TRENDnet TE-500plus User manual

TE-500plus
TE-800plus
TE-910plus
Palm Size
10Base-T Ethernet Hub
User’s Guide

FCC Warning
This equipment has been tested and found to comply
with the regulations for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with this user’s guide, may cause harmful interference
to radio communications. Operation of this equipment
in a residential area is likely to cause harmful
interference, in which case the user will be required to
correct the interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment,
this product may cause radio interference, in which
case the user may be required to take adequate
measures.

Table of Contents
INTRODUCTION............................................................................1
PRODUCT FEATURES.....................................................................1
THE FRONT PANEL OF PALM SIZE HUBS...............................2
THE REAR PANEL OF PALM SIZE HUBS.................................3
LED INDICATORS..........................................................................4
REAR PANEL CONNECTORS..........................................................4
Twisted-pair Jacks..................................................................4
Uplink Jack..............................................................................5
Power Jack..............................................................................5
INSTALLATION..............................................................................6
INSTALLINGTHE HUB...................................................................6
CONNECTING THE POWERADAPTER..........................................6
CABLES AND CONNECTORS..........................................................7
CROSSOVER CABLES.....................................................................8
SPECIFICATIONS.......................................................................10
GENERAL......................................................................................10
ENVIRONMENTAL AND PHYSICAL.............................................10
Rev.01

1
Introduction
Thank you for choosing the PALM SIZE 10BASE-T Ethernet
Hub. The hub was designed and manufactured to give you
years of trouble-free and reliable service.
The hub is designed for plug-and-play installation and easy
management. The hub provides an Uplink connection (shared
with Port 1) for your network expansion via a RJ-45 MDI-II
connector, making it easy to link two or more hubs together.
The hub features LINK/RX LEDs to show the network
connection and packet receiving status of each twisted pair port.
PWR (power) and COL (collision) indicators show the
operational status of the hub.
Product Features
?? Compliance with IEEE 802.3 10Base-T and 10Base-2
(TE-910plusonly) standard.
?? Automatic partitioning function of each port to isolate
network failure.
?? RJ45 ports support Category 3 or better twisted-pair
cable.
?? LED indicators for each twisted pair port for link and
receive status.
?? Uplink jack for easy linking of two hubs to further expand
the network.
?? Compact in size.

2
The Front Panel of The Hub
5-port Ethernet Hub
8-port Ethernet Hub
9-port Ethernet Hub with BNC port

3
The Rear Panel of The Hub
5-port Ethernet Hub
8-port Ethernet Hub
9-port Ethernet Hub with BNC port

4
LED Indicators
Power (PWR):
This indicator lights green when the hub
is receiving power.
Collision (COL): This indicator indicates data collisions
on
the hub. Whenever a collision is detected,
the respective COL indicator will briefly
blink amber.
Note: Occasional collision is
acceptable. If the collision LED is al
ways
on, maybe there is a problem with the
network or the hub, or the network traffic
is high.
Link/Receive:
(LINK/RX)
This indicator lights green when a
network connection is established.
This
indicator blinks green when
the hub is
receiving data packets.
BNC:
(TE-910plus only) This indicator blinks green when BNC
port connection has network activities
(network connection is established on the
BNC port).
Rear Panel Connectors
RJ45 MDI-X Twisted-pair Jacks
Use these jacks to connect Ethernet devices
(server/workstation/print server) to the hub. These are MDI-X
(Medium Dependent Interface, Cross-Wired) jacks, which
means you can use ordinary stright-through twisted-pair cables
to connect workstations and servers to the hub. If you need to
connect another device with an MDI-X jack, such as another

5
hub or an Ethernet switch, you should use a crossver cable, or
make the connection using the Uplink jack.
Uplink Jack
The Uplink jack is an MDI-II jack, which means you can
connect the hub to an Ethernet device’s (i.e. Hub or Switch)
MDI-X port using straight-through cable.
Port1 and the Uplink port is really the same port, except their
pinouts are different. Do not use both Port-1 (1X) and the
Uplink port at the same time.
When uplinking hubs together, please do not exceed the
“4-repeater (hub) count, 3 segments, and 2 populated
segments” Ethernet connection rule. Basically, you can only
uplink 4 hubs together using the UTP cable. The maximum
CAT3, 4, or 5 twisted pair cable distance between two Ethernet
devices is 100 meters. If you have question about this rule,
please contact our support department at
[email protected].
BNC Port (TE910plusonly)
To connect the 10Base-2 network, attach the thin coax cable’s
BNC “T Connector” to the BNC port. Terminate the open end
of the “T Connector” with a 50 Ohms Terminator. The coax
cable should be marked RG58U or RG58 A/U, the maximum
cable length between the two terminators is 185 meters, and
you can connect up to 30 nodes on this cable.
Power Jack
For connecting the External power adapter.

