Trimline Fires 70 SL User manual

Trimline 70 SL 1023
INSTALLATION INSTRUCTIONS
GBR

Trimline 70 SLInstallation instructions 2
1 INSTALLATION INSTRUCTIONS...........................................................................................................3
1.1 General instructions.......................................................................................................................3
2 INSTALLING THE UNIT............................................................................................................................3
2.1 Connection to the gas pipes ........................................................................................................3
2.2 Preparation and placement .........................................................................................................3
2.3 Installing the unit............................................................................................................................4
2.4 Installation.......................................................................................................................................5
 
..................................................................................................................7
  ......................................7
  ............................................................................................7
5 TECHNICAL DETAILS GV60....................................................................................................................9
 ...................................................................10
 ...................................................................................................11
8 CONCENTRIC PATHWAYS....................................................................................................................13
  ..............................................................................................................14
  ...........................................................................14
 ......................................................................14
 ...................................................................14
9.4 Parts ...............................................................................................................................................15
9.5 Installation.....................................................................................................................................15
 ......................................................16
 ........................................................................................................17
12 QUICK REFERENCE GUIDE FOR FAULTSSEARCH FOR ENCLOSED GAS FIRES
 ................................................................................................20
 ........................................................................................................22
 ...................................................................23
thermoCet International B.V.
Laagerfseweg 27
3931 PC Woudenberg
The Netherlands

CONTENTS
V41120


Trimline 70 SLInstallation instructions 3
1 INSTALLATION INSTRUCTIONS
NOTICE
The installation may only be carried out by an authorised
person.
1.1 General instructions
• 


• 
roof face must also meet the requirements outlined in

•The temperature of the walls and shelves near the side


ambient temperature 20 °C plus 80 K gives a maximum
temperature of 100 °C.
•The unit has been approved in combination with the

in accordance with European CE standards for gas units,
and may therefore only be applied with this system.
• 


•The instructions are only applicable if the relevant country
code is stated on the unit.
•If this is not the case, the gas technical information for the

discussed with the manufacturer.
• 

•Ignite the heater according to operating instructions and




Distance from ammable materials
A distance of 1000mm must be maintained from the front,

and/or other combustible material unless otherwise stated

Distance to non-ammable materials
The unit needs to be placed a minimum distance of 10mm
from the wall unless stated otherwise in these instructions.
WARNING
•
installing the appliance the glass surface is considered
active zone. The glass surface can become very hot!
•Accordingly, care should be taken, for example children



•
NOTICE
•



with the above requirements.
•If in doubt, consult your dealer.
2 INSTALLING THE UNIT
NOTICE

read Chapter 9 Concentric ue system.
2.1 Connection to the gas pipes
You can determine where the gas pipes will be placed,
dependent on the layout. Ensure control equipment is not
twisted during installation and there is no excessive tension.
Accessibility of various connection points in relation to
components needs to be maintained. After installation, check


sand and that the gas and combustion controls in the various
components and all appliance functions operate correctly.

electricity supply is disconnected. Failing to do so may cause
damage to the gas control equipment.
2.2 Preparation and placement

Do not tilt the packaging. Remove the packaging
and check the unit for possible damage.
NOTICE
•Place the unit on a stable surface.
•Do not place the unit on its side.
•Put the unit in its place of destination.
The packaging contains the following components:
•Unit
•Remote control
•Log set
•Battery holder
•4 x AA battery
•2 x AAA battery
•Installation box
•Finishing plate
•Installation manual
•User manual

whether everything is whole and complete. You must then



Trimline 70 SLInstallation instructions 4
To assemble the unit, proceed as follows:
Disassemble the frames.
Remove frame with glass pane
There are cover strips on the left and right. Take these strips
out and you will see the assembly of the frame with glass pane.
•Partially loosen the 2 bolts on the left, two bolts on the top
and the two bolts on the right.
•Slightly slide the frame and glass pane upwards and move it
forwards.
NOTICE
•



•Our advice is to remove all the screws and take the glass

the glass pane. A second recommendation is to remove

glass pane. The cleaning of the glass pane is important
because otherwise the deposit will burn on it and it will
not be possible to clean it properly. This also applies when
working with Black glass wandset and/or AR glass.
Remove the cover frame
•First remove the frame with glass pane.
•There are then four Allen bolts to be loosened.
•Slide the frame forward to release it.
2.3 Installing the unit
The unit can now be put into place. The unit has eight mounting
brackets, four on the frontside and four on the backside.
Depending on the situation the brackets on the front or on the
rear can be used. The unit must be hung on a refractory wall.


