TriMark e-FOB User manual

e-ASK
electronic Access Security Keyless-entry
e
e- -FOB FOB RF Keyless RF Keyless- -entry entry
Full Function Consumer Manual
Full Function Consumer Manual
FCC ID: TV2EFOB1
FCC ID: TV2EFOB1
(UM19 ~ 22793-01)

Table of Contents
Introduction .................................................................................. 1
e-FOB Operation and Features - Standard Mode...................... 2
e-FOB Operation and Features - Cargo Mode........................... 2
Teaching Additional FOB Transmitters ..................................... 3
Training Wireless Switches ..................................................... 4
Additional System Features........................................................ 5
Light Activation ........................................................................ 5
2nd Unlock Output................................................................... 5
3rd Unlock Output.................................................................... 5
Auxiliiary Output....................................................................... 5
2nd Auxiliary Output ................................................................ 5
Panic Mode.............................................................................. 5
Lock/Unlock Confirmation........................................................ 5
Lock/Unlock Confirmation Control........................................... 5
Emergency Override................................................................ 6
Starter Kill Feature................................................................... 6
Smart LED............................................................................... 6
Vehicle Alarm........................................................................... 6
Troubleshooting........................................................................... 7

Introduction
This manual provides the necessary information for the proper use of
TriMark’s e-FOB transmitter/receiver system. Basic functions of the
system include:
 Locking and unlocking entry and compartment doors
 Light activation
 Panic mode (standard configuration only)
 Auxiliary function support
The e-FOB system includes:
 TriMark Full-Function RF Receiver
 2 eFOB key fob transmitters
 Smart LED
 Push button switch
The TriMark Full-Function receiver and eFOB transmitters are
shipped programmed.
1

e-FOB Operation and Features—Standard Mode
Horn button
Unlock button
2
Button Function
Lock Locks all entry doors and arms security system.
Unlock Unlocks doors and disarms security system. Also
activates the porch light.
Horn button Activates panic mode when pressed and held for 2
seconds.
*button *button function is OEM/dealer defined. Possible
assignment include: interior/exterior lighting, awning
extension/retraction, gas cap, hood, etc.
Notes:
 While the engine is running only the Unlock (Entry Unlock)
function of the e-FOB remains activated — other functions are
deactivated.
*button
Lock button
e-FOB Operation and Features—Cargo Mode
Button Function
Entry Lock Locks all entry doors and arms security system.
Entry Unlock Unlocks entry doors and disarms security system. Also
activates the porch light.
Cargo Lock Locks cargo compartments and arms security system.
Cargo Unlock Unlocks compartment doors and disarms security
system.
Entry Lock
Cargo Lock Entry Unlock
Cargo Unlock
Unlock button

Teaching Additional FOB Transmitters
1. Plug the LED into C6 and the push button into C7 on the
receiver. Your OEM may have already installed these in your
vehicle.
2. Turn ignition off and disarm alarm.
3. Press and release the programming button 3 times. The LED
will turn on red after 3 seconds.
4. Press and release the Lock button of each new FOB
transmitter once. The LED will flash off and the horn will sound
once. Up to 60 transmitters may be programmed at one time.
5. Repeat step 4 until all fobs are programmed.
Notes:
 If you place the system in learn mode and teach nothing, the
system will exit in 10 seconds.
 When new transmitters are taught, all old transmitters are
erased.
 The memory for codes will not be erased if power is removed.
 As soon as the LED turns off, the system is fully functional.
3

4
Training Wireless Switches
Up to 20 wireless switches can be trained to the RF controller. A wire-
less switch can provide door ajar information, input from a shock sen-
sor, a motion sensor, a glass break sensor, etc.
1. Plug the LED into C6 and the programming button into C7 on
the receiver. Your OEM may have already installed these in
your vehicle
2. Turn ignition off and disarm alarm.
3. Press and release the programming button 5 times. The LED
will turn on green after 2 seconds.
4. Press the programming button X number of times to store the
wireless sensor in X position (1-25). The LED will briefly flash
red.
5. Remove the magnet from the wireless sensor to activate the
output. The horn will honk and the siren will sound.
6. 6. Repeat steps 4 and 5 to train additional wireless sensors. If
two sensors are trained to the same position, only the second
sensor will be active.
Notes:
 As soon as the LED turns off, the system is fully functional.
 The system exits learn mode after 10 seconds of inactivity.
 To erase all wireless sensors, turn ignition on and press the
programming button 10 times. The horn and siren will sound
once to indicate that all sensors have been erased.
 The memory for codes will not be erased if power is removed.

