Trigon Elektronik Exxceed User manual

MANUAL
INTEGRATED AMPLIFIER
Exxceed
E ceed
XX
Mono On/OffMenue
Integrated Amplifier
SPK On/OffPhones
Input 1
DSDBalan-In
PCMInput 1
Input 2
Input 3
Digital 1
Digital 2
MuteDigital 3
SPKDigital 4
MonoUSB

Contents
1 Introduction................................................................................................................3
2 General Description...................................................................................................3
2.1 Sa ety In ormation..............................................................................................3
2.2 Installation In ormation.......................................................................................4
2.3 Warranty and Service In ormation.....................................................................4
3 Initial Setup................................................................................................................6
3.1 Front Panel Controls and Display......................................................................7
3.2 Settings...............................................................................................................9
3.2.1 Level.............................................................................................................9
3.2.2 Volume Start................................................................................................9
3.2.3 Balance......................................................................................................10
3.2.4 Out.............................................................................................................10
3.2.5 DAC............................................................................................................10
3.2.6 Unity Gain..................................................................................................10
3.2.7 Power Management...................................................................................11
3.2.8 Color...........................................................................................................12
3.2.9 Name..........................................................................................................12
3.3 Rear Panel Connections...................................................................................13
3.3 Quick Start Manual............................................................................................15
3.4 Exxceed and the Remote Controller Director Premium.....16
4 What to do, i ...........................................................................................................17
4.1 ... unit doesn’t turn on?......................................................................................17
4.2 ... no sound is produced?..................................................................................17
4.3 ... there is a hum?.............................................................................................18
4.4 ... unrealistic tests are carried out?...................................................................18
5 Technical Data.........................................................................................................19
2

1 Introduction
Valued Trigon - Customer,
We are excited that you have chosen to purchase the Exxceed integrated
ampli ier.
This unit was built using the highest quality control to insure utmost precision in
manu acturing.
Whether you are a beginner to High-Fi or advanced user, it is highly recommended
that you read and understand this User’s Manual thoroughly be ore using your new
integrated ampli ier.
Be sure to keep this manual easily accessible as it could come in handy during
normal use o this ampli ier.
We hope that you enjoy your new ampli ier and thank you or choosing Trigon.
2 General Description
The Exxceed is a High-End integrated ampli ier with 9 inputs (CD-Player, Tuner,
TV etc.). There are 4 analogue inputs and 4 (5) inputs or digital devices.
The integrated PHONES ampli ier is able to drive headphones with an impedance
between 30 and 250 Ohm. The power ul analog output stage can drive loudspeakers
with an impedance rom 3 ohms. The Exxceed can be operated via two rotary
knobs and our touch sensors as well as the optionally available IR remote control
Director Premium.
The LED displays are customizable to your personal needs. The TFT display in orms
you about all settings. The color o this display is individually adjustable.
The massive housing o the Exxceed consists o 2mm steel plate as well as a
10mm strong aluminum ront panel. The device eet work according to the principle o
a plate spring and decouple the Exxceed e ectively rom the stand. Due to this
elaborate housing design, sound e ects are minimized through microphony.
2.1 afety Information
Trigon Ele troni GmbH will not assume any responsibility or
damages occurred rom unsa e handling o the product or rom not adhering to the
recommend sa ety instructions below.
- The ampli ier should not be used un-monitored in close proximity to heat
producing devices such as Water heaters, Fireplaces or Flammable materials.
- The ampli ier is not designed to withstand heavy impacts or severe vibrations.
- The ampli ier should not be used un-monitored when being transported rom a
cold environment into a warm room.
- The ampli ier should not be used when placed out in direct contact with the Sun.
3