Finishing example

must be no hindrance to the radiant heat at the front of the unit.
For more information, see Paragraph 1.1 General regulations.
Adjustable mounting brackets
Cover
strip
Cover
strip
Type plate
Inner wall
refractory
materials
Do not
build on

Space
between
wall and

10mm
Support
refractory
material
Inner wall
refractory
materials
Refractory insulation
around concentric

Cavity
External wall
Concentric

100/150
Floor

Trimline 70 SLInstallation instructions 5
NOTICE
•Ensure the unit is not tightly enclosed to take expansion of
the unit into account.
•
above the unit. A windowsill for example. The convection
air is very hot.
Use
You are advised to read the user manual before use.

case of emergencies. This switch can also be used during

2.4 Installation
Flue gas connection
This unit has a rear outlet. A recess must be made in the

to the correct length and placed on the outlet of the unit.
9Concentric ue system.
Remove the bafe plate

at the top. Loosen these bolts and then tilt the plate and holder


restriction plate can be mounted in case of a longer pathway.
70mm restriction.
Connecting the gas
There is a separate removable panel at the front of the unit


There are break plates in the unit that can be removed,
depending on the position of the supply gas line.
Gas control system GV60 see Chapter 5 Technical data GV60.
Gas connection

Breakout plateBreakout plate
On/Off switch
Cable entryBreakout plate
for gas tube



Trimline 70 SLInstallation instructions 6
NOTICE
•Ensure that there is a gas valve in the gas circuit and that

•
Otherwise, the risk is that the burner base with technical
equipment cannot be removed from the unit.
Now the unit has been connected to the gas, a check can be
carried out. The check can be carried out without the glass
pane being in place. Check the following points:
•Ensure the pipe is clean before the unit is switched on.
•Venting the pipe.
• 


• 
burning.
•The blocks can be put in place in accordance with the
images shown in Chapter 4 Placing the ceramic wood set.
•If there is doubt about the supply pressure and burner, see
Chapter 11 Cleaning and maintenance.
• 
checked, the installation can be completed.
Replacing the batteries
There is a battery holder in the battery box with cover plate.
This includes 4 x AA batteries. When the batteries are fully
discharged, the cover plate can be disassembled and the
batteries replaced.
NOTICE

to fail.

held remote indicates when it is empty.


holder to the receiver. (See Chapter 5 Technical data GV60
Power cable

Trimline 70 SLInstallation instructions 7
3 INSTALLATION OF THE ADDITIONAL HIGH-GLOSS BLACK
GLASS WALLS OR STONE MOTIF WALLSET
NOTICE



3.1 Mounting instructions for the optional
high-gloss black glass set
4 INSTALLING THE CERAMIC WOOD SET
Place the glow material on the burner.
Place the ceramic blocks in sequence, such as shown in
images 1 through 8.
NOTICE
•No glow materials on the grid, see Figure 1 on the next
page. 1
•In Figure 3, the pins are located in the logs. 3
•Always ensure the pilot light remains free of any material.
Pin
Pin

