Triad Outdoor OD25 & OD26 - Quick Start Guide ver 2016.6.21
TriadSpeakers.com • Sales: 1800-666-6316
OVERVIEW
Triad outdoor speakers are attractive, weather-resistant speakers
engineered in the U.S. to have a rich and full sound. To help them better
integrate into their surroundings, Triad Outdoor Speakers are available in
custom colors directly from Triad. Thank you for purchasing this product!
IN THE BOX
Two (2) Speaker Assemblies
including:
A - Enclosure
B - Bracket
C - Assembly knobs
Enclosure size (H x W x D) in.
Enclosure WITH bracket
(H x W x D) in.
Enclosure size (H x W x D) mm
Enclosure WITH bracket
(H x W x D) mm
Product weight /each
Shipping weight / pair
Shipping weight
Master pack (4 ea.)
Tweeter - size (in./mm)
Tweeter material
Woofer - number & size (in./cm)
Woofer material
Recommended
amplifier power (W)
Nominal Impedance (ohms)
Minimum Impedance (ohms)
Sensitivity (dB @ 2.83v, 1 m)
Frequency Response
2 π +/- 3dB (Hz)
10 9/16 x 7 1/2 x 7 1/2
10 9/16 x 7 1/2 x 8 1/2
270 x 190 x 190
270 x 190 x 216
7.5lb / 3.4kg
17lb / 7.7kg
37lb / 16.8kg
1" / 25mm
Titanium
(1) 5.25" / 14cm
Carbon fiber
25-150
6
4.8
84
75 - 20k
OD26
12 7/16 x 8 7/8x 8 1/4
12 7/16 x 8 7/8x 9 3/8
319 x 224 x 210
319 x 224 x 238
9lb / 4.1kg
21.5lb / 9.8kg
47lb / 21.4kg
1" / 25mm
Titanium
(1) 6.5" / 17cm
Carbon fiber
25-150
6
4.8
86
65 - 20k
OD25
A
B
C
C
SPECIFICATIONS
DIMENSIONS - OD26
PAINTING AT THE FACTORY
OD25 & OD26 outdoor speakers have already undergone an extensive
multi-step prep and painting process at the factory. Out of the box they are
painted either black or white. As an option, Triad can also paint OD25 &
OD26 speakers custom colorsto match any environment. This paint is
applied at the Triad factory for a nominal charge. Custom colored products
are not returnable. Contact Triad Sales for custom painting details.
PAINTING IN THE FIELD
If the Triad OD25 & OD26 speakers must be painted in the field, special
procedures MUST be followed. Do not attempt field painting without calling
Triad Sales Department for details at 1-800-666-6316. Field painting voids
warranty.
WARRANTY
North American Limited Warranty
Triad speakers are warranted to be free from defects in manufacturing
and workmanship for (5) years when operated under normal conditions.
Finishes are excluded from this warranty. Should any such defects
occur within the warranty period, call Triad Service at 1-503-256-2600 for
an RA (Return Authorization) number. Note that we cannot accept
products for warranty consideration without RA numbers.
Return the product in intact factory packaging with RA number clearly
visible on outside of box and proof & date of purchase inside to:
Triad Speakers Inc.,
15835 NE Cameron Blvd.,
Portland, Oregon 97230 USA
The product should be returned in its original packaging together with
proof and date of purchase. At our discretion, we will repair or replace
the product and return it, free from charge. If you do not have the
original packaging for the product, you can purchase it from Triad.
Contact your dealer or Triad Service for details.
DIMENSIONS - OD25
x 2
190
7.5
268
10.5
270.4
10.7
190.2
7.5
2.4
0.1
268
10.5
270.4
10.7
216.2
8.5
94.8
3.7
224
8.8
317
12.5
319.5
12.6
2.5
0.10
238.2
9.4
107.2
4.2
210
8.3
317
12.5
2.5
0.1
319.5
12.6
Outdoor Speakers - Product Info & Warranty - Page 1

Triad Outdoor OD25 & OD26 - Quick Start Guide ver 2016.6.21
TriadSpeakers.com • Sales: 1800-666-6316
On a wall, vertically On a wall, horizontally Under an eave
SPEAKER PLACEMENT
Traid Outdoor OD25 & OD26 speakers can be installed in numerous
locations. The bracket can be affixed vertically or horizontally.
INSTALLATION
To install the speakers, first install the bracket to desired location.
INSTALLATION, cont.
1Pass wire through
hole in bracket.
MAKE SURE
CUTOUTS IN
BRACKET ARE
ORIENTED
CORRECTLY
2Screw bracket to wall, keeping
screws (not included) LOOSE.
3Slide bracket so screw
heads are securely in a slot.
Tighten screws.
GRILL REMOVAL & REPLACEMENT
6Aim speakers to optimal position,
then tighten both knobs.
4
A
B
B
A
B
Assemble speaker into bracket.
Screw knobs LOOSELY through
bracket into enclosure.
5Attach wires to binding posts in back of
speaker. Be sure to keep proper polarity
from the amplifier to the speakers.
Push binding posts
down to align wire
holes & insert wire.
Release binding
post top when wire
has been inserted.
If grill removal is necessary for any reason, see instructions below:
red
positive
post
polarity indicators
black
negative
post
REMOVE: Use a Triad Grill
Pick or other suitable tool to
grab grill & pull outward.
REPLACE: First slip bottom end into
enclosure, then slide downward
and push top into place.
Outdoor Speakers - Product Info & Warranty - Page 2