- Insure that the installation location or this product has adequate ventilation.
- The ampli ier should not be doused with any type o liquid. It is imperative that
no liquid get inside the unit.
- Never use this product without the shielded top cover installed.
- Be ore removing the top cover always insure that the AC cord has been
removed rom the AC outlet and that the product has sat to drain any residual
current.
- Never short any o the uses. Replace broken uses only with original uses o
the same value and type.
- Do not attempt to service this unit. Repairs are only to be done by authorized
service centers or through the actory direct. Any such unauthorized repairs will
result in a voided warranty.
–Always make sure that your complete audio system is shut o be ore changing
any cables or connecting any other components.
The Exxceed is set at the actory to be operated in 230V AC. Contact your local
dealer or Trigon directly i you should need a di erent voltage version.
2.2 Installation Information
During unpacking, please inspect the unit or any potential transportation damage. I
you notice any damage, please get in contact with your dealer.
Con irm the contents o the box. In addition to the Exxact, you should also have
the ollowing:
User’s Manual
Warranty Card
Power cord
Place the unit on a dry, level sur ace. Be sure that the unit has good ventilation
around it. Strong magnetic ields commonly ound in ampli ier trans ormers and
halogen light trans ormers can induce hum into a system. Because o this, it is best
to place the unit a reasonable distance rom such devices. Also, the audio
interconnects should not be run in parallel to AC power cables as this can also
induce noise.
Hum is also produced rom light bulbs. It is best to place audio equipment at least 3
eet away rom them.
Try to utilize natural light and make sure not to use the Exxceed unmonitored
next to heat sources.
2.3 Warranty and ervice Information
In choosing the Exxceed, you have selected a valuable and technologically
advance product. We at Trigon are trying to improve our quality control through
all steps in the production cycle to insure that all Trigon products meet our
4

quality expectations. I a problem is experienced, Trigon Ele troni
GmbH o ers a three-year warranty. This warranty covers repairs or any
manu acturing de ects.
It does not cover damages that are the result o neglect or misuse. It also is
considered void i unauthorized personnel do any repairs or modi ications. Any
alterations to the serial number, or transportation damage are not covered as part o
this warranty.
5

3 Initial etup
A ter unpacking the ampli ier, the unit should warm up to the ambient temperature.
Particularly in the cold season, moisture can also build up inside the case when the
device comes rom a cold to a warm environment.
I the equipment has been acclimatized, we recommend that you amiliarize yoursel
with your new Exxceed.
Exxceed
ront view
Plug the Trigon Volt cable into the Exxceed socket (11) and connect the
power plug to the power supply.
Switch on the integrated standby power supply by pressing the switch (11) on the
back o the Exxceed.
Exxceed
rear view
ATTENTION!!! Be ore you start with the wiring, however, you should switch o the
Exxceed, as well as the other devices o your system, as always when working on
the cabling. Avoid plugging into a UNBAL INPUT when the Exxceed RCA plug is
plugged in. Un ortunately, these connectors irst connect to the signal contact and
then connect to the neutral eedback (ground), which usually results in a very strong
hum , which can destroy the ampli iers and / or your speakers!
6
230V AC
500W max
Handmade In GERMANY
IN TEGRATED AMPLIFIER EXXCEED
PEAKER
RIGHT CHANNEL
PEAKER
LEFT CHANNEL
- -
+ +
INPUT 1INPUT 2INPUT 3
D-IN-1 GROUNDERVICED-IN-2D-IN-3D-IN-4D-IN-5REMOTE
PRE/REC-OUT
BAL-OUT-L BAL-IN-LBAL-OUT-R BAL-IN-R
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
20
11 12 13 14 15 16 17 18 19
21 22 23 24 25 26
10
E ceed
XX
Mono On/OffMenue
Integrated Amplifier
SPK On/OffPhones
Input 1
DSDBalan-In
PCMInput 1
Input 2
Input 3
Digital 1
Digital 2
MuteDigital 3
SPKDigital 4
MonoUSB
1
2
3 4 56 7
8
9

