TRENDnet TI-RP262i User manual

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Table of Contents
i
Contents
Product Overview ...........................................................................1
TI-RP262i........................................................................................................................ 1
Package Contents ................................................................................................ 1
TI-PG102i ....................................................................................................................... 5
Non-PoE......................................................................................................................... 8
TI-G642i ......................................................................................................................... 8
TI-G102i ....................................................................................................................... 11
TI-G160WS................................................................................................................... 14
TI-G160i ....................................................................................................................... 17
Switch Installation ........................................................................20
DIN-Rail Installation ..................................................................................................... 20
Install power supply connections ................................................................................ 21
SFP Transceiver/Optical Cable Installation .................................................................. 21
Basic IP Configuration.................................................................................................. 22
Connect additional devices to your switch.................................................................. 23
Accessing switch management interfaces......................................24
Access your switch command line interface................................................................ 24
CLI Command Modes......................................................................................... 24
Access your switch web management page................................................................ 26
System Information.......................................................................27
Basic Settings................................................................................28
General Settings .......................................................................................................... 28
System ............................................................................................................... 28
Jumbo Frame ..................................................................................................... 29
SNTP................................................................................................................... 30
Management Host ............................................................................................. 32
MAC Management ...................................................................................................... 34
Static MAC Settings............................................................................................ 34
Age Time Settings .............................................................................................. 36
MAC Table ......................................................................................................... 36
Port Mirror................................................................................................................... 37
Port Settings ................................................................................................................ 39
General Settings ................................................................................................ 40
Information........................................................................................................ 42
Advanced Settings ........................................................................43
Bandwidth Control ...................................................................................................... 43
QoS .................................................................................................................... 43
Rate Limitation .................................................................................................. 49
IGMP Snooping............................................................................................................ 52
IGMP Snooping .................................................................................................. 52
Multicast Address .............................................................................................. 55
VLAN ............................................................................................................................ 58
Port Isolation ..................................................................................................... 58
802.1Q VLAN...................................................................................................... 59
MAC VLAN ......................................................................................................... 63
DHCP Options .............................................................................................................. 64
DHCP Relay .................................................................................................................. 67
EEE (Energy Efficient Ethernet).................................................................................... 70
ERPS (Ethernet Ring Protection Switching) ................................................................. 71
Link Aggregation.......................................................................................................... 75
Loop Detection ............................................................................................................ 80
Modbus........................................................................................................................ 82
Power over Ethernet ................................................................................................... 86
STP ............................................................................................................................... 91
Security ...................................................................................... 100

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Table of Contents
ii
IP Source Guard ......................................................................................................... 100
Binding Table ................................................................................................... 105
ARP Inspection................................................................................................. 107
Filter Table ....................................................................................................... 109
Access Control List (ACL)............................................................................................ 110
802.1x ........................................................................................................................ 114
Port Security .............................................................................................................. 119
Monitor ......................................................................................121
Alarm ......................................................................................................................... 121
Port Statistics............................................................................................................. 121
Port Utilization........................................................................................................... 122
RMON Statistics ......................................................................................................... 123
SFP Information ......................................................................................................... 123
Traffic Monitor........................................................................................................... 124
Management ..............................................................................126
SNMP ......................................................................................................................... 126
SNMP Trap ....................................................................................................... 128
Auto Provision ........................................................................................................... 129
Mail Alarm ................................................................................................................. 130
Maintenance.............................................................................................................. 133
System Log................................................................................................................. 136
User Account ............................................................................................................. 136
Device Management.................................................................................................. 138
Toplogy Map.............................................................................................................. 142
Technical Specifications .............................................................. 143
TI-PG541i ................................................................................................................... 143
TI-PG102i ................................................................................................................... 148
TI-G642i ..................................................................................................................... 151
TI-G102i ..................................................................................................................... 154
TI-G160WS................................................................................................................. 157
TI-G160i ..................................................................................................................... 160
Troubleshooting ......................................................................... 163
Appendix....................................................................................164

