The TEG-S224M is a high-capacity management stackable Fast
Ethernet master switch that provides the scalability and flexibility
to deploy a cost-effective network environment. The TEG-
S224M has three slots. Slot 1 is a 2-port 10/100Base-TX module
(switched), which it can be replaced with either a 2-port
100Base-FX (MT-RJ) module (optional) or a 1-port 100Base-FX
(SC) module (optional). Slot 2 is dedicated for a 3-port stacking
module (optional extension port). Slot 3 provides an optional 1 or
2-port 1000Base-SX (SC) Gigabit Ethernet module. The TEG-
S224M stacks with up to three TEG-S224S. Using the optional
switched modules, they support a maximum configuration of 94
10/100Mbps Ethernet/Fast Ethernet ports and two Gigabit
Ethernet ports.
TEG-S224M
22-port 10/100/1000Mbps Management Stackable Fast Ethernet Master Switch
Complies with IEEE 802.3, IEEE 802.3µ, IEEE 802.1p/Q, IEEE 802.3x standards
22 N-way auto-negotiation UTP/STP ports
Port-based VLAN
Half- and full-duplex modes
Store-and-forward switching method
Data filtering eliminates bad packets and runts
Back-plane bandwidth up to 21.32Gbps
Supports IEEE 802.1d Spanning Tree Protocol
12K MAC address table per device
IEEE 802.1q VLAN tagging and extended Port/MAC based VLAN
Integrated flow control
Port aggregation support
IGMP snooping - Multimedia Applications support
Broadcast Storm Filtering monitors the broadcast traffic
Console or Telnet configuration
Flash memory for software upgrade
Web-based network management to monitor and configure the device
Front panel port status LEDs
EIA-19 rack mountable
5 Year Warranty
BENEFITSFEATURES
Performance:
Expandability:
Reliability:
Flexibility:
Manageability:
The full-duplex Gigabit switch brings
high bandwidth with 2000Mbps speed.
Provides up to 94-port 10/100Base-TX
ports and two Gigabit ports.
Supports IEEE 802.1p Traffic
Prioritization for time-sensitive and
mission-critical traffic.
With different optional modules, the
switch can be easily connected to
other networks.
Provides the benefit of extensive and
simple management through SNMP,
HTTP, and four RMON groups.
TEG-S224M (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
Standards:
• IEEE 802.3, IEEE 802.3µ, IEEE
802.1p/Q, IEEE 802.3x,
IEEE 802.3z
Protocol:
• CSMA/CD
Switching Method:
• Store-and-forward
Management Protocols:
• SNMP, Web-based Management,
RMON, Java Management Application,
Telnet, MIBs (MIB-II, Bridge, RMON,
and VLAN), Local and remote
out-of-band management
LEDs:
• Per Device: Power, Console,
Slot, Stacking Port,
Gigabit Port
• Per Port: 100M, Link/Act
Cabling:
• CAT 3, 4, 5 UTP/STP RJ-45 for
10Mbps, 100 meter max.;
• CAT 5 UTP/STP RJ-45 for
100Mbps, 100 meter max.;
multimode SC-type fiber, 2 km
max.; multimode MT-RJ type
fiber, 2 km max.
• For Gigabit connection:
Multimode Fiber 50/125
micron-meter, 525 Meter max.;
Multimode Fiber 62.5/125
micron-meter, 275 Meter max.
Console Port:
• 9 pin-male, D-type EIA-232 port
Power:
• 100-240 VAC, 50/60Hz,
46Watt max.
Dimensions:
• 441 x 367 x 44 mm /
17.3 x 8.0 x 1.7 inches
Weight:
5 kg / 11 lbs.
Temperature:
• Operating: 0° to 50° C /
32° to 122° F
Humidity:
• 5 % to 95 % non-condensing
Certifications:
• FCC, CE, VCCI Class A,
C-tick, BCIQ
TEG-S224M
22-port 10/100/1000Mbps Management Stackable Fast Ethernet Master Switch
TEG-S224M
22-port 10/100/1000Mbps Management Stackable Fast Ethernet Master Switch
PRODUCT INFORMATION
TEG-PCISX 64-bit 1000Base-SX Gigabit Ethernet Adapter with SC Connector
TEG-S40SX 4-port 1000Base-SX Gigabit Ethernet Switch
TEG-S224M 22-port 10/100Mbps Management Stackable Master Switch with
Optional Gigabit Ethernet
TEG-S224S 24-port 10/100Mbps Management Stackable Fast Ethernet Slave
Switch
TEG-M101F 1-port 100Base-FX (SC) Module for TEG-S224M and TEG-S224S
TEG-M102FM 2-port 100Base-FX (MJ-RJ) Module for TEG-S224M and TEG-
S224S
TEG-M3S 3-port SIO Stacking Extension Module forTEG-S224M
TEG-M1G 1-port 1000Base-SX (SC) Gigabit Ethernet Module for TEG-S224M
TEG-M2G 2-port 1000Base-SX (SC) Gigabit Ethernet Module for TEG-S224M
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit
____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: 310-891-1100
Fax: 310-891-1111
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