1
5
2
6
3
7
4
8
Trimline 70 SLInstallation instructions 8
Pin Pin

Pilot Burner
G30-ZP2M
Receiver
B6R-R8(9)P…
Thermocurrent Cable SW
with ON / OFF Switch
G60-ZSKS(L)S…
Thermocurrent Cable TC
G60-ZKIRS…
8 Wire Cable
G6R-C…
Interrupter Block
G60-ZUS…
Ignition Cable
G60-ZKIS…
RESET Button
Main Burner
Combination Control
GV60…
Antenna
Battery
holder
A
B
C
D
E
C
E
Pilot Burner
G30-ZP2M
Receiver
B6R-R8(9)P…
Thermocurrent Cable SW
with ON / OFF Switch
G60-ZSKS(L)S…
Thermocurrent Cable TC
G60-ZKIRS…
8 Wire Cable
G6R-C…
Interrupter Block
G60-ZUS…
Ignition Cable
G60-ZKIS…
RESET Button
Main Burner
Combination Control
GV60…
Antenna
Battery
holder
D
A
B
C
D
E
B
A
D
C
Trimline 70 SLInstallation instructions 9
5 TECHNICAL DETAILS GV60
Gas control block type 
Automatic ignition control type 
Ignition Remote control and Piezo ignition
Gas connection  A B= Gas burner outlet C= Thermocouple connection
D E= Battery holder power supply cable
Unit category 
Pilot 
Combustion gas outlet and combustion air inlet Concentric: Ø100/Ø150mm
WARNING
Sealed parts must not be adjusted.
D
C
E
Adjustment screw burner
pressure
Main gas control knob
Inlet pressure
Outlet pressure Gas exhaust
Gas intake
Thermocouple
connection
Piezo connection
Adjustment screw
burner pilot light
Main adjustment
Pilot light
connection

Trimline 70 SLInstallation instructions 10
6 INSTRUCTIONS FOR THE MERTIK MAXITROL GV60
WARNING
Ensure the fuel supplied to the unit is clean and free from
particles and moisture.

present and/or is broken.

main gas pipe at the gas meter and to the gas control block
of the unit, clean and dry compressed air needs to have been
blown through it. Copper and aluminium pilot light pipes that
have been cut must be deburred and blown clean before they
are connected.
Heat, moisture and dust are a threat to all electronic
components
Protect the electronic gas control until all construction,
plastering and paintwork has been completed. If you cannot
avoid this work, then protect the control against dirt and

instance.
WARNING
Electronic components become permanently faulty when
they are exposed to temperatures higher than 60°C. Normal

the battery contents will damage the electronic switches



unnecessarily expensive.
Only install the gas control block and receiver as pre-
installed at the factory.
Remember that components may have to be replaced
or that repairs may have to be performed at a later date.

in a different way to how we have described in instructions.
Only insert the batteries after the receiver, gas control block
and pilot light set have been wired.
Premature connection to the power source can damage

Ensure the ignition cable is not near the antenna wire and that
they do not cross each other.
The high voltage released during ignition may damage

the unit becomes less responsive or totally unresponsive

NOTICE
•Do not tighten the contact breaker and the thermocouple
connection too tightly on the gas control block.
•

the connection to the magnetic coil below and/or the
insulation around the aluminium contact pin in the contact
breaker. This may cause the magnetic coil to not open
the gas supply to the pilot light and prevent the unit from
functioning.
Prevent leakage of ignition spark to parts of the installation
other than the ignition rod on the pilot light. Ensure the ignition
cable is not in contact with the body or other metal parts.
If a cable extension is used, ensure the connections have
additional silicone insulation.
The receiver and the control units on the gas control block


The oval disc on the gas control block should be turned to
ON position. The I/0 witch should be set to I. The ignition
cable should be connected to the SPARK connection point on
the receiver box.

transmitter. The manual transmitter operates best at a distance

occurs via shortwave radio signals, it is recommended that you

unit, in a place where the user wishes to experience a pleasant
temperature. Do not place the manual transmitter in direct
sunlight or other warm locations. The thermostat measures

the gas unit.
NOTICE
•Sealed parts must not be adjusted, to do so would void

•A waiting time of 5 minutes between each start attempt
must be observed.