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
1
Product Overview
TI-RP262i
Package Contents
In addition to your switch, the package includes:
•Quick Installation Guide
•Console cable (RJ-45 to RS-232)
•Rackmount Kit
If any package contents are missing or damaged, please contact the retail store, online
retailer, or reseller/distributor from which the product was purchased.
TRENDnet’s Industrial Gigabit L2 Managed PoE+ Rackmount Switch Series offers
advanced layer 2 managed features with enhanced traffic controls to meet the evolving
demands of today’s SMB networks. Each industrial layer 2 rackmount switch is equipped
with an IP30 rated metal enclosure, designed to withstand a high degree of vibration
and shock, while operating within a wide temperature range of -40° –70° C (-40° –158°
F) for industrial environments. Our industrial layer 2 rackmount switch models feature
copper gigabit ports for high-speed device connections, as well as SFP slots that support
100/1000Base-FX SFP modules for long distance fiber networking applications. These
industrial layer 2 rackmount switches feature a fanless design that eliminates operating
noise and lowers energy consumption.
These Industrial Gigabit L2 Managed PoE+ Rackmount Switch Series provides an intuitive
web-based management interface. Each TRENDnet industrial layer 2 rackmount switch
supports advanced traffic management controls, troubleshooting, and SNMP
monitoring. Advanced managed switch features include LACP to group ports together
and increase bandwidth between switches, VLANs for segmenting and isolating virtual
LAN groups, QoS to prioritize traffic, port bandwidth controls, SNMP monitoring, and
more, making each TRENDnet industrial layer 2 rackmount switch a powerful solution
for SMB networks.

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
2
Front View
Rear View
•LED Indicators –Indicators on the left display ALM, PWR, and POST status.
LEDs on each port show the status of the port based on the mode selected
using the Mode Button.
•Mode Button –Press the mode button to change the left LED indicator on each
port to display Speed, or PoE Mode. When button is depressed it will display
PoE, when not pressed it will indicate if 1000Mbps.
•Gigabit Ethernet PoE+ Ports (1-24) –Connect either network PoE+ or non-PoE
devices.
•Reset Button –Press and hold the button for less than 5 seconds to reboot, or
more than 5 seconds to reset to factory default.
•SFP Slots (25-26) –Supports optional 1000BASE-SX/LX mini-GBIC modules for
uplink or downlink connections.
•Console Port –The console port is a female RJ-45, use the included RJ-45 male
to RS-232 serial DB-9 female console cable.
•Power Terminals –Using proper gauge wire, terminate the leads from your
power supply to these power terminals to power your switch.
LED Indicators
•Ports 1-4 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in both
half-duplex and full-duplex transfer modes. Supports Auto MDI-X and capable
of delivering up to 30W (802.3at PoE+) per port.
•Port 5 - Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in both
half-duplex and full-duplex transfer modes. Supports Auto MDI-X
•SFP Slot 6 –Designed to operate at Gigabit speeds.
•Reset/Reboot Button –Push the button for 10 seconds and release to reset the
switch to factory defaults. Push the button for 3 seconds and release to reboot.
•Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
Note: For any unused ports or SFP slots, it is recommended to leave the rubber plugs
installed during operation.
LED
State
Status
PWR
(Green)
ON
When the PWR LED is on, the device is using the primary
power input source.
OFF
Primary power input source is off, disconnected, or has
failed.
ALM
(Red)
ON
Indicates alarm has been triggered on DIP switch settings and
signal sent out through ALM terminals on terminal block to
third party alarm device.
OFF
No alarm triggered.
POST
(Green)
ON
Device is ready and completed boot process.
OFF
Device is not ready.
SFP Slot 6
(Green)
ON
SFP link is connected.
BLINKING
Data is transmitting/receiving.
OFF
SFP link is disconnected.
PoE Ports 1-4
(Green)
ON
PoE supplied to Ethernet port.
OFF
No PoE supplied to Ethernet port.
Ports 1-5
1000M
(Green)
10/100M
(Off)
ON
Ethernet port is connected.
BLINKING
Data is transmitting/receiving.
OFF
Ethernet port is not connected.

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
3
Top View
DC Jack Input for External Power Adapter
The device includes a DC Jack for an external power adapter and can
also be used as an additional redundant power supply (RPS) input.
Please ensure that the external power adapter is supplying 48VDC @
120W or above. 130W for max. PoE+ power. Please note power
adapter is sold separately (model: 48VDC3000)
*Please note power supply is sold separately*
**Supported power supplies: TI-S12024 (120W), TI-S24048 (240W), TI-S48048 (480W).
Lower wattage power supplies may be used but may result in decreased PoE power
budget**
6-pin Removable Terminal Block
Input/Ouput
Function
PWR Input
(+) & (-)
Connects primary power source (ex. external power supply) to power the
device. Device will obtain power from this input first priority if available.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Please ensure that the external power supply is supplying within the
range of 48VDC ~ 57VDC @ 120W or above. 130W for max. PoE+ power.
Please note power supply is sold separately (model: TI-24048)
Device supports overload current protection and reverse polarity
protection.
RPS Input
(+) & (-)
Connects redundant power source (ex. external power supply) to power
the device. Device will obtain power from this input secondary priority if
primary power input is not available or has failed.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Please ensure that the external power supply is supplying within the
range of 48VDC ~ 57VDC @ 120W or above. 130W for max. PoE+ power.
Please note power supply is sold separately (model: TI-24048)
Device supports overload current protection and reverse polarity
protection.
ALM Output
Connects external alarm and sends output signal if fault is detected
based on DIP switch settings.
Supports an output with current carrying capacity of 1A @ 24V DC.
DIP Switches
Reset Button
(bottom of unit)
Ground point
6-pin terminal
block (PWR,
RPS, ALM)
DIP switch
definition
DC Jack
(optional, see below)

