TRENDnet TPE-S44 - Switch Installation and operation manual

8-Port 10/100Mbps PoE Switch
TPE-S44
1.11
ŸGuide d'installation rapide (1)
ŸTechnical Specifications (4)
ŸTroubleshooting (5)

1
Configuration du système
Contenu de l'emballage
Si tout le contenu ci-dessus sont manquantes, s'il vous plaît contactez votre
revendeur.
1. Avant de commencer
ŸUn ordinateur avec un adaptateur réseau correctement installé
Ÿ
Ÿ
Ÿ
Ÿnon fourni)
ŸCâble réseau RJ-45 Cat. 5, Cat. 5e ou Cat. 6
La surface sous le commutateur doit pouvoir résister à un poids minimum
de 430g
ŸLa prise secteur doit être située à un maximum de 1,82 mètres de
l'appareil
Inspectez visuellement la prise d'alimentation et assurez-vous qu'elle est
correctement connectée à l'adaptateur secteur
Vérifiez la présence d'une source de ventilation adéquate autour du
commutateur pour une dissipation efficace de la chaleur
ŸNe placez pas d'objets lourds sur le commutateur.
ŸPériphérique alimenté par IEEE 802.3af
TPE-112GS (
ŸTPE-S44
Cordon d'alimentation
48V DC, 800mA)
ŸGuide d'installation rapide
Ÿ
ŸAdaptateur secteur (
Remarque: Le TPE-S44 ne supporte que les péripériques alimentés qui
respectent la norme IEEE 802.3af

2. LEDs
2
Couleur
Rouge Fixe
Clignotant
Clignotant
Séquence Définition
PoE Max
System
Power
PoE Status
(Ports 1 à 4)
Link/Act
(Ports 1 à 8)
100Mbps
(Ports 1 à 8)
Vert
Eteint
Eteint
Eteint
Vert
Vert
Vert
Vert
Eteint
Fixe
Fixe
Fixe
L'appareil est hors.
Fixe
Eteint
L'appareil est sur le.
Fixe Si le Switch détecte qu'il y a 7,5W
(ou moins) decourant disponible, ce
voyant s'allumera. Ceci indique une
surtension.
Si le voyant est rouge, le port n'a pas
réussi à fournir l'alimentation.
Activité depuis cette liaison.
LAN port de données de transmission /
réception ou de 10/20Mbps
100/200Mbps (Half / Full Duplex).
Si le Switch detecte qu'il y a plus de
7,5W de courant disponible, ce voyant
ne s'allumera pas.
Si aucun périphérique alimenté n'est
branché, le voyant ne s'allume pas.
Port est débranché / Non Ethernet Link.
Rien n'est détecté sur le port.
Lorsque le Switch est relié à un
périphérique PoE et que le port fournit
correctement l'alimentation, le voyant
est vert.
Le port est relié à une activité
Ethernet / Fast Ethernet dispositif de.
Port LAN connecté à 10/20 Mbps ou
100/200Mbps (Half / Full Duplex).
Voyants
lumineux

3. Installation du matériel
Remarque : La tension maximale disponible est de 15,4 watts par port et de 30
Watts au total. Si une surcharge se produit, le Switch donnera la priorité à la
distribution de courant par port (du plus bas au plus haut). Donc, le port 1
recevra la priorité la plus importante et le port 4, la priorité la plus faible. La
fonction PoE des ports avec la priorité la plus faible sera désactivéejusqu'à ce
qu'au moins 7,5 Watts soient disponibles.
1. Branchez le cordon d'alimentation
sur l' adaptateur secteur. Branchez
l'adaptateur secteur au TPE-S44 et
à une prise de courant.
2. Branchez un câble réseau RJ-45
entre l'ordinateur et un port
Ethernet disponible sur le TPE-S44.
3
3. Branchez un câble RJ-45 cable
entre un port PoE (1 à 4) du
TPE-S44 et le port LAN du
périphérique PoE
(p. ex. le TV-IP322P)
4. Vérifiez que les voyants suivants
du panneau sont allumés: System
Power, PoE Status et Link/ACT.

Technical Specifications
Standards ŸIEEE 802.3 10Base-T
ŸIEEE 802.3u 100Base-TX
ŸIEEE 802.3af Power over Ethernet
Network Media Ÿ10Mbps: Cat 3,4,5 Unshielded Cable
Ÿ100Mbps Cat 5,5e,6 Unshielded Cable
Data Transfer Rate ŸEthernet: 10/20Mbps (half/full-duplex)
ŸFast Ethernet: 100/200Mbps (half/full-duplex)
Power 48V DC 800mA External Power Adapter
Hardware
Power Consumption Ÿ6.3 Watts max. (no Power Device (PD) connected)
Ÿ36.3 Watts max. with 30w PoE Device connected
Protocol/Topology CSMA/CD, Star
Ports
RAM Buffer/Filtering
Diagnostic LEDs
96 Kbytes/ 1K entry per device
Ÿ4 x 10/100Mbps Auto-MDIX POE Ports (1~4)
Ÿ4 x 10/100Mbps Auto-MDIX Fast Ethernet Ports (5~8)
ŸPer Unit: Power, Power MAX
ŸPer Port: Link/Activity, 100M
ŸPoE: PoE Status, Link/Activity, 100M
Dimension 171 x 98 x 29mm (6.7 x 3.7 x 1.1 in.)
Weight
ŸOperating: 0° ~ 40° C (32° ~ 104° F)
ŸStorage: -10° ~ 70° C (14° ~ 158° F)
Humidity
Temperature
10%-90% (non-condensing)
Certifications FCC, CE
430g (13.8 oz)
PoE
Power over Ethernet ŸPower budget: 30 watts (max)
ŸUp to 15.4 watts per Port
ŸPD classification Identify
ŸPoE Over Current Portection
ŸPoE Circuit Sorting Protection PoE Power on RJ-45
pin 3,6 Power+ and pin 1,2 for Power-
4

Troubleshooting
1. After connecting the Switch to a power outlet, the LEDs do not turn on.
1. Check the connection of the external power adapter to the TPE-S44
and the power outlet
2. Check that the power outlet is receiving power.
2. After I connect my PCs to the Switch, I am unable to share files.
1. Check the LEDs on the Switch. Make sure the Link/ACT LED is on.
2. Check the network cable. The minimum length of the cable is 1.5
meters and the maximum length of the cable is 100 meters.
3. Disable any software firewall program.
4. Verify that you have file sharing enabled. Please contact your Operating
System support for more information.
3. After I connect my PCs to the Switch, I can only get onto the Internet
from one computer.
The Switch was not designed to share Internet between multiple computers.
You need to get an Internet router such as the TW100-S4W1CA.
4. My 802.3af Powered device does not power on when I plug the device
into the Switch. What should I do?
1. Verify that the PoE device supports IEEE 802.3af protocol.
2. Power cycle the PoE switch. Unplug power to the Switch, wait 15
seconds, then plug the power back in.
3. Plug the device into a different port on the PoE switch.
4. Try using another RJ-45 network cable.
5. A power overload may have an occurred. Connect your 802.3af
Powered Device into port 1 and/or disconnect all other 802.3af
Powered Device.
5. Where is the uplink port located on the Switch?
Since all the ports on the Switch are Auto-MDIX, any of the ports can
be used as an uplink port.
If you still encounter problems or have any questions regarding the TPE-S44
please contact Trendnet's Technical Support Department.
5
