TRENDnet TK-800R User manual

TRENDnet's TK-800R 8-Port KVM Switch allows you to
manage multiple PC's with just one keyboard, monitor, and
mouse. Switching between PC's with a simple press of a
button! Eliminate the hassle of cable swapping and save
money and space with TRENDnet's TK-800R. Designed with
ease of expansion in mind, you can daisy-chain up to 8 units
together to control maximum of 64 PC's. With its rack-mount
size and slim one unit height, it is perfect for mounting on EIA-
19" rack in the Equipment Room and Computer Lab. Rich in
features such as On Screen Display (OSD) Menu, Hot-Plug,
Auto-Scan, and Hot-Key Operation, TRENDnet's TK-800R is
the perfect choice for managing multiple PC's.
TK-800R
8-Port Rack Mount KVM Switch
Support Microsoft Intellimouse, Microsoft Intellimouse Explorer, Logitech
NetMouse or other fully compatible MS Mouse.
Support DOS, Windows 3.x/95/98/ME/NT/2000/XP, Netware, Unix,
Linux, and more
Very high video quality - up to 1920 x 1440 resolution and 200Mhz bandwidth
No software required - easy PC selection via On Screen Display (OSD) Menu,
Push Buttons, and Hot-Key Operation
Hot-Plug, add or remove PC's without powering off the KVM switch or other PC's
On Screen Display (OSD) Menu for easy management
Support eight characters password protection
Auto-Scan Mode for monitoring PCs, with configurable scan interval from 5 to 99
seconds
Keyboard status restored when switching PCs
LED Display for easy status monitoring
Beeping sound for switching port confirmation
Built-in daisy-chain port (2.5 feet (0.85 meter) daisy-chain cable included)
Auto-detect bank number (daisy-chain)
EIA-19" rack-mountable (hardware included)
1Year Warranty
BENEFITSFEATURES
Integration Friendly:
Expandable:
Cost Effective:
Performance:
Does not require driver/software for
the installation and operation.
Switching between PC's with the push
button, Hot-Key operation, and OSD
Menu.
Stackable, you can daisy-chain up to 8
TK-800R together to control maximum
of 64 PC's. Its Rack-mountable size is
also perfect for EIA-19" equipment
rack.
Manage multiple PC's with single
keyboard, monitor, and mouse. Save
on equipment cost, utility, and space.
Support very High Video Quality up to
1920 x 1440 with 200Mhz bandwidth.
Keyboard status is saved for each PC.
TK-800R (03-06-2003)
TRENDnet
TRENDware, USA
What's Next in Networking

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TK-801R: 8-Port Rack Mount KVM Switch
TK-200: 2-Port KVM Switch Kit
TK-400: 4-Port KVM Switch
TK-800R: 8-Port Rack Mount KVM Switch
TK-C06: 6 feet KVM Cable
TK-C10: 10 feet KVM Cable
NETWORKING SOLUTIONS
SPECIFICATIONS
Computer Port:
8 ports.
Keyboard and Mouse: PS/2 type mini
Din 6-pin,
VGA: HDDB 15-pin
•
•
•
Daisy-Chain Port:
• 1 port.
• Keyboard and Mouse: PS/2 type mini
Din 6-pin
• VGA HDDB 15-pin
Console Port:
• 1 port.
• Keyboard and Mouse: PS/2 type mini
Din 6-pin,
• VGA: HDDB 15-pin
KVM Cable:
• 1 x 2.5 feet (0.85 m) high-grade KVM
cable (UL2919 for VGA monitor).
PC Selection:
• On Screen Display Menu, Hot-Keys,
and push button
LED Segment:
• One Bank LED, Two PC Port LEDs
Auto-Scan Intervals:
• 5 ~ 99 seconds
Keyboard State:
• Saved and restored
Video Bandwidth:
• 200MHz
Power Adapter:
• External AC Power adapter, 12VDC,
1A (or 9VDC, 1A)
Dimensions:
• 410 x 165 x 47 mm
(16.1 x 6.5 x 1.85 inches)
Weight:
• Appro. 2.2 Kg. (4.85 lbs)
Temperature:
• Operating: 0° ~ 40° C (32° ~104° F)
• Storage: -20° ~ 60° C (-4 ~ 140° F)
Humidity:
• 0 ~ 80%, Non-Condensing
Certifications:
• FCC, CE
TK-800R
8-Port Rack Mount KVM Switch
TK-800R
8-Port Rack Mount KVM Switch