3.1 Front Panel Controls and Display
We tried to design the number o control elements according to the ormula "as much
as necessary, as little as possible". In addition, it was important to us during the
conceptualization that the ampli ier in the basic unctions remains as simple to
operate as possible and can be operated intuitively. So everyone will immediately
assign the unction o the volume setting to the large right rotary knob (8)
The rotary knob (1) on the le t is used to select the inputs and the Exxceed is
switched on or o with the sensor button (7).
The elements in detail:
(1) Inputselector
This knob selects the input. The selected input is shown in the display (9). The name
o the individual inputs can be set individually. (See also 5.9)
(2) IR-Window
Behind this disc is the in rared remote control receiver.
(3) Headphone jack
A 6.3mm jack plug o a headphone can be plugged into this socket. The impedance
o the headphone should be between 32 and 250 ohms.
I you want to switch o the playback via the loudspeakers while you are using the
headphones, tap the sensor ield (4). The LED above the headphone connector lights
up and indicates that the loudspeakers are now switched o .
To reconnect the speakers, tap the sensor ield again (4). The LED above the
headphone jack goes out, the volume is reduced to the power-on level, and the
speakers are reconnected.
(4) ensor Key PK On/Off
The speakers can be switched on or o at this sensor ield. When the loudspeakers
are switched on, a dot on the le t be ore the label "SPK" appears in the lower right
corner o the display (9).
(5) ensor Key MENUE
The Exxceed has extensive settings. Touching the MENUE button will take you
to the Settings menu.
7

The ollowing settings are available:
Level (3.2.1) Unity Gain (3.2.6)
Volume Start (3.2.2) Power Management (3.2.7)
Balance (3.2.3) Color (3.2.8)
Out (3.2.4) Name (3.2.9)
DAC (3.2.5)
(6) ensor Key MONO
This button can be used to switch the mono unction on or o . I MONO is activated,
a dot appears in the lower right corner o the display be ore the "MONO" label. In
addition, the last LED o the volume indicator lights up.
(7) On/Off Key
I the main power switch (11) on the back o the device is switched on, the Exxceed is
switched on or o . Tap your inger on the circle icon under the label On / O . Within
the circle, an LED is lit and as soon as you remove the inger, the Exxceed turns on
or o . When the power is o , the LED above the keypad will turn red (standby) and
green when the keypad is in the state.
During the power-up process, the color o this LED lashes between yellow and
green. As soon as the switch-on process is completed, the LED is constantly green.
REMARK: We have equipped the Exxceed with a very power saving standby power
supply. The power consumption in standby mode is less than 1 watt. You can always
connect the Exxceed to the power supply in standby mode without switching it o
completely with the mains switch (11).
I , however, you do not want to use the Exxceed or a longer period o time (holidays,
etc.), you can also switch o the power supply completely with the switch (11).
In the case o severe storms with a risk o lightning, it is also recommended to
disconnect the mains connection, ie pull the mains plug!
(8) Volume knob and volume indicator, mute function
This button is used to adjust the volume. The adjusted volume is indicated by the
LED's arranged around the volume knob.
8
S ettings
Level Unity Gain
Volume Start Power Management
Balance Color
Out Name
DAC

Pressing the volume button invokes the mute unction, i. the volume is set to a
minimum value. When the mute unction is activated, a dot appears in the lower right
corner o the display be ore the name "Mute".
Pressing the rotary knob again or turning the volume knob will cancel the mute
unction and restore the previous volume level.
(9) Display
The Exxceed is equipped with a TFT display, which in orms about all settings. The
text colors can be set individually in the "Settings → Color" menu. I you want to
switch o the display completely, you can set this in the menu "Settings → Power
Management".
3.2 ettings
Note: All the descriptions below assume that you have already switched on the
settings menu as described above.
3.2.1 Level
In this menu, you can individually adjust the volume (level) or each input to minimize
volume di erences when switching to another input. Since only a lowering o the
levels can be made, the input with the lowest level should be selected as re erence.
All other inputs are then tuned to this input.
–Use the input selection switch (1) to select the Level sub-menu
–Press the input selector (1) to enter the company level
–Turn the input selector until you reach the input you want to set.
–Use the volume knob (8) to adjust the level. To be able to compare the level
with the "re erence input", use the input selection switch (1) to set this input
again. Proceed with all other inputs.
–To exit the submenu "Level", press the input selector (1) once and return to
the "Settings" menu.
To return to the standard inter ace and exit rom the setup menu, tap the Menu ( 5)
button.
3.2.2 Volume tart
The Exxceed has an electronic volume setting. In this submenu, you can adjust
the volume that is set when the Exxceed is turned on.
–Use the input selection switch (1) to select the Volume tart submenu
–Press the input selector (1) to enter the Volume tart submenu
–Use the volume knob (8) to adjust the desired startup volume
–Press the input selector (1) again to exit this submenu.
9