G25,3 G20/G25 G20 G20/25
25 20 20 20/25
NL DE AT/CH/CY/CZ/DK/EE/ES/FI/
FR/GB/GR/HR/IE/IT/LT/LU/
LV/NO/PT/RO/SE/SI/SK/TR
BE/FR
I2EK
I23
I2ELL I2H I2E+
2x5 mm 2x5 mm 2x5 mm 2x5 mm
25 20 20 20/25
22 14,6 14,6 14,6/18,2
11,2 8,2 8,3 8,3/10,3
1,8 1,8 1,8 1,8
272 272 272 272
1,8 1,8 1,8 1,8
5,3 5/4,2 5 5
4,74 4,5/3,77 4,5 4,5
0,57 0,48/0,46 0,48 0,48
3,97 3,8/3 3,8 3,8
2,7 2,8/2,2 2,8 2,8
75,5 83/75 83 83
1 1 1 1
83,7 83,7/81,4 83,7 83,7
81,3 80,5/79,5 80,5 80,5
0 0 0 0
0 0 0 0
78 78/75 78 78
CC/D C C
5 5 5 5
Trimline 70 SLInstallation instructions 11
7 GAS-TECHNICAL SPECIFICATIONS
Type of indication(s) Trimline 70 SL (1023)
Unit type C11, C31, C91
Concentric extraction system Holetherm CC 100-150
Gas type G25.3 G20/G25 G20 G20/25
Supply pressure in mBar 25 20 20 20/25
Country/Countries NL DE AT/CH/CY/CZ/DK/EE/ES/FI/
FR/GB/GR/HR/IE/IT/LT/LU/
LV/NO/PT/RO/SE/SI/SK/TR
BE/FR
Category I2EK
I23
I2ELL I2H I2E+
Primary air 2x5mm 2x5mm 2x5mm 2x5mm
Supply pressure mBar 25 20 20 20/25
Burner pressure - high position mBar 22 14.6 14.6 14.6/18.2
Burner pressure - low position mBar 11.2 8.2 8.3 8.3/10.3
Injector orice Ø mm 1.8 1.8 1.8 1.8
Pilot light injector CODE 272 272 272 272
Small position orice mm 1.8 1.8 1.8 1.8
Load Hs kW 5.3 5/4.2 5 5
Hi load kW 4.74 4.5/3.77 4.5 4.5
Gas consumption m³/h 0.57 0.48/0.46 0.48 0.48
Nominal power - high position kW 3.97 3.8/3 3.8 3.8
Nominal power - low position kW 2.7 2.8/2.2 2.8 2.8
NOx Hs mg/kWh 75.5 83/75 83 83
Efciency class NE613 1 1 1 1
Useful return (NCV) system**
For nominal heat output % 83.7 83.7/81.4 83.7 83.7
For minimal heat output % 81.3 80.5/79.5 80.5 80.5
Supplementary electricity consumption
Nominal kWh 0 0 0 0
Stand-by kWh 0 0 0 0
Energy efciency***
Energy efciency index EEI 78 78/75 78 78
Energy label C C/D C C
NOx Hi class 5 5 5 5
Heat output type/room temperature control
Indirect heat functionality No
Single stage heat output, no room temperature control No
 No
With mechanical control of room temperature by thermostat No
With electronic control of room temperature Yes
 Yes
 Yes
Other control options
Control of room temperature with presence detection* Yes
Control of room temperature with open window detection* Yes
With remote control option Yes
* In combination with home automation
** Shortest system path


