User Manual
Gas Cooker
SG552D

2
Important safety information
These warnings are provided in the interests
of your safety. Ensure that you understand
them all before installing or using the
appliance. Your safety is of paramount
importance. If you are unsure about any of
the information in this book contact the
Customer Care Department.
Installation
Germany
The appliance must be installed by an
authorised person in order to guarantee that
the local requirements of the gas supplier
are considered.
Unqualified works or repairs are dangerous
as they could lead to explosion, short circuit
or electrocution. Work on the appliance
must only be done by a qualified person
(e.g. tech. after sales person).It is important
that the appliance is suitable for your gas
supply. Your installer should check the rating
plate.
Make sure that a stability bracket is fitted.
The appliance must be installed in an
adequately ventilated room.
If the appliance is to be placed on a base,
measures must be taken to prevent the
appliance from slipping from the base.
This appliance is heavy and care must be
taken when moving it.
Do not attempt to lift or move this appliance
by the handles.
All packaging, both inside and outside the
appliance must be removed before the
appliance is used.
It is dangerous to alter the specifications or
modify the appliance in any way.
After installation please dispose of the
packaging with due regard for safety and the
environment. Your local authority can
arrange this.
Child safety
Do not allow children to play with any part of
the packaging.
Do not allow children to sit or climb on the
drop down doors.
This appliance is not intended for use by
children and other persons whose physical,
sensory or mental capabilities or lack of
experience and knowledge prevents them
from using the appliance safely without
supervision or instruction by a responsible
person to ensure that they can use the
appliance safely.
Children should be supervised to ensure that
they do not play with the appliance.
CAUTION: Accessible parts may be hot
when the grill is in use. Young children
should be kept away.
During use
This appliance is not intended to be
operated by means of an external timer or
separate remote control system.
This appliance has been designed for
domestic use to cook edible foodstuffs only
and must not be used for any other
purposes.
Take great care when heating fats and oils
as they will ignite if they become too hot.
When you are lighting any burner check that
it is lit before you leave the appliance. When
turning off a burner, do not leave the
appliance until the flame has gone out.
Never place plastic or any other material that
may melt in or on the oven.
Always support the grill pan when it is in the
withdrawn or partially withdrawn position.
Always use oven gloves to remove and
place food in the oven.
Ensure cooking utensils are large enough to
contain foods to prevent spillages and boil
overs.

3
During use the appliance becomes hot. Care
should be taken to avoid touching the
heating elements inside the oven.
Ensure that all vents are not obstructed to
ensure ventilation of the oven cavity.
Never line any part of the appliance with foil.
Always stand back from the appliance when
opening the oven door to allow any build up
of steam or heat to release.
Never leave the appliance unattended
when the oven doors are open.
Do not place sealed cans or aerosols inside
the oven. They may explode if they are
heated.
Ensure that all control knobs are in the OFF
position when not in use.
Do not stand on the appliance or on the
open oven doors.
Do not hang towels, dishcloths or clothes
from the appliance or its handles.
Do not use this appliance if it is in contact
with water. Never operate it with wet hands.
Cleaning and maintenance
For hygiene and safety reasons this
appliance should be kept clean at all
times. A build-up of fats or other
foodstuffs could result in a fire especially
in the grill pan.
Do not leave cookware containing
foodstuffs, e.g. fat or oil in the appliance in
case it is inadvertently switched on.
Do not disconnect the appliance from the
gas supply if the supply pipe does not have
a bayonet connection as described in the
installation section. If this is the case contact
the person who installed the appliance.
Always allow the appliance to cool before
switching off at the wall prior to carrying out
any cleaning/maintenance work.
Only clean this appliance in accordance with
the instructions given in this book.
Never use steam or high pressure steam
cleaners to clean the appliance.
At the end of the appliance’s
life
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it shall be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local city office,
your household waste disposal service or
the shop where you purchased the product.

