TRENDnet TEG-S2500i User manual

The TEG-S2500i 24 Port 10/100 Stackable SNMP Switch
provides small and medium businesses with the foundation
for a highly scalable and easily managed network. The
Web/SNMP Managed Switch allows network administrators
to remotely monitor and manage network performance and
security. Network administrators can stack up to 8 Switches
and manage them with only one IP address using a standard
web browser. Server bottlenecks are a thing of the past with
the Gigabit module slot that supports a series of optional
Gigabit Copper, Gigabit Fiber and GBIC modules. Security
and performance are optimized with advanced Port/Tag-
based VLAN, QoS, Trunking and monitoring features.
TEG-S2500i
24-Port 10/100Mbps Stackable SNMP Switch with Gigabit Slot
BENEFITSFEATURES
Performance:
Expandability:
Flexibility:
Security:
Cost-Effectiveness:
Gigabit bandwidth between Stacking
Switches and backbone
Expand the network by connecting
multiple Stacks of Switches together
via Gigabit backbone
Stack Switches in the same room or in
different rooms. Single IP
Management allows Administrator to
manage/monitor all the Switches
locally or remotely (requires public IP)
using one IP address
Administrator can setup 802.1Q or
Port-based VLAN to further
segmenting the network.
Provides SNMP management and
Gigabit Performance at an affordable
price.
Stackable up to 8 Switches* (requires Gigabit Module); provides up to 192
10/100Mbpbs connections (* You can stack 16 Switches together. But, for better
network performance, we suggest stacking no more than 8 Switches.)
Manage all uplinked or Stacked Switches with one IP address from local LAN or
Internet (requires valid public IP. If the Switch is behind a Firewall/Router, please
open Port 80 and the Agent Control Port 28019 for the Switch’s IP)
24 10/100Mbps Auto-Negotiation and Auto-MDIX Fast Ethernet Ports
1 Gigabit Module Slot for optional module with Copper and/or Fiber Gigabit
connections
Full/Half-duplex transfer mode for each 10/100Mbps port (1000Mbps port supports
only full-duplex mode)
Store-and-forward switching architecture with non-blocking wire-speed performance
IEEE 802.3x flow control for full-duplex and collision-based back pressure function
for half-duplex operation
Broadcast Storm Filtering and Head-of-Line blocking Prevention
Port-Based VLAN (256 Groups), IEEE 802.1q Tag-Based VLAN (PVID 1~255) and
IEEE 802.1D Spanning Tree (STP)
IEEE 802.1v protocol-based VLAN classifications and IEEE 802.1x Authentication
and Authorization
Port-Trunking with flexible load distribution control and fail-over functions (7 trunk
groups, max 4 ports per group)
IP Multicast, IGMP Snooping, and RMON Group 1,2,3,9
2-level priority queuing, Ingress port security mode and by-port Egress/Ingress rate
control
Configuration via Console Port (serial cable included), SNMP (v1.0, MIB II), TELNET,
and Web Browser
Upgradeable firmware via TFTP and Ping function from the Switch for network
diagnostic
8.8Gbps switching fabric
Supports QoS and 802.1p Priority
Standard 19” Rack-Mount Size (rack-mount kit included)
5-Year Warranty
TEG-S41SX (10-28-2004)
TRENDnet
TRENDware, USA
What's Next in Networking

RELATED PRODUCT
To Order Please Call:
1-888-326-6061
TEG-S2500i: 24-Port 10/100Mbps Stackable SNMP Switch with
Gigabit Slot
Option Gigabit Modules for TEG-S2500i:
TEG-S24M2C: 2-Port 10/100/1000 Copper Gigabit Module
TEG-S24M1F: 1-Port Multimode SC-type Fiber Gigabit Module
TEG-S24M2F: 2-Port Multimode SC-type Fiber Gigabit Module
TEG-S24M100F: 1-Port Multimode SC-type 100Base-FX
Module
TEG-S24M200F: 2-Port Multimode SC-type 100Base-FX
Module
TEG-S24M11GF: 1-Port 10/100/1000Mbps Copper Gigabit + 1-
Port 1000Base-SX/LX GBIC Multimode SC type Module
NETWORKING SOLUTIONS
SPECIFICATIONS
TEG-S2500i
24-Port 10/100Mbps Stackable SNMP Switch with Gigabit Slot
TEG-S2500i
24-Port 10/100Mbps Stackable SNMP Switch with Gigabit Slot
Standards:
• IEEE 802.3 10Base-T Ethernet
• IEEE 802.3u 100Base-TX Fast Ethernet
• IEEE 802.3z 1000Base-SX/LX Gigabit Ethernet
• IEEE 802.3x Flow Control
• IEEE 802.1D Spanning Tree
• IEEE 802.1q Tag-based VLAN, Priority Control
• IEEE 802.1v Protocol-Based VLAN
• IEEE 802.1x RADIU Authentication
and Authorization
Interfaces:
• 24 x 100Base-TX RJ-45 STP Ethernet Ports
• 2 x 1000Base-TX RJ-45 Connector Ports or
optional 1000Base-SX and/or
• 1 x RS-232 Serial Port
Console Port:
• RS-232, female 9-Pin Serial Port
(serial cable included)
Buffer Memory:
• 1MB for Control, 3MB for Packet Filter
Filtering Address Table:
• 6K MAC (255 entry of Static MAC), 4K
VLAN and 2K Multicast Entries
Packet Forwarding and Filtering Rate:
• 1000M Ethernet: 1,488,100 packets per
second per port
• 100M Ethernet: 148,810 packets per second
per port
• 10M Ethernet: 14,880 packets per second
per port
Cabling:
• Fast Ethernet
- UTP/STP Cat. 5, EIA/TIA-568 100-ohm,
100 meters max.
- 62.5/125um Multimode Fiber with SC-type
connector, 2Km max.
• Gigabit Ethernet
- UTP/STP Cat. 5, EIA/TIA-568 100-ohm,
100 meters max.
- 62.5/125µm Multimode Fiber with SC-type
connector, 220 meters max.
- 50/125µm Multimode Fiber with SC-type
connector, 550 meters max.
Protocol/Topology:
• (CSMA/CD) / Star
LED Display:
• Per Device: Power, Diagnostic, FAN1, FAN2.
• Per Port: Link, Activity,
Power Consumption:
• 30 Watts max. (Input: 100~240VAC,
50/60Hz Internal Power Supply)
Dimensions:
• 440 x 184 x 44mm (17.3 x 7.3 x 1.8 inch)
(W x H x D)
Weight:
• 2.3 Kg. (5.1 lb.)
Temperature:
• Operating: 5° ~ 45° C (41° ~ 113° F).
• Storage: -20° ~ 70° C (-4° ~ 158° F)
Humidity:
• 10% ~ 90% (no-condensing)
Certifications:
• FCC, CE/ CB, UL
TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
TRENDnet
TRENDware, USA
R
Workstations with
Fast Ethernet Card
(TEG-PCIWN)
Workstations with
Fast Ethernet Card
(TEG-PCIWN)
1000Mbps
100Mbps
24-Port 10/100Mbps
Stackable SNMP Switch
(TEG-S2500i)
Server with
Copper Gigabit PCI Adapter
(TEG-PCITXR)
Server with
Copper Gigabit PCI Adapter
(TEG-PCITXR)
U
L
R