G30/31 G30
 30/50
BE/CH/CY/CZ/ES/FR/GB/GR/IE/IT/LT/PT/
SI/SK
NL/CH/CY/FR/GB/IT/LT/ SI/SK/AT/CH/DE/
FR/SK/PL
I3
+I3B/P
2x Ø8 mm+1x Ø14 mm 2x Ø8 mm+1x Ø14 mm
 30/50
23,1/29,3 23,1
9/11,5 9
1 1
221 221
1 1,1
4,3 4,3
4 4
0,124 0,124
3,3 3,3
2 2
72,5 72,5
1 1
82,4 82,4
77,5 77,5
0 0
0 0
76 76
C C
5 5
Trimline 70 SLInstallation instructions 12
Type of indication(s) Trimline 70 SL (1023)
Unit type C11, C31, C91
Concentric extraction system Holetherm CC 100-150
Gas type G30/31 G30
Supply pressure in mBar  30/50
Country/Countries BE/CH/CY/CZ/ES/FR/GB/GR/IE/IT/LT/PT/SI/SK NL/CH/CY/FR/GB/IT/LT/ SI/SK/AT/CH/DE/FR/
SK/PL
Category I3
+I3B/P
Primary air 2x Ø8mm+1x Ø14mm 2x Ø8mm+1x Ø14mm
Supply pressure mBar  30/50
Burner pressure - high position mBar 23.1/29.3 23.1
Burner pressure - low position mBar 9/11.5 9
Injector orice Ø mm 1 1
Pilot light injector CODE 221 221
Small position orice mm 1 1.1
Load Hs kW 4.3 4.3
Hi load kW 4 4
Gas consumption m³/h 0.124 0.124
Nominal power - high position kW 3.3 3.3
Nominal power - low position kW 2 2
NOx Hs mg/kWh 72.5 72.5
Efciency class NE613 1 1
Useful return (NCV) system**
For nominal heat output % 82.4 82.4
For minimal heat output % 77.5 77.5
Supplementary electricity consumption
Nominal kWh 0 0
Stand-by kWh 0 0
Energy efciency***
 EEI 76 76
Energy label C C
NOx Hi class 5 5
Heat output type/room temperature control
Indirect heat functionality No
Single stage heat release, no room temperature control No
 No
With mechanical control of room temperature by thermostat No
With electronic control of room temperature Yes
 Yes
 Yes
Other control options
Control of room temperature with presence detection* Yes
Control of room temperature with open window detection* Yes
With remote control option Yes
* In combination with home automation
** Shortest system path


Y1
X
X1
X
X1
Y2
X
Y
Y
Y
Y1
X
X1
X
X1
Y2
X
Y
Y Y
Y1
X
X1
X
X1
Y2
X
Y Y
Y
Y
Y1
X
Y
A
Y
Y1
X
Y
B
C D E
A 0 0 0,5 0,5
B 1 4 0,1 0,5
C 2 9 0 0,5
D 3904
E 3902
Trimline 70 SLInstallation instructions 13
8 CONCENTRIC PATHWAYS
Table of concentric pathways
Pathway Illustration X total in metres Y total in metres Restriction
x = vertical and y = horizontal min* max* min* max* 1023
Direct façade outlet G20/25.3/G30 A 0 0 0.5 0.5 No
Indirect façade outlet G20/25.3/G30 B 1 4 0.1 0.5 
 C 2 9 0 0,5 See restriction provisions
 D 3904
 E 3902
45 bend: calculation length 1 metres
90 bend: calculation length 2 metres
* Length including roof or exterior wall outlets. Always adhere to a starting length of 1 metre.
** Ratio vertical : horizontal X + X1 + X2: Y ≥ 2: 1
*** Ration vertical : horizontal X + X1: Y ≥ 2: 1
Restriction provisions all gas types
Vertical pathways
Distance Bafe plate Restriction
 Yes 50mm
 Yes 70mm
Direct façade outlet Yes No

Trimline 70 SLInstallation instructions 14
9 CONCENTRIC FLUE SYSTEM



while the fresh combustion air is supplied via the gap between

9.1 Components of the concentric
uesystem

system. These are:
Through the roof face and through the exterior wall
The pathway used for this system can be laid in different ways,
but there are a few important conditions:
• 


• 
• 
•The outlet can be installed at any point on the roof face or
exterior wall (supply and discharge in an identical pressure

•Flue pathways must not be insulated.
NOTICE
•Ensure the restriction plate is mounted in the correct
manner, as indicated in these instructions.
•The correct restriction plate will provide the unit with the

•
malfunction of the unit.
9.2 Indirect/direct façade connection
ifapplicable

The outlet may also be installed above the exhaust in the
wall, taking any hindrance to the surrounding area into
consideration, in accordance with national, regional, local
standards and regulations.
NOTICE
Ensure wind pressure on the outlet is not excessive,

very narrow alleys, etc., as this can negatively affect the
performance of the unit.
• 

refractory




We recommend our clearance box use as a direct façade

• 


•Determine the position of the unit and outlet and begin

unit, paying attention to the direction of installation and
connecting the elements by means of clamp strips.
• 
connecting to the unit. If necessary, use wall brackets

