Tribest slowstar SW-2020 User manual

Vertical Slow Juicer and Mincer
Read Instructions Before Using / Lisez les instructions avant l’utilisation / Bitte lesen
Sie vor der Verwendung die Anleitung / Antes de usar el producto, lea las instrucciones
OPERATION MANUAL
MODE D’EMPLOI
BEDIENUNGSANLEITUNG
MANUAL DE USO
Model / Modèles / Modell / Modelo:
SW-2020 / SW-2000

LANGUAGES
• English…………….……….……….……….……….……….……….……….…......5
• Français………………….……….……….……….……….……….…………...21
• Deutsch………………….……….……….……….……….……….…………....37
•Español………………….……….……….……….……….……….…………….53

5
EN
TABLE OF CONTENTS
• Important Safeguards………….……….……….……….……….……….………...…….6
• Warnings……………………….……….……….……….……….……….……...………7
•Precautions……………….……….……….……….……….……….………..…………..8
•Features…………….……….……….……….……….……….………...………………..9
• Parts…………….……….……….……….……….……….……….…………………...10
• How toAssemble………………….……….……….……….……….………....………...11
• How to Use………….……….……….……….……….……….…......…………………12
• How to Disassemble……………….……….……….……….……….……..……………14
• How to Clean and Store………….……….……….……….………............……………..15
• Tips for Silicone Parts…………….……….……….……….……….……………………16
• Troubleshooting……………….……….……….……….……….……….…..………….17
• Specications…………….……….……….……….……….……….…….……………..19

6
IMPORTANT SAFEGUARDS
Warnings & Cautions
When using electrical appliances, basic safety precautions should always be employed, including the
following:
1. Read all instructions.
2. To protect against the risk of electrical shock do not immerse the Main Body of the Slowstar in
water or other liquid.
3. Close supervision is necessary when any appliance is used by or near children.
4. Unplug the Slowstar from the electrical outlet when not in use, before assembly or disassembly of
parts, and before cleaning.
5. Avoid contact with moving parts.
6. Do not operate any appliance with a damaged power cord or plug. Do not operate if the Slowstar
malfunctions or if the Slowstar is dropped or damaged in any manner. Contact the nearest autho-
rized service facility for examination, repair, and/or electrical/ mechanical adjustments.
7. Do not use parts that are not recommended or sold by the manufacturer of the Slowstar, as it may
cause re, electric shock, or injury.
8. Do not use outdoors.
9. Do not let the power cord hang over the edge of a table or counter.
10. Do not let the cord come in contact with hot surfaces, including the stove.
11. Always make sure that the Feeding Chute Assembly is locked securely in place before turning on
the Slowstar. Do not unfasten the Feeding Chute Assembly while the Slowstar is in operation.
12. Be sure to turn the switch to the ‘OFF’ position after each use. Make sure the motor stops
completely before disassembling.
13. Do not put your ngers or other objects into the Slowstar openings while it is in operation. If
food is lodged in the Feeding Chute, use the Plunger or another piece of fruit or vegetable to push
the lodged food down. If the food is still lodged, turn the Slowstar off, unplug it, and disassemble
the Slowstar to remove the remaining food.
14. Do not use the Slowstar if the Pulp Wiping Assembly is damaged.
SAVE THESE INSTRUCTIONS
Physical injury or property
damage may occur if the
instructions are not followed.
Death or serious injury may
occur if the instructions
are not followed.

7
EN
WARNINGS
• Do not disassemble, x, or alter the Slowstar; otherwise re, electric
shock, or injury may occur; contact the manufacturer for repair.
• When the cord or the plug is destroyed or damaged, do not plug it
into an electrical socket. Contact a licensed electrician for repair;
otherwise electric shock, short circuit, or re may occur.
• Do not put a foreign object into any opening or hole in the Slowstar;
otherwise re, electric shock, or injury may occur.
• Do not place the Slowstar near a hot surface or pour water into the
Main Body; otherwise electric shock or injury may occur.
• Close supervision is absolutely necessary when any appliance is
used near children; improper handling or dropping of the Slowstar
may resultin injury or failure of the product.
• While the Slowstar is in use, do not disassemble or insert ngers/
foreign objects into the Feeding Chute or Juice Outlet; otherwise
injury or accident may occur.
• Do not plug/unplug the machine while your hands are wet; otherwise
electric shock or injury may occur.
• Plug in the cord correctly; otherwise electric shock or re may occur.
• Use only proper voltage electricity; otherwise, electric shock or re
may occur. Use a transformer when using a different voltage electricity.
• Do not bend or tie the cord by force. Do not jerk or place the cord near
high temperatures. Do not place the cord under a heavy object or plug
into a narrow place. Damage to the cord may cause electric shock or re.

