Trident ModCom One User manual

Trident
Communication
Technology
ModCom One
Corded Reference Guide

ModCom One Corded Reference Guide. V2 1
Contents
Thank You ............................................................................................................................................ 2
Please Read this Reference Guide ......................................................................................................... 2
Features ............................................................................................................................................... 2
Connect the Audio Cable ...................................................................................................................... 3
Position the Boom ................................................................................................................................ 3
Adjust Headband .................................................................................................................................. 4
Headband Disassembly ......................................................................................................................... 4
Install Windscreen and Ear Cushion ...................................................................................................... 5
Microphone Orientation ....................................................................................................................... 5
Cleaning and Maintenance ................................................................................................................... 5
Troubleshooting ................................................................................................................................... 6
Warranty and Customer Support .......................................................................................................... 7
Safety and Regulatory Information ....................................................................................................... 8

ModCom One Corded Reference Guide. V2 2
Thank You
We appreciate your purchase of the Trident™ ModCom One Corded Headset. This rugged corded
headset combines high-quality audio performance, environmental durability, and lightweight comfort
without sacrificing stability during active use.
Please Read this Reference Guide
Please take the time to follow the instructions in this reference guide carefully. It will help you set up
and operate your Headset properly and enjoy its advanced features. Please save this guide for future
assistance.
Features

ModCom One Corded Reference Guide. V2 3
Connect the Audio Cable
Insert the 3.5mm audio cable jack into either the top or bottom audio cable port, depending on right
or left placement of the microphone boom.
Position the Boom
Do not rotate the boom beyond the stop point.
*Applies to Mono and Binaural Model. The Behind the Neck model has only left side boom placement.

ModCom One Corded Reference Guide. V2 4
Adjust Headband
The headband can be squeezed for a tighter or a looser fit to the head. The stainless steel head band
will click as it is lengthened or shortened into a comfortable position. When adjusting the headband:
• Position the ear cushion in the center of the ear.
• Position the T-Bar above the ear, half way between the top of the ear and the top of the head.
Headband Disassembly
1. Loosen the Headband Set Screw Counterclockwise
2. Remove Headset Module from Headband

ModCom One Corded Reference Guide. V2 5
Install Windscreen and Ear Cushion
Microphone Orientation
Cleaning and Maintenance
To maintain the ModCom One Headset we suggest the following guidelines:
• Do not expose the Headset to harsh chemicals or cleaning agents.
• If the Headset becomes dirty, wipe it with a soft damp cloth. Do not use soap, cleaning fluids or
chemicals.
• Keep dust, dirt and debris out of the Headset audio connector port.
•

ModCom One Corded Reference Guide. V2 6
Troubleshooting
Operation
Problem
Possible Solution
Transmission
No Transmit (TX) Callers cannot
hear me or speech recognition
software does not hear me.
Make sure 3.5 mm audio connector is
completely plugged into ModCom One audio
port.
Make sure 3.5 mm audio connector is
completely plugged into phone.
Make sure Quick Disconnect (QD) adapter, if
purchased, is properly connected to device’s QD
adapter. Verify that QD pins are not damaged.
No Receive (TX) No incoming
sound.
Make sure 3.5 mm audio connector is
completely plugged into ModCom One audio
port.
Make sure 3.5 mm audio connector is
completely plugged into phone.
Make sure Quick Disconnect (QD) adapter, if
purchased, is properly connected to device’s QD
adapter. Verify that QD pins are not damaged.

ModCom One Corded Reference Guide. V2 7
Warranty and Customer Support
• For the complete Trident Communication Technology, LLC. hardware product warranty
statement, visit: http://www.tridentcomtech.com/warranty
• If you have problem using your equipment, contact Trident Customer Support at
http://www.tridentcomtec.com/support
• For the latest version of this User Manual visit: http://www.tridentcomtech.com/manuals

ModCom One Corded Reference Guide. V2 8
Safety and Regulatory Information
• Contains small parts which can be a choking
hazard.
• Not suitable for children under age 3.
• This product contains magnets which can be
harmful to pacemakers, or similar medical
devices.
• To reduce the risk of fire or electrical shock, do
not expose the product to rain or moisture.
• As with any electronic products, use care not
to spill liquids into any part of the system.
Liquids can cause a failure and/or a fire hazard.
• Do not place any naked flame sources, such as
lighted candles, on or near the apparatus.
• Use caution when using your headset while
operating a vehicle or engaging in any activity
that requires your full attention. Check and
follow local laws regarding mobile phone and
headset use. Some jurisdictions impose
specific limitations, such as single earpiece
configuration, on the use of such products
while driving.
• Sounds that you rely on as reminders or
warnings may sound different when using a
headset. Be aware of how these sounds may
vary in character so you can recognize them as
needed.
CAUTION:
Do not make modifications to the headset or
accessories. Unauthorized alterations may
compromise safety, regulatory compliance,
and product performance and warranty.
• Long-term exposure to loud music may cause
hearing damage. It is best to avoid extreme
volume when using a headset, especially for
extended periods.
• Use caution when using a Headset while
operating a motor vehicle or anywhere the
inability to hear outside sounds may present a
danger to you or others.
• The ModCom One Headset does not require
scheduled cleaning. Should cleaning be
necessary, simply wipe the outside surfaces
with a soft damp cloth.
Regulatory Information
All Trident Communication Technology, LLC.™
devices are designed to be compliant with rules
and regulations in the locations they are sold
and will be labeled as required. This regulatory
information applies to Model number MC1-BT.
CE NOTICE TO USERS
Trident Communication Technology, LLC.™
hereby declares that this product is in
compliance with the essential requirements and
other relevant provisions of CISPR22 Class B.
FCC NOTICE TO USERS
In the United States:
This equipment has been tested and found to
comply with the limits for a Class B device,
pursuant to Part 15 Subpart B of the FCC Rules.
Waste Electrical and Electronic Equipment
This symbol on the product or on its packaging
indicates that this product must not be
disposed of with your other household waste.
Instead, it is your responsibility to dispose of
your waste equipment by handing it over to a
designated collection point for the recycling of
waste electrical and electronic equipment. The
separate collection and recycling of your waste
equipment at the time of disposal will help to
conserve natural resources and ensure that it is
recycled in a manner that protects human
health and the environment. For more
information about where you can drop off your
waste equipment for recycling, please contact
your local city/town office or the distributer
where you purchased your equipment.
