TRENDnet TK-802R User manual

kvm
TK-802R 8-port Stackable KVM Switch allows you to manage
multiple PCs with just one keyboard, monitor and mouse. Switching
between PCs with a simple press of a button! Eliminate the hassle of
cable swapping and save money and space with TRENDnet’s TK-
802R. Designed with ease of expansion in mind, you can stack up to
8 units together to control maximum of 128 PCs. With it’s rack-mount
size and slim one unit height, it is perfect for mounting on EIA-19”
rack in the Server Room and computer lab. Rich in features such as
On Screen Display (OSD) Menu, Hot-Plug, Auto-Scan, and Hot-Key
operation, TK-802R is the perfect choice for managing multiple Pcs.
TK-802R(V1.1R)
8-Port Stackable Rack Mount KVM Switch with OSD
TK-802R
rev:09.09.2009
• 8-Port stackable KVM Switch
• Support Microsoft Intellimouse, Microsoft Intellimouse Explorer, Logitech NetMouse, Optical Mouse and more.
• Compliant with DOS, Windows 3.x/95/98/ME/2000/XP/2003 Server/Vista, Netware, Unix, Linux, and more
• High video quality – up to 1920 x 1440 resolution
• Support password protection
• Stackable up to 16 KVM switches (128 PCs)
• Auto-Scan Mode for monitoring PCs, with adjustable scan interval from 5~99 seconds
• Keyboard status restored when switching from PCs
• LED Display for easy status monitoring
• On Screen Display (OSD) control for easy management
• Beeping sound for port switching confirmation (enabled/disabled)
• Auto-detect bank number (when daisy-chaining)
• Built-in daisy-chain port？
• Hot-key or push button switching
• Plug & Play and Hot-Pluggable
• Standard 19” (1U) rack mount design
• 2-Year Limited Warranty
FEATURES

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
8-Port Stackable Rack Mount KVM Switch with OSD
TK-802R
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
RELATED PRODUCTS
TK-801R
NETWORKING SOLUTIONS
8-Port PC/2 Rack Mount KVM Switch
TK-803R
TK-1602R
8-Port USB/PC/2 Rack Mount KVM Switch
16-Port Stackable Rack Mount KVM Switch with OSD
Cable
Management
PC Port (all female)
Supported OS
PC Selection
Daisy Chain Level
LED
• 1 x PS/2 Mouse 6-pin Mini Din
• 1 x Daisy-Chain Cable (male to male)
• Up to 16 KVM Switches (128 PCs)
• Unit: Bank (Red) Port: Link (Red) and Select (Green)
• DOS, Windows 3.x/95/98/ME/2000/XP/2003 Server/Vista, Linux, Unix and more
• 8 computers
• 8 x PS/2 Mouse 6-pin Mini Din
• 1 x PS/2 Mouse 6-pin Mini Din
• 5-100 seconds (Programmable through Hot-Key)
• On Screen Display (OSD) Control, Hot-Key or Push Button
Console Port (all female)
Daisy Chain Port (all female)
Hardware
SPECIFICATIONS
Keyboard Status
Power Adapter
Dimensions
Temperature
Operating Humidity
Certifications
• Saved & Restored
• 9V DC 1A External Power Adapter
• 407 x 165 x 45mm (16 x 6.5 x 1.8in.)
• 1.97kg (4.33lb)
• Operating: 0°C~40°C (32°F~104°F) Storage: -20°C~60°C (-4°F~140°F)
• 0 ~ 80%RH (non-Condensing)
• CE, FCC
Auto-Scan Interval
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
• 8 x PS/2 Keyboard 6-pin Mini Din • 8 x VGA HDB 15-pin
• 1 x PS/2 Keyboard 6-pin Mini Din • 1 x VGA HDB 15-pin
• 1 x PS/2 Keyboard 6-pin Mini Din • 1 x VGA HDB 15-pin
Weight
RELATED PRODUCTS
• TK-802R
• Multi-Language Quick Installation Guide
• Daisy Chain Cable
• Power Adapter (9V DC, 1A)
• Rack Mount Kit
Monitor
8-Port PS/2 Rack Mount
KVM Switch with OSD
(TK-802R)
Mouse
Keyboard
PC 2
PC 1
PC 3
PC 5PC 7
PC 4PC 6PC 8
Stand Alone
Monitor
PC 2PC 4PC 6PC 8
MouseKeyboard PC 1PC 3PC 5PC 7
Daisy-Chain
Daisy-Chain
8-Port PS/2 Rack Mount
KVM Switch with OSD
(TK-802R)