8
PRECAUTIONS
• The Slowstar must be operated on an even surface; otherwise injury or accident may occur.
• Do not place any foreign objects, such as forks, knifes, or spoons, into the juice outlet under any
circumstances; otherwise injury or accident may occur.
• Do not move the Slowstar during operation; otherwise re, electric shock, or injury may occur.
• If the Duoblade Auger stops while the Slowstar is in use, turn the switch to the ‘REVERSE’ position
for 2~3 seconds; then push the ‘ON’ button. If the Slowstar is kept running when there is an over-
load, the motor may overheat and this may result in a malfunction.
• Do not assemble or disassemble the parts while in operation; otherwise a malfunction or injury may
occur. Please assemble or disassemble the parts after stopping the Slowstar, and unplug the cord
from the outlet.
• Do not use any utensil other than Plunger while inserting ingredients into the Feeding Chute;
otherwise injury or accident may occur.
• Do not operate the Slowstar for more than 30 minutes at a time; otherwise the motor may overheat
and a malfunction may occur. Please wait 5 minutes before operating the Slowstar again.
• Do not apply excessive impact on the Slowstar or drop it; otherwise electric shock, impairment, or
re may occur.
• Please unplug the Slowstar when not in use, and do not unplug it by pulling the cord, otherwise,
injury, accident, or malfunctioning may occur.
• Stop operating the Slowstar if strange noises, excessive heat, or smoke is noticed. Contact the
distributor or warranty service center.
• The Slowstar weighs approximately 20 lbs/9 kg, and must be moved using both hands. You may
drop the Slowstar by moving it with one hand, and injury or malfunction may occur.
• Do not wash the Slowstar with water higher than 80°F because it may cause the machine to malfunction.

9
EN
FEATURES
• Slow juicing at approximately 47 RPM
The Slowstar extracts juice using a slow juicing mechanism to retain the maximum amount of
nutrients and enzymes for a naturally healthier juice.
• Mincing and Homogenizing with the Mincer Attachment (SW-2000 only)
With the Mincer Attachment, included with the SW-2000 (not included in SW-1000), mincing foods
is easy and simple. Easily mince foods, from fruits and vegetables to meats and sh, to make sauces
and meat balls.
• Duoblade Double-Edged Auger
Unlike ordinary vertical slow juicers, which have a single-bladed auger, the Slowstar is equipped
with a unique Duoblade Auger, which has two blades to cut stringy vegetables, such as celery. The
result is juicing with less jamming and improved juice quality with less pulp mixed into the juice.
• Torque force equivalent to a 9 HP motor
The powerful 200 watt motor and 3-stage reduction gear system produce the torque force equivalent
to a 9 HP motor.
• 3-Stage Speed Reduction Gears
Using the 3-stage reduction gear system, the Slowstar creates up to 30 ft. lbs. of torque using only
200 Watts of electricity.
• Easy to assemble & disassemble
The Auger Housing and Main Body detach easily for efcient cleaning and assembly.
• Additional Safety Switch
All parts must be assembled properly. The Feeding Chute Assembly and Auger Housing must be
locked securely in place in order to turn on the Slowstar, assuring safe operation.
• Virtually BPA-Free HD Ultem Duoblade Auger and Juicing Screen are 8 times
stronger ordinary plastic parts.
• On/Off/Reverse Switch
• Full 10-year warranty

10
PARTS
1. Plunger
2. Cleaning Brush
3. Feeding Chute Assembly
3a. Mincer Lid
4. Duoblade Double-Edged Auger
5. Juicing Screen
6. Pulp Wiping Assembly
7. Auger Housing
7a. Auger Housing For Mincer
8. Main Body
9. Juice Container & Pulp Container
10. Power Switch
11. Additional Safety Switch Link
The Main Body, Auger Housing, and
Feeding Chute Assembly must be
assembled before the switch is turned on.
(otherwise the Slowstar will not turn on)
WARNING: The Slowstar will not operate unless the
Main Body, the Auger Housing and Auger Housing Lid
are properly assembled with the inner safety switch is
locked in place.
Hopper
1.
3.
4.
7.
8.
9.
7a.
5. 6.
3a.
2.
Rotator
Safety
Switch
Handle
Juice Outlet
Pulp Outlet
Silicone Blade
Auger Housing Lid
Safety Link
10.
11.