Mounting using the roof pass-through option
• 

and must meet the applicable rules and regulations.
• 
sloping tiled roofs can be used for a watertight duct.

the roof decking should be 5cm larger all around to ensure

•One needs to take into account the regulation regarding




•Determine the position of the unit and the outlet and begin



purposes. Connect the elements using the clamping straps.
Ensure all connections are gastight.
• 


9.3 Installation instructions regarding
existing ues

Instructions

must be built in accordance with national rules and regulations



through must not be smaller than 150mm round/square,




situations, consult your supplier/manufacturer.

Trimline 70 SLInstallation instructions 15
9.4 Parts
Check all parts for damage before commencing the


described in .
NOTE
The renovation kit consists of parts:
4
5
8
9.5 Installation
• 67.
•Attach the slider 5

•Keep the bottom of the slider at the same height as


• 8,
clamp it with a hose bracket. Stainless steel Ø90 to Ø165,
secure the whole with Parker screws.
•Attach the mounting plate to the chimney coping watertight
on the roof 8using silicone sealant and stainless steel
screws.
• and secure it in place using
the supplied clamping strip 9.
•The slider 5will protrude approximately 100mm

•Attach the inner mounting plate 4gastight against


•Position the unit in accordance with the instructions of

• 
2.
• 2up to

3 by hand in the mounting plate inside.

Trimline 70 SLInstallation instructions 16
10 PASS-THROUGH POSITIONS AND FUNCTION CORRECTLY
Dimensions Outlet positions Distance mm
A Distance to ventilation openings Room*
B Distance to ventilation openings Room*
C Distance to ventilation openings Room*
D Gutter channel base pipes or outlet pipes below here 500
E Under the eaves 500
F Under a carport, roof or balcony, inside and outside corners 500
G From vertical ground pipes or drain pipes 300
H Inside and outside a corner 500
I Above an external gas pressure regulator 1000
Side of a gas pressure regulator 500
J Room*
K Roof drain centre to centre 1000
L From the centre of both roof drains 450
Two wall drains above each other 1000
N Two wall drains next to each other 1000
* In accordance with local building codes
Plot boundary
External extension pipe
Roof pass-through

Trimline 70 SLInstallation instructions 17
11 CLEANING AND MAINTENANCE

recognised and registered person at least once a year. As
a minimum, the inspection and maintenance must ensure
the unit works correctly and safely. It is advisable that the
unit be cleaned of dust and dirt regularly during the heating
season, and especially when the unit has not been used for
an extended period of time. This can be done with a soft

detergent if necessary. Do not use aggressive or corrosive
substances to clean the unit.

Also check:
1 The seal of the gas combustion products and combustion
air supply circuit.
2 The seal of the pressure hatches at the top and bottom

 
and close freely.
4 Correct operation of the gas control block and ignition of

5 The seal of the explosion hatch must be checked and/or

6 Clean the convection space once a year.
Service and repair
If this unit needs to be inspected and/or repaired, you can
completely remove the burner with base.
Removing the burner base and technical equipment.
Disassemble the glass pane with frame and possibly the

By loosening the cover frame, a little more space will be created.
Take the ceramic blocks out of the unit and then the grate.
Standing this up straight is easiest. The burner and burner
support on the left is then visible. There is a Parker screw here.
Partly loosen it, and then slide the burner to the left. The glow
material can therefore remain on the burner. We see the base
upon which the technical equipment is located.
There are Parker screws on the outer edge. These must be


the left. The base is now loose. There is also a gas hose on the
technical equipment. Disconnect this hose, the base can then
be completely removed with the technical equipment. Replace
in reverse order.
Measuring nipples
If the plan is only to disassemble the burner, a square plate
under the gas pipe can be seen. Remove the four Parker
screws and release the plate. Look through the hole and you

counter clockwise. The measuring nipples are now visible.
The left nipple is for the supply pressure, and the right nipple
is the burner pressure. You can now insert a hose through the
convection chamber towards the measuring nipples and use a
set of combination pliers to slide the hose onto the measuring
nipple. The detached plate can then be replaced with the burner.