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
4
ALM DIP Switches
DIP No
Name
State
Status
1
PWR
ON
Primary power input source alarm trigger enabled.
OFF
Primary power input source alarm trigger disabled.
2
RPS
ON
Redundant power input source alarm trigger enabled.
OFF
Redundant power input source alarm trigger disabled.

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
5
TI-PG102i / TI-PG102i-M
Front View
•PoE+ Ports 1-8 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in
both half-duplex and full-duplex transfer modes while simultaneously providing
power to supported PoE devices. Supports Auto MDI-X.
•SFP Slot 9-10 –Designed to operate at Gigabit or 100Mbps speeds.
•Reset Button –Push the button for 5-10 seconds and release to reset.
•Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
LED Indicators
PoE+ Gigabit
RJ-45 ports
10/100/1000
Mbps per port
LED indicator
LINK/ACT per
port LED
indicator
IP30 Rated
Housing
PoE LEDs
SFP+ Slots

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
6
Top View
*Please note power supply is sold separately*
**Supported power supplies: TI-S12024 (120W), TI-S24048 (240W), TI-S48048 (480W).
Lower wattage power supplies may be used but may result in decreased PoE power
budget**
6-pin Removable Terminal Block
Note: Turn off the power before connecting modules or wires.
Calculate the maximum possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for each wire size. If current
go above the maximum ratings, the wiring could overheat, causing serious damage to
your equipment.
Input/Output
Function
PWR Input
(+) & (-)
Connects primary power source (ex. external power supply) to power the
device. Device will obtain power from this input first priority if available.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
RPS Input
(+) & (-)
Connects redundant power source (ex. external power supply) to power
the device. Device will obtain power from this input secondary priority if
primary power input is not available or has failed.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
ALM Output
Connects external alarm and sends output signal if fault is detected
based on DIP switch settings.
Supports an output with current carrying capacity of 1A @ 24V DC.
DIP Switches
Reset Button
Ground point
6-pin terminal
block (PWR,
RPS, ALM)
DIP switch
definition

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
7
ALM DIP Switches
Switch
Status
Function
1
OFF
Disable alarm relay for PWR power input
ON
Enable alarm relay for power failure on PWR power input
2
OFF
Disable alarm relay for RPS power input
ON
Enable alarm relay for power failure on RPS power input
3
OFF
Storm control managed by switch configuration
ON
Enable storm control (Broadcast and DLF rate set to 300pps)
Takes precedence over storm control switch configuration
4
OFF
802.1p QoS managed by switch configuration
ON
Enable 802.1p QoS on ports 1 and 2 (Set CoS priority to tag 4
on ports 1 and 2)
Takes precedence over 802.1p QoS switch configuration
5
OFF
Port 9 SFP set to Gigabit speed full duplex
ON
Port 9 SFP set to 100Mbps speed full duplex
6
OFF
Port 10 SFP set to Gigabit speed full duplex
ON
Port 10 SFP set to 100Mbps speed full duplex

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
8
Non-PoE
TI-G642i
Front View
•Ports 1-4 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in both
half-duplex and full-duplex transfer modes. Supports Auto MDI-X.
•SFP Slot 5-6 –Designed to operate at Gigabit speeds.
•Reset Button –Push the button for 3 seconds and release to reset to factory
defaults.
•Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
LED Indicators
Gigabit
RJ-45 ports
10/100/1000
Mbps per port
LED indicator
LINK/ACT per
port LED
indicator
IP30 Rated
Housing
Gigabit
SFP Slots