3.2.3 Balance
In this submenu the stereobalance can be adjusted.
–Use the input selection switch (1) to select the Balance sub-menu
–Use the volume knob (8) to adjust the stereo balance
–Press the input selector (1) again to exit this submenu
3.2.4 Out
In this submenu, you can turn the headphones connection (Phones) on and o , and
you can speci y how the preamp output PRE / REC-OUT (22) should be connected.
Turn on or off headphones:
–Use the input selector (1) to select the Out submenu
–Press the input selector (1) to enter the Out submenu
–Use the input selector (1) to select Phones
–Use the volume knob (8) to turn on or o
–Press the input selector (1) again to exit this submenu.
electing Record or Preamp Out:
–Use the input selector (1) to select the Out submenu
–Press the input selector (1) to enter the Out submenu
–Use the volume knob (8) to select PreOut or Record
–Press the input selector (1) again to exit this submenu.
3.2.5 DAC
In this submenu di erent ilters can be switched on with the integrated digital-analog
converter. Select the ilter that you like best.
–Use the input selector (1) to select the DAC submenu
–Press the input selector (1) to enter the DAC submenu
–Use the volume knob (8) to select one o the our ilters
–Press the input selector (1) again to exit this submenu.
3.2.6 Unity Gain
With this setting, the volume control o the selected input is bridged. This setting is
required when the Exxceed is operated within a multi-channel system. Unity gain
is only available or the analog inputs.
Enable Unity Gain:
–Use the input selector (1) to select the Unity Gain submenu
–Press the input selector (1) to enter the Unity Gain submenu
–Use the input selection switch (1) to select the analog input to which your
multi-channel ampli ier is connected.
–Turn the volume knob (8) to the right until "Unity Gain [the selected input] is on".
–Press the input selector (1) again to exit this submenu.
10

Unity gain is now activated or the selected input. This input is highlighted in the
standard screen. Whenever you switch to this input, the volume is automatically
raised until the unity gain level is reached.
I , in spite o all the care, you have accidentally activated Unity Gain, and i this is not
the case, you can adjust the volume manually by turning the volume knob (8). Note,
however, that the Unity Gain setting remains stored until you are deactivated.
Disable Unity Gain:
–Use the input selector (1) to select the Unity Gain submenu
–Press the input selector (1) to enter the Unity Gain submenu
–Use the input selection switch (1) to select the analog input with which Unity
Gain is activated.
–Turn the volume knob (8) to the le t until "Unity Gain [the selected input] is o ".
–Press the input selector (1) again to exit this submenu.
Now UnityGain or this input is switched o again.
3.2.7 Power Management
In this submenu, you can set the ollowing:
(3.2.7.1) Display Timeout
(3.2.7.2) LED-Brightness
(3.2.7.3) Power Timeout
(3.2.7.4) Remote Power
3.2.7.1 Display Timeout
Here you can switch the display on and o . However, the display will always turn on
again when you make changes to the device (e.g., other input). The time (timeout),
which should remain on the display, can be set here. A timeout between 3 and 255
seconds can be set.
–Use the input selection switch (1) to select the Power Management submenu
–Press the input selector (1) to enter the Power Management submenu
–Use the input selection switch (1) to select Display Timeout
–Use the volume knob (8) to set the time between 3 and 255 seconds. In
position "Off", the display timeout is switched o and the display is
permanently switched on again.
–Press the input selector (1) again to exit this submenu.
3.2.7.2 LED-Brightness
Here you can adjust the brightness o the LED volume display.
–Use the input selection switch (1) to select the Power Management submenu
–Press the input selector (1) to enter the Power Management submenu
–Use the input selection switch (1) to select LED Brightness
–Use the volume knob (8) to adjust the brightness in steps between 0 and 20.
–Press the input selector (1) again to exit this submenu.
11

