The 8-Port 10/100Mbps Layer 2 Managed Switch provides exceptional
performance, ease of use and flexibility for managing business networks. Utilizing a
robust 3.8Gbps backplane, the 8 port managed switch can connect to multiple
switches while handling full-duplex operations. In addition to the switch's
scalability, it also offers a variety of management features such as SNMP, IGMP for
multi-media applications, VLAN, Port Security, Spanning Tree Protocol, Port
Trunking, Broadcast Storm Filtering, Port Mirroring and other features that can
easily be accessed through a web browser or a command line interface.
TE100-S800i
8-Port 10/100Mbps Layer 2 Managed Switch
TE100-S800i
rev:11.30.2005
• 8 x 10/100Mbps Auto-MDIX Ports
• Supports switch Fabric up to 3.8GBps
• Layer 2 Management Switch with Full Software Support
• IGMP Snooping with Query Mode Support for Multi-Media Application
• Supports Broadcast Storm Filtering
• Supports Port Status Control (Status, Auto-Negotiation, Speed, Duplex and Flow Control)
• Supports Port Trunking with Flexible Load Distribution Control and Fail-Over Functions
• Supports Port-Based VLAN and IEEE 802.1Q Tag-Based VLAN
• Supports IP Multicast, Port Mirroring, Spanning Tree, SNMP and RMON
• Supports Port Security and IEEE 802.1p Class of Services
• Store-and-Forward Switching Architecture with Non-Blocking Wire-Speed Performance
• Configuration via RS-232 Console Port, Telnet, and Web Browser (HTTP)
• TFTP Firmware Upgrade via Browser
• Configuration File Save and Restore Support
• 5-Year Warranty
FEATURESFEATURES

LED Display
Interface
Packet Forwarding and Filtering Rate
Cabling
Console Port
Protocol/Topology
Buffer Memory
Power
Power Consumption
Weight
Humidity
Safety Emissions
Dimensions
Temperature
• IEEE 802.3 10Base-T Ethernet; IEEE 802.3u 100Base-TX Fast Ethernet
• Up to 3.8Gbps
• IEEE 802.3x Flow Control; IEEE 802.1D Spanning Tree
• Power, Link/Activity, Full Duplex/Collision
• 250 x 133 x 37mm (9.8 x 5.2 x 1.5 inch) (W x H x D)
• Operating: 0° ~ 45° C (32° ~ 113° F)
• 8 x 10/100Mbps Auto-MDIX RJ45 Fast Ethernet Port
• 100M Ethernet: 148,800 packets per second per port
• Fast Ethernet: UTP/STP Cat. 5, EIA/TIA-568 100-ohm, 100 meters max
• RS-232, female 9-Pin Serial Port (M-M serial cable included)
• Input: 100~240VAC, 50/60Hz Internal Power Supply
• (CSMA/CD) / Star
• 2Mbits Data Buffer
• 8K MAC Address Entries
• 1.08 Kg. (2.4 lb.)
• 17 watts
• 10% ~ 90% non-condensing
• FCC, CE
Filtering Address Table
Bandwidth
Standards
Hardware
SPECIFICATIONSSPECIFICATIONS
8-Port 10/100Mbps Layer 2 Managed Switch
TE100-S800i
• IEEE 802.1q Tag-based VLAN; IEEE 802.1p Class of Service
• IEEE 802.3ad Link Aggregation
• 10M Ethernet: 14,880 packets per second per port
• Storage: -40° ~ 70° C (-40° ~ 158° F)
NETWORKING SOLUTIONSNETWORKING SOLUTIONS
Servers with 32-bit PCI
Fast Ethernet Card
(TE100-PCIWA)
Accounting Department
Workstations with 32-bit PCI
Fast Ethernet Card
(TE100-PCIWN)
Workstations with 32-bit PCI
Fast Ethernet Card
(TE100-PCIWN)
Sales Department
8-port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S88Eplus)
5-port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S5Pplus)
8-port 10/100Mbps
Fast Ethernet Mini Switch
(TE100-S8P)
MIS Department
8-Port 10/100Mbps Layer 2 Managed Switch
(TE100-S800i)
Internet
100Mbps

Management
Trunk
Class of Service
QoS
VLAN
IP Multicast
Filter Database
Port Mirror
Broadcast Control
Spanning Tree
RFC Standard
• Web Management, RS-232 Console Management, Telnet
• Max 4 Groups ( up to 4 ports per group)
• Supports High and Low Priority
• Supports 8 Levels of Priority and Mapping to High/Low Priority Queue for Class of Service
• Up to 256 VLAN groups and up to 4094 VLAN ID
• IGMP Snooping up to 256 groups • 2 Types of Query Mode: Enable/Disable or Auto Query
• Port Static MAC address lock, MAC filter and Port Security
• Up to 8 ports
• None, 5%, 10%, 15%, 20%, 25%
• IEEE 802.1d Support
• RFC 768 UDP, RFC 783 TFTP, RDC791 IP, RFC 792 ICMP, RFC 854 TELNET Server/Client, RFC 1112 IGMP, RFC 2068
HTTP, RFC 2674 VLAN MID, RFC 1493 Bridge MIB, RFC 1157 SNMP, RFC 1213 MIB II, Bridge MIB, RFC 1643 Ethernet
Like, RFC 1757 RMON1, LANTECH Enterprise MIB, RFC 1215 Trap
To Order Please Call:
1-888-326-6061
ORDERING INFORMATIONORDERING INFORMATION
3135 Kashiwa Street,Torrance, CA. 90505. USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
8-Port 10/100Mbps Layer 2 Managed Switch
TE100-S800i
Wireless
SPECIFICATIONSSPECIFICATIONS
TEG-S081Fi
TE100-S810Fi 8-Port 10/100Mbps Layer 2 Managed Switch
with 100Base-FX Port
• Quick Installation Guide
• RS-232 Cable / Power Cord
8-Port 100Base-FX Layer 2 Managed Switch
with GBIC Slot
• TE100-S800i
• CD-ROM (User's Guide)
RELATED PRODUCTSRELATED PRODUCTS
PACKAGE CONTENTSPACKAGE CONTENTS
