Tripp Lite U280-Q01FL-BK User manual

1
Quick Start Guide
10W Qi-Certified
Wireless Charging Pad
Model: U280-Q01FL-BK
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR surge protector in our monthly drawing!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
All trademarks are the property of their respective owners.
Español 7 • Français 13 • Русский 19

2
Product Features
Package Includes
• Qi technology optimizes your charging capabilities when used
with the latest Quick Charge (QC) compliant 2.0/3.0 adapters
• Universally compatible with all Qi-certified smartphones* and
devices*
• Intelligent two-color LED indicator displays charging status at a
glance
• Designed to charge without the hassle of removing your case
and engineered to work with lightweight cases up to 5 mm
• Exclusive protection technology prevents overheating and
overcharging
• Slim, lightweight portable design minimizes the spatial impact
on your desk
* Compatible with Apple iPhone XS Max/XR/XS/X/8/8 Plus and Samsung
Galaxy S10/S10 Plus/S10E/S9/S9 Plus/S8/S8 Plus/Note 9/Note 8/S7/
S7 Edge/S6 Edge Plus/Note 5.
• U280-Q01FL-BK 10W Wireless Charger
• USB 2.0 A to Micro-B Cable, 3 ft. (0.9 m)
• Quick Start Guide

3
Operation
Notes:
• To achieve high-speed charging capabilities (up to 7.5W for Apple
devices and 10W for Samsung devices), Quick Charge (QC) 2.0/3.0
adapters are recommended.
• Phone cases thicker than 5 mm may result in slower charging speeds.
• Magnetic or metal attachments will prevent charging.
• Compatible with Apple iPhone XS Max/XR/XS/X/8/8 Plus and Samsung
Galaxy S10/S10 Plus/S10E/S9/S9 Plus/S8/S8 Plus/Note 9/Note 8/S7/
S7 Edge/S6 Edge Plus/Note 5.
1. Connect the included 3 ft. (0.9 m) USB 2.0 A to Micro-B
cable to the Wireless Charging Pad.
2. With a user-supplied power adapter, connect the USB-A
connector of the included accessory cable to the power
adapter, then plug it into an available AC wall outlet.
Note: To achieve full charging capabilities, QC 2.0/3.0 power
adapters are strongly recommended.
3. Once the power adapter is connected to AC power, the Smart
LED will turn red. Place your Qi-compatible device on the
wireless charging pad.
4. The Smart LED will turn solid blue to indicate the device is
charging.
5. Once the device is fully charged, the Smart LED will turn red.
Remove your device from the wireless charging pad.

4
Specifications
Input Micro-B USB: 5V/2A, 9V/1.67A
Output 5V/1A (5W), 9V/1.1A (10W)
Qi Compatible Yes
Switch Frequency 110K-205K
Operating Temperature Range 32°F to 95°F / 0°C to 35°C
Storage Temperature Range -4°F to 158°F / -20°C to 70°C
Operating Humidity Range 10% to 80% RH,
Non-Condensing
Storage Humidity Range 5% to 95% RH,
Non-Condensing
Max Output for Apple iPhone Up to 7.5W
Max Output for
Samsung Galaxy
Up to 10W
Dimensions (H x W x D) 4 x 4 x 0.57 in. /
102 x 102 x 15 mm
Weight 0.32 lb. / 145 g

5
Warranty and
Product Registration
2-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and
workmanship for a period of two (2) years from the date of initial purchase.
TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its
sole option) any such defective products. To obtain service under this warranty, you
must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or
an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE
or an authorized TRIPP LITE service center with transportation charges prepaid and
must be accompanied by a brief description of the problem encountered and proof
of date and place of purchase. This warranty does not apply to equipment, which
has been damaged by accident, negligence or misapplication or has been altered or
modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore,
the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR
DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING
OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost
profits or revenue, loss of equipment, loss of use of equipment, loss of software,
loss of data, costs of substitutes, claims by third parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll
be automatically entered into a drawing for a chance to win a FREE Tripp Lite
product!*
*No purchase necessary. Void where prohibited. Some restrictions apply. See
website for details.