11
EN
HOW TO ASSEMBLE
1. Insert the Pressure Plug (located at the bottom
of the Auger Housing) by inserting it into the
Pulp Outlet properly, as shown in the picture.
2/2a. Attach the Auger Housing or Auger
Housing for Mincer to the Main Body.
Rotate the housing clockwise towards
the Safety Switch Link.
3. Place the Juicing Screen into the Pulp Wiping
Assembly, then assemble the Pulp Wiping
Assembly with the Auger Housing. Assemble
the Auger Housing with the Pulp Wiping
Assembly by aligning the marks on each of
the units as shown in the picture.
4/4a. Place the Duoblade Auger into the center
of the Juicing Screen or Auger Housing
for the Mincer.
5. Assemble the Feeding Chute Assembly/Mincer Lid.
Match the marks on Feeding Chute Assembly/
Mincer Lid to the marks on Auger Housing/Auger
Housing for Mincer, then rotate the Feeding Chute
Assembly towards the mark on the Handle of Auger
Housing as shown on the picture.
CAUTION: Assemble the Feeding Chute Assembly
last. If the Feeding Chute Assembly is assembled
before the Auger Housing is assembled on the Main
Body, the Auger Housing and the Main Body cannot
be assembled.
6. Place the juice and pulp containers as shown in
the picture. Both containers look identical.
7. Plug the Power Cord into the power outlet.
Safety
Link
Marks
1.
2.
4.
5.
6. 7.
4a.
3.
2a.

12
HOW TO USE
1. Prepare ingredients for juicing.
• Cut stringy, brous ingredients (such as celery or kale) into 4-5 inch pieces for best results.
For even better results, cut the ingredients to a width of 1 inch and insert the pieces one by one.
• Cut carrots into halves or quarters lengthwise before feeding them into the Feeding Chute.
• Cut fruits into small pieces so they can go smoothly through the Feeding Chute, and remove
any big hard seeds.
• Feed the ingredients into the Feeding Chute piece by piece in order to properly extract juice
without clogging.
• The amount of juice extracted will vary depending on the water content of the ingredient.
• Soak hard grains in clean water for about 4~8 hours before mincing, or it may cause overload
damage to the Slowstar.
2. Turn on the Machine.
1) Check that the power switch is at the ‘OFF’ position. Then plug the cord into the wall outlet
before turning it on.
*Do not run the Slowstar without juicing or mincing foods for more than 1 minute. (It may
wear out the Duoblade Auger and/or the Juicing Screen and may cause a malfunction.
*Check that the Juice and Pulp Containers are properly placed at the base of the spouts to
prevent juice or pulp leakage.
2) Push the switch to ‘ON’ position to start operation.
3. Insert clean ingredients into the Feeding Chute with the Plunger.
TIPS:
• Use the freshest ingredients possible for optimal juice extraction.
- Soak refrigerated vegetables in drinking water for at least 10 minutes.
- Soak pine needles in water for an hour before juicing.
- Chop arrow root to smallest size possible in order to extract the juice.
- In order to extract green angelica juice, use only the leaves or chopped stems smaller than 2cm.
• Remove seeds rst when juicing fruits with hard seeds.
• While in use, the Slowstar may make some noise, which is normal.
• Please insert ingredients one by one, when switching to a different ingredient wait until the previous
ingredient is fully extracted.
NOTES AND CAUTION:
• It is best to drink juice right after extraction.
• The Slowstar may be used for preparing seasonings (garlic or pepper), but when grinding grains, be
sure to soak for 4~8 hours. (not doing so may cause damage to the machine or cause malfunctions).
• Do not operate the Slowstar with wet hands; completely dry your hands before operating; otherwise
an electric shock, short circuit, or re may occur.
• Do not operate the Slowstar for more than 30 minutes continuously. Otherwise the motor may
overheat and a malfunction may occur. Please let the machine rest for 5 minutes before continuing.