4
Contents
For the user
Important safety information 2
Description of the appliance 5
Getting to know your appliance 6
Before using the appliance 7
Rating plate 7
Preparing to use your appliance 7
Condensation and steam 7
Cookware 7
Grill and oven furniture 7
The timer 9
The hob 10
Using the hob 10
To light the hob burners 10
To turn off any burner 11
Things to note 11
Hints & tips 11
The grill 12
Using the grill 12
Things to note 12
The grill pan and handle 13
Hints & tips 13
Grilling chart 14
The main oven 15
Heat zones 15
Preheating 15
To fit the main oven shelves 15
Using the main oven 15
Hints & tip 16
Cooking chart 17
Roasting chart 18
Slowcook 19
Using slowcook 19
Food preparation 19
General points 20
Care and cleaning 21
Cleaning materials 21
Cleaning the outside of the appliance 23
Cleaning the control knobs and
handles 21
Cleaning the hob 22
When replacing hotplate burner parts 22
Cleaning the shelves and grill/oven
furniture 23
Cleaning the grill 23
Cleaning inside the oven(s) 23
Hints and tips 23
Cleaning the door(s) 24
Replacing an oven light bulb 25
Something not working 26
Service and spare parts 28
Guarantee conditions 29
For the installer
Technical details 30
Important safety requirements 31
Provision for ventilation 31
Moving your appliance 31
For your safety 32
Location of appliance 32
Levelling the appliance 33
Connecting to electricity supply 33
Connecting to gas supply 34
Fitting the stability bracket 34
Testing 35
General note 35
To help you the following symbols will be
found in the text.
Hints and Tips
Safety Instructions
Please read the instruction book carefully
before use and retain for future reference.

5
Description of the appliance
Gas slip-in single oven
Main Oven
Control Panel
Grill

6
Getting to know your appliance
The control panel
Features
A - Grill control
B - Hotplate controls
C - Electronic minute minder
D - Hotplate controls
E - Main oven temperature control
F - Ignition switch
ABCD
F
Alarm
Stop
SET TIME
Push
Both
E
5
4
3
2
1
6
9
7
8

7
Before using the appliance
Rating plate
This is situated on the lower front frame of
the appliance and can be seen upon
opening the door. Alternatively the rating
plate may also be found on the back or top
of some models (where applicable).
The appliance must be protected by a
suitably rated fuse or circuit breaker. The
rating of the appliance is given on the rating
plate.
Do not remove the rating plate from the
appliance as this may invalidate the
guarantee.
Preparing to use your
appliance
Wipe over the base of the oven(s) with a soft
cloth and hot soapy water and wash the
furniture before use. We suggest that you
run the oven(s) and grill for 10 – 15 minutes
at maximum temperature, to burn off any
residue from their surfaces. Accessible parts
may become hotter than in normal use.
Children should be kept away. During this
period an odour may be emitted, it is
therefore advisable to open a window for
ventilation.
Condensation and steam
When food is heated it produces steam
similar to a boiling kettle. The vents allow
some of this steam to escape. However,
always stand back from the appliance when
opening the door(s) to allow any build up of
steam or heat to release.
If the steam comes into contact with a cool
surface on the outside of the appliance, e.g.
a trim, it will condense and produce water
droplets. This is quite normal and is not
caused by a fault on the appliance.
To prevent discolouration, regularly wipe
away condensation and also soilage from
surfaces.
For your safety wall coverings at the rear of
the appliance should be securely fixed to the
wall.
Cookware
Main oven - Do not use baking trays larger
than 30cm x 30cm (12” x 12”) as they will
restrict the circulation of heat and may affect
performance.
Grill and oven furniture
The following items of grill and oven furniture
have been supplied with the appliance. If
you require replacements of any of the items
listed below please contact your local
Service Force Centre, quoting the relevant
part number.
1 grill pan
(311409401)
1 grill pan handle
(311468100)
Note:
If you require an additional handle for your
grill pan, this can be ordered from your local
Service Force Centre by quoting part
number 311479800\6.
1 grill pan grid
(311757500)
1 straight shelf
(for grilling)
2 straight shelves
(for main oven cooking)