3.2.7.3 Power Timeout
The Exxceed has an adjustable automatic shut-o device. The time until the
Exxceed switches o is adjustable between 10 and 255 minutes. The shutdown time
also depends on when the last audio signal was played back. From this point
onwards, the timer starts counting down the set time and then turns o the device. I ,
however, an audio signal is reproduced again within this time, the timer is reset to its
initial time.
–Use the input selection switch (1) to select the Power Management submenu
–Press the input selector (1) to enter the Power Management submenu
–Use the input selector (1) to select Power Timeout
–Use the volume knob (8) to set the time between 10 and 255 minutes. In Sell
"O ", PowerTimeout is switched o .
–Press the input selector (1) again to exit this submenu.
3.2.7.4 Remote Power
The Exxceed can provide a 10V DC voltage to the socket (12) or remote
switching o other devices that can be turned on or o by means o such a control
voltage (e.g., active subwoo ers). I Remote Power is switched on (On), this control
voltage is present at the socket (12) whenever the Exxceed is switched on. I you
want to switch o the remotely switched-on device ( or example, to listen to music
with headphones), you can also switch o the control voltage in this submenu.
–Use the input selection switch (1) to select the Power Management submenu
–Press the input selector (1) to enter the Power Management submenu
–Use the input selector (1) to select Remote Power
–Switch on the control voltage (On) or O (O ) with the volume knob (8)
–Press the input selector (1) again to exit this submenu.
3.2.8 Color
The text colors o the display can be set individually at the Exxceed.
–Use the input selector (1) to select the Color sub-menu
–Press the input selector (1) to enter the submenu Color
–Use the input selection switch (1) to select the "Headline, Text or election"
unction
–Use the volume knob (8) to change the color setting. The selected color is
displayed or checking in a small square
–Press the input selector (1) again to exit this submenu.
3.2.9 Name
You can assign individual names to the inputs. Each name can consist o seven
characters.
–Use the input selector (1) to select the submenu name
–Press the input selector (1) to enter the submenu name
12

–Use the input selection switch (1) to select an input (le t text column) that you
want to change
–Use the volume knob (8) to select the letter position. Press the volume knob
(8).
–Use the volume knob (8) to select the character you want to use
–Press the volume button (8) again to ix the character.
–Use the volume knob (8) to select the next letter position and con irm by
pressing the volume knob (8)
–Use the volume knob (8) to select the character you want to use
–Proceed with all other characters
–Finally, press the input selector switch (1) to exit the submenu name
3.3 Rear Panel Connections
(10 & 20) Loudspeaker Binding Posts
The loudspeaker cable can be connected to the two binding posts o that terminal.
The positive output terminal is in the top row, the negative is in the bottom row.
Make sure that no loudspeakers with an impedance o less than 3 Ohm are
connected. Never short-circuit the binding posts in order to avoid damage to your
integrated ampli ier.
(11) Power Connection, Power witch and Fuse
tanby Power witch: This switch is used to connect the network connection to the
Exxceed. However, the Exxceed is only switched on completely by pressing
the button (7).
Fuse: Here is the use. Only one use with the same value may be used!
Power ocket: The power cable is plugged in here. Always pay attention to the
correct mains voltage. The Exxceed is set as standard or a mains voltage o 230
V AC. I the Exxceed has been set up or other mains voltages, there are
corresponding indications (labels) on the device.
(12) REMOTE
A 10V DC voltage is applied to this socket as soon as the Exxceed is switched on.
This control voltage can be used or the synchronous switching on or o o external
devices ( or example active subwoo ers) i these devices have an appropriate input.
(13) U B Digital Audio Input (U B)
A computer or Mediaplayer can be connected to this socket. With the appropriate
playback so tware, high-resolution audio iles can be played back in PCM or DSD
ormat.
13

