Triad InWall Bronze/4 PowerSub User manual

Triad Bronze Slimsub - Quick Start Guide 2014.5.19
InRoom Bronze SlimSub
TriadSpeakers.com • Sales: 1800-666-6316
Bronze SlimSub - Product Info & Warranty - Page 1
Bronze SlimSub Family
Triad offers 3 versions of our critically acclaimed high-performance Slim Sub subwoofer to fit virtually any application, room & location. Driven by the RackAmp 350 DSP, each version
delivers the same exceptional power and deep bass from its remarkably compact enclosure. You can match any decor with our Custom Color option or hide the sub from view completely.
Taking up little to no floor space, it is easy to find space for the 4 corner-subwoofer configuration recommended by industry experts* as the easiest and best way to get deep, powerful, and
accurate bass over the largest listening area. With this setup SlimSubs can fill large rooms better than a single bigger subwoofer. To make multi-subs easier, SlimSubs can be ordered with
two 8 ohm enclosures driven in parallel by a single amp, giving performance halfway between 1 sub/ 1 amp and 2 subs/ 2 amps.
*CEA/CEDIA Bulletin CEB22: Home Theater Recommended Practice: Audio Design.
Specifications
Applicable Models Dimensions Woofer Size/Material F3 (-3dB) Max Output Impedance Weight Amplifier
Inches / cm Midwall Nominal lbs/kg
InRoom Bronze SlimSub Encl 14.0x19.5x4.3**/ 35.6x49.5x10.9 10"/26cm aluminum 28 Hz 108dB 4 ohms 19.0/8.6 RackAmp 350 DSP
OnWall Bronze SlimSub Encl 14.0x19.5x4.3 / 35.6x49.5x10.9 10"/26cm aluminum 28 Hz 108dB 4 ohms 19.0/8.6 RackAmp 350 DSP
InWall Bronze/4 SlimSub Encl 13.5x19.0x3.9 / 34.3x48.3x9.9 10"/26cm aluminum 28 Hz 108dB 4 ohms 24.5/11.1 RackAmp 350 DSP
**InRoom Bronze SlimSub is 15.0 inches (38.1cm) tall when upright on feet and requires 5.9 inches (15.0cm) depth for the standing feet. Enclosure is 4.0 inches (10.2cm) deep without grill.
North American Limited Warranty
Triad speakers are warranted to be free from defects in manufacturing and workmanship
(10) years when operated under normal conditions. Should any such defects occur within the warranty period call Triad Service at 1-503-256-2600 for an RA (Return Authorization) number.
Return the product in intact factory packaging with RA number clearly visible on outside of box and proof & date of purchase inside to:
Triad Speakers Inc., 15835 NE Cameron Blvd.,
Portland, Oregon 97230 USA
Triad is not responsible for any shipping damage coming in to Triad. If you do not have intact factory packaging, contact your dealer or Triad Service for purchase. At our discretion we will
repair or replace the product and return it free of charge. International customers should contact their dealer for service. This limited warranty is extended only to Triad products and
is expressly in lieu of all other warranties expressed or implied.
RackAmp Connections & Set Up InRoom Bronze SlimSub - Face Down (Flat) Installation
Note:
Placing InRoom
Bronze SlimSub face
down under furniture
(bed, couch, cabinet,
etc.) requires a
minimum height
clearance of 5-1/8
inches plus 14-1/8 x
19-5/8 inches of clear
space.
Enclosure GrillUpright
Parts
Face Down
Parts
Unpacking / Contents - 3 models
(4) 25 - 20 x .625 button screws
(2) Acorn nuts
(2) .265 x .562 x .048 washers
(2) Rubber cone/standing feet
(1) 5/32” Allen key
OnWall Bronze SlimSub
Template
Enclosure Grill
(2 ea) 3 in EZ Brackets,
knobs, & washers.
(8) #10 x 1.25" oval
screws & anchors.
4 Bumpers
Parts
InWall Bronze/4 SlimSub
Grill Frame
Enclosure GrillTemplate
(1) 4 ohm sub (2) 8 ohm subs
wired in parallel
RackAmp Settings:
Pick Sub: IW Bronze DSP
Boundary: Midwall within 2 feet of single boundary
InRoom farther than 2 feet from boundary
Corner within 2 feet of corner.
AB
With grill off, remove all 4 button screws from
enclosure face with Allen key; replace with included
spikes or cone feet. Adjust so that all 4 feet make
solid contact with floor or carpet without rocking or
tipping. With spikes, remember to tighten the lock nuts.
Securely connect speaker wires (min 14
gauge AWG) through push-in binding posts.
Be sure to preserve correct polarity with amp
(red to red); Place sub in position face down,
connect RackAmp and set up as shown.
+ 2
Spike or Cone
5.1 inch
12.9 cm
4.8 inch
12.2 cm

Triad Bronze Slimsub - Quick Start Guide 2014.5.19
1: Attach cone feet to the standing feet with acorn nuts &
washers (see insert). 2: With cone feet to the back of the enclosure,
securely screw the 2 standing feet into the 4 inserts in the bottom of
the enclosure with 4 button screws and 5/32" Allen key.
Attach grill at one end; snap grill into place
making sure that all 4 magnets are secure and
that grill is snug all around.
ASecurely connect speaker wires (min
14 gauge AWG) through push-in binding
posts. Be sure to preserve correct polarity
with amp (red to red).
Set subwoofer in place. Connect speaker
wires to RackAmp and set up RackAmp with
instructions on Page 1.
C
BD
InRoom Bronze SlimSub - Upright Installation
OnWall Bronze SlimSub - Installation
Bronze SlimSub - Installation Instructions - Page 2
Level & pin template to wall. Sub can be
positioned horizontally (landscape) or vertically
(portrait) with binding posts at either end. Outline
wire hole and all 8 screw holes for 2 mounting
posts. Screw post(s) into a stud if possible.
Cut wire hole; install anchors if there are
no studs. Always screw both mounting posts to
wall with 4 screws per post. Test both posts
for shear strength.
APull speaker wire through wire hole.
Securely connect speaker wires (min 14
gauge AWG) through push-in binding
posts. Be sure to preserve correct polarity
with amp (red to red).
Attach adhesive backed bumper to
each of the 4 back corners. Mount speaker
on posts; loosely tighten knobs through
washers into posts. Level or align +/- 1/4”
(6.35mm), then tighten both knobs.
C
BD
Assemble
cone feet
1
Attach grill at one end; snap grill
into place making sure that all 4 magnets
are secure. Snug all around. Connect
speaker wires to RackAmp and set up
RackAmp with instructions on Page 1.
E
2
x2
