Tripp Lite EZB-HDMIM-2 Installation instructions

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: EZB-HDMIM-2
Easy Pull Type-B Connectors - M/M set of HDMI
Highlights
HDMI Connector Kit includes: 2 x HDMI Male 1 ft. Cables
Versatile trunk cable allows for a variety of connection options
High quality digital cable supports resolutions up to 1080p
Requires Tripp Lite B122-000 signal booster, P166-001-A Active Wall plate
Signal Booster or B123-001 HDMI Signal Booster
Description
Easy Pull Connector Kit includes: 2 x HDMI Male Cables - 1 ft. pigtails. Completes your Easy Pull trunk run with a finished appearance. Digital
video support up to 1080p. Use with either PVC or Plenum digital trunk cables. Requires Tripp Lite B122-000 signal booster, P166-001-A Active Wall
plate Signal Booster or B123-001 HDMI Signal Booster.
Applications
Use where standard HDMI cables won't fit, such as conduit or confined wall or ceiling spaces
Package Includes
2 x HDMI Male 1 ft. Pigtail Cable
Features
Eliminates the need to field terminate HDMI connectors
Allows cable to be run according to code - inside conduit, drop ceilings, etc.
Makes pulling long cables fast and easy
Digital trunk cables available in 50 and 100 ft. lengths
Use with Tripp Lite P166-001-A Active Wallplate Signal Booster, or B123-001 HDMI Signal Booster
High quality digital cable supports resolutions up to 1080p
Specifications
OVERVIEW
Display Style Easy Pull
INPUT
Cable Length (ft.) 1
Cable Length (m) 0.30
CONNECTIONS

Connector A
HDMI (MALE)
Connector B
HDMI (MALE)
Number of Connectors 2
WARRANTY
Product Warranty Period
(Worldwide)
Lifetime limited warranty
Related Items
Optional Products
Product Type Related Model Description Qty.
Extenders/Signal Boosters B123-001 1-ft. HDMI v1.3 Active Signal Extender Cable
(HDMI M/F)
1
Video Cables & Adapters EZB-050 50-ft. Easy Pull Long-Run Display Cable
Type-B Digital PVC Trunk Cable
1
Video Cables & Adapters EZB-100 100-ft. Easy Pull Long-Run Display Cable
Type-B Digital PVC Trunk Cable
1
Wallplates P166-001-A HDMI Display-side Wallplate with Signal Booster 1
Wallplates P166-001-P HDMI Send/Recieve Pass-through Wallplate 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3800.