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
9
Top View
*Please note power supply is sold separately*
**Supported power supplies: TI-M6024, TI-S12024 (120W), TI-S24048 (240W) **
6-pin Removable Terminal Block
Note: Turn off the power before connecting modules or wires.
Calculate the maximum possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for each wire size. If current
go above the maximum ratings, the wiring could overheat, causing serious damage to
your equipment.
Input/Output
Function
PWR Input
(+) & (-)
Connects primary power source (ex. external power supply) to power the
device. Device will obtain power from this input first priority if available.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
RPS Input
(+) & (-)
Connects redundant power source (ex. external power supply) to power
the device. Device will obtain power from this input secondary priority if
primary power input is not available or has failed.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
ALM Output
Connects external alarm and sends output signal if fault is detected
based on DIP switch settings.
Supports an output with current carrying capacity of 1A @ 24V DC.
DIP Switches
Reset Button
Ground point
6-pin terminal
block (PWR,
RPS, ALM)
DIP switch
definition

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
10
ALM DIP Switches

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
11
TI-G102i
Front View
•Ports 1-8 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in both
half-duplex and full-duplex transfer modes. Supports Auto MDI-X.
•SFP Slot 9-10 –Designed to operate at Gigabit or 100Mbps speeds.
•Reset Button –Push the button for 3 seconds and release to reset to factory
defaults.
•Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
LED Indicators
Gigabit
RJ-45 ports
10/100/1000
Mbps per port
LED indicator
LINK/ACT per
port LED
indicator
IP30 Rated
Housing
Gigabit
SFP Slots

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
12
Top View
*Please note power supply is sold separately*
**Supported power supplies: TI-M6024, TI-S12024 (120W), TI-S24048 (240W) **
6-pin Removable Terminal Block
Note: Turn off the power before connecting modules or wires.
Calculate the maximum possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for each wire size. If current
go above the maximum ratings, the wiring could overheat, causing serious damage to
your equipment.
Input/Output
Function
PWR Input
(+) & (-)
Connects primary power source (ex. external power supply) to power the
device. Device will obtain power from this input first priority if available.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
RPS Input
(+) & (-)
Connects redundant power source (ex. external power supply) to power
the device. Device will obtain power from this input secondary priority if
primary power input is not available or has failed.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
ALM Output
Connects external alarm and sends output signal if fault is detected
based on DIP switch settings.
Supports an output with current carrying capacity of 1A @ 24V DC.
DIP Switches
Reset Button
Ground point
6-pin terminal
block (PWR,
RPS, ALM)
DIP switch
definition

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
13
ALM DIP Switches

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
14
TI-G160WS
Front View
•Ports 1-16 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in
both half-duplex and full-duplex transfer modes. Supports Auto MDI-X.
•Reset Button –Push the button for 3 seconds and release to reset to factory
defaults.
•Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
LED Indicators
Gigabit
RJ-45 ports
10/100/1000
Mbps per port
LED indicator
LINK/ACT per
port LED
indicator
IP30 Rated
Housing

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
15
Top View
*Please note power supply is sold separately*
**Supported power supplies: TI-M6024, TI-S12024 (120W), TI-S24048 (240W) **
6-pin Removable Terminal Block
Note: Turn off the power before connecting modules or wires.
Calculate the maximum possible current in each power wire and common wire. Observe
all electrical codes dictating the maximum current allowable for each wire size. If current
go above the maximum ratings, the wiring could overheat, causing serious damage to
your equipment.
Input/Output
Function
PWR Input
(+) & (-)
Connects primary power source (ex. external power supply) to power the
device. Device will obtain power from this input first priority if available.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
RPS Input
(+) & (-)
Connects redundant power source (ex. external power supply) to power
the device. Device will obtain power from this input secondary priority if
primary power input is not available or has failed.
Please make sure to power supplies are turned off before wiring in.
Use a flat-head screw driver to push the orange notches in order release
the wiring connections. While holding in released position, insert the
wiring into the connection inputs from the external power supply and
release the orange notch to lock in the wire connections.
Device supports overload current protection and reverse polarity
protection.
ALM Output
Connects external alarm and sends output signal if fault is detected
based on DIP switch settings.
Supports an output with current carrying capacity of 1A @ 24V DC.
DIP Switches
Reset Button
Ground point
6-pin terminal
block (PWR,
RPS, ALM)
DIP switch
definition

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
16
ALM DIP Switches

© Copyright 2020 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
Managed Industrial L2 Switches
17
TI-G160i
Front View
•Ports 1-16 –Designed to operate at 10Mbps, 100Mbps, or Gigabit speed in
both half-duplex and full-duplex transfer modes. Supports Auto MDI-X.
•Reset Button –Push the button for 3 seconds and release to reset to factory
defaults.
•Grounding point/screw –The switch chassis can also be connected to a known
ground point for additional safety and protection. (grounding wire not
included)
LED Indicators
Gigabit
RJ-45 ports
10/100/1000
Mbps per port
LED indicator
LINK/ACT per
port LED
indicator
IP30 Rated
Housing