(14 & 15) Optical Digital Audio Inputs (Digital-3, Digital-4)
Digital sources (according to the SPDIF standard) can be connected to these two
sockets via iber optics. (E.g., TV set)
(16 & 17) Digital Inputs (DIG-1, DIG-2)
Digital sources (according to the SPDIF standard) can be connected to these two
sockets. (E.g., CD player)
(18) ERVICE
A Mediaplayer (CHRONOLOG) rom our company can be connected to this USB
port. This gives the possibility to control the Exxceed by tablet, smartphone or PC
in its basic unctions (volume, input selection).
(19) GROUND
In some countries it is necessary to separate the metal housing o the Exxceed
separately. This addition can be attached to this contact.
(21) BAL-OUT-R, BAL-Out-L
The preamp output signal is applied to these jacks in a symmetrical orm.
(Pin1 = GND, Pin2 = Pos, Pin3 = Neg)
(22) PRE/REC OUTPUT
At this output the unbalanced preamp output can be picked up be ore the volume
control (RECORD unction) or a ter the volume control (PREAMP unction).
The setting is made in the "Settings → Out" menu.
(23 & 24 & 25) Analogue Input Jacks (Input-1, 2, 3)
Analogue high-level source devices can be connected to these sockets.
(e.g. Tuner, CD-Player, etc.)
(26) Analogue Input Jacks, balanced (Bal-In)
Analogue high-level source devices with balanced outputs (XLR) can be connected
to these sockets.
14

3.3 Quick tart Manual
For the very impatient o you, who have already gained some experience with the
use o high-end ampli iers, there is a short introduction to the speed-up.
- Cabling (connect sources and speakers)
- Connect the appliance to the mains and switch on the mains switch (11) on
the back
- Press the On/O button (7)
- Select the source device with the input selection switch (1)
- Ready or operation
- Use volume knob (8) to set the listening volume
15

3.4 Exxceed and the Remote Controller
Director Premium
O course, the most important unctions can also be operated with the Trigon in rared
system remote controller Director Premium.
Button (6 & 11): up, down – When the main screen is active, the input can be
selected with these buttons.
I the Settings menu is selected, you can use these buttons to navigate to the
submenus.
Button (6 & 11): up, down – These buttons are also used to navigate the various
submenus in the Settings menu.
Button (8): MONO, selection confirmation – When the main screen is active, this
button can be used to switch the mono unction on and o .
In the Settings menu, the selected sub-menu is selected with this key.
Button (10): peaker On/Off – This button is used to turn the loudspeaker outputs
on and o .
Button (12): ettings Menü – This button is used to switch the settings menu on
and o .
16
D ir e c t o r
p r e m iu m
C
8
1
2 3 4
5 6
7 8 9
10 11 12
17
1615
1413
The igure shows the remote control Director Premium.
Since it is a system remote control, it can be operated by three
di erent devices rom our company.
The device to be operated can be selected with the (1) button.
An LED indicates which device has been selected. Each press
o the button (1) changes the device selection. The LED always
lights up brie ly to acknowledge the pushbutton.
To operate ampli iers, the irst LED in the series must be set, as
shown in the illustration on the le t. Two keys (shown here in
orange) have no unction or the Exxceed.
The functions in detail.
Button (2): On/Off - Here the Exxceed can be switched on
or o .
Button (3): LED Brightness - The brightness o the LEDs or
the volume display can be set in several steps.
Button (4): Display Timeout - The timeout or the display can
be switched on here. I this unction is activated, the display
goes out approx. 1.5 seconds a ter the last operation
Button (5): Back – Return to the level menu.

