TEG-S240TX is a high performance 24-port rack mountable Copper
Gigabit Switch. With auto-negotiation technology, the TEG-S240TX
automatically negotiates between 10Base-T, 100Base-TX and
1000Base-T network speeds, as well as half and full duplex modes.
The Auto-MDIX feature on each port automatically detects and
adjusts connection type with either straight-through or crossover
cable. Providing simple migration, scalability, and flexibility to
handle new applications and data types, TEG-S240TX is a highly
reliable and cost effective solution for high-speed network
applications.
TEG-S240TX(E1.0R)
24-Port 10/100/1000Mbps Copper Gigabit
Switch
TEG-S240TX
rev:02.15.2007
• 24 10/100/1000Mbps Auto-Negotiation and Auto-MDIX ports
• Full/Half Duplex Transfer Mode for Each Port (1000Base-T connections support full-duplex mode only)
• Store and Forward Switching Method
• High Performance Single-Chip Design
• Non-Blocking Wire Speed Reception and Transmission
• IEEE 802.3x Full-Duplex Flow Control
• Integrated Address Look-Up Engine, Supports 8k Absolute MAC Address
• 500KBytes RAM Data Buffering
• Extensive Front Panel Diagnostic LEDs
• Standard 19” Rack-Mount Size
• 5-year Warranty
FEATURES

LED
Transmission Method
Switch Fabric
Transfer Rates
Power
Power Consumption
Dimensions
Temperature
Emissions
Weight
Humidity
• IEEE 802.3 10Base-T, 802.3u 100Base-TX and 802.3ab 1000Base-T, IEEE 802.3x Full Duplex Flow Control
• 8K entries per device
• Ethernet: 2-pair UTP Cat. 3, 4, 5, up to 10Mbps
• Per Unit: Power • Per Port: Link/ACT, 1000M, 100M
• 100~240V AC, 50/60Hz, Internal Power Supply
• 19 watts. (max)
• Operating: 0° ~ 40° C (32° ~ 104°F)
• FCC, CE
• Fast Ethernet: 2-pair UTP Cat. 5, up to 100Mbps
• Gigabit: 4-pair UTP Cat. 5, 5E, 6, up to 1000Mbps
• Store-and-Forward
• 46Gbps Forwarding Capacity
• 440 x 210 x 44 mm (17.3 x 8.27x 1.73 inch) (W x H x D)
• Ethernet: 10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
• Fast Ethernet: 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
• Gigabit Ethernet: 2000Mbps (Full-Duplex)
• Storage: -10° ~ 70° C (14° ~ 158°F)
• 3Kg (6.6 lb)
• 10% ~ 90% (non-condensing)
• 500Kbytes
Data RAM Buffers
MAC Table
LAN Standards
Hardware
