.
Enter the user name and password. By default:
Console User Name: admin
Note: User Name and Password are case sensitive.
Enable Mode/Privileged Exec User Name: admin
Enable Mode/Privileged Exec Password: admin
Setting
Default Value
Default Username
admin
Default Password
admin
Setting
Default Value
IP Address
192.168.10.200
Subnet Mask
255.255.255.0
Default Gateway
0.0.0.0
Management VLAN
1
Default Username
admin
Default Password
admin

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
11
CLI Command Modes
Node
Command
Description
enable
show hostname
This command displays the system’s network
name.
configure
reboot
This command reboots the system.
eth0
ip address A.B.C.D/M
This command configures a static IP and subnet
mask for the system.
interface
show
This command displays the current port
configurations.
acl
show
This command displays the current access
control profile.
vlan
show
This command displays the current VLAN
configurations.
The Node type:
enable
Its command prompt is “TI-PG1284I#”.
It means these commands can be executed in this command prompt.
configure
Its command prompt is “TI-PG1284I(config)#”.
It means these commands can be executed in this command prompt.
In Enable code, executing command “configure terminal” enter the configure
node.
TI-PG1284I# configure terminal
eth0
Its command prompt is “TI-PG1284I(config-if)#”.
It means these commands can be executed in this command prompt.
In Configure code, executing command “interface eth0” enter the eth0
interface node.
TI-PG1284I(config)#interface eth0
TI-PG1284I(config-if)#
interface
Its command prompt is “TI-PG1284I(config-if)#”.
It means these commands can be executed in this command prompt.
In Configure code, executing command “interface gigaethernet1/0/5” enter
the interface port 5 node.
Or
In Configure code, executing command “interface fastethernet1/0/5” enter
the interface port 5 node.
Note: depend on your port speed, gigaethernet1/0/5 for gigabit Ethernet
ports and fastethernet1/0/5 for fast Ethernet ports.
TI-PG1284I(config)#interface gigaethernet1/0/5
TI-PG1284I(config-if)#
vlan
Its command prompt is “TI-PG1284I(config-vlan)#”.
It means these commands can be executed in this command prompt.
In Configure code, executing command “vlan 2” enter the vlan 2 node.
Note: where the “2” is the vlan ID.
TI-PG1284I(config)#vlan 2
TI-PG1284I(config-vlan)#
acl
Its command prompt is “TI-PG1284I(config-acl)#”.
It means these commands can be executed in this command prompt.
In Configure code, executing command “access-list test” enter the access-list
test node.
Note: where the “test” is the profile name.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
12
TI-PG1284I(config)#access-list test
TI-PG1284I(config-acl)#
Access your switch web management page
Note: Your switch default management IP address http://192.168.10.200 is accessed
through the use of your Internet web browser (e.g. Internet Explorer®, Firefox®,
Chrome™, Safari®, Opera™) and will be referenced frequently in this User’s Guide.
Throughout this user’s guide, the term Web Conifiguration will be used to reference
access from web management page.
1. Open your web browser and go to the IP address http://192.168.10.200. Your switch
will prompt you for a user name and password.
2. Enter the user name and password. By default:
User Name: admin
Password: admin
Note: User Name and Password are case sensitive.
Parameter
Description
User ID
Enter the user name.
Password
Enter the password.
Default:
User name: admin
Password: admin

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
13
System Information
CLI Configuration
Node
Command
Description
enable
show hostname
This command displays the system’s network
name.
enable
show interface eth0
This command displays the current Eth0
configurations.
enable
show model
This command displays the system information.
enable
show running-config
This command displays the current operating
configurations.
enable
show system-info
This command displays the system’s CPU loading
and memory information.
enable
show uptime
This command displays the system up time.
Web Configuration
System Status > System Information
Parameter
Description
Model Name
This field displays the model name of the Switch.
Host name
This field displays the name of the Switch.
Boot Code
Version
This field displays the boot code version.
Firmware Version
This field displays the firmware version.
Built Date
This field displays the built date of the firmware.

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
14
DHCP Client
This field displays whether the DHCP client is enabled on the
Switch.
IP Address
This field indicates the IP address of the Switch.
Subnet Mask
This field indicates the subnet mask of the Switch.
Default Gateway
This field indicates the default gateway of the Switch.
MAC Address
This field displays the MAC (Media Access Control) address of the
Switch.
Serial Number
The serial number assigned by manufacture for identification of
the unit.
Management
VLAN
This field displays the VLAN ID that is used for the Switch
management purposes.
CPU Loading
This field displays the percentage of your Switch’s system load.
Memory
Information
This field displays the total memory the Switch has and the
memory which is currently available (Free) and occupied (Usage).
Current Time
This field displays current date (yyyy-mm-dd) and time
(hh:mm:ss).
DHCPv6 Client
This field displays whether the DHCPv6 client is enabled on the
Switch.
IPv6 Link Local
This field displays the Switch’s link local IP address for IPv6.
IPv6 Default
Gateway
This field displays the default gateway for IPv6.
IPv6 Global
This field displays the Switch’s global IP address for IPv6.
Refresh
Click this to update the information in this screen.
Basic Settings
General Settings
System
Management VLAN
To specify a VLAN group which can access the Switch.
The valid VLAN range is from 1 to 4094.
If you want to configure a management VLAN, the management VLAN should
be created first and the management VLAN should have at least one member
port.
Host Name
The hostname is same as the SNMP system name. Its length is up to 64 characters.
The first 16 characters of the hostname will be configured as the CLI prompt.
Default Settings
The default Hostname is TI-PG1284I
The default DHCP client is disabled.
The default Static IP is 192.168.10.200
Subnet Mask is 255.255.255.0
Default Gateway is 0.0.0.0
Management VLAN is 1.
CLI Commands
Node
Command
Description
enable
ping IPADDR [–c COUNT]
This command
sends an echo
request to the
destination host.
The –c parameter
allow user to
specific the packet