Button (13 & 14): Volume up, down quickly – Use these buttons to reduce or
increase the volume by 10 steps.
Button (15): Mute-Function – This button is used to turn the mute unction on and
o .
Button (16 & 17): Volume- , Volume+ – Use these buttons to adjust the volume.
NOTE: The unction "Volume" (key 16 and key 17) is always active or the ampli ier
mode, regardless o which device the remote control is currently set to.
4 What to do, if...
This chapter is designed to help diagnose and trouble-shoot some o the most
common errors.
4.1 ... unit doesn’t turn on?
- Is the AC plug rom the Power supply connected properly to the AC outlet? –
Secure connection.
- Does the AC outlet that you have the power supply connected to have current, or is
it possible that the use or that outlet has been blown? – Test the fuse for that AC
outlet at the house fuse box.
- Is the power switch (11) at the rear side switched ON? – Switch it ON.
- Is the internal fuse blown? – Contact your dealer.
4.2 ... no sound is produced?
–Is the correct input selected? - Select the correct input.
–oes the source provide a signal at all? - Check sources.
–Are the loudspeaker outputs switched off? - Turn back on.
–Is the mute function activated? - Switch the mute off.
–Has an electrostatic discharge occurred on the device? - Sometimes it can
happen, especially in the winter months, when the air humidity is low, that
your clothing is electrostatically charged and this electrostatic voltage is
suddenly broken when the amplifier is touched. uring such discharges, the
microprocessor integrated in the Exxceed can "crash", which is similar to
that of computers. In this case, the Exxceed may shut down the output
relay or stop responding. isconnect the Exxceed for about 10-20
seconds from the power supply by turning off the power switch (11) on the
back of the Exxceed . As a rule, the device will then function properly again.
17

4.3 ... there is a hum?
Are all the connections fastened securely? – Test all cable connections.
Sometimes multiple problems can contribute to a magnetic reception, which will
result in a system hum. To ix these types o problems, it is recommend that you
contact your local dealer who has many years o experience in trouble shooting such
issues.
It only hums when the tuner, the video recorder or the TV is connected to the
Exxceed . - All these devices are connected to an antenna that is itself grounded.
This problem can also be related to a magnetic reception. In this case however, the
resolution is quite simple. Use of a shielded power filter on the antenna can reduce
or eliminate this hum. These types of shielded power filters are readily available at
most HiFi or Radio stores..
4.4 ... unrealistic tests are carried out?
The Exxceed integrated ampli ier has been designed to operate under normal real
conditions intended or audio ampli iers. Only in this way it will be able to produce
high quality playback o audio signals. Unrealistic tests, such as listening to an
unoccupied input at ull volume, only result in a nonsense noise and noise signal,
which is normal under such conditions. Also quickly successive actuation o the
control buttons or rotary switches at the Exxceed or also at the remote control has
no realistic meaning or purpose and produces only mal unctions, without having any
bene it or symbolizing a quality eature.
So that you can enjoy your audio system or a long time, it should be operated as
intended.
18

5 Technical Data
Inputs : 5x analogue, 4x digital SPDIF
: optional 1x USB-HiRes Audio PCM/DSD
Input Impedance : analog 47 KOhm
Input ensitivity : 0,5V (analogue)
Output Power : 2x 100 / 170 W at 8/4 Ohm
Damping Factor : >100 (at 8 Ohm 1KHz)
Distortion ( THD + N) : < 0.015%
Outputs : 1x Speaker, 1x Phones,
: 1x unbalanced Line Out / Rec Out,
: 1x balanced XLR Pre Out
Bandwidth : digital Inputs 20 Hz – 22kHz (-3dB)
: analogue Inputs 5Hz – 250kHz (-3dB)
ignal Noise : > -86 dB at 1 Watt at 4 Ohm
Noise (A-filtered) : > -92 dB at 1 Watt at 4 Ohm
Weight : 18,3Kg
Dimensions : 440 x 110 x 380 mm ( BxWxD )
01.2017 Änderungen vorbehalten
Designed and Manufactured by:
Trigon Ele troni GmbH
Crumbacher Str. 60
D-34277 Fuldabrück - Bergshausen
Tel. [phone]
Fax [phone] Designed and Manufactured by
e-mail: [email protected]
web: www.trigon-audio.de
19