13
EN
• Do not insert any utensils, knives, or ngers into the Slowstar. Please use the Plunger to push down
the food. Placing foreign objects into the juicer may damage some parts of the machine, cause
in jury, or accident.
• Do not insert fruits without removing hard seeds rst. Hard seeds in the feeding chute may damage
or cause the machine to malfunction.
What to do if the Slowstar stops working while in operation.
If the Slowstar stops in the middle of operation, please turn the switch to the ‘OFF’ position rst. Turn
the switch to ‘REVERSE’ position and dislodge the fruit or vegetable pieces that are stuck between
the Duoblade Auger and the Auger Housing. Turn the switch to the ‘OFF’ position then to the ‘ON’
position. (Repeat this procedures up to 3 times or as many times as necessary). Upon releasing the
‘REVERSE’ button, the Slowstar will stop.
• While operating the Slowstar in the ‘ON’ position, please turn the switch to the ‘OFF’ position
and wait until the Slowstar stops completely before using the ‘REVERSE’ function. If the Slowstar
is switched to ‘REVERSE’ before the Slowstar stops completely, it may cause a malfunction.
• If the Slowstar still does not work, please turn the switch to the ‘OFF’, unplug the Slowstar,
disassemble the parts and clean it before trying to operate again.
How to use the Mincing Attachment
1. Assemble the Auger Housing for Mincer with the Main Body. Rotate the housing clockwise towards
the Safety Link.
2. Place the Duoblade Auger into the middle of the Auger Housing for the Mincer.
3. Match the Mincer Lid marks with the Auger Housing for Mincer marks, and then rotate the Mincer
Lid towards the Auger Housing for Mincer handle marks to lock in place.
4. Place a container under the Outlet.
5. Put ingredients into the Feeding Chute.

14
HOW TO DISASSEMBLE
1. Before turning off the Slowstar, remove the bers in
the Auger Housing by pouring 1 or 2 cups of water
into the Feeding Chute after each use (Self-Cleaning).
2. Turn off the Slowstar rst, then unplug the machine.
3. Disassemble the Feeding Chute Assembly rst by rotating
counter-clockwise (shown as 3 in the picture).
4. Disassemble the Auger Housing from the Main Body in the
direction of 4a and 4b in the picture.
CAUTION: Only after disassembling the Feeding Chute
Assembly can the Auger Housing be detached from the
Main Body.
5. Disassemble the parts as the reverse sequence
of assembling.
a) Disassemble the Feeding Chute Assembly by
rotating it counter-clockwise.
b) Remove the Duoblade Auger.
c) Disassemble the Juicing Screen.
d) Remove the Pulp Wiping Assembly.
Please be aware that unless the Slowstar is cleaned right after each use, residue may build up. This
may lower the performance of the Slowstar or cause difculties in cleaning.

15
EN
HOW TO CLEAN AND STORE
1. Please turn on the Slowstar and pour 1~2 cups of water into the Feeding Chute to clean out most
of the pulp remaining in the housing.
2. Disassemble the parts.
3. Clean the disassembled parts under running water using the cleaning brush.
• Do not use a steel brush, abrasive solvent, or harsh cleaning agent.
• Do not use an automatic dishwasher or dish dryer.
4. Do not clean the Main Body with running water. Clean the Main Body with a damp, soft towel.
5. After cleaning each part, dry each part completely, and place it on a clean surface.
TIPS:
1. Order of Disassembly and Assembly
• Disassembly:
1) Disassemble the Feeding Chute Assembly by rotating it counter-clockwise.
2) Disassemble the Duoblade Auger Housing by rotating it counter-clockwise.
3) Separate all parts in the Auger Housing.
4) Clean all juicing parts using the Cleaning Brush under running water.
5) Dry all parts completely.
• Assembly:
1) Assemble the Auger Housing on the top of the Main Body by rotating it clockwise.
2) Install the Pulp Wiping Assembly inside of the Auger Housing.
3) Insert the Juicing Screen into the Pulp Wiping Assembly.
4) Insert the Duoblade Auger into the Juicing Screen.
5) Assemble the Feeding Chute Assembly on top of the Auger Housing by rotating
it clockwise.
2. If the Feeding Chute Assembly lid does not open after operation.
• Press the switch to the ‘REVERSE’ position 2~3 times rst, then press the switch to the ‘ON’
position to remove any residue that may be stuck between the Auger Housing and Lid.

