TREX COMP-NOVA User manual

COMP-NOVA
USER MANUAL

COMPRESSOR PEDAL
Congratulations on your purchase of T-REX COMP-NOVA
Comp-Nova is a compressor pedal with a perfectly simple set of controls
and pure, naturally compressed sound.
It “evens out” the irregularities in your signal by lowering high-input
signals while boosting low-input signals, giving you smooth sustain
without degrading the clarity and dynamics of the original sound.

COMPRESSION DONE RIGHT
If you’ve never used a compressor before, the effect can seem compli-
cated at first. But it only takes an hour or so of experimenting and you’ll
discover a world of settings that add the subtle enhancement only a
compressor can provide.
Place your Comp-Nova in the beginning or in the end of the pedal chain
- it’s all a matter of taste. For long sustain, the compressor should be
placed after the distrortion pedals.
CONTROLS
The COMP knob determines the compression amount. The more you
turn it up, the more you compress your sound.
The ATTACK knob controls the sensitivity - how much of the signal will
be compressed. Longer Attack times mean more natural signal before
the compressor starts to work.
The LEVEL knob sets the overall volume. At max. level the signal is
boosted approximately 3dB.
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz Higher than 1M Ohm
Output Impedance@1KHZ Lower than 1K Ohm
Power supply 9V DC (T-Rex FuelTank)
Minimum Power supply Voltage 8V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 11 mA
Maximum Input signal Vp/p 1,5Vp/p
Battery Type 9 V battery 6F22
Battery Life 8 to 11 Hours
External connectors Input Jack, Output Jack, 9V DC jack
Controls On/Off, Level, Comp, Attack
Pedal size incl. knobs (W x H x D) 100 x 55 x 120 mm
3,9 x 2,2 x 4,7 inch
Weight excl. battery and packaging 0,310 kg / 10,9 oz

RoHS
REACh
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a
malfunction, please contact our technical support at service@t-rex-eects.
com before sending us the product for repair. When the product has been
sent to us at sender’s cost, we will repair or replace your product and send
it back to you - free of charge and usually within 4 weeks (shipping not
included). The product needs to be accompanied by a copy of your receipt,
serial number, return address, phone number, e-mail address and a brief
explanation of the problem. Please note that we cannot replace a product
until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse,
accident, or neglect; or if the product has been repaired or serviced by
persons not authorized by T-Rex. Read more about warranty conditions at
www.t-rex-eects.com/service
ABOUT T-REX
Based in Vejle, Denmark, T-Rex Engineering makes classic and sig-
nature eects pedals for the world’s best musicians. Our approach
blends hi-tech innovation with old-world craftsmanship – always
in the service of killer tone.
EU REGULATIONS • ENVIRONMENT PROTECTION
T-Rex accepts and follows the regulations and directives issued
by the EU. We nd these environment protecting regulations very
good, and we are happy to follow them.
