TRENDnet TEG-2 248WS User manual

TREflDnET
•48-Port 10/100Mbps Web Smart Switch
TEG-2 248WS
• Quick Installation Guide (1)
TEG-2248WS (C1 ] / 06.17.2014

PyCCKMft ESPANOL I DEUTSCH FRANQAIS ENGLISH
1. Before You Start
Package Contents
• TEG-2248WS
• Multi- anguage Quick Installation Guide
• CD-ROM (Utility and User's Guide)
• Power cord
• Rack mount kit
Minimum Requirements
• Computer with an Ethernet port and web browser
• Network cable
Optional Equipment
• EIA standard 19” rack
• SFP modules (e.g. TE100-MGBFX, TEG-MGBSX, TEG-MGBS10, TEG-MGBS40, TEG-MGBS80)
1

. Hardware Installation and Configuration
4. Open your web browser, type the IP address of the switch in the address bar, and then press Enter.
The default IP address is 192.168.10.200.
5. Enter the User name and Password, and then click ogin. By default:
User Name: admin
Password: admin
Note: User Name and Password are case sensitive.
2

ESPANOL I DEUTSCH FRAN^AiS ENGLISH
6. Click System and then click IPv4 Setup.
7. Configure the switch to match the requirements of your network. Then click Apply.
8. Click OK.
Note:
1. If you would like to easily discover all the Web Management Switches on the network, assign IP
address, change password, then install the Web Smart Switch Management Utility. Follow the
steps provided on the user's guide.
2. To download the latest version of the user's guide and the utility, please go to
http://www.trendnet.com/support and select the TEG-2248WS within the Products Download
dropdown list.
For detailed information regarding the TEG-2248WS’s configuration and advanced settings, please
refer to the User's Guide on the provided CD-ROM.