everything back in reverse order. The burner pressure can


If the burner pressure is to be adjusted after installation,

Injector
Unscrew for
access panel for
measuring nipples Disassemble
burner base
Disassemble
burner base
Disassemble
burner base
Pivot panel
for measuring
nipples

Trimline 70 SLInstallation instructions 18
Reset button accessible
by removing the frame
with glass with a small
hex key.
Hose mounted on burner
pressure
This access has been made available to aid checking the supply
pressure and the burner pressure after installation. The burners are
tuned and sealed by the factory. If a correction is necessary, the burner
base will have to be disassembled in order to reach the adjusting screw.
Explosion
hatch
Thermocouple
Adjustment screw
burner pressure

Trimline 70 SLInstallation instructions 19
AR glass (Anti-Reective glass) cleaning
instructions
General



that the coating layers are more sensitive than the ceramic,
therefore it is necessary to follow special cleaning procedures.
NOTE
Wear soft cotton gloves at all times.
Important
Do not use any of the following cleaning agents:
•Hard or abrasive sponges, steel wool, abrasives
• 
•Paper towels, ceramic hob cleaner.
Only use water or a suitable detergent surfactant
We recommend our thermoCet Cleaner.
Remove frame with glass pane
See Paragraph 2.2 Preparation and placement on page 3.
Important



The higher the frequency of use, the more often cleaning is
required. After more frequent use, more frequent cleaning of
the glass will be necessary. By not cleaning the glass in time,

Information
If a unit with AR glass is placed near windows, or if there is



If the AR glass is cleaned regularly, or by frequently using
products that are not recommended, the AR effect will fade
over time.

Trimline 70 SLInstallation instructions 20
12 QUICK REFERENCE GUIDE FOR FAULTSSEARCH FOR ENCLOSED
GAS FIRES USING MERTIK GV60 GASCONTROL
Function Possible cause Solution
1. Acoustic signals 1 long beep reset switch OFF (0Set switch to (I
1 long beep connections not complete Check connections in thermocouple circuit
1 long beep  Check connections in connector/replace

1 long beep micro switch defective Replace gas valve
1 long beep Sync not OK Carry out new sync procedure for remote
control/receiver
3 short beeps power supply 
2. No reaction
remote control/receiver Power supply problem 
No sync remote/receiver Carry out sync procedure
Distance between remote control/receiver Change position of receiver
Defective receiver Replace receiver
Faulty remote control Replace remote control
3. No pilot light gas GV60 DC magnet unit does not open (no clicking

Check wiring and breaker on thermocouple circuit

control and gas valve
1 x sparks and stop: check ground cable under torx
gas valve
Replace receiver
Replace gas valve
4. Poor/no spark Spark cable loose Check spark cable connections
Short circuit between cable and metal Check whether cable is free of metal parts
Poor spark candle Check spark candle for fractures, replace

Distance of sparkling candle to pilot light head Check distance is approximately 4mm
   Adjust gas supply pressure or adjust the pilot light
pressure using the gas valve
 Adjust gas supply pressure, check gas pipes, or
adjust pilot light pressure using the gas valve
 
Injector blocked Clean or replace pilot light injector
Blocked/curved pilot light pipe Check and clean pipe
Pilot light head damaged Check and replace pilot light
6. Pilot light goes out after ignition  Check gas supply pressure, possibly too low
Check pilot light injector and gas pipe

thermocouple tip
Check gas supply pressure, too high, adjust
Adjust pilot light pressure on gas control block
Air in pipes, vent
 Check premix opening on pilot light, must be open
Poor connections in thermocouple circuit Check cables/breaker in thermocouple circuit
Check thermocouple connections in gas control


minimum
Bad thermocouple Check open circuit voltage of thermocouple

Poor DC magnet unit in GV60 Replace gas valve
7. Pilot light goes out when the

False air along pilot light holder/gasket Check pilot light holder and gasket for leaks
False air hatches Check pressure hatches/gasket is completely
closed
 
regulations
