465-C1
Rotating Drum Bypass Humidifier
H-465-C1-1008
TECHNICAL ENGINEERING SPECIFICATION
Air Purification Systems
Performance:
Save on Energy Costs and Improve Comfort•
Increasing a Home’s Relative Humidity Makes it Feel More•
Comfortable at 68ºF / 20ºC than it does at 73ºF / 23ºC at a Low
Relative Humidity Level
Lower Thermostat Settings Deliver Substantial Savings on Monthly•
Energy Bills
Features:
Unit Mounts on a Right or Left-Hand Discharge•
Great Compatibility – Works with a Heat Pump or with Gas/Oil•
Fired Furnaces
Self-Piercing Saddle Valve Makes Installation Easy•
Accessing the Drum Is a Snap – Just Remove The Retaining Clip•
For Easy Maintenance
High Capacity Unit Can Help Achieve Comfortable Conditions in•
Even the Largest Residential Environment
Flexible Humidistat Controls Adjust from 20% to 80% Relative•
Humidity
How Humidifiers Work:
This rotating drum type humidier is installed on either the return or
supply duct, where air is drawn across the moistened evaporator pad
(wettedthroughthehome’swatersupply),creatingasupernemistthat
is released into the home. The adjustable, precision-made humidistat
allows the user to choose the optimum level of relative humidity for
indoor comfort.
Warranty:
2-year Limited Warranty•

www.trioninc.com
465-C1
Rotating Drum Bypass Humidifier
©2008 Trion®-IndoorAirQualitySolutions|Herrmidier®-EngineeredHumidicationSolutionsTrion® andHerrmidier® are registered trademarks
of Air System Components, Inc. Trion®reservestherighttoreviseormodifyproductsand/orspecicationswithoutnotice.
Allproductspecicationsreectavailableinformationattheprintingofthisbrochure.
Trion®| 101 McNeill Road | Sanford, NC 27330 | Phone: [phone] | Fax: [phone]
Web: www.trioninc.com | Email: [email protected]
H-465-C1-1008
TECHNICAL ENGINEERING SPECIFICATION
Air Purification Systems
Evaporator Supply Capacity
Furnace Temp. Supply Return
°F °C Gallons per Day Liters per Hour Gallons per Day Liters per Hour
100°F 37.7°C 10.6 1.67 7.8 1.23
120°F 48.8°C 16.5 2.60 12.4 1.95
140°F 60°C 22.5 3.55 17.1 2.70
Model 465-C1
PART NO. 352440-001
TYPE OF UNIT Bypass Rotating Drum
MAX EVAPORATIVE CAPACITY 22.5 Gallons Per Day – (3.5 LPH)
VOLT/Hz/MOTOR 24 V, 60 Hz, 3 Watt Motor
EVAPORATOR PAD 81/2” W x 1” D x 25” H (216mm W x 25mm D x 635mm H)
DIMENSIONS 143/4” W x 11” D x 111/2” H (375mm W x 280mm D x 292mm H),
NOTE: Height Including Clearance is 143/4” (375mm)
PACKAGING 14” W x 221/2” H x 171/2”L (356mm W x 572mm H x 444mm L)
DUCT OPENING 45/8” x 75/8” (117mm x 194mm)
WEIGHT 12 lbs (5.44 kg) / Shipping – 14 lbs (6.35 kg)
HUMIDISTAT 24 V, Adjustable from 20% to 80% RH
WATER INTAKE 1/4” (6mm) Copper or Plastic, 20–120 PSI (1.4 – 8.3 Bar), Not Included
DRAIN 1/2” (13mm)
BYPASS 7” (179mm) Diameter Flexible or Rigid Duct, Not Included
465-C1
Installation Options
UpowBottom
Return
Downow
Counterow
Upow
Side Return
Horizontal
