Installation Guide
Link Span Kit for
Wire Basket Cable Trays
Models:
SRWBARCBFFL, SRWBARCBFFL4
Este guía esta disponible en español
en la página de Tripp Lite:
www.tripplite.com/support
Ce guide est disponible en français
sur le site Web de Tripp Lite :
www.tripplite.com/support
Русскоязычная версия настоящего
краткого руководства представлена
на веб-сайте компании Tripp Lite по
адресу: www.tripplite.com/support
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.

2
Parts List
Assembly
1 x 4 x
90° Bends
6" (150 mm) Wire Basket Model(s): SRWB6210STR, SRWB6410STR
Wire Tray Configuration
For instructions on cutting and fabricating wire basket
trays, please refer to the documentation included
with the SRWB Wire Baskets (sold separately).
This section provides wire tray cutting patterns and configuration
instructions. For the sectional views shown for each wire tray model,
the wires in the red portions should be cut and wires in the black
portions should remain intact (see example below).
Uncut
Wires
Cut Wires
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
19-06-069 93-3921_RevA
12" (300 mm) Wire Basket Model(s): SRWB12210STR, SRWB12410STR
18" (457 mm) Model: SRWB18410STR
SRWBARCBFFL or SRWBARCBFFL4
(For use with (For use with
2" tall wire baskets) 4" tall wire baskets)
Axis Coupler
(Model SRWBAXISCPLR,
sold separately)
Axis Coupler
(Model SRWBAXISCPLR,
sold separately)
Axis Coupler
(Model SRWBAXISCPLR,
sold separately)
Coupler
(Model SRWBUNVCPLR,
included)
Coupler
(Model SRWBUNVCPLR,
included)
Coupler
(Model SRWBUNVCPLR,
included)
SRWBUNVCPLR
Coupler