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
15
count. The default
count is 4.
enable
ping IPADDR [–s SIZE]
This command
sends an echo
request to the
destination host.
The –s parameter
allow user to
specific the packet
size. Valid range: 0
~ 1047 bytes.
enable
ping IPADDR [–c COUNT –s SIZE]
This command
sends an echo
request to the
destination host.
The –c parameter
allow user to
specific the packet
count. The default
count is 4. The –s
parameter allow
user to specific the
packet size. Valid
range: 0 ~ 1047
bytes.
enable
ping IPADDR [-s SIZE –c COUNT]
This command
sends an echo
request to the
destination host.
The –c parameter
allow user to
specific the packet
count. The default
count is 4. The –s
parameter allow
user to specific the
packet size. Valid
range: 0 ~ 1047
bytes.
configure
reboot
This command
reboots the
system.
configure
hostname STRINGS
This command sets
the system's
network name.
configure
interface eth0
This command
enters the eth0
interface node to
configure the
system IP.
configure
configure terminal
This command
changes the mode
to config mode.
configure
interface eth0
This command
changes the mode
to eth0 mode.
eth0
show
This command
displays the eth0
configurations.
eth0
ip address A.B.C.D/M
This command
configures a static
IP and subnet
mask for the
system.
eth0
ip address default-gateway A.B.C.D
This command
configures the
system default
gateway.
eth0
ip dhcp client (disable|enable|renew)
This command
configures a DHCP

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
16
client function for
the system.
Disable: Use a
static IP address
on the switch.
Enable & Renew:
Use DHCP client to
get an IP address
from DHCP server.
eth0
management vlan VLANID
This command
configures the
management vlan.
eth0
ip ipv6-address
AAAA:BBBB:CCCC:DDDD:EEEE:FFFF:GGGG:HHHH/M
This command
configures a global
scope of IPv6
address and
subnet mask for
the system.
eth0
ip ipv6-address default-gateway
AAAA:BBBB:CCCC:DDDD:EEEE:FFFF:GGGG:HHHH
This command
configures a
default gateway
for the system.
eth0
ip ipv6-dhcp client (disable|enable|renew)
This command
configures a
DHCPv6 client
function for the
system.
Disable: Use a
static IP address
on the switch.
Enable & Renew:
Use DHCPv6 client
to get an IP
address from
DHCPv6 server.
Example: The procedures to configure an IP address for the Switch.
To enter the configure node.
TI-PG1284I#configure terminal
TI-PG1284I(config)#
To enter the ETH0 interface node.
TI-PG1284I(config)#interface eth0
TI-PG1284I(config-if)#
To get an IP address from a DHCP server.
TI-PG1284I(config-if)#ip dhcp client enable
To configure a static IP address and a gateway for the Switch.
TI-PG1284I(config-if)#ip address 192.168.202.111/24
TI-PG1284I(config-if)#ip address default-gateway 192.168.202.1
To configure a static global IPv6 address and a gateway for the Switch.
Please set the static global IPv6 address first.
TI-PG1284I(config-if)#ip ipv6-address 3ffe::1235/64
And the set the IPv6 default gateway address.
TI-PG1284I(config-if)#ip ipv6-address default-gateway 3ffe::1234

© Copyright 2016 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TI-PG1284i
17
Web Configuration
Basic Settings > General Settings > System
IP Address
Configures a IPv4 address for your Switch in dotted decimal
notation. For example, 192.168.10.200.
Subnet Mask
Enter the IP subnet mask of your Switch in dotted decimal
notation for example 255.255.255.0.
Default Gateway
Enter the IP address of the default outgoing gateway in dotted
decimal notation, for example 192.168.10.1.
IPv6 Settings
DHCPv6 Client
Select Enable to allow the Switch to automatically get an IP
address from a DHCPv6 server. Click Renew to have the Switch
re-get an IP address from the DHCP server.
Select Disable if you want to configure the Switch’s IP address
manually.
Global Address
Configure a global IPv6 address for the Switch.
Default Gateway
Set –Set an IPv6 default gateway for the Switch.
Unset –Unset the IPv6 default gateway for the Switch.
Apply
Click this button to take effect the settings.
Refresh
Click this button to reset the fields to the last setting.
Jumbo Frame
Jumbo frames are Ethernet frames with a payload greater than 1500 bytes. Jumbo frames
can enhance data transmission efficiency in a network. The bigger the frame size, the
better the performance.
Notice:
The jumbo frame settings will apply to all ports.
If the size of a packet exceeds the jumbo frame size, the packet will be dropped.
The available values are 1522, 1536, 1552, 9010, 9216, 10240.
Default Settings
The default jumbo frame is 10240 bytes.
CLI Configuration
Node
Command
Description
enable
show jumboframe
This command displays the
current jumbo frame settings.
