TRENDnet’s TEG-S80TXE Copper Gigabit Ethernet Switch
with External Power Supply consist of eight
10/100/1000Mbps Copper Gigabit Ethernet ports with Auto-
negotiation and Auto-MDIX features. The Switch offers a
reliable and affordable LAN solution to meet immediate
bandwidth demand. Users can connect Server(s) to the
Gigabit port(s) to increase network performance or cascade
Copper Gigabit Switches together to create high-bandwidth
Gigabit backbones. TRENDnet’s TEG-S80TXE provides
simple migration, scalability and flexibility to handle new
applications and data types, making it a highly reliable and
cost effective solution for high-speed network connectivity.
TEG-S80TXE
8-Port 10/100/1000Mbps Copper Gigabit Switch
8 x 10/100/1000Mbps Auto-Negotiation, Auto-MDIX
Gigabit Ethernet Ports
Full/Half-duplex transfer mode for 10/100Mbps, Full-
Duplex mode for 1000Mbps
Store-and-Forward switching method
Wire-speed reception and transmission
IEEE 802.3x flow control for full-duplex mode
Back pressure flow control for half-duplex mode
Integrated address Look-Up engine, supports 4K MAC
addresses
Built-in 128KB RAM Buffer
Extensive front-panel diagnostic LEDs
External Power Supply
Sturdy metal housing
5-Year warranty
BENEFITSFEATURES
Performance:
Flexibility:
Expandability:
Effectiveness:
Each port provides 1000Mbps Gigabit
connection to Power Server or
another Gigabit Switch.
All ports automatically negotiate
10/100/1000Mbps network speed. All
ports support Auto-MDIX media type
detection (connect with either straight
through or a crossover cable).
Uplink to other Gigabit Switches to
create Gigabit backbones.
Provides Gigabit Performance at an
affordable price.
TRENDnet
TRENDware, USA
R
TEG-S80TXE (07-29-2003)

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TEG-S18TXE: 9-port 10/100/1000Mbps Copper Gigabit
Switch with External Power Supply
TEG-PCITX: 32-Bit PCI 10/100/1000Mbps Copper Gigabit
Ethernet Adapter
TEG-PCITX2: 64/32-Bit PCI 10/100/1000Mbps Copper
Gigabit Ethernet Adapter
TEG-S40TXE: 4-port 10/100/1000Mbps Copper Gigabit
Switch with External Power Supply
TEG-S50TXE: 4-port 10/100/1000Mbps Copper Gigabit
Switch with External Power Supply
TEG-S80TXE: 8-port 10/100/1000Mbps Copper Gigabit
Switch with External Power Supply
NETWORKING SOLUTIONS
ORDERING INFORMATION
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendware.com
TRENDnet
TRENDware, USA
R
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.trendware.com.
©
Copyright TRENDware International, Inc. 2002. All Rights Reserved.
SPECIFICATIONS
TEG-S80TXE
8-Port 10/100/1000Mbps Copper Gigabit Switch
TEG-S80TXE
8-Port 10/100/1000Mbps Copper Gigabit Switch
Standards:
IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX
Fast Ethernet, IEEE 802.3ab 1000Base-T Copper Gigabit
Ethernet, IEEE 802.3x Flow Control
Data Transfer Rate:
Ethernet: 10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
Fast Ethernet: 100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
Gigabit Ethernet: 2000Mbps (Full-Duplex)
Cabling:
Ethernet: 2-pair UTP/STP Cat. 3,4,5, 100 meters max.
Fast Ethernet: 2-pair UTP/STP Cat. 5, 100 meters max.
Gigabit Ethernet: 4-pair UTP/STP Cat. 5, 100 meters max.
Protocol:
CSMA/CD
Topology:
Star
Data RAM Buffers:
128KB per Device
Filtering Address Table:
4K entries per device
•
•
•
•
•
•
•
•
•
•
•
Diagnostic LEDs:
Power, Link/ACT, 100Mbps, 1000Mbps
Power Consumption:
10.5 Watts; 5V DC, 2.4A External Power Adapter
Dimensions (WxDxH):
190 x 120 x 38mm (7.5 x 4.7 x 1.5 inch)
Weight:
0.77kg (1.7lb)
Temperature:
Operating: 0° ~ 40° C (32° ~ 104° F)
Storage: -10° ~ 55° C (14° ~ 131° F)
Humidity:
5% to 95% non-condensing
Certifications:
FCC Class A, CE mark Class A, VCCI-A
•
•
•
•
•
•
•
•