6
Warranty and
Product Registration
WEEE Compliance Information for Tripp Lite Customers and Recyclers
(European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and
implementing regulations, when customers buy new electrical and electronic
equipment from Tripp Lite they are entitled to:
• Send old equipment for recycling on a one-for-one, like-for-like basis
(this varies depending on the country)
• Send the new equipment back for recycling when this ultimately
becomes waste
Use of this equipment in life support applications where failure of this equipment
can reasonably be expected to cause the failure of the life support equipment or to
significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Specifications are subject to
change without notice.
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
19-07-241 93-39C1_RevA

7
Guía de Inicio Rápido
Panel de Carga
Inalámbrica de 10W
Certificada por Qi
Modelo: U280-Q01FL-BK
1111 W. 35th Street, Chicago, IL 60609 EE. UU.
En la dirección de correo electrónico www.tripplite.com/support
Copyright © 2019 Tripp Lite. Todos los derechos reservados.
Todas las marcas registradas son propiedad de sus respectivos propietarios.
English 1 • Français 13 • Русский 19

8
Características del Producto
El Paquete Incluye
• La tecnología Qi optimiza sus capacidades de carga cuando se
utiliza con los adaptadores 2.0/3.0 más recientes que cumplen
con la característica de Carga Rápida (QC).
• Compatible universalmente con todos los smartphones* y
dispositivos* certificados por Qi
• El indicador LED inteligente de dos colores muestra de un
vistazo el estado de carga
• Diseñado para cargar sin tener que retirar la funda y diseñado
para funcionar con carcasas ligeras de hasta 5 mm
• La tecnología de protección exclusiva evita sobrecalentamiento
y sobrecarga
• El diseño portátil ligero y estilizado minimiza el espacio
ocupado en su escritorio
* Compatible con Apple iPhone XS Max/XR/XS/X/8/8 Plus y Samsung
Galaxy S10/S10 Plus/S10E/S9/S9 Plus/S8/S8 Plus/Note 9/Note 8/S7/
S7 Edge/S6 Edge Plus/Note 5.
• U280-Q01FL-BK - Cargador Inalámbrico de 10W
• Cable USB 2.0 A a Micro B, 0.9 m [3 pies]
• Guía de Inicio Rápido

9
Operación
Notas:
• Para lograr las capacidades de carga de alta velocidad (hasta 7.5W
para dispositivos Apple y 10W para dispositivos Samsung),
se recomiendan adaptadores de Carga Rápida (QC) 2.0/3.0.
• Las carcasas para teléfono de más de 5 mm de grosor pueden dar
lugar a velocidades de carga más lenta.
• Los accesorios magnéticos o de metal impedirán la carga.
• Compatible con Apple iPhone XS Max/XR/XS/X/8/8 Plus y Samsung
Galaxy S10/S10 Plus/S10E/S9/S9 Plus/S8/S8 Plus/Note 9/Note 8/S7/
S7 Edge/S6 Edge Plus/Note 5.
1. Conecte el cable USB 2.0 A a Micro B de 91 cm [3 pies] al
Panel de Carga Inalámbrica.
2. Con un adaptador de corriente suministrado por el usuario,
conecte el conector USB-A del cable accesorio incluido
al adaptador de corriente y después enchúfelo en un
tomacorriente de pared de CA disponible.
Nota: Para alcanzar las capacidades de carga completa, se
recomiendan adaptadores de alimentación QC 2.0/3.0.
3. Una vez que el adaptador de corriente esté conectado a
energía de CA, el LED inteligente se pondrá de color rojo.
Coloque su dispositivo compatible con Qi sobre el panel de
carga inalámbrica.
4. El LED inteligente se pondrá de color azul fijo para indicar que
el dispositivo se está cargando.
5. Una vez que el dispositivo está totalmente cargado, el LED
inteligente se pondrá de color rojo. Retire el dispositivo del
panel de carga inalámbrica.

10
Especificaciones
Alimentación USB Micro-B: 5V/2A, 9V/1.67A
Salida 5V/1A (5W), 9V/1.1A (10W)
Compatible con Qi Sí
Cambiar Frecuencia 110K-205K
Rango de Temperatura de
Operación
0°C a 35°C [32°F a 95°F]
Rango de Temperatura de
Almacenamiento
-20 °C a 70 °C [-4 °F a 158 °F]
Rango de Humedad de
Operación
10% a 80% de HR,
Sin Condensación
Rango de Humedad de
Almacenamiento
5% a 95% de HR,
Sin Condensación
Salida Máxima para Apple
iPhone
Hasta 7.5W
Salida Máxima para
Samsung Galaxy
Hasta 10W
Medidas (Al x An x Pr) 4" x 4" x 0.57" /
102 x 102 x 15 mm
Peso 0.32 lb / 145 g