16
TIPS FOR SILICONE PARTS
-Silicone parts can be disassembled and washed.
-Fully dry the silicone parts after washing.
-Please check if the silicone parts are assembled correctly.
*Juice may leak if you do not assemble the silicone parts properly.
• Silicone Blade
1. Disassembly: Hold the Tail portion (2 in the drawing)
of the silicone blade and push upward to the middle
(3 in the drawing) of the blade slot, then pull outward.
2. Assembly:
1) Insert the Head portion (1 in the drawing) into the
middle of the blade slot in the Rotator (3 in the
drawing), making sure the Silcone Blade groove
and the Rotator blade slot groove t together, and
slide the Head upward .
2) Insert the Tail portion into the middle of the blade slot,
making sure the Silcone Blade groove and the Rotator
blade slot groove t together, and slide the Tail downward.
*After inserting pull the Silicone Blade tabs on the inside to
make sure it is securely assembled.
• Sealing ring
1. Disassembly: Push from the bottom side of
the Auger Housing (smaller silicone ring) for
easy cleaning.
2. Assembly: After it is thoroughly dried, put the
sealing ring properly back in its place. Push the
sealing ring (with the larger side facing up) back
in place from the inside of the Auger Housing.
• Pressure Plug
After washing, put the Pressure Plug
in correctly as shown in the picture
Blade Slot
Groove
Silicone
Blade Groove

17
EN
TROUBLESHOOTING
The Slowstar does not work. • Check if the power cord is plugged in properly.
• Check if all parts are assembled correctly.
Motor stops during use. • Check if the power cord is plugged in properly.
• Check if all parts are assembled correctly.
• The Motor may stop if too many juicing ingredients are inserted
at the same time. If this occurs, turn the Switch to “OFF” and then
turn the switch to “Reverse” to unclog the materials. Then turn
the switch to “ON” to push the materials down. (Repeat this step
3 times.)
• Turn the switch to “OFF” and place the Main Body in a cool area.
Let the Slowstar rest for an hour to cool the
motor down and try turning the Slowstar on again.
• Remove all the hard seeds in the juicing ingredients before juic-
ing. Hard seeds may break down the Juicing Screen and Duoblade
Auger.
Amount of juice is too little. • Each food produces a different amount of juice depending on
how fresh it is.
• To extract more juice, refrigerate ingredients, then soak for about
10 minutes in clean water before juicing.
• Check if the Pressure Plug is assembled properly.
Juice Container is shaking in the middle of
operation.
• It is completely normal if the juice container shakes a little bit
during operation.
Seems like the Duoblade Auger is grinding. • Operating the Slowstar without feeding any food may cause the
Duoblade™ Auger to grind.
Hearing a lot of sounds coming from
the Slowstar.
• Turn the switch to “OFF” and check if parts are
assembled properly.
• Check if the Slowstar is operating on an uneven surface.
• There may be some squeaky friction noise while in use. This is a
normal sound that occurs, and user should not
worry about it.
• Check if juicing materials are cut to the right sizes.
Juice is spilling out of the Slowstar. • Check if pressure plug is assembled properly.
After extraction, the color of the Juicing
parts and Juice Container are different.
• Right after use, if the Slowstar is not cleaned, then it is more
difcult to clean and may even cause reduced performance.
• Disassemble Silicone Blades and wash them separately.
The Feeding Chute Assembly does not
disassemble easily.
• Grab the Feeding Chute rmly and rotate it counter-clockwise
with force.

19
SPECIFICATION
Product Juicer
Model SW-2020, SW-2000
Voltage USA Models: 120V~, 60 Hz
Europe/Asia Models: 220~240V, 50/60 Hz
Power Consumption 200W
RPM 47
Torque Power 9.4 HP
Maximum Use Less than 30 minutes continuously
Cord Length 51 in.
Net Weight 19 lbs.
Dimension 190(W) x 225(L) x 460 (H) mm
Compression Type Low Speed Compression
Warranty 10 Years
EN