6
Installation
Installing the Hub
The site where you install the hub may greatly affect
its performance. When installing, consider the
following pointers:
Install the hub in a fairly cool and dry place, for
the acceptable temperature and humidity operating
ranges.
?? Install the hub in a site free from strong
electromagnetic field generators (i.e.
motors), vibration, dust, and direct
exposure to sunlight.
?? Leave at least 10 cm of space at the front
and rear of the hub for ventilation. Note not
to block the ventilation holes on the top of
the hub.
?? Install the hub on a sturdy, level surface
that can support its weight.
?? You can stack two or more hubs together by
inserting the two small round legs at the
bottom of the hub to the two holes on top of
another hub.
Connecting the Power Adapter
Power is supplied to the Ethernet Hub through an AC
power adapter. Connect the adapter to the power
outlet and then connect the plug to the hub’s power
jack.

7
Cables and Connectors
Twisted-Pair Cable: Category 3 or better
unshielded twisted-pair or EIA/TIA-568 compliant,
100-ohm shielded twisted-pair data cable with 0.4
to 0.6 mm (22 to 26 AWG) wires in two or four
twisted pairs (only two pairs, four wires, are used
for 10BASE-T).
Maximum segment length: 100 meters.
Connectors: RJ-45.
Straight Twisted-Pair Cable Pinouts
Contact MDI-X Signal MDI-II Signal
1RD+ (receive) TD+ (transmit)
2RD-(receive) TD-(transmit)
3TD+ (transmit) RD+ (receive)
4Not used Not used
5Not used Not used
6TD-(transmit) RD-(receive)
7Not used Not used
8Not used Not used
BNC Cable: Thin Coax RG-58U or RG-58A/U 50 Ohms cable.
185 meters maximum segment length (requires 50 Ohms T
Connector for each connection and Terminator at the first and
last nodes).

8
Twisted-pair Crossover Cables
When making an uplink connection between two hubs (or
between a hub and a switch, a bridge, or other Ethernet device)
using MDI-X type jacks at both ends, you must use a crossover
cable. In a crossover cable, two pairs of wires are switched at
one end. Carry out the following steps to create a crossover
twisted-pair cable:
1. Leave one end of the cable as-is, with the wiring on the
RJ-45 connector unchanged. The wiring needs to be
modified at one end only.
2. At the other end of the cable, connect wire 1 from the
unchanged connector to wire position 2, connect wire 3
to wire position 6, connect wires 3 to wire position 1
and connect wire 1 to wire position 2. Refer to the
following diagram:
If you have question regarding making the cross-over cable,
please visit our web site at
http://trendware.com/support/cable/cable.htm or contact us at
[email protected].

10
Specifications
General
Standards: IEEE 802.3 10BASE-TEthernet repeater, and
ANSI X3T9.5 twisted-pair transceiver
Topology: Star
Protocol: CSMA/CD
Network Data
Transfer Rate:
10Mbps (Ethernet)
Number of Ports: 5 xSTP / 8 x STP / 8 x STP + 1 x BNC
Network Media:Category 3 or better UTP cable, maximum
length 100 meters.
Thin coax RG-58U or RG-58 A/U cable
maximum185 meters.
Environmental and Physical
Power Adapter: Output 7.5VDC/1A
Dimensions: 176mm ?81.5mm ?31.3mm
(TE-910plus): 176mm ?91.5mm ?31.3mm
Operating Temperature: 0 to 40?C
Storage Temperature: –20 to 70?C
Humidity: 5% to 90% (non-condensing)
Emissions: FCC Class A, CE Mark Class A,
VCCI.