8
Electronic minute minder
1 = ( - ) Decrease control &
Minute minder
2 = ( + ) Increase control
( ) Bell Symbol
The electronic minute minder can also be
used to show the time of day.
Please note that this is a 24 hour clock, for
example 2.00pm is shown as 1400.
In the following pages we explain how to set
the controls. Read through them a few times
until you are familiar with the procedure.
If the appliance is switched off on the wall, or
there is a loss of power, the clock will stop
and you will not be able to use the main
oven.
Set the time of day
When the electricity supply is first switched
ON, the display will flash 0.00. See Fig.1.
Press buttons (1) and (2) together. Release
buttons, 0.00 will appear in the display as
Fig. 2. Within 5 seconds press button (2),
12.00 will show in the display as Fig. 3.
Within 5 seconds press and hold either
button (1) to decrease or button (2) to
increase the time until the correct time of day
on the 24 hour clock is reached, e.g. 14.30.
See Fig. 4.
Note: The increase and decrease control
buttons operate slowly at first and then
more rapidly. They should be pressed
separately.
The minute minder
The minute minder gives an audible
reminder at the end of any period of cooking
up to 23 hours and 59 minutes.
To set press button (1) and the display will
read 0.00, see Fig. 5.
Alarm
Stop
SET TIME
Push
Both
Button 2
Button 1
Bell
Symbol
Alarm
Stop
SET TIME
Push
Both
Fig.1
Alarm
Stop
SET TIME
Push
Both
Fig.2
Alarm
Stop
SET TIME
Push
Both
Fig.3
Alarm
Stop
SET TIME
Push
Both
Fig.4
Alarm
Stop
SET TIME
Push
Both
Fig.5

9
Release button (1) and press and hold
button (2). The display will count up in one
minute intervals until the interval to be timed
is reached e.g. 30 minutes, see Fig. 6. If
necessary press and hold button (1) to
achieve the correct time interval.
The bell symbol will show in the display.
The minute minder will begin to count down
once set. The time of day will show in the
display. To show the remainder of the cook
time press button (1).
At the end of the timed period an audible
signal will sound for up to 2 minutes. The
bell symbol will flash and the time of day will
show in the display, see Fig 7.
To stop the sound press button (1). The bell
symbol will go out and show the time of day
e.g. 15.00, see Fig 8.
To cancel the minute minder
If you change your mind and want to cancel
the minute minder. Press and release button
(1).
Press and hold button (1) and the display will
count down in one minute intervals to 0.00.
See Fig. 9.
Release button (1). After a few seconds the
time of day will show in the display, see Fig.
10.
Alarm
Stop
SET TIME
Push
Both
Fig.6
Alarm
Stop
SET TIME
Push
Both
Fig.7
Alarm
Stop
SET TIME
Push
Both
Fig.8
Alarm
Stop
SET TIME
Push
Both
Fig.9
Alarm
Stop
SET TIME
Push
Both
Fig.10

10
The hob
Using the hob
The gas hob has different burner sizes to
suit different types of cooking:
To ensure maximum burner efficiency only
use pots and pans with flat bases
appropriate to the burner size used.
Larger burner (Rapid) - use a large pan for
food such as chips.
Medium burners (Normal) - use for everyday
cooking.
Small burner (Simmer) - use for simmering
foods such as soups and stews.
The largest pan which you should use on
any burner is 230mm (9"). The base of the
smallest pan should not measure less than
100mm (4").
Ensure the pan supports are
correctly fitted before using the
hob.
To light the hob burners
The hob ignition works by means of an
electric spark system.
• Push in and hold the control knob, turn
to the large flame symbol (highest
setting) and press the ignition button
immediately. Keep the control knob
depressed for up to 5 seconds, but no
longer than 10 seconds. After this time
release the controls. The flame should
remain alight. If after 10 seconds the
burner has not lit, stop operating the
appliance and wait at least 1 min before
attempting a further ignition of the
burner.
• When the burner has lit release the
control and ignition button, adjust the
setting as required.
Warning: If the ignition button is
not pressed immediately a build
up of gas may cause the flame to
spread.