Additional System Features
Light Activation
When the alarm is armed, the parking lights and headlights flash. With
an unlock instruction from the key fob, the dome light stays illuminated
for 30 seconds and the parking and headlights flash.
2nd Unlock Output
Press and release the Unlock button twice to unlock the bay doors.
(Standard Mode Only)
3rd Unlock Output
The 3rd Unlock output is actuated with the unlock command and with
the secure operation (5 / 6) or (3). (Standard Mode only)
Auxiliary Output
This is OEM/dealer defined feature activated by the *button. Possible
assignments include: interior/exterior lighting, awning control, gas cap,
etc. Ask your dealer for functionality. (Standard Mode only)
2nd Auxiliary Output
The 2nd auxiliary output is actuated by holding down the Unlock (Entry
Unlock) button for two seconds. Ask your dealer for functionality.
Panic Mode
Available in standard mode. Pressing and holding the Horn button
(center left) for 2 seconds activates panic mode. During panic mode,
horn/siren is continuously activated and headlights and parking lights
flash for 30 seconds. Pressing the Unlock button deactivates panic
mode. (Standard Mode Only)
Lock/Unlock Confirmation
The horn/siren chirps once when the alarm is armed. If the alarm has
been set off since the last unlock command, the horn/siren chirps 4
times to indicate the alarm activity when the system is disarmed. The
headlights and parking lights flash once on lock and unlock.
Lock/Unlock Confirmation Control
The siren and horn confirmation is controlled by pressing lock, unlock
and auxiliary (*) buttons at the same time. A single chirp is heard when
confirmation is muted. A double chirp occurs when turned on.
(Cargo mode: Press Entry Lock, Entry Unlock and Cargo Unlock.)
5

6
Emergency Override
To disarm the alarm in case of FOB transmitter loss or malfunction:
1. Turn ignition on.
2. Press and hold the push button for 3-seconds. LED turns off.
3. Turn ignition off.
Starter Kill Feature
The starter kill feature is active for 30 minutes after the alarm is
activated.
Smart LED:
The smart LED indicates system status:
 Slow flash = Armed
 Off = Disarmed
 Fast flash = Alarm activated
Vehicle Alarm
When the alarm is armed, the parking lights flash and the horn/siren
chirps. The smart LED flashes continuously.
 In standard mode, the alarm is armed with either a single or double
Lock button press. See dealer to change this configuration.
 In cargo mode, both the Entry Lock and Cargo Lock must be
pressed within 5 seconds.
The alarm is activated with a security trigger input or if the ignition is
started. The horn/siren, parking lights and head lights flash for 30
seconds. The starter kill is activated for 30 minutes. Press the Lock or
Unlock buttons to deactivate the alarm.
There is a 5 second delay before the system will recognize a security
input after being armed. If a security input (door ajar switch, motion
sensor, glass break sensor, etc.) is triggered while the alarm is armed,
the security input must be turned off and then on before the alarm is
activated. The horn/siren chirps 3 times if a security input is active
when the alarm is armed.
The alarm is disarmed three ways.
 Press the Lock (Entry Lock) on the FOB transmitter.
 Press the Unlock (Entry Unlock) button on the transmitter.
 Turn the ignition on and hold the programming button for 5
seconds.

This product has been manufactured with methods to ensure high
quality and to meet the high expectations of our customers. TriMark
warrants this product to be free from workmanship defects and will
remedy issues per TriMark's warranty policy.
Remote transmitter FOBs, batteries, and other equipment subject to
normal wear and deterioration may need to be replaced periodically by
dealer and/or end user and are not covered by this warranty. TriMark
will not be liable for indirect, special, incidental or consequential
damages.
This system complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference and (2) This device must accept any interference
received including interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or television
interference caused by unauthorized modification to this equipment.
Such modification could void the user’s authority to operate the
equipment. 7
Troubleshooting
Problem Description Possible Solution
e-FOB Hints
Button press does not provide
correct operation
Verify power to the RF receiver
Replace FOB transmitter battery
Re-teach the FOB transmitter to the
receiver
No operation or intermittent
operation
Mount RF receiver away from
enclosed metal areas and fully
extend antenna
Check FOB transmitter battery
voltage. Batteries need to be
changed every 1-2 years depending
on usage.
One particular e-FOB function
does not work
Check wire connection of affected
function at RF module and wiring
harness
For additional troubleshooting service, assistance, and/or warranty
information on OEM-installed systems, please contact the OEM of your
vehicle.

8

9

UM19
22793-01
09/13-4
